Bolia JOY User Manual

JOY BT SPEAKER

User Manual

Joy BT Speaker - User Manual

Thank you for using our BT speaker!

In order to give you a good experience,

please read this User Manual before

using this product.

Features:

1. Bluetooth Version: 3.0

2. Bluetooth music

3. AUX-in function

4. Charging function via USB

5. Power Bank

Operation:

1. Bluetooth Pairing

This device has a built-in battery. Press

and hold button for 3-4 seconds to

start the device in Auto paring mode,

(the ashes blue). If previous paring

failed, press button once to enter into

new searching and paring mode (the

ashes blue).

Use your mobile phone to search the

device ”Joy BT Speaker”. If a password

is needed, then write ”0000”. To turn off

the device press and hold on button

for 3-4 seconds.

2. Bluetooth Music

Start your mobile phone’s media player

and choose your favourite song. When

you want to change the song, press

button to pick the next song, and

press button to pick the previous

song.

When you want to adjust the volume,

press and hold the button to increase

the volume, press and hold the but-

ton to reduce the volume.

Press button to pause or play the

music. When there is a call incoming,

please answer your mobile phone. After

the call has ended, the speaker will start

playing again.

3. AUX in function:

Connect the device’s AUX IN cable with

computer’s (or other audio devices) out-

put interface , while keeping the other

end into the AUX port. This device will

enter into AUX mode automatically.

4. Charging function:

Please insert the charging cable into the

“DC-5V IN” port and connect the USB

end with a computer or a charger (not

included). When charging, the small

lights above the USB port lights up.

When the speaker is fully charged, it will

turn off automatically.

5. Power Bank:

5.1: Battery level:

To check the current battery level short-

ly press button, the battery indicator

is placed at the back of the speaker

above the USB port. The battery level

has 4 levels: 25% 50% 75% 100%.

When all 4 lights are on, the speaker

is fully charged. The indicator turns off

after 8 seconds and 60-90 seconds later

it will enter into the standby mode auto-

matically. When the battery level is less

than 20% (3.2V), the blue light ashes

as a reminder that the battery is running

low. Please charge it in time, otherwise

it will automatically shut down.

5.2 Charging your mobile phone:

To use the Joy BT Speaker as a phone

charger, insert your mobile phone USB

cable in the USB port and the other end

of the cable to your mobile phone. The

charging will start automatically.

Notes:

1. When the ashes blue please

charge the device in time, or it will turn

off automatically.

2. When the device is connected with

your mobile phone or in Bluetooth Music

mode, you can charge it with the charg-

ing cable at the same time. But if you

pull out the charging cable, the device

will turn off automatically.

Product parameters:

Charging voltage: DC-5V
Working voltage: 3.7-4.2V
Product Power: 100-180MA
Battery capacity: 500MAH

Battery capacity: 2200MAH (battery bank)
Working hours: 20h (based on 80% Volume)
Speaker impedance: 4Ω 3W *2

Speaker distortion: ±5%MAX
Frequency distortion: <1%
