Technical Data
Mounts in partition of barrier-free toilet compartment for physically disabled persons.
One side is flush against partition to allow clearance for grab bar across front of unit.
PARTITION-MOUNTED
TOILET-SEAT-COVER AND
TOILET TISSUE DISPENSER
(SERVES TWO TOILET COMPARTMENTS)
B-3471
30-5/8''
780mm
6''
150mm
S
19-5/8''
500mm
S
5''
125mm
20-1/2''
520mm
to Back Wall
17-3/16''
435mm
16-1/16''
410mm
15-3/16''
385mm
9/16''
14mm
Toilet-Seat-Cover
Dispenser (2)
S
Sight-Barrier Panel
Grab Bar
(Not Furnished)
Toilet Tissue
Dispenser (4)
S
1''
25mm
Ty p.
Fixed Flange
(Barrier-Free
Compartment)
Permanent
33''
840mm
Floor
to
Panel
S
4-5/16''
110mm
Adjustable Flange
S
S
Lock & Key
Door
S
Lock
1/2'' to 3-7/8''
13 to 98mm
28-5/8''
725mm
1075mm
42-1/4''
For Universal / Barrier-Free Design
Recommended Mounting Height Off Floor
Rough Partition Cutout
15-1/2" (395mm) wide
28-7/8" (735mm) high
1/2" to 3-7/8" (13 to 98mm)
partition thickness
MATERIALS:
Cabinet — 18-8 S, type-304, heavy-gauge stainless steel. All-welded construction. Exposed sur faces have satin finish. Equipped
with a plastic sight-barrier panel for the toilet-seat-cover dispenser.
Flanges (2) — 18-8 S, type-304, 22-gauge (0.8mm) stainless steel with satin finish. Drawn and beveled, one-piece, seamless
construc tion.
Door & Permanent Panel — 18-8 S, type-304, 18-gauge (1.2mm) stainless steel with satin finish. One-piece, seamless construction. Door is secured to cabinet with a full-length stainless steel piano-hinge and equipped with two tumbler locks keyed
like other Bobrick washroom accessories.
Toilet Tissue Dispensers (4) — .100" (2.5mm) thick ABS. Equipped with four theft-resistant, heavy-duty, one-piece, molded
ABS spindles.
OPERATION:
Toilet-seat-cover dispenser is serviced from one side and holds 1000 single- or half-fold paper covers. Door unlocks with key
provided and swings open for filling. Spindles may be removed from cabinet when door is open; when door is closed, removal
requires a special key provided for the concealed locking mechanism in spindles. Unit holds four standard-core toilet tissue
rolls up to 5-1/4" (135mm) diameter (1800 sheets), two for each compartment.
Designer's Note: It is recommended that one full toilet tissue roll remain wrapped until the other roll has been depleted to avoid
wasting ends of both rolls.
continued . . .
The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. Rev. 1/6/11
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2011 by Bobrick Washroom Equipment, Inc.
R/A, S/C
Printed in U.S.A.
INSTALLATION:
Mount unit in toilet partition 1/2" to 3-7/8" (13 x 98mm) thick, centered through a cutout specially ordered from partition
manufacturer or field cut. Dimensions of cutout are to be 15-1/2" wide x 28-7/8" high (395 x 735mm). Top of cutout should be
42-1/4" (1075mm) from finish face of floor with rear edge of cutout 20-1/2" (520mm) from back wall of compartment to allow
placement of horizontal grab bar at 33" (840mm) height across front of unit. For factory-made cutouts, location and size details
must be furnished to partition manufacturer. For hollow-core metal partitions, provide solid framing into which sheet-metal
mounting screws can be secured.
For installation with sheet-metal screws furnished, place unit firmly in partition cutout, making certain entire perimeter of fixed
flange is flush with and tight against partition sur face. Install the unit so the side that has the fixed flange flush with face of
cabinet is in a barrier-free compar tment for physically disabled persons. Secure to partition with sheet-metal screws through
four mounting holes at points indicated by an S. On other side of partition, position adjustable flange (which ser ves as an
escutcheon) so mounting holes are not inline with mounting holes in fixed flange. Make certain entire perimeter of adjustable
flange is flush with and tight against partition sur face before securing with sheet-metal screws furnished.
For through-bolting method of installation, make sure mounting holes in adjustable flange are inline with holes in fixed flange.
Using adjustable flange as template to mark locations, drill 7/32" or 1/4" (5.5 or 6.4mm) holes through partition. Provide
four binder posts and #6 (3.5mm) flat-head screws to secure unit and its adjustable flange. Obtain binder posts and screws by
ordering Bobrick Binder Post Kit No. 354-119 for partitions 1/2" (13mm) thick only or Kit No. 354-124 for partitions 3/4" to
1-1/4" (19 to 32mm) thick.
Note: Cutouts in Bobrick toilet partitions can be pre-cut for Bobrick partition-mounted accessories at factory if location and
size of cutouts are specified and order for both partitions and accessories are received together.
Designer's Note: on left side of toilet (when seated on toilet) rear edge of panel cut-out should be 32-1/2" to 34-1/2" (825 to
876mm from rear edge of panel to position toilet tisue dispensers centerline 7" to 9" (180 to 230mm) in front of leading edge of
toilet. For units on right side of toilet, rear edge of panel cut-out should be 25" to 27" (635 to 685mm) from rear edge of panel.
Cut-out locations based on toilet projecting 30" (760mm) from rear wall, and a 1/2" (13mm) gap between rear edge of panel
and rear wall
SPECIFICATION:
Partition-mounted toilet-seat-cover and toilet tissue dispenser shall be type-304 stainless steel with all-welded constr uction;
exposed surfaces shall have satin finish. Toilet tissue dispenser shall be ABS plastic. Flanges shall be drawn and beveled, onepiece, seamless construction. Unit shall mount in par tition and serve two toilet compartments. One side of unit shall mount
flush against partition of barrier-free compartment to allow clearance for grab bar across front of unit. Door shall be one-piece,
seamless construction; secured to cabinet with a full-length stainless steel piano-hinge; and equipped with two tumbler locks
keyed like other Bobrick washroom accessories. Toilet-seat-cover dispenser shall be serviced from one side only, be equipped
with a plastic sight-barrier panel, and hold 1000 paper covers. Unit shall be equipped with four theft-resistant, heavy-duty ABS
toilet tissue spindles that hold standard-core rolls up to 5-1/4" (135mm) diameter (1800 sheets). Spindles shall be removable
from cabinet when door is open; when door is closed, removal shall require a special key provided for the concealed locking
mechanism in spindles.
Partition-Mounted Toilet-Seat-Cover And Toilet Tissue Dispenser shall be Model B-3471 of Bobrick
Washroom Equipment, Inc., Clifton Park, New York; Jack son, Tennessee; Los Angeles, California; Bobrick
Washroom Equipment Company, Scarborough, Ontario; Bobrick Washroom Equipment Pty. Ltd., Australia; and
Bobrick Washroom Equipment Limited, United Kingdom.
QA010711
The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. B-3471 r1/6/11
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2011 by Bobrick Washroom Equipment, Inc.
R/A, S/C
Printed in U.S.A.
