Operating Manual
LED Profile light
LED Profile light
EV-06012018
Power consumption: 220w Max
LED resource: 1x 200w COB white
or warm white color(3200k or 6500k)
Control: 3 DMX channels
LCD display + 4 soft keys 4
selectable dimming curves
master/slave; stand alone
Optical group: 5200 LUx at 4meter
Beam Angle: 10/19/26/36/50°.
Body in plastics: IP20 protection
rating. Operating comperature: -20 °C
t 40 °C measurements:
64.5x28x22(cm) Weight: 8.0KG
Features
1 6
LED Profile light
LED Profile light
10.Notes
3.Wiring Diagram
Power Input
To next Power
To next DMX Signal
Power cable
DMX Signal cable
AC100~240V
50-60Hz
DMX Controller
The back
Power Cable
Manual
LED Spotlight
Operating Manual
Unit mm
2.Measurements
1.Packing List
EV-06012018
5 2
LED Profile light
LED Profile light
9.Function
DMX Mode
Dimming Mode
Strobe Mode
Master/Slave Setting
DMX 3 Channels
DMX Address Allocation 001-512
Brightness adjust 0001-4096 Dimming
Strobe/Speed 01-12 Dimming
1 Master Dimming Mode/ Strobe Mode
2 All Salves DMX001 as below
%
0%
25%
50%
75%
100%
1
DIMMING
ALL DIMMING
2
STROBE
0
10
255
STROBE
CH
3
Dim4
255
64
128
192
Dim4
Dim3
Dim2
0
Dim1
Invalid
5.Installation
Floor
Hanging
4.Illumination Diagram
Distance 4m
Distance6m
Distance8m
Distance10m
Distace15m
Beam angle 19
Beam angle 26
LED Profile light
Beam angle 36
4m
6m
8m
10m
15m
Beam angle 50
Illumination Center/Lux
Illumination Center/Lux
Beam Diameter/cm
Beam Diameter/cm
3350
2340
1490
960
852
602
680
570
335
235
124
185
180
277
248
370
315
462
503
693
Beam angle 19
Beam angle 26
Illumination Center/Lux
Illumination Center/Lux
Beam Diameter/cm
Beam Diameter/cm
1480
895
650
360
480
235
360
155
145
86
220
373
380
560
430
746
620
933
900
1400
Beam angle 36
Beam angle 50
CCT 3200K
EV-06012018
3
4
LED Profile light
LED Profile light
7.Technical parameters
LED Source
1xWhite200W LED(3200K),CRI>90;(5600K LED is available)
Optical group
Beam angle 19,26( Beam angle 36 , 50 available)
with high-efficiency optical system
Control
3 DMX channels;LCD display+4 soft keys;4 selectable dimming curves
Connection
PowerCON In & Out; 3-pole DMX In & Out (5-pole DMX available)
Voltage
Max Power
Measurements
Electronic full-range AC 90-260V 50/60Hz
200W
Size 58X28X21cm Weight 8Kg
8.Control Panel
MENU Enter Down Up
Adjust keys function on panel
Press MENU --->Display first-level menu--->
Press Enter --->Display second-level menu--->
Press Down & Up to adjust relevant function--->
Press Enter and MENU to quit current menu--->
Press MENU --->To next first-level menu...
9.Menu
MENU
Press once
DMX Mode
Press once
Enter
Press once
Up
Change
Valid
Press once
Down
Change
Valid
Press once
Enter
MENU
Press once
Press once
Enter
Press once
Up
Dimming
Valid
Press once
Down
Valid
Press once
Enter
MENU
Press once
Press once
Enter
Press once
Up
Timing
Valid
Press once
Down
Valid
Press once
Enter
MENU
Press once
Cycle
Back to first step
Dimming Mode
Dimming
Strobe Mode
Timing
