LTC-1300 1.5GHz Thin Client
Easily Deployed, Centrally Managed, Secure
BOSaNOVA, Inc. 2012 W. Lone Cactus Drive, Phoenix, AZ 85027
Tel: (866) 865-5250 GFax: (623) 516-8697 [email protected]
Enterprise Class Remote Administration
The BOSaNOVA LTC-1300 Thin Client is simple to
configure either locally or remotely using SNMP based
BOSmanager, which enables the following tasks:
G
Complete terminal configuration from a central
location, including terminal emulation settings
G
User lock-out from configuration changes
G
Scheduling of power down/power up
G
Cloning of user environments
G
Control over which applications run on a
particular terminal
Overview
The LTC-1300 represents a quantum leap forward in high-end Linux for
the desktop. Powered by 1.5 GHz Via processor CPU and featuring the
the most advanced Linux desktop deployment available anywhere.
With built-in Web Browser (Firefox), Terminal Emulation, Adobe
Acrobat Reader, Common Unix Printing System (CUPS) for enhanced
printing capabilities, Thunderbird e-mail client and OpenOffice embedded
on the Thin Client, companies of all sizes can take advantage
of the many benefits of thin client computing.
The LTC-1300 is available with an 802.11 b/g internal wireless option. The
built-in PCI and PCMCIA expansion slots can provide capability for fax
cards, video cards, and wireless network adapters.
Advantages
G
1.5 GHz Via Processor with 8X AGP Graphics Accelerator
G
Windows Vista look and feel with Linux stability and performance
G
Firefox browser with full Macromedia and Sun JVM support
G
OpenOffice included for word-processor, speadsheet and presentation
support
G
File explorer providing visualization and browsing of local drives with
copy/paste functions
G
Support of Provision Networks, XenDesktop, and Leostream VDI clients
G
Writable shared partition and multiple network share ability
G
Integration with VoIP (Skype)
G
Real Adobe Acrobat Reader, POP3 e-mail, Lotus Notes support
G
Integrated with CUPS for enhanced printing capabilities
G
PCI compliant GUI TN5250e and TN3270, with customizable Hot Spots
G
802.11 b/g internal wireless option
G
ICA V10, RDP 5.2, Propalms, X-Windows, VNC clients
G
PCI and PCMCIA expansion slots standard
G
DVI for optimal Flat Panel Display
G
Customizable wallpaper
G
CrossRun (enhanced RDP based Terminal Server product) standard
G
Expandable to 1GB DDR2 and 4GB Storage
The BOSaNOVA LTC-1300 offers the look and feel of
Windows Vista and the versatility and speed of Linux.
Page 2
LTC-1300 1.5GHz Thin Client
Easily Deployed, Centrally Managed, Secure
BOSaNOVA, Inc. 2012 W. Lone Cactus Drive, Phoenix, AZ 85027
Tel: (866) 865-5250 GFax: (623) 516-8697 [email protected]
Ordering Information
PID
7901
8012
Description
LTC-1300 5250/3270, Linux, OpenOffice, JVM, RDP,
ICA, Adobe Acrobat Reader
9009
Built-in internal 802.11 b/g wireless
VESA Mounting Bracket
8122x
122-key Driverless PC Keyboard
Options
8X AGP
Supports 8 TN5250e and TN370e
sessions,Telnet with SSH, SSL,
Ericom, Wyse 60, VT100 and
VT200, x-Term, and Optional SCO
790x
512MB x 512MB
Version 10
5.2
Firefox
Up to 1600 x 1200
••
Part Number
Standard Flash/RAM
Standard Client Software
ICA
Web Interface
RDP
Host Access
Browser
Propalms
Video
Maximun Video
Resolution and
Refresh Rate
@ 32-Bit Color
Linux
Read-only file system,
locked-down user account,
administative passwords
Autostart/auto-restart connection,
multiple level lockdown
user interface
•
•
•
•
•
•
Software Configuration
Operating System
Security Features
Client Software
Citrix ICA
RDP
NX Client
X-Windows
OpenOffice
BOSmanager
Special Features
•
•
•
•
Management
BOSmanager Support
Push/Pull Updates
VNC for Remote
Configuration
Software/Configuration
Clonning
Compact metal case
VIA 1.5 GHz
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLan, PXE boot,
Internal/External wireless option
2
1
4
1 Keyboard/1 Mouse
2” W x 11.5” H x 8.2” D
53mm x 292mm x 237mm
8.4 lbs.
32-1040F (0-400 C)
20-90% non-condensing
0-20,000 ft (0-6,096 m)
100-240 VAC, 50-60 Hz
Max AC Input Power: 15 W
UL, UL1950, FCC Class B, cUL,
CSA-C22, No. 950M89, CE
Mark: EMC/LVD, TUV-GS
••
••
Form Factor
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
I/O and Expansion
Serial Port – D-Sub
9-Pin Male Connector
Parallel Port – D-Sub
25-Pin Female Conn.
USB Ports – Type 2
PS/2 Ports
Physical Specifications
Dimensions
Shipping Weight
Operating Temperature
Operating Humidity
Operating Altitude
Power Requirements
Safety Certifications
Hardware Configuration
Enviornmental
PCMCIA and PCI
External Power Option
••
CrossRun
••
Security
Kensington Security Lock Slot
VDI
Provision Networks, XenDesktop,
Leostream, VMWare
Wide Screen Support
••
••
V0508
