Page 1
WARRANTY & WATCH CARE
www.bomberg.ch
1968 - CHRONOGRAPH
Page 2
2
CONTENT
WARRANTY & usER INsTRuCTIONs.
Warranty Page 3
Instructions Model - 1968 - Chronograph Pages 4-7
Page 3
3
WARRANTY
BOMBERG watches are produced according to highly professional technical
criteria using materials qualitatively tested, even those more innovative.
BOMBERG watches are 10 ATM water resistant, however do not operate the
crown or the pushers under water.
To obtain service under warranty you will be required to present your war-
ranty card. To be valid, the warranty card must be properly lled in and
dated by your dealer.
Your watch is guaranteed for twenty-four months from the date of purchase
under the following conditions. This international warranty covers any manu-
facturing and material defect. The watch must be sent to an ofcial After
Sales Center. Please refer to the contact page of www.bomberg.ch.
THE WARRANTY IS VALID ONLY IF CORRECTLY AND FULLY COMPILED
WITH DEALER’S CODE, DATE OF PURCHASE, STAMP AND SIGNATURE
OF THE OFFICIAL DEALER.
The warranty excludes the following: the battery, the band, the strap, the
crystal breaking and scratching as well as possible faults caused by improper
use as well as factors due to normal aging or wear of the watch.
Page 4
4
1968 - Chronograph
Normal crown position
2nd click position
1st click position
Crown
Button B
Minute hand
Second hand
Date*
Chronograph second hand
Chronograph
-30 minutes hand
-12 hours hand
Hour hand
Button A
Page 5
5
BOMBERG MODEL - 1968 - Chronograph
Setting the time:
1. Pull the crown out to the 2nd click position so that the second hand stops.
2. Turn the crown to set hour and minute hands.
3. When the crown is pushed back to the normal position, small second
hand begins to run.
Setting the date:
1. Pull the crown out to the 1st click position.
2. Turn the crown counter-clockwise to set the date.*
3. After the date has been set, push the crown back to the normal position.
*If the date is set between the hours of around 8:30pm and 0:00am, the date may not
change on the following day.
Page 6
6
BOMBERG MODEL - 1968 - Chronograph
Using the chronograph:
This chronograph is able to measure and display time in 1/1 second united
up to 12 hours, 59 minutes and 59 seconds.
Measuring time with the chronograph:
1. The chronograph can be started and stopped each time button “A”
is pressed.
2. Pressing button “B” resets the chronograph and the hands return to
zero position.
Measuring intermediate time with the chronograph:
1. Press the button “A” to start the chronograph.
2. Press the button “B” to display an intermediate time. Timing continues in
background.
3. Press the button “B” again to restart the chronograph. The 3 chronograph
hands are quickly advanced to the ongoing measured time.
4. Press the button “A” to stop the chronograph.
5. When the chronograph is stopped, pressing button “B” resets every
fonction and the hands return to zero position.
1968 - Chronograph
Page 7
7
BOMBERG MODEL - 1968 - Chronograph
Chronograph reset (INCL. AFTER REPLACING BATTERY):
This procedure should be performed when the chronograph second hand
does not return to zero position after the chronograph has been reset, and
including after the battery has been replaced.
1. Pull the crown out to the 2nd click position.
2. Keep buttons “A” and “B” pushed simultaneously for at least 2 seconds;
the chronograph second hand rotates by 360°->corrective mode activated.
3. Press button “A” to set the chronograph hand to the zero position. The
chronograph hand can be advanced rapidly by continuously pressing
button “A”.
4. Press button “B” to set the next chronograph hand and repeat step 3.
5. Once the hands have been zeroed, return the crown to the normal position.*
Page 8
Bomberg
A division of Park Lane Partners SA
Rue de la Gare 4
2034 Peseux/NE
Switzerland
Website: www.bomberg.ch
Information: [email protected]
