BOSaNOVA, Inc. Phone: 866-865-5250 Email: sales@bosanova.net Web: www.bosanova.net
BOSaNOVA LTD (Europe) Phone: +44 1509 276252 Email: sales@bosanova.co.uk
Overview
The RBT Series delivers on the promise of increased
performance and low cost in a compact package.
Assembled in the USA, the RBT Series weighs just over
1lb allowing you flexible mounting options and lower
shipping costs. The robust and fan-less construction
allows for quiet and reliable operation.
The RBT Series are 200% faster, 30% smaller, consume
less than half the power and run 30 degrees cooler than
the other "Mini" or Turtle shell type thin clients!
Versatile Operating Environment
The RBT-466 supports three modes of operation:
TBT Mode - Text based setup with startup wizard (no
mouse required), terminal green screen with auto start
and auto-reconnect, 122 key keyboard support,
Function key macro support and split screen.
WBT Mode - Windows based Terminal mode, where
the terminal behaves like a CE.NET device with full
screen applications, GUI 5250/3270, Terminal Server
access, Citrix or Propalms which auto start and
auto-reconnect.
Desktop Mode - Windows XP type user interface
provides access to all applications in a windowing
environment.
The RBT-466 Thin Client is simple to configure
either locally or remotely using the BOSmanager.
The RBT-466 Thin Client
Faster, Smaller, Cooler
Benefits:
O
The RBT-466 outperforms similar products
by more than three times.
O
Industry standard OS (Linux 2.6 Kernel)
O
Small form factor for space-saving, desktop
and mounted deployments
O
Advanced emulation with 8 5250 sessions.
Split Screen, Rule Cursor, macro support,
multi host, GUI, SSL, 122-key keyboard
support
O
Available option for internal wireless
O
3-year advance exchange warranty
* Shown with Optional Internal Wireless
9009
BOSaNOVA, Inc. Phone: 866-865-5250 Email: sales@bosanova.net Web: www.bosanova.net
BOSaNOVA LTD (Europe) Phone: +44 1509 276252 Email: sales@bosanova.co.uk
The RBT-466 Thin Client
Ordering Information
PID
5466
Description
RBT-466 Thin Client, Linux, 5250, RDP, ICA, AC/DC
Adapter
VESA Mounting Bracket
9004
Hardware Configuration
Form Factor
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
Networking
Browser
I/O and Expansion
PS2 Port
USB Ports – Type 2
Options
Compact stand-alone metal case
VIA Eden 400MHz
Q
Q
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLAN, PXE boot,
USB 802.11 b/g support
4
1.4" W x 5.9" H x 4.7" D
35mm x 150 mm x 120 mm
1.4 lbs. (.66kg)
0° ~ 35°C
32° ~ 95°F
Software Configuration
Operating System
Security Features
Client Software
Citrix ICA
NX Client
Secure Gateway
VNC Shadowing
BOSmanager
ThinPrint
Language Support
Special Features
Options
Linux 2.6 Kernel
Read-only file system,
locked-down user account,
administrative passwords
Q
Q
Q
Q
Q
Q
US, UK English, Spanish, Italian,
German, French, and 30 more
including Eastern Europe
Autostart/auto-restart connection,
multiple level lock-down user
interface
Management
BOSmanager Support
Push/Pull Updates
VNC
Software/Configuration
Cloning
Options
Q
Q
Q
Q
Options
Supports 8 TN5250e and TN3270e
sessions,Telnet with SSH, SSL,
Wyse 60, Xterm R6, VT100, VT220
and VT400
5466
128MB/256MB (Flash/Ram)
Version 10
6.0
•
Part Number
Standard Flash/Ram
Standard Client Software
ICA
RDP
Host Access
Widescreen Support
Faster, Smaller, Cooler
8104b
Internal Wireless
104-key PC Keyboard
8122b
122-key Driverless PC Keyboard
CrossRun
•
•
Propalms TSE
Optical Mouse
MS001
Dimensions
Physical Specifications
Base Weight
Environmental
8-9 Watts average
Operating Temperature
Operating Humidity
Power Consumption
Power Requirements
Security
0% ~ 90%
DC12V, 1.2A, 8W
Kensington Security Lock Slot
