Bolens BL50 User Manual
Today,homeowners around the country rely
on Bolens for durable,reliable power
equipment at an affordable price
.
Operator’s
Manual
Since it began making garden tools in
1850,Bolens has been known for long-
lasting,dependable products.Bolens
eventually carried that hard-working
heritage into the outdoor power
equipment industry,when it designed
and built the first-ever power-driven
garden tractor.
Electric T rimmer
Model
BL50
THANK YOU
Thank you for buying this quality product. This modern
outdoor power tool will provide many hours of useful service.
You will find it to be a great labor-saving device. This
operator’s manual provides you with easy-to-understand
operating instructions. Read the whole manual and follow all
the instructions to keep your new outdoor power tool in top
operating condition.
PRODUCT REFERENCES,ILLUSTRATIONS AND
SPECIFICATIONS
All information, illustrations, and specifications in this manual
are based on the latest product information available at the
time of printing. We reserve the right to make changes at any
time without notice.
Copyright ©2002 MTD SOUTHWEST INC, All Rights Reserved.
Bump Head™ is a trademark of MTD SOUTHWEST INC
SplitLine™ is a trademark of MTD SOUTHWEST INC
SERVICE INFORMATION
Service on this unit both within and after the warranty period
should be performed only by an authorized and approved
service dealer.
For service call 1-330-558-7220 or 1-866-840-6483 to
obtain a list of authorized
service dealers near you.
DO NOT RETURN THE UNIT TO THE RETAILER. PROOF OF
PURCHASE WILL BE REQUIRED FOR WARRANTY SERVICE.
Before beginning, locate the unit’s model plate. It lists the
model and serial numbers of your unit. Refer to the sample plate
below and copy the information for future reference.
2
TABLE OF CONTENTS
Calling Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Rules for Safe Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Maintenance and Repair Instructions . . . . . . . . . . . . . . . . .10
Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Accessories and Replacement Parts . . . . . . . . . . . . . . . . . . .12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Inside Back Cover
CONTENTS OF CARTON
• Model BL50 Trimmer
∆ Large Bump Head Cutting Attachment
∆ D-Handle and Hardware
• Cutting Attachment Shield with Hardware
• Operator's Manual
• Product Registration Card
∆ These items are either pre-installed on the unit or located
in the hardware pack
Copy the model / parent part
number here:
Copy the serial number here:
Make sure you carefully read and understand this manual before
starting or operating this equipment.
THIS PRODUCT IS COVERED BY ONE OR MORE U.S. PATENTS.
OTHER PATENTS PENDING.
INTRODUCTION
3
Read the Operator’s Manual(s) and follow all warnings and safety instructions.
Failure to do so can result in serious injury to the operator and/or bystanders.
FOR QUESTIONS,CALL 1-330-558-7720 or 1-866-840-6483
SAFETY ALERT SYMBOL: Indicates danger, warn-
ing or caution. Attention is required in order to
avoid serious personal injury. May be used in conjunction with other symbols or pictographs.
• SAFETY SYMBOLS •
• IMPORTANT SAFETY INFORMATION •
READ ALL INSTRUCTIONS
T
he purpose of safety symbols is to attract your attention to possible dangers.The safety symbols,and their explanations,
deserve your careful attention and understanding.The safety warnings do not by themselves eliminate any danger.The
instructions or warnings they give are not substitutes for proper accident prevention measures.
SYMBOL MEANING
DANGER: Failure to obey a safety warning will
result in serious injury to yourself or to others.
Always follow the safety precautions to reduce
the risk of fire, electric shock and personal injury.
WARNING: Failure to obey a safety warning can
result in injury to yourself and others. Always follow the safety precautions to reduce the risk of
fire, electric shock, and personal injury.
CAUTION: Failure to obey a safety warning may
result in property damage or personal injury to
yourself or to others. Always follow the safety
precautions to reduce the risk of fire, electric
shock, and personal injury.
SYMBOL MEANING
NOTE:
Advises you of information or instructions vital to the operation or maintenance of the equipment.
BEFORE OPERATING
• Read the instructions carefully. Be familiar with the controls
and proper use of the unit.
• Do not operate this unit when tired, ill or under the influ-
ence of alcohol, drugs or medication.
• Children under the age of 15 must not use the unit; teens
may operate the unit with adult guidance.
• Inspect the unit before use. Replace damaged parts. Make
sure all fasteners are in place and secure. Replace cutting
attachment parts that are cracked, chipped or damaged in
any way. Make sure the cutting attachment is properly
installed and securely fastened. Be sure that the cutting
attachment shield is properly attached, and positioned as
recommended. Failure to do so can result in personal injury
to the operator and bystanders, as well as damage to the
unit.
• This unit was not designed to be used as a brushcutter. Do
not attach or operate this unit with any type of brushcutting blade or brushcutting attachment.
WARNING:
When using the unit, you must follow
the safety rules. Please read these instructions
before operating the unit in order to ensure the
safety of the operator and any bystanders. Please
keep these instructions for later use.
• Use only a 0.065-inch (1.65 mm) diameter genuine factory
parts replacement line. Never use metal-reinforced line,
wire, chain or rope. These can break off and become dangerous projectiles.
• Be aware of risk of injury to the head, hands and feet.
• Clear the area to be cut before each use. Remove rocks,
broken glass, nails, wire, string and other objects which
may be thrown or become entangled in the cutting attachment. Clear the area of children, bystanders and pets; keep
them outside a 50-foot (15 m.) radius, at a minimum. Even
then, they are still at risk from thrown objects. Encourage
bystanders to wear eye protection. If you are approached,
stop the unit immediately.
ELECTRICAL SAFETY WARNINGS
• Since the tool is double-insulated, a 2-wire extension cord
(an extension cord without a ground) may be used. A 3wire extension cord (an extension cord with a ground) that
uses a NEMA type connector (parallel blade, U ground) is
recommended. Extension cords are available from your
local retailer. Use only round-jacketed extension cords
approved for outdoor use.
DANGER:
When using electric gardening appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric shock
and personal injury. Carefully read and understand
the entire operator's manual before using your
trimmer. Pay close attention to the operating
instructions and safety warnings.
INTRODUCTION
4
• This tool is double-insulated. Use only identical replacement
parts when servicing. Repair or replace damaged cords.
• To reduce the risk of electrical shock, this unit has a polarized plug (one blade is wider than the other). This unit will
fit with a polarized plug in one way only. If the plug does
not fit fully into the unit, reverse the plug. If it still does not
fit, use a cord with the correct connection. Do not modify
the unit in any way.
• CORD SETS: Make sure your cord set is in good condition,
with a cord that is heavy enough to carry the current that
your unit will draw. An undersized cord set will cause a
drop in line voltage resulting in a loss of power, as well as
overheating. The table shown above illustrates the correct
size to use depending on the cord length and nameplate
amperage rating. If in doubt, use the next heavier size line
gauge. The smaller the gauge number, the heavier the
cord. To prevent the cord from disconnecting from the
unit, use the cord hook shown in the Operating Instructions.
• Do not abuse the power cord. Do not pull or carry the unit
by the cord, use the cord as a handle, close a door on the
cord, or pull the cord around sharp edges or corners. Keep
the cord away from heated surfaces, oil and sharp edges.
• Ground Fault Circuit Interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) that will be used
for the unit. Use receptacles with built-in GFCI protection
for an extra measure of safety.
•A nameplate on your unit indicates the voltage used. Never
connect the unit to an AC voltage that differs from this
voltage.
• Avoid dangerous environments. Never operate your unit in
damp or wet conditions. Moisture is a shock hazard.
• Inspect all extension cords and the unit power connection
periodically. Look closely for deterioration, cuts or cracks in
the insulation. Also inspect the connections for damage.
Repair or replace the cords if any defects appear.
• Do not use the unit in the rain.
• Do not handle the plug or the unit with wet hands.
WHILE OPERATING
• Wear safety glasses or goggles that meet ANSI Z87.1 standards and are marked as such. Wear ear/hearing protection
when operating this unit. Wear a face or dust mask if the
operation is dusty.
• Wear heavy long pants, boots, gloves and a long sleeve
shirt. Do not wear loose clothing, jewelry, short pants, sandals or go barefoot. Secure hair above shoulder level.
• The cutting attachment shield must always be in place while
operating the unit. Do not operate unit without both trimming lines extended, and the proper line installed. Do not
extend the trimming line beyond the length of the shield.
• Adjust the D-handle to your size to provide the best grip.
• Be sure the cutting attachment is not in contact with anything before starting the unit.
• Use the unit only in daylight or good artificial light.
• Avoid accidental starting. Do not carry around a unit that is
plugged in with your finger on the trigger switch. Be sure
the switch is in the off position when plugging in the unit.
•
Use the right tool. Only use this tool for its intended purpose.
• Do not overreach. Always keep proper footing and balance.
• Always hold the unit with both hands when operating.
Keep a firm grip on both handles or grips.
• Keep hands, face, and feet at a distance from all moving
parts. Do not touch or try to stop the cutting attachment
when it rotates.
• Always stop the motor when cutting is delayed or when
walking from one cutting location to another.
• If you strike or become entangled with a foreign object,
stop the motor immediately and check for damage. Do not
operate before repairing damage. Do not operate the unit
with loose or damaged parts.
• Stop the unit and unplug it for maintenance or repair.
•Use only genuine original equipment replacement parts
and accessories for this unit. These are available from your
authorized service dealer. Use of any non-original parts or
accessories could lead to serious injury to the user, or damage to the unit, and void your warranty.
•
Keep unit clean of vegetation and other materials. They may
become lodged between the cutting attachment and shield.
OTHER SAFETY WARNINGS
• Disconnect the unit from the power supply when it is idle,
when you are storing or transporting it, when you are servicing it, and when you are changing attachments.
• Store the unit in a dry area, locked up to prevent unauthorized use or damage, and stored in a high place out of the
reach of children.
• Never douse or squirt the unit with water or any other liquid. Keep handles dry, clean and free from debris. Clean
after each use. See the Cleaning and Storage instructions.
• Keep these instructions. Refer to them often and use them
to instruct other users. If you loan someone this unit, also
loan them these instructions.
SA VE THESE INSTRUCTIONS
WARNING: To reduce the risk of electrical shock,
use only SW-A, SOW-A, STW-A, STOW-A, SJW-A,
SJOW-A, SJTW-W or SJTOW-A cord types.
Cord length (ft.) 25 50 100 150
Wire size (AWG) 16 16 16 14
MINIMUM WIRE SIZE FOR EXTENSION CORDS FOR 120
VOLT APPLIANCES USING 0-6 AMPS
RULES FOR SAFE OPERATION
5
SYMBOL MEANING
• SAFETY ALERT SYMBOL
Indicates danger, warning or caution.
May be used in conjunction with other
symbols or pictographs.
•WARNING - READ
OPERATOR'S MANUAL
Read the operator’s manual(s) and follow
all warnings and safety instructions.
Failure to do so can result in serious
injury to the operator and/or bystanders.
•WEAR EYE AND HEARING
PROTECTION
WARNING: Thrown objects and loud
noise can cause severe eye injury and
hearing loss. Wear eye protection
meeting ANSI Z87.1 standards and ear
protection when operating this unit. Use
a full face shield when needed.
• KEEP BYSTANDERS AWAY
WARNING: Keep all bystanders,
especially children and pets, at least 50
feet (15 m) from the operating area.
SYMBOL MEANING
• THROWN OBJECTS AND ROTATING
CUTTER CAN CAUSE SEVERE
INJURY
WARNING: Do not operate without the
cutting attachment shield in place.
Keep away from the rotating cutting
attachment.
•HOT SURFACE WARNING
Do not touch hot surfaces like the gear
housing. You may get burned. These parts
get extremely hot from operation. They
remain hot for a short time after the unit is
turned off.
• SHARP BLADE
WARNING: Sharp blade on cutting
attachment shield. To prevent serious
injury, do not touch line cutting blade.
SAFETY AND INTERNATIONAL SYMBOLS
This operator's manual describes safety and international symbols and pictographs that may appear on this product.
Read the operator's manual for complete safety, assembly, operating and maintenance and repair information.
RULES FOR SAFE OPERATION
6
KNOW YOUR UNIT
As a trimmer:
•Cutting grass and light weeds
•Decorative trimming around trees,fences,etc.
Cutting Attachment
Shield
D-Handle
Cutting Attachment
Shaft Housing
Line Cutting Blade
Housing Grip
Switch Trigger
Recessed
Plug
Motor Housing
RULES FOR SAFE OPERATION
Switch Trigger
7
Fig.1
On some units, the D-handle may be pre-installed. In this
case you must loosen screws and adjust the handle to fit the
operator. Go to step 4 if the D-handle is pre-installed.
INSTALLING AND ADJUSTING THE D-HANDLE
1. Remove the items that were installed on the D-handle
for shipping.
2. Place the D-handle over the shaft housing and push it on
the boom (Fig. 1).
3, Install the bolt, washer and wing nut. Tighten them.
4. If the D-handle was pre-installed, loosen the wing nut on
it just enough so it is movable.
5. While holding the unit in the operating position, arrange
or rotate the D-handle to the location that provides you
the best grip (Fig. 2).
6. Tighten the wing nut until the D-handle is secure.
INSTALLING THE CUTTING SHIELD
Use the following instructions if the cutting attachment shield
on your unit is not installed or if you ever need to re-install it.
1. Place the cutting attachment shield onto the shaft
housing above the clamp assembly (Fig. 3).
2. Push the cutting attachment shield down to the top of
the cutting attachment assembly. Then rotate the shield
until its screw holes line up with the holes in the cutting
attachment. The shield guard should fit into the recessed
pocket (Fig. 3).
3. Install the screws with a Phillips screwdriver (Fig. 4).
WARNING: To prevent serious personal injury,
never operate the trimmer without the cutting
attachment shield in place.
Fig.2
Clamp
Assembly
Cutting
Attachment
Shaft Housing
(4) Screws
Cutting Attachment
Shield
Fig.3
Fig.4
ASSEMBLY INSTRUCTIONS
8
CONNECTING THE CORD
Use the cord hook when connecting the extension cord to the
power cord outlet. This helps prevent any disconnection.
1. Make a narrow loop with the extension cord.
2. Push the loop through the opening and move it onto the
hook on the motor housing (Fig. 5).
3. Plug the cord properly into the socket.
Only use outdoor-approved extension cords. Cord sets are
specified in theImportant Safety Information section.
STARTING/STOPPING INSTRUCTIONS
Once the unit is plugged in, stand in the operating position
(Fig. 7). Squeeze the trigger to start the unit. To stop the unit,
release the trigger (Fig. 6).
WARNING: Always wear eye, hearing, foot and
body protection to reduce the risk of injury
when operating this unit.
HOLDING THE UNIT
Before operating the unit, stand in the operating position
(Fig. 7). Check for the following:
•
The operator is wearing eye protection and proper clothing
• With a slightly-bent right arm, the operator’s hand is
holding the shaft grip
• The operator’s left arm is straight, the left hand holding
the D-handle
• The unit is at waist level
•
The cutting attachment is parallel to the ground and easily contacts the grass without the need to bend ove
r
Trigger
ADJUSTING TRIMMING LINE LENGTH
The Bump Head™ cutting attachment allows you to release
trimming line without stopping the motor. To release more line,
lightly tap the cutting attachment on the ground (Fig.8) while
operating the trimmer at high speed.
NOTE: Always keep the trimming line fully extended.
Line release becomes more difficult as cutting
line becomes shorter
Each time the head is bumped, about 1 inch (25.4 mm) of
trimming line releases. A blade in the cutting attachment
shield will cut the line to the proper length if any excess line
is released.
Fig.7
Fig.6
Fig.5
WARNING: Always wear eye, hearing, foot and
body protection to reduce the risk of injury
when operating this unit.
OPERATING INSTRUCTIONS
9
• Cut from left to right whenever possible. Cutting to the right
improves the unit's cutting efficiency. Clippings are thrown
away from the operator.
•Slowly move the trimmer into and out of the cutting
area at the desired height. Move either in a forwardbackward or side-to-side motion. Cutting shorter
lengths produces the best results.
• Trim only when grass and weeds are dry.
• The life of your cutting line is dependent upon:
• Following the trimming techniques previously explained
• What vegetation is cut
• Where vegetation is cut
For example, the line will wear faster when trimming against
a foundation wall as opposed to trimming around a tree.
DECORATIVE TRIMMING
Decorative trimming is accomplished by removing all
vegetation around trees, posts, fences and more.
Rotate the whole unit so that the cutting attachment is at a
30°angle to the ground (Fig. 9).
TIPS FOR BEST TRIMMING RESULTS
• Keep the cutting attachment parallel to the ground.
• Do not force the cutting attachment. Allow the tip of the line
to do the cutting, especially along walls. Cutting with more
than the tip will reduce cutting efficiency and may overload
the motor.
• Cut grass over 8 inches (200 mm) by working from top to
bottom in small increments to avoid premature line wear
or motor drag.
For best results, tap the bump knob on bare ground or hard soil.
If you attempt a line release in tall grass, the unit may stall.
Always keep the trimming line fully extended. Line release
becomes more difficult when the cutting line gets shorter.
NOTE: Do not rest the Bump Head™ on the ground
while the unit is running.
Some line breakage will occur from:
• Entanglement with foreign matter
• Normal line fatigue
• Attempting to cut thick, stalky weeds
•
Forcing the line into objects such as walls or fence posts
CAUTION:
Do not remove or alter the line cutting
blade assembly. Excessive line length will make the
unit overheat. This may lead to serious personal
injury or damage to the unit.
Fig.9
Fig.8
OPERATING INSTRUCTIONS
10
SERVICING DOUBLE INSULATED UNITS
This unit is double-insulated. In a double-insulated unit, two
systems of insulation are provided instead of grounding.
There is no grounding provided and no means of grounding
should be added to this unit.
Extreme care and knowledge of the system is required when
servicing a double-insulated unit. Service should be
performed by qualified service personnel only. Replacement
parts for a double-insulated unit must be identical to the
parts they replace. Refer any repair to an authorized service
dealer. A double-insulated unit is marked with the words
“double insulation” or “double insulated.”
LINE INSTALLATION
This section covers both SplitLine™ and standard single line
installation.
Always use genuine factory parts 0.065 in. (1.65 mm)
replacement line. Using line other than the specified may
make the unit overheat or fail.
There are two methods to replace the trimming line:
• Wind the inner reel with new line
• Install a prewound inner reel
Winding the Existing Inner Reel
1. Hold the outer spool with one hand and unscrew the
bump knob counterclockwise (Fig. 10). Inspect the bolt
inside the bump knob to make sure it moves freely.
Replace the bump knob if damaged.
2. Remove the inner reel from the outer spool (Fig. 11).
3. Remove spring from the inner reel (Fig. 11).
4. Use a clean cloth to clean the inner reel, spring, shaft, and
inner surface of the outer spool.
5. Check the indexing teeth on the inner reel and outer
spool for wear (Fig. 12). If necessary, remove burrs or
replace the reel and spool.
Bump Knob
Bolt
Loop
NOTE: SplitLine™ can only be used with the inner reel
with the slotted holes. Single line can be used
on either type of inner reel. Use Figure 13 to
identify the inner reel you have.
NOTE: Always use the correct line length when
installing trimming line on the unit. The line may
not release properly if the line is too long.
Inner Reel
Spring
Outer Spool
Indexing Teeth
Slotted Holes
For Use with SplitLine™
or Single Line
For Use with
Single Line ONLY
WARNING: Never use metal-reinforced line,
wire, chain or rope. These can break off and
become dangerous projectiles.
Fig.14
Fig.13
Fig.12
Fig.11
Fig.10
MAINTENANCE & REPAIR INSTRUCTIONS
11
Single Line Installation
Go To Step 8 for SplitLine™ Installation
6. Cut approximately 25 feet (7.6 m) of new trimming line,
then loop it into two equal lengths. Insert each end of the
line through one of the two holes in the inner reel
(Fig. 14). Pull the line through the inner reel so that the
loop is as small as possible.
7. Wind the lines in tight even layers, onto the reel
(Fig. 15). Wind the line in the direction indicated on the
inner reel. Place your index finger between the two lines
to stop the lines from overlapping. Do not overlap the
ends of the line. Proceed to step 11.
SplitLine™ Installation
8. Cut approximately 12 feet (3.65 m) of new trimming line.
Insert one end of the line through one of the two holes in
the inner reel (Fig. 16). Pull the line through the inner reel
until only about 4 inches is left out.
9. Insert the end of the line into the open hole in the inner
reel and pull the line tight to make the loop as small as
possible (Fig. 16).
10. Before winding, split the line back about 6 inches.
11. Wind the line in tight even layers in the direction
indicated on the inner reel.
NOTE:
Failure to wind the line in the direction indicated will
cause the cutting attachment to operate incorrectly
.
12. Insert the ends of the line into the two holding slots (Fig. 17).
Loop
13. Insert the ends of the line through the eyelets in the
outer spool and place inner reel with spring inside the
outer spool (Fig. 18). Push the inner reel and outer spool
together. While holding the inner reel and outer spool,
grasp the ends and pull firmly to release the line from the
holding slots in the reel.
NOTE: The spring must be assembled on the inner reel
before reassembling the cutting attachment.
14. Hold the inner reel in place and install the bump knob by
turning clockwise. Tighten securely.
INSTALLING A PREWOUND REEL
1. Hold the outer spool with one hand and unscrew the
bump knob counterclockwise (Fig. 10). Inspect the bolt
inside the bump knob to make sure it moves freely.
Replace the bump knob if damaged.
2. Remove the old inner reel from the outer spool (Fig. 11).
3. Remove the spring from the old inner reel (Fig. 11).
4. Place the spring in the new inner reel.
NOTE: The spring must be assembled on the inner reel
before reassembling the cutting attachment.
5. Insert the ends of the line through the eyelets in the
outer spool (Fig. 18).
6. Place the new inner reel inside the outer spool. Push the
inner reel and outer spool together. While holding the inner
reel and outer spool, grasp the ends and pull firmly to
release the line from the holding slots in the reel.
7. Hold the inner reel in place and install the bump knob by
turning clockwise. Tighten securely.
Replacement Parts
Refer to the Accessories / Replacement Partssection.
Holding Slots
Spring
Eyelet
Eyelet
Fig.15
Fig.18
Fig.17
Fig.16
MAINTENANCE & REPAIR INSTRUCTIONS
12
CLEANING
Switch off the unit and disconnect it from the power source.
Use a small brush to clean off the outside of the unit. Do not
use strong detergents. Household cleaners that contain
aromatic oils such as pine and lemon, and solvents such as
kerosene, can damage plastic housing or handle. Wipe off
any moisture with a soft cloth. Also keep the air vents free of
obstructions.
INSPECT EXTENSION CORDS
Inspect all extension cords. Look closely for deterioration,
cuts or cracks in the insulation. Inspect the connectors for
damage. Replace a damaged or defective cord.
WARNING: To avoid serious personal injury,
always turn your trimmer off and allow it to cool
before you clean or service it.
STORAGE
• Allow the unit to cool before storing.
• Lock the unit to prevent unauthorized use or damage.
• Store the unit in a dry, well-ventilated area.
• Store the unit out of the reach of children.
ACCESSORIES/REPLACEMENT PARTS
Replacement Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160425
Replacement Line Cartridge . . . . . . . . . . . . . . . . . . . . . . . .160425
Inner Reel Spring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 610317
Bump Knob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153066
Bump Knob Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147153
These replacement parts can be purchased from your local
authorized dealer.
MOTO R
Motor type....................................................................................................................................................................................A.C.,120 Volts Electric
Operating RPM..................................................................................................................................................................................... up to 7,400 rpm
Ignition Switch........................................................................................................................................................................................................Trigger
Amperage............................................................................................................................................................................................................. 4.7 amps
DRIVE SHAFT AND CUTTING HEAD
Drive Shaft Housing........................................................................................................................................................................................Aluminum
Shoulder Strap.................................................................................................................................................................................................... Optional
Unit Weight (cutting attachment shield and D-handle)...............................................................................................................9 lbs.(4.1 kg)
Line Spool....................................................................................................................................................................................... Bump Line Releaser
Line Spool Diameter......................................................................................................................................................................3 inches (76.2 mm)
Cutting Path Diameter......................................................................................................................................................................... 15 in (381 mm)
Trimming Line Diameter.............................................................................................................................................................. 0.065 in (1.65 mm)
MAINTENANCE & REPAIR INSTRUCTIONS
SPECIFICATIONS
13
CAUSE ACTION
Unit is unplugged Check cord to make sure it is still plugged into an electrical outlet
MOT OR WILL NOT STAR T
CAUSE ACTION
Cutting attachment bound with grass Stop the unit and clean cutting attachment
Cutting attachment out of line Refill with new line
Inner reel bound up Replace the inner reel
Cutting head dirty Clean inner reel and outer spool
Line welded Disassemble, remove the welded section and rewind
Line twisted when refilled Disassemble and rewind the line
Not enough line is exposed Push the bump knob and pull out line until 4 inches (102 mm) of line
is outside of the cutting attachment
CAUSE ACTION
Oil, cleaner or lubricant in cutting head Clean and thoroughly dry the cutting head
If further assistance is required, contact your authorized service dealer
CUTTING ATTACHMENT WILL NOT ADVANCE LINE
CUTTING LINE ADVANCE UNCONTROLLABLY
TROUBLESHOOTING
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
FOR QUESTIONS CALL 1-866-840-6483
OPERATOR’S MANUAL PART NO. 769-00431 9/02
PRINTED IN U.S.A.
