Bogen R6-R6T, R8-R8T User Manual

Models R6/R6T and R8/R8T
LANDSCAPE LOUDSPEAKERS
OWNER’S GUIDE
R6/R6T
R8/R8T
54-2038-01R3 0205
LOW FREQUENCY OUTPUT
NEAR ROCK loudspeakers are engineered to deliver ample bass output in open areas. However, bass output will increase if the speakers are placed near a reflecting surface (such as a wall).
UNDERPOWERING VS. OVERPOWERING
Most speaker damage is caused by amplifiers with too little power. An overdriven amp sends clipping distortion to the speakers. Clipping is usually audible; it may vary from a harsh sound to a fuzzy or blurry sound. If you hear clipping at loud volume levels, turn down the volume until the distortion is no longer present. Damage caused by operating the speakers at distorted volume levels is not covered by the warranty.
MAINTENANCE
Speaker cabinets can be wiped clean or even hosed off. CAUTION: Although NEAR ROCK speakers are waterproof, avoid spraying high-pressure water directly into the speaker grilles.
SPEAKER PLACEMENT
NEAR ROCK loudspeakers are designed to be placed on the ground, with the grille facing the listening area. The speaker drivers are angled upward to provide proper vertical sound dispersion for listeners standing 10 feet or more away. Sound coverage in the horizontal plane is 100º. Keep this angle in mind when positioning the speakers for stereo reproduction. Too great a distance between any 2 speakers will create a dead spot in the coverage. When in doubt, use additional speakers to ensure adequate coverage.
VERTICAL SOUND DISPERSION (45 DEGREES)
HORIZONTAL SOUND DISPERSION (100 DEGREES)
10 FEET
REFLECTING SURFACES INCREASE BASS OUTPUT
C
16W
C
16W
C
16W
C
16W
C
16W
C
16W
AMPLIFIER WITH 70V OUTPUT
SIX MODEL R8T SPEAKERS CONNECTED IN PARALLEL USING 16W TAPS
C 70V
Common wire (black)
16W wire (white)
R8T R8T R8T R8T R8T R8T
AMP’S SPEAKER OUTPUTS
C
70V
Join like wires with wire nuts
C
16W
C
16W
JOINING SPEAKERS IN PARALLEL
red
black
red
black
AMP’S SPEAKER OUTPUTS
NOTE: The total number of speakers multiplied by the tap value cannot exceed the output power (in watts) of the 70V amplifier. The above example shows 6 speakers. Using the 16W taps, you need at least (6) x (16W) = 96W. A good rule of thumb is to select an amplifier with 20% greater power; in this case, an amplifier that delivers about 115W.
CAUTION: Nominal system impedance is halved (to 4 ohms) when connecting a second pair of ROCK speakers. Adding a third pair will reduce the impedance load further and could damage an amplifier not designed to operate at impedances below 4 ohms.
EXAMPLE OF 70V SYSTEM CONFIGURATION
EXAMPLE OF 8SYSTEM CONFIGURATION
CONNECTIONS
(Wire colors may vary. If so, contact Technical Support.)
NEARROCK LANDSCAPE LOUDSPEAKERS
Observe correct polarity for maximum bass performance. Connect + to + and – to – as illustrated.
WIRE JACKET FROM SPEAKER
white
black
8W 16W 32W
C
16W 32W 64W
C
whiteblack red green
green
red
MODEL R6T
MODEL R8T
TAP (+) CONNECTIONS
red
WIRE JACKET FROM SPEAKER
black
MODELS R6 and R8
SPECIFICATIONS
MODEL NUMBER
MID/BASS DRIVER
TWEETER
FREQUENCY RESPONSE
NOMINAL IMPEDANCE
MAXIMUM POWER
SENSITIVITY (1W @ 1M)
SOUND DISPERSION
DIMENSIONS (in / cm)
WEIGHT (lbs / kg)
R6/R6T
6" MDT™
1-1/8" inverted-dome
75Hz – 20kHz
R6: 8 R6T: 70V
R6: 100W @ 8 R6T: 32W @ 70V
88dB
Horiz - 100˚, Vert - 45˚
(in.) 18 W x 14 D x 10 H (cm) 46 W x 36 D x 25 H
R6: 35 lbs; 15.9 kg R6T: 37 lbs; 16.8 kg
R8/R8T
8" MDT™
1-1/8" inverted-dome
60Hz – 20kHz
R8: 8 R8T: 70V
R8: 175W @ 8 R8T: 64W @ 70V
90dB
Horiz - 100˚, Vert - 45˚
(in.) 23 W (cm) 58 W x 38 D x 41 H
R8: 64 lbs; 29.1 kg R8T: 67 lbs; 30.4 kg
x 15 D x 16 H
NEAR®TECHNOLOGIES
NEAR’s exclusive MDT™ metal-alloy diaphragm is about as light as is physically possible – nearly the ideal massless piston. The benefits are immediately recognized in the musical accuracy, fine detail of sound, and ease of listening. Here is a summary of MDT benefits:
High rigidity and low mass of metal versus traditional papers and plastics
• Extremely stable cone structure over long periods of time
• Fast transmission of sound through the diaphragm means low energy storage
• Special anodizing process creates a ceramic coating for increased stiffness
• Efficient heat-sinking of voice coils under long-term, high-power situations
In addition to MDT, another unique technology is incorporated into NEAR speakers: Magnetic Liquid Suspension (MLS™). MLS eliminates the traditional mechanical centering device (the “spider”) for the voice coil and replaces it with a magnetic fluid that remains permanently suspended in the gap of the magnet, allowing the voice coil to stay centered and to operate with extreme linearity. In fact, the louder it plays, the more accurate the centering forces become. Here is a summary of MLS benefits:
• Voice coil is constantly centered as it moves up and down, for lower distortion
• Voice coil is more efficiently heat-sinked by fluid instead of air
Dual-layer voice coil with separate inner and outer windings reduces distortion at high output levels
Greater linearity is accomplished because the mechanical spider is eliminated
• Constant lubrication of the gap prevents oxidation from outdoor use
Long-term operation is more consistent since fluid doesn't change characteristics
Longer excursions with smaller diameter woofers; spiders limit excursions
P.O. Box 575, Ramsey, NJ 07446 U.S.A.
tel 201-934-8500 fax 201-934-9832
e-mail: nearspeakers@bogen.com www.nearspeakers.com
Specifications are subject to change without notice. ©2000 Bogen Communications, Inc.
