DDG Extruder
DDG Extruder for Ultimaker 2+/3 that
feeds filament without grinding and
with a very firm grip of the filament that
will allow for faster printing without
under-extrusion problems and high
retraction prints like Voroni models
without grinding.
The original stepper motor of the
printer will be reused, and the extruder
will be mounted at the same position
and in the same mounting holes as the
factory extruder making the installation
easy and fast.
Ultimaker 2+ upgrade contains: One
right hand DDG extruder.
Ultimaker 3 upgrade contains: One
right hand and one left hand DDG
extruder.
The picture and drawing show the
right-hand edition.
Technical Specification Arial 16
• EAN-Code -
• Weight g
• Nettovikt g
• Package Dimension -
• Max Current A
• Gearing ratio mm
• Filament Diameter mm
• Temperature 0 to +100°
• E-steps value -
Drawing Arial 16
RITNING PÅ PRODUKTEN
Contact Information
Bondtech AB E-mail: support@bondtech.se
Repslagarevägen 3J Web: www.bondtech.se
33153 Värnamo
Sweden
Technical Specification
• EAN-code U2+ 7350011410408
• EAN-code U3 7350011412051
• Net weight 112.5g
• Gross weight 161.5g
• Package dimension 137×94×65mm
• Gearing ratio original used (3.27:1)
• Filament diameter 2.85mm
• Operating
temperature 0–80°C
• E-steps value 311
Drawing
