BOOMBOTIX MINI User Manual

USER GUIDE

CONTENTS

1. BOOMBOT ANATOMY

2. GETTING STARTED

3. BLUETOOTH PAIRING

4. AUDIO CONTROLS

5. SPECIFICATIONS

6. TROUBLESHOOTING

7. WARRANTY

BOOMBOT ANATOMY

INDICATOR
LED

REMOVABLE
GRILL

HIP CLIP

36mm DRIVER

WATER RESISTANT
DOOR

VOLUME +VOLUME -

POWER ON/OFF

PL AY/PAUSE

COMMAND

GETTING STARTED

POWER ON/OFF - HOLD COMMAND

INDICATOR LED

HOLD

FULLY CHARGE YOUR BOOMBOT MINI
BEFORE USE WITH INCLUDED MICRO
USB CABLE

FULL CHARGE IS REACHED IN

1.5 - 3 HOURS

PULSING ORANGE - CHARGING

SOLID ORANGE - FULLY CHARGED

BLINKING RED - LOW BATTERY

BATTERY LIFE TYPICALLY RANGES
FROM 2.5 - 16 HOURS, 6 HOURS
OF PLAYBACK AT 70% VOLUME

CHARGING PORT

YOUR BOOMBOT MINI IS NOT
WATER RESISTANT WHILE CHARGING,
IT IS ONLY WATER RESISTANT
WITH THE REAR DOOR CLOSED

BLUETOOTH PAIRING

YOUR BOOMBOT MINI CONNECTS EASILY
WITH YOUR BLUETOOTH DEVICE

1. POWER ON BOOMBOT MINI INDICATED
BY A BLINKING BLUE LED

2. SELECT BOOMBOT MINI ON YOUR
BLUETOOTH DEVICE’S DISCOVERABLE
DEVICE LIST

3. BOOMBOT MINI WILL CHIME WITH A
PAIRING ALERT AND A SOLID BLUE LED

HOLD (2 SECONDS)

YOUR BOOMBOT MINI WILL AUTOMATICALLY
BE PAIRED TO THE MOST RECENTLY
CONNECTED DEVICE

TO DISCONNECT YOUR BOOMBOT MINI,
HOLD BOTH VOLUME BUTTONS (+ AND -)
SIMULTANEOUSLY FOR 2 SECONDS

HOLD

TO RESET BLUETOOTH CONNECTION,
HOLD BOTH VOLUME BUTTONS (+ AND -)
SIMULTANEOUSLY FOR 2 SECONDS

HOLD

AUDIO CONTROLS

YOUR BOOMBOT MINI IS BUILT FOR
OPTIMAL AUDIO QUALITY WITH
THE SPEAKER CLIPPED ON OR SEATED
WITH BUTTONS FACING UPWARD

PLAY - PRESS COMMAND

PAUSE - PRESS COMMAND

NEXT TRACK - PRESS COMMAND X 2

VOLUME UP - PRESS VOLUME UP

VOLUME DOWN - PRESS VOLUME DOWN

VOLUME CONTROLS RAMP IN SPEED
WHEN HELD DOWN

-OR-HOLD HOLD

SPECIFICATIONS

PROPRIETARY 36MM 3W ACOUSTIC DRIVERAUDIO

6 HOURS OF CONTINUOUS PLAYPLAY TIME

UP TO 14 DAYSSTANDBY TIME

STEREO INFORMATION

DEVICE COMPATIBILITY

INGRESS PROTECTION

120g/ 4.25ozWEIGHT

60mm L x 42mm W x 79mm HDIMENSIONS

INPUT: BLUETOOTH WIRELESS
OUTPUT: N/A

BLUETOOTH-ENABLED DEVICES INCLUDING
iPHONE, iPAD, iPOD TOUCH, ANDROID
SMARTPHONES AND TABLETS, AND MOST
MAC OR PC COMPUTERS

IPX4 WATER RESISTANT

BLUETOOTH 2.1

BATTERY TYPE/CAPACITY

BATTERY STATUS

PROFILES:
ADVANCED AUDIO DISTRIBUTION
PROFILE(A2DP) 1.2,
50-FOOT RANGE

RECHARGEABLE, NON-REPLACEABLE
LITHIUM POLYMER

DISPLAYED ON HANDSET, AUTOMATICALLY
SHUTS DOWN AFTER 5 MINUTES OF
INACTIVITY OR UNPAIRED

MICRO USB (CABLE INCLUDED)CHARGE CONNECTOR PORT

LESS THAN 100 MINUTES FOR FULL CHARGECHARGE TIME (MAXIMUM)

1-YEAR LIMITED WARRANTYWARRANTY AND SERVICE

TROUBLESHOOTING

DEVICE NOT PAIRING

DEVICE NOT CHARGING

TURN UNIT ON AND OFF AND RESET
BLUETOOTH BY HOLDING + AND -

DELETE ADDITIONAL BLUETOOTH
DEVICES FROM BLUETOOTH SETTINGS

CHECK MUSIC SOURCE AND INTERNET/DATAMUSIC NOT PLAYING

CONFIRM MICRO USB CABLE IS SEATED
PROPERLY IN PORT AND DEVICE HAS
APPROPRIATE POWER INPUT

FOR ADDITIONAL SUPPORT HEAD OVER TO

BOOMBOTIX.COM/SUPPORT

WARRANTY

Boombotix warrants to the original retail purchaser
of this Boombotix portable speaker that should this
product or any part thereof during normal consumer
usage and conditions, be proven defective in material
or workmanship that results in product failure within
the first twelve (12) month period from the date of
purchase, such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the Company’s option,
without charge for parts or labor directly related
to the defect(s). The antenna, keypad, display,
rechargeable battery and battery charger, if included,
are similarly warranted for twelve (12) months from
date of purchase. This Warranty is not transferable or
assignable. This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions,
accident, mishandling, neglect, unauthorized
alteration, misuse, improper installation or repair
or improper storage;
(b) Product whose mechanical serial number or
electronic serial number has been removed,
altered or defaced;
(c) Damage from excessive exposure to moisture,
humidity, excessive temperatures or extreme
environmental conditions;
(d) Damage resulting from connection to, or use of any
accessory or other product not approved or
authorized by the Company;
(e) Defects in appearance, cosmetic, decorative
or structural items such as framing and
nonoperative parts;
(f) Product damaged from external causes such
as fire, flooding, dirt, sand, weather conditions,
blown fuse, theft or improper usage of any
electrical source.
(g) Product taken apart without written permission
by Boombotix. This includes and is not limited
to removing the metal clip or removing the
screws holding the casing together.
Boombotix reserves the right to inspect any
Product subject to a warranty claim to determine,
at its sole discretion, whether the claimed defect
is a Manufacturing Defect or otherwise. Note that
Boombotix regularly changes the models, colorways,
and styles of its Products and cannot guarantee the
availability of an exact replacement for any Product.
BOOMBOTIX DOES NOT ASSUME ANY LIABILITY FOR
ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES UNDER THIS LIMITED WARRANTY.

FCC Statement

This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and
receiver.

- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV
technician for help.

This device complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.

Caution!
Any changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.

www.boombotix.com
