Integrated delivery of therapeutic gas
Operating guidelines
Step by step
INHALO
®
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
The product label is xed to the cylinder
collar and contains information such as
gas code, UN number, cylinder size,
cylinder contents, cylinder capacity, safe
handling notes, and safety precautions
relating to the gas contents.
Check product label to ensure
you have the correct gas.
1
Always use the label as the primary
means of identication.
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
The contents gauge is easy to read and
provides a clear indication of when the
cylinder is full (green zone), in between
(1/4, 1/2, 3/4), or when you should
consider changing (red zone). The
gauge is live at all times which saves
time and wasted gas when checking the
cylinder contents.
Check there is sucient contents
for your requirements.
2
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
The ow selector knob is designed for
maximum grip and ease of use, it is used
in conjunction with the rtree outlet 6
and the OPEN/CLOSE hand wheel 8 to
deliver variable gas ow (0 – 15 lpm). The
ow indicator window rotates clockwise to
select higher ow settings, and in reverse
for lower settings and to return to zero.
When not in use or before opening the
cylinder for the rst time the ow selector
should be set to zero.
Turn ow selector to zero.
3
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
The tamper evident seal ensures quality,
and when removed provides access to the
OPEN/CLOSE hand wheel. Grasp the pull
ring and simply remove the tamper evident
seal as shown. These covers are recyclable,
please discard thoughtfully.
Remove the light grey
tamper evident seal.
4
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
To access the gas outlet ports open the
cover as shown. Simply swing the cover
down allowing it to stay attached at the
hinge where possible. These covers are
recyclable, please discard thoughtfully.
Open the light grey hinged
cover which protects the rtree
and Diameter Index Outlet
(DIO) connections.
5
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
After you have checked that the ow
selector is set to zero
3
attach therapy
tubing, mask or cannulae directly to the
rtree outlet. This will allow you to deliver
gas to the patient after the OPEN/CLOSE
hand wheel has been opened 8 and the
ow selector set 9 .
The rtree outlet is suitable for tubing
diameters from 6mm to 8mm.
Connect
Firtree outlet:
This outlet is for connecting therapy
tubing, mask or canulae to the
variable ow selector.
6
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Connect
DIO (Diameter Index Outlet):
This outlet is for the connection
of equipment eg. portable
suctiondevice.
NOTE: DIO is also know as SIS –
Sleeve Index System, refer AS2896
7
To achieve a gas-tight seal
equipment should only be tted
to the DIO hand-tight. To ensure
a good seal rst check that the
equipment to be tted to the DIO
has an O-ring in good condition
in place. Then t the equipment
connection to the DIO hand-
tight only. Tools or leveraging of
equipment should never be used
to secure equipment to the DIO
as it may damage the device and
endanger the user.
Summary
The DIO outlet is used in conjunction with the
OPEN/CLOSE hand wheel to deliver gas (4
Bar) to equipment attached to the DIO. Gas
will not ow from the DIO unless equipment
is attached to it. The DIO outlet delivers gas
independently of the rtree outlet.
Use the hand wheel connection on your
equipment to attach directly to the DIO,
ensure that the ow selector is set to
zero
3
then open the OPEN/CLOSE
hand wheel 8 to use equipment.
The DIO connection will allow you to
connect a variety of equipment depending
on your needs eg. portable suction devices,
ventilators and owmeters for low and
high range applications.
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
To open the cylinder valve
slowly rotate the OPEN/CLOSE
hand wheel in an anticlockwise
direction fully, then a quarter of
a turn clockwise, as illustrated.
8
Summary
The OPEN/CLOSE hand wheel is used
to provide gas to both the rtree outlet
6
once a ow setting has been
selected, and the DIO outlet 7 once
equipment has been attached.
The rtree & DIO outlets work
independently of each other.
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
Summary
The ow selector is used in conjunction
with the rtree outlet 6 and the OPEN/
CLOSE hand wheel 8 to deliver variable
gas ow (0 - 15 lpm). When not in use or
before opening the cylinder for the rst
time the ow selector should be set to zero.
The ow indicator window rotates clockwise
to select higher ow settings, and in reverse
for lower settings and to return to zero.
Always place the setting directly on
the number in the window. The unique
design of the ow meter allows a nominal
amount of gas ow between settings if
accidentallyselected.
Rotate the gas ow selector
knob to the desired ow rate
for your application.
9
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
After use.
10
b
Depressurise equipment.
d
Remove equipment and tubing,
replace grey cover where possible
and return to BOC.
c
Set ow selector to zero.
a
Slowly close the OPEN/CLOSE hand
wheel by rotating in a clockwise
direction until it stops, as illustrated.
BOC: Living healthcare
Step by step operating guidelines – INHALO
®
xxxxxxxxxxxxx
xxx - 000x
xxx 00 xx
00.00.00 (x)00
Carry handle
The carry handle has been
ergonomically designed to provide a
balanced and safe carry point for the
INHALO® device. The handle acts as a
protection barrier for the gas outlets if
the cylinder should be knocked over.
Cylinder ll port cover
and batch label.
For BOC use only, the cylinder ll port
should never be tampered with as
serious injury may occur. The batch
label acts as a tamper evident seal.
Thank you for your attention.
Australia: BOC Limited
ABN: 95 000 029 729
BOC Healthcare
10 Julius Ave, North Ryde NSW 2113
T: 1300 363 109 F: 1300 363 438
E: hospital.care@boc.com
www.boc-healthcare.com.au
