Bonnet B1AC712PM2 User Manual

BONNET GRANDE CUISINE
Registered office:

Rue des Frères Lumière - Z.I Mitry Compans

OPTIMUM,

Accessories, MOBILE FRAMES 200mm high

F-77292 MITRY MORY Cedex

MOBILE FRAMES

B1AC78PM2 / B1AC79PM2 / B1AC712PM2 / B1AC716PM2

GENERAL

* All stainless steel construction.

MOBILE FRAMES

* 200mm high.
* with 4 or 6 swivel castors 2 or 3 braked.
* Supplied with intermediate rails to assembly of multiple appliances on a same mobile frame.

Kind of frames Number of appliances / width

- Frame of 800mm : 1 x 800 or

- Frame of 900mm : 1 x 900

- Frame of 1200mm : 3 x 400 or

- Frame of 1600mm : 2 x 800 or

2 x 400

1 x 800 + 1 x 400
4 x 400 or

1 x 800 + 2 x 400

STANDARDS

XP U 60-010: Hygiene.

: Compliance with standards

BONNET GRANDE CUISINE
Registered office:

Rue des Frères Lumière - Z.I Mitry Compans
F-77292 MITRY MORY Cedex

B1AC78PM2 / B1AC79PM2 / B1AC712PM2 / B1AC716PM2

CODE
DIMENSIONS (mm)

B1AC78PM2 B1AC79PM2 B1AC712PM2 B1AC716PM2

Appliance width A 800 900 1200 1600
Width 707 807 1107 1507
Depth 636 636 636 636
Height 220 220 220 220
Space between legs B

PACKAGING (mm)

598 698 998 1398

Width 850 950 1205 1650
Depth 650 650 650 650
Height 300 300 300 300

WEIGHT (KG)

13.5 14.5 18 24

Non contractual Document 01/2012 edition – 3BE B1AC7_PM2
