b mobile AX660 Users Manual

USER MANUAL

Table of Contents

1.Foreword ................................................................................. 48

2.Getting to know your touch phone.............................................52

3.Starting up the device ................................................................54

4.Introduce the basic phone function ...........................................58

5.Technical Specifications ............................................................66

6.FCC Cautions…………. ............................................................67

AX660

1. Foreword

Safety

In order to ensure the phone is used safely and correctly, please read the precautions below carefully before use.

1.1 General precaution

•Your phone is only suitable for the battery and charger approved by our company or else it may cause the battery to leak, overheat, explode or even catch fire.

•Do not knock, vibrate or throw the phone heavily to avoid malfunction, fire, overheating, explosion or fire.

•If there are abnormal phenomena, like temperature rising, color change or distortion during the usage, charging or storage of the battery, please stop using it and replace it with a new battery.

•It may burn the skin if liquid in the battery leaks onto skin or clothes. If this happens please flush with plenty of clean water immediately and go to a hospital at once.

•Please keep the battery away from fire to avoid fire and explosion if the battery leaks or emits a strange smell.

•Do not place expose the battery to moisture or it may cause overheating, fumes and corrosion.

•Do not use or place the battery under direct sunlight, or in hot places, it may cause leakage and overheating, thus reducing performance and shortening the lifespan.

•Do not charge the battery for over 24 hours continuously.

•Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can cause hearing loss.

1.2 Precaution for the use of charger

•Do not cause short circuit to the charger, or it may cause electric shock, fumes and damage to the charger.

•Do not use the charger if the power wire is broken, or it may cause fire and electric shock.

•Please remove accumulated dust on the power plug.

•Do not put water containers next to the power supply to avoid overheating, fire, electric shock and malfunction in case they come into contact.

•Do not disassemble or tamper with the charger or it may cause personal injury, electric shock, fire and the damage of the charger.

•Do not use the charger in places of high humidity, like bathrooms, or it may cause electric shock, fire and damage of charger.

•Do not touch the charger, power cord or power plug with wet hands or it can cause electric

shock.

•Do not put heavy objects on the power cord or change the power cord or it may cause electric shock and fire.

•Please unplug the power socket before cleaning and maintenance.

•Please hold the charger to unplug the socket as pulling the power cord may damage the power wire and cause electric shock and fire.

1.3 Cleaning and maintenance

•As the phone, battery and charger are not waterproof, do not use them in places of high humidity and avoid them being wet by rain.

•Please clean the battery and charger with a soft dry cloth.

•Never use alcohol, thinner or solutions, like benzene, to wipe the phone.

•Dirty sockets can cause poor contact and power down, and even make recharging unavailable. So, please clean them periodically.

1.4 Common Precaution

Mobile Phone:

•Please use the phone in an en vironment with temperature between -20Ԩ- 45Ԩand humidit y of <75%.

•Please use the phone far away from regular telephones, TV sets, radio sets and office

automation equipment, to avoid affecting the normal use of these equipments and mobile phone. Battery:

•Store the battery in cool and ventilated place without direct sunlight.

•The battery has a limited lifespan. The usage of battery will be shortened progressively due to frequent charging. Once the battery is out of use, it means that its lifespan has ended, and you will need to replace it with an approved new battery.

•Do not dispose of old batteries as household waste. Give them to specified disposal places and follow any stipulated instructions for disposal. CAUTION:RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCYIONS. Charger:

•Do not charge under following conditions:

-- places with direct sunlight

-- places with ambient temperature less than 0Ԩ or over 40Ԩ, wet or dusty places with strong vibrations (it may cause malfunction)

-- places near electrical appliances (it may affect the image and sound) like TV set, radio, etc

-- Adapter shall be installed near the equipment and shall be easily accessible.The plug considered as disconnect device of adapter

2. Getting know your phone

1）Front Camera

2) Proximity Sensor

3) Earpiece

4) Volume Button

5) LCD Display

6) Settings – Home – Back Buttons

7) Microphone

8) Loudspeaker

9) Turn on / off Button

10) Back Camera

11) USB / Charger Connector

12) Flash

13) Headphones Connector (Jack 3.5)

3. Starting your device

•Make sure your device is turned off.

•Firmly hold the device with the front panel facing down.

•Slide your finger into the groove at the top of the phone and gently pull open the back cover.

To install the SIM card

•Remove the battery if it is installed.

•Locate the SIM card slot, and then insert the SIM card with it s go ld contacts facing down and its cut-off corner facing out of the card slot as shown in the diagram.

•Slide the SIM card completely into the slot.

Note: The phone can support two SIM cards. The cardwill support 2G card.

To install a memory card

To have additional storage for your images, videos, music and files, you can purchase a memory card and install it in your device. Locate the memory card slot on the panel as shown on the image. Insert the memory card into the slot with its gold contacts facing down until it clicks into place

To install the battery

1. Align the battery’s exposed copper contacts with the battery connectors at the bottom part of the battery compartment.

2. Insert the contacts side of the battery first and then gently push the battery into place. Replace the back cover. Charging the Battery New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles. Note: Only the AC adapter and USB sync cable provided with your device must be used to charge the dev ice. Connect the USB connector of the AC adapter to the sync connector on your device, and then plug in the AC adapter to an electrical outlet to start charging the battery. As the battery is being charged while the device is on, a charging icon appears in the title bar of the Home screen. After the battery has been fully charged, a full ba ttery icon a ppears in the title bar of the Home screen.

Warning:

• Do not remove the battery from the device while you are charging it using the AC or car adapter.

• As a safety precaution, the battery stops charging before it overheats.

Power on/off

To power off your phone, press & hold POWER. On release, the Phone options menu opens. Select ‘Power off’ and confirm. To power on again, press & hold power
