BN Thermic FST2-EX User guide

This product conforms to EU Directive 2002/96/EC.
This appliance bears the symbol of the crossed waste bin. This indicates that, at the end of its useful life, it must not be disposed of as
domestic waste, but must be taken to a collection centre for waste electrical and electronic equipment. It is the user's responsibility to
dispose of this appliance through the appropriate channels. Failure to do so may incur penalties established by laws governing
waste disposal.

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without
prior notice.

BN Thermic Ltd,

34 Stephenson Way,

Crawley, RH10 1TN

Tel: [phone]

Email: [e-mail]

Web: www.bnthermic.co.uk

Thank you for purchasing a BN Thermic product. Manufactured to a high standard this product will, if installed and used according to these
instructions, give you years of trouble free performance.

1. SAFETY INSTRUCTIONS

1 . 1 ELECTRICAL SAFETY



WARNING!

It is the responsibility of the Installer, owner and operator to read, understand and comply with the following:

1.1.1 All electrical wiring must be carried out by a fully qualified Electrician in accordance with the current IEE wiring regulations.

1.1.2 An isolator having a contact separation of at least 3mm on all poles must be incorporated in the fixed wiring as a means of fully
disconnecting the mains supply.

1.1.3 The Circuit should also be protected by a suitably rated fuse or MCB.

1.1.2 The Thermostat must be earthed by means of the earth screw in the metal back-plate.

1.1.3 The electrical supply must be disconnected before fitting the unit to the back-plate or removing the cover.

1.1.4 MAXIMUM LOAD MUST NOT EXCEED 20 AMPS

2. INSTALATION INSTRUCTIONS

Location

The FST2-IN should be wall-mounted at approximately 1.5m above floor level. Do not position above a radiator or in direct sunlight.

Installation

The metal back-plate can be fitted to a wall or to a single gang back-box and should be earthed using the screw on the plate.

1. Loosen the cover retaining screws and remove the cover.

2. Remove the Knob by gently pulling towards you.

3. Swing the terminal cover open to reveal the electrical terminals.

4. Pull the wires through the back of the thermostat and secure the thermostat to the back-plate using the two captive screws.

5. Electrical connections should be made in accordance to the relevant wiring diagram below and to the current I.E.E regulations.

6. Swing the terminal cover back into position and replace the knob then the main cover, tightening the retaining screws.

7. The desired temperature should be set by rotating the dial to the required position.

3. WIRING DIAGRAMS

Please ensure you follow the correct diagram for the correct load

INSTRUCTIONS FOR:-

INDOOR FROST THERMOSTAT
FST2-IN

PLEASE READ THESE INSTRUCTIONS, NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS,

AND CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.

FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.

IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Your BN Thermic product is guaranteed for one year from date of purchase. We

will repair or replace at our discretion any part found to be defective. We cannot assume any
consequential liability. This guarantee in no way prejudices your rights under common law and
is offered as an addition to consumer liability rights.

FST2-ININS-v01
