Technical Data
COAT hOOk
b-212
wITh buMPER
Finish Face of Wall
1/4''
1-1/2''
40mm
2''
50mm
1/4''
6mm
MATERIALS:
Hook and Base — Solid cast aluminum with matte finish.
Bumper — Hard rubber secured with drive-screw. Protects wall or par tition surfaces.
INSTALLATION:
Mount unit on wall with four screws, furnished by manufacturer, at points indicated by an S. For plaster or dry wall
construction, provide concealed backing to comply with local building codes, then secure hook with screws furnished. For
other wall surfaces, provide fiber plugs or expansion shields for use with screws furnished, or provide 1/8" (3mm) toggle bolts
or expansion bolts.
1''
25mm
6mm
1-7/16''
35mm
5/32''
(4mm)
Dia.
Countersunk Holes
1-1/2''
40mm
3-3/4''
95mm
2''
50mm
1/8''
3mm
S
S
965mm to 1015mm
38'' to 40''
Recommended Mounting Height
Off Floor For Barrier-Free Design
SPECIFICATION:
Coat hook shall be constructed of solid cast aluminum with matte finish. Unit shall be equipped with hard r ubber bumper.
Coat Hook With Bumper shall be Model B-212 of Bobrick Washroom Equipment, Inc., Clifton Park, New York;
Jackson, Tennessee; Los Angeles, California; Bobrick Washroom Equipment Company, Scarborough, Ontario;
Bobrick Washroom Equipment Pty. Ltd., Australia; and Bobrick Washroom Limited, United Kingdom.
The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. Revised 5/06 Printed in U.S.A.
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2006 by Bobrick Washroom Equipment, Inc.
