BOSaNOVA, Inc. Phone: 866-865-5250 Email: [email protected] Web: www.bosanova.net
BOSaNOVA LTD (Europe) Phone: +44 1509 276252 Email: [email protected]
Overview
The RBT-402 delivers on the promise of increased
performance and low cost in a compact package.
Assembled in the USA, this unit weighs 1.4 lbs allowing
you flexible mounting options and lower shipping costs.
The VIA Eden 400MHz processor provides users with
exceptional performance and low power consumption.
Available with internal 802.11 b/g wireless, the RBT-402 is
one of the smallest thin clients on the market with this
option.
The RBT-402 is available with a full array of features
including FireFox browser, Thunderbird email client,
Common Unix Printing System (CUPS) for enhanced
printing capabilities, Remote Desktop Protocol (RDP) and
Independent Computing Architecture (ICA).
Versatile Operating Environment
The RBT-402 supports three modes of operation:
WBT Mode - Windows based Terminal mode, where the
terminal behaves like a CE.NET device with full screen
applications, GUI 5250/3270, Terminal Server access,
Citrix or Propalms which auto start and auto-reconnect.
Desktop Mode - Windows Vista type user interface
provides access to all applications in a windowing
environment.
Kiosk Mode - dedicated Kiosk type of interface not
configurable by the user of the terminal.
The RBT-402 Thin Client
Faster, Smaller, Cooler
Benefits:
O
Industry standard OS (Linux 2.6 Kernel)
O
Small form factor for space-saving, desktop
and mounted deployments
O
Advanced emulation with 8 5250 sessions.
Split Screen, Rule Cursor, macro support, multi
host, GUI, SSL,122-key keyboard support
O
Internal 802.11 b/g wireless option
O
Includes RDP, ICA and Propalms clients
O
Firefox browser and Thunderbird email client
O
Integrated with CUPS for enhanced printing
capabilities
O
Support of Provision Networks, XenDesktop,
VMWare, Ericom and Leostream VDI clients
O
File explorer feature providing visualization
and browsing of local drives
The RBT-402 offers the look and feel of Windows Vista
and the versatility and speed of Linux.
:*Shown with Optional Internal Wireless
Page 2
BOSaNOVA, Inc. Phone: 866-865-5250 Email: [email protected] Web: www.bosanova.net
BOSaNOVA LTD (Europe) Phone: +44 1509 276252 Email: [email protected]
The RBT-402 Thin Client
Ordering Information
PID
5402
Description
RBT-402 Thin Client, Linux, 5250, RDP, ICA, AC/DC
Adapter, Optical Mouse
9006
VESA Mounting Bracket
Hardware Configuration
Form Factor
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
Networking
USB Ports – Type 2.0
Physical Specifications
Base Weight
Environmental
Operating Temperature
Operating Humidity
Power Requirements
Security
Options
Compact stand-alone metal case
Q
Q
1.4" W x 5.9" H x 4.7" D
35mm x 150 mm x 120 mm
1.4 lbs. (.66kg)
0° ~ 35°C
35° ~ 95°F
0% ~ 90%
12V DC 2A
Kensington Security Lock Slot
Software Configuration
Operating System
Security Features
Client Software
Citrix ICA
Secure Gateway
VNC Shadowing
BOSmanager
PDF Viewer
Thunderbird
NX Client
VDI Client
Language Support
Special Features
Options
Linux 2.6 Kernel
Read-only file system,
locked-down user account,
administrative passwords
Q
Q
Q
Q
Q
Q
Q
US, UK English, Spanish, Italian,
German, French, and 30 more
including Eastern Europe
Autostart/auto-restart connection,
multiple level lock-down user
Management
BOSmanager Support
Push/Pull Updates
VNC
Software/Configuration
Cloning
Options
Q
Q
Q
Q
Options
Supports 8 TN5250e and TN3270e
sessions,Telnet with SSH, SSL,
Ericom, Wyse 60, Xterm R6,
VT100, VT220 and VT400
5402
256MB/256MB (Flash/Ram)
Version 10
5.2
Part Number
Standard Flash/Ram
Standard Client Software
ICA
RDP
Host Access
Browser
Faster, Smaller, Cooler
9009
8009
Internal Wireless
OpenOffice Suite and Java Cache V1.1.3
8122b
122-key Driverless PC Keyboard
Video Resolution
•
Up to 1920 x 1440
Propalms
Firefox
X-Windows
Q
Provision Networks, Leostream,
XenDesktop, VMWare, Ericom
V1108
Power Consumption
8 - 9 watts average
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLAN, PXE boot,
Internal 802.11 b/g wireless
I/O and Expansion
PS2 Port
4
Q
Dimensions
VIA Eden 400MHz
