BOLIDE
TECHNOLOGY GROUP
KPC600
Compact Design Camera with Case
Compact Design
Camera with Case
Description
This is one of the smallest spy cameras in the market.
The size is only 36mmx36mm. It has 420 lines and 1.0
lux. It has a wide range of working voltage from 9 to 12
VDC. These super tiny cameras can be used for any
purpose. They come with a RCA connector, power plug
and mounting bracket. Just plug and play.
468 South San Dimas Ave,
San Dimas, CA 91773
www.bolideco.com
ISO
Certifi ed
Features
• 1/3” Color CCD
• 420 Lines of Resolution
• 0.5 lux
• Optioinal Audio
• Standard: 3.6mm Pinhole Lens
Specifi cation
Model No. KPC600
Image Device 1/3” Color CCD
Effective Pixels 512(H) x 492(V)
Resolution 420 TVL
SYNC System Internal
Shutter Speed 1/60 ~ 1/100,000 sec
S/N Ratio >48dB
Video Output 1.0 Vp-p 75ohm
Min. Illumination 0.5 lux
Power Supply 9VDC~12VDC
Power Consumption 120mA
Dimension 36x36mm
Specifi cation subject to change without notice. Bolide Technology Group all right reserved® 2008
