Bogen HFCS1LP User Manual

Specifications subject to change without notice.

54-2091-01D 1111

High-Fidelity Ceiling Speakers

Models HFCS1 and HFCS1LP

Installation and Use Manual

Product Description

Bogen’s coaxial 2-way hi-fi ceiling speakers deliver unsurpassed performance and value. The HFCS1(LP)’s steel back can and front exit venting allow for deep bass response, enhancing the quality and intelligibility of both speech and music. The HFCS1LP uses a smaller, low-profile back can that allows for a greater range of installations.

Both speakers can be installed either in suspended ceiling structures or hard surfaces (such as sheetrock). They come ready to install with integral swinging arm clamps. An optional mounting bracket (TBCR) is available for additional support (recommended for all suspended ceiling applications). The bracket can also be used for new construction ceilings, providing a cutout guide behind the sheetrock surface and as a C-ring to stiffen the edges of the cutout opening.

A variety of speaker power levels are easily selected via a front panel rotary switch. Settings for both 70V and 100V high-impedance systems, as well as a low-impedance (16-ohm) position, are provided.

The HFCS1(LP) features a removable snap-lock input connector, providing easy wire connection for input as well as loop-through to the next speaker.

IMPORTANT

The HFCS1 and HFCS1LP are not outdoor speakers. Do not expose the

speakers to rain or moisture. The HFCS1 and HFCS1LP should only be

installed by qualified personnel.

Always follow these basic safety precautions when installing and using the unit:

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean unit with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade, or the third prong, are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer. An operation manual is provided with the product.

12. Unplug this apparatus during lightning storms or when not used for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

Product Diagrams

Front Drawing (grille removed)

1. Coaxial Driver Assembly

2. Bass Tuning Vents (x2, HFCS1; x1, HFCS1LP)

3. Grille Retention Groove

4. Power Tap Selection Switch

5. Mounting Clamp Screws (x4)

Rear Drawing

6. Metal Back Can

7. Snap-Lock Input Connector

8. Mounting Clamps (x4)

Rear Drawing (terminal cover)

9. Terminal Covers (2 identical halves)

10. Eyelets (x2)

11. Mounting Screws (x4)

12. Wire Exit Slot

13. Conduit Knockout (x2)

Front Drawing

(grille removed)

Rear Drawing

(terminal cover)
