blupura COOL1 Use & Maintenance Manual

1

6

0

4

5

5

1

7

0

5

E

N

Before Install or use the product read to the precautions and
general recommendations inside.

COOL1

U

s

e

&

M

a

i

n

t

e

n

a

n

c

e

M

a

n

u

a

l

3

Precautions and general recommendations

This appliance is intended to be used in household and similar
applications such. Appliance for internal use only. Place the unit
away from water jets.

Always connect the water cooler to a water main that supplies
drinking water only.

Before each installation, the unit must be sanitized by an
authorized technician.

After installation, ensure that the unit is not resting on the power
cable.

Check that the unit is level and that it is resting on a floor with
sufficient load-bearing capacity, in an environment that is suitable for its dimensions and its use.

Before any maintenance or cleaning operation is carried out, remove the plug from the socket or
disconnect the power supply.

Ensure that the product is not sited close to sources of heat.

To guarantee adequate ventilation, leave at least 10 cm of space around the unit.

Install the product in a clean, dry, well-ventilated environment. The product is designed to
function in environments with a temperature range of between 5°C and 32°C - Climate Class N.

Take care not to damage the cooling fluid circuit: it is filled with R290, which is a highly flammable
gas. It is essential to ensure that the tubes of the refrigerant circuit are not damaged.

Ensure that it is possible to disconnect the power supply either by removing the plug or via a two­pole circuit-breaker, with an opening distance of the contacts that allows complete disconnection
in the conditions of overvoltage category III, placed upstream of the plug.

Check that the voltage shown on the serial number plate corresponds to the voltage being
supplied at the installation site.

The unit must not be cleaned with a water jet. Do not position other electrical equipment in the
immediate vicinity of the water cooler.

Turn off the main water inlet tap if the unit is not to be used for a long period.

Keep the areas surrounding the unit dry to avoid the risk of people slipping.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified person in order to avoid a hazard. Do not use extension leads or
adapters.

This appliance is intended to be used by persons (including children aged from 8 years)
with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
provided that they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance. The appliance is only to be installed in locations
where it can be overseen by trained personnel.

The Appliance shall be protected by a ground-fault circuit interrupter.

This equipment is to be installed in compliance with the local plumbing codes. Water
pipe connections and fixtures directly connected to a potable water supply shall be sized,
installed, and maintained in accordance with federal, state, and local codes.

This publication is based on information available when approved for printing. Continuing design
refinements could cause changes that may not be included in this publication.

4

Index

• BEFORE INSTALLING THE WATER COOLER 5

• RECOMMENDATIONS FOR SAFEGUARDING THE ENVIRONMENT 6

• CERTIFIED 7

• ASSOCIATIONS 8

• INTERNATIONAL AWARDS 8

• DESCRIPTION OF THE UNIT 9

• KEYPAD DESCRIPTION 12

• TECHNICAL FEATURES 13

• INSTALLATION 16

• INSTALLATION OF THE CO2 CYLINDER (FIZZ MODEL) 20

• HANDLING THE GAS CYLINDERS 21

• SANITIZATION – NOTES 24

• ORDINARY MAINTENANCE 25

• SERVICE HISTORY 26

• WARRANTY CONDITIONS 27

5

Before installing the water cooler

Congratulations for choosing a BLUPURA product.

We have designed and manufactured this product with great care to ensure that it
will dispense water of the highest quality.

In order to get the most out of your water cooler, please read the instructions in
this manual and retain the manual for future reference.

6

Recommendations for safeguarding the environment

Packaging materials

The packaging materials are 100% recyclable.

Please follow the local guidelines on waste
disposal. For safety reasons keep the packaging
material out of the reach and sight of children.

Scrappage

The water cooler is made using recyclable material.

This unit is marked in compliance with European Directive 2012/19/UE
on Waste Electrical and Electronic Equipment (WEEE). By ensuring that
the product is scrapped correctly, you are helping to prevent potential

negative consequences for the environment and for health. The symbol
on the unit indicates that the product should not be treated as domestic waste
but should be taken to a dedicated recycling centre for electrical and electronic
equipment. Immediately prior to scrapping, cut off the power cable.

For more information on the treatment, recovery and recycling of this product,
please contact the appropriate local office, the waste disposal service or the
reseller from which the product was purchased.

Information on the natural, eco-friendly refrigerant gas used in
this cooler

This product contains no CFCs or HFCs, which contribute to global warming.

Indeed, it is the first water cooler on the market to use natural refrigerant.

The refrigerating system is filled with HC R290 – Propane: a natural gas that does
not contribute to global warming and that, thanks to its specific characteristics,
allows for substantial energy savings to be made.

7

Certified

See official list

Materials compliant for contact with drinking water

This unit is intended for the dispensing of drinking water, and so the materials
that enter into direct contact with water meet the criteria for food-grade
components pursuant to the current legislation. In addition, the unit is
manufactured in compliance with Italian Ministerial Decrees 174 of 06/04/2004
and 25 of 07/02/2012.

Electrical safety

This water cooler is designed, manufactured and marketed in compliance with:

• the safety objectives of the Machinery Directive 2006/42/CE;

• the protection requirements of the Electromagnetic Compatibility Directive
2014/30/EU.

The electrical safety of the product is ensured only when it is properly connected
to an efficient, legally compliant grounding circuit.

D.M. 174

1

0

0

%

M

A

D

E

I

N

I

T

A

L

Y

C

E

R

T

I

F

I

C

A

T

E

I

T

P

I

UNI EN ISO 9001:2015

UNI EN ISO 14001:2015

ANSI/UL 399

8

Associations

International Awards

2015 - BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2015, ROME

2015 - BEST ENVIRONMENTAL PRACTICE/GREEN INITIATIVE

EUROPEAN AQUA AWARDS 2015, ROME

2014 - BEST PROMOTION OF HEALTH AND HYDRATION

EUROPEAN AQUA AWARDS 2014, BUDAPEST

2013 - BEST PRODUCT INNOVATION
EUROPEAN AQUA AWARDS 2013, BERLIN

2012 - BEST ENVIRONMENTALLY FRIENDLY PRACTICE

EUROPEAN AQUA AWARDS 2012, ISTANBUL

2011 - BEST PRODUCT DESIGN/INNOVATION
EUROPEAN AQUA AWARDS 2011, ODESSA

2010 - BEST ENVIRONMENTALLY FRIENDLY PRACTICE

EUROPEAN AQUA AWARD 2010, PRAGUE

9

Description of the unit

COOL1 - The best solution for canteens, self service areas, schools, gyms.

The main features of the unit are as follows:

• Refrigerant system with natural gas.

• Modern design and and main body in stainless
steel.

• High-insulation ice bank, with a high output of cold,

still and sparkling water, available in versions 150 lt/hr and

80 lt/hr.

• 3 dispensing options (FIZZ model): cold water +
room-temperature water + cold sparkling water.

• Professional stainless-steel carbonator.

• Electromechanical dispensing buttons.

• Front opening and internal space for UV IN filters
and CO2 cylinder.

10

Frontal view

1

4

3

2

1

7

6

5

2

3

4

5

6

7

Cold sparkling water dispensing
nozzle (detachable)

Room temperature water
dispensing nozzle (detachable)

Drip tray with grid

Cold water dispensing nozzle
(detachable)

Dispensing buttons

Front panel security lock

Adjustable feet

11

Rear view

3

2

1

6

5

4

1

4

5

6

3

Ice bank overflow waste pipe
(Ø8mm)

Power button

Adjustable thermostat

Drinkable water inlet pipe joint
(Ø8mm)

Drip tray waste pipe (Ø40mm)

2

IEC power cord plug

12

P. 3

P. 2

P. 5 P. 7

P. 4

P. 6

The water cooler features a mechanical button keypad.

FUNCTIONS OF THE BUTTONS:

- SPARKLING WATER PRESSURE-ACTIVATED DISPENSING button (P.3)

- ROOM-TEMPERATURE WATER PRESSURE-ACTIVATED DISPENSING button
(P.5)

- COLD WATER PRESSURE-ACTIVATED DISPENSING button (P.7)

The water is dispensed while pressure is being applied to the button.

- SPARKLING WATER START-STOP DISPENSING button (P.2)

- ROOM-TEMPERATURE WATER START-STOP DISPENSING button (P.4)

- COLD WATER START-STOP DISPENSING button (P.6)

Pressing the button causes the water to be dispensed. Pressing the same button
again stops the dispensing of the water.

Keypad description

13

Technical Features – Technical Data Plate

17 Year of manufacture

04 Month of manufacture

03030 Serial number

[mod. Cool1]

14

Technical Features - dimensions (mm)

3,150in

80mm

3,150in

80mm

12,480in

317mm

40,224in

1022mm

16,449in

418mm

56,673in

1440mm

18,866in

479mm

2,926in

74mm

4,598in
117mm

11,685in

297mm

16,864in

428mm

Water Inlet

27,547in

700mm

Drip Tray Drainage

31,418in

798mm

Ice Bank Drain

10,894in

277mm

Power Cord IEC

31,421in

798mm

1,575in

40mm

[mod. Cool1]

15

Technical data
sheet

Cool1

150 lt

Cool1

80 lt

Cooling capacity

150 lt/h 80 lt/h

Max continuous
dispensing

80 lt 45 lt

Water temperature

5°-12°C *

Cooling system

Dual-coil ice bank Single-coil ice bank

Tank capacity

18 lt 14 lt

Ice bank

8 kg 5 kg

Pump

Professional rotary
carbonation pump

Professional membrane

carbonation pump

Power supply

Single-phase 230V-50Hz

Power consumption

920 W - 4 A 300W - 1,3 A

Compressor power

1/3 HP 1/3 HP

Cooling

Forced ventilation

Refrigerant gas

Natural gas HC R290

Ambient cooling
temperature

Min 5°C - Max 35°C

Dimensions LxDxH (mm)

479 x 428 x 1440

Packaging dimensions (mm)

520 x 474 x 1562

Net weight (kg)

49 42

Gross weight (kg)

55 48

* rated at a room temp. of 25°C and inlet water temp. of 20°C

For the technical data sheet of other models, examine the technical data plate attached in the unit.

16

Installation

Unpacking

Cut the packing tab and pull up the
cardboard box and the inner caps.

Carefully check that the watercooler has
not been damaged during transport. Any
signs of damage must be reported to the
Agent immediately.

If the watercooler has been transported in
a horizontal or inclined position, a wait of
8 hours is needed before turning it on so
that the refrigeration circuit can function
perfectly.

Ensure that a qualified technician
connects it to the electric supply following
the manufacturer’s instructions and
according to the local safety regulations

The end user is not permitted to access
the internal service parts of the unit.
Only technical personnel should carry
out operations of this nature.

17

Fig. 17.1 - Mod. 150 lt

1

Siting the unit

Wear safety gloves when handling the unit.
The unit must be handled by two people.

Site the unit away from sources of heat.

The machine is equipped with 4 adjustable
feet. Do not place on inclined surfaces.

Leave at least 10 cm around the unit to
allow for aeration.

SANITIZE the machine as described in the
paragraph on page 24.

Filling the ice bank

Open the front panel using the key
supplied.

Pour drinking water into the ice-bank using
the hole (1).

The ice-bank is full when water flows out of
the drain tube positioned on the back of
the machine (2)

Once you have filled the ice bank, avoid
moving the unit.

If you have to move the unit, remember to
empty the ice bank first.

Fig. 17.2 - Mod. 80 lt

Fig. 17.3

1

18

Fig. 18.1

1

2

3

Connection to the mains water
supply

Check that the mains pressure is between
1 bar and 3,5 bar. To enhance the quality
of the sparkling water dispensed, an
incoming flow rate in excess of 3,5 lt/min is
recommended.

Connect incoming water tube Ø8 mm (2)
to the drinking-water main, ideally with a
tap upstream of the unit.

The unit is equipped with a safety valve
and a non-return valve.

Connect waste pipes (3) and (1) to a
waste water manifold. Once the pipes are
attached, turn on the tap. Ensure there are
no leaks.

Before drinking the water from the system,
perform a thorough rinse of the circuit by
dispensing water from each product line.

CAUTION!

To connect the water cooler to the mains
water supply, you will need to use a new set
of connectors (joints, gaskets and pipes).

Do not use a set of connectors that has
already been used elsewhere.

The water pressure entering the unit must
be between a minimum of 1,0 bar (0,10
MPa) and a maximum of 3,5 bar (0,35 MPa)

19

Fig. 19.1

1

3

2

Electrical connection

The connections must comply with local
regulations. The grounding of the unit is
a legal requirement.

Connect the power supply cable to the
IEC plug (1) and to the electric socket.

Turn the unit on by selecting the “I”
position on the main on/off rocker switch
(2). The ice-bank pump, compressor
and fan are now activated. On the
FIZZ models, the pump for filling the
carbonator with water is also activated.

Press the “Sparkling Water” button in
order to release any air in the circuit and
to allow the pump to fill the carbonator
with water.

After around 1-2 minutes, the sparkling
water pump stops.

Thermostat

The thermostat (3) is set in the maximum
position to control the ice bank.

If you want to avoid the formation of ice
in the bank, turn the thermostat screw at
least 1/4” anti-clockwise.

In the case of freezing of the water
circuit, turn off the unit and keep it off for
at least 12 hours.

20

Fig. 20.2

Once the unit is connected to the mains
water and electricity, and the ice-bank
tank has been filled, you can install the
E290 food-grade carbon dioxide (CO2)
cylinder.

The machine is not equipped with a
CO2 pressure reducer or CO2 cylinder
(optional).

Inside the machine, you can install
cylinders with a maximum diameter of
160 mm and a maximum height of 780
mm – standard 5 kg or 6 kg cylinders are
generally within these dimensions. The
unit is equipped with a tear tape for the
safety fixing of the cylinder.

To increase or decrease the level of
carbonation of the water, you need to
adjust the screw (1). Turning it clockwise
increases the level of carbonation. We
recommend that you do not exceed 4
bar of pressure (2).

To reduce the carbonation level, turn
the screw anti-clockwise. The level will
decrease as soon as sparkling water is
dispensed.

To achieve a good level of carbonation,
you need to wait until the water is
sufficiently cold – i.e. at least one hour
after installation.

Installation of the CO2 cylinder (FIZZ model)

1

2

Fig. 20.1

21

* Replacement of the CO2 cylinder. All of the operations
must be carried out exclusively by qualified technical
personnel. To view the video tutorial, scan the QR code.

* Suggestions for optimal carbonation. All of the operations
must be carried out exclusively by qualified technical
personnel. To view the video tutorial, scan the QR code.

Handling the gas cylinders

All of the cylinders must be fitted
with a valve protector cap, which
must be on tight at all times when
the cylinder is not in use.

The cylinders must be handled
with care. It is essential to avoid:
clashes with other cylinders or
surfaces; dropping the cylinders;
or subjecting them to mechanical
stress. All of the above may
compromise their integrity and
resistance.

The cylinders must not be lifted
by the cap, or dragged, rolled or
slid along the floor. Even if only
being moved for short distances,
an appropriate hand cart or other
suitable means of transport should
be used.

Do not use magnetic lifters or slings with ropes or chains to lift the cylinders.
If the cylinders are to be lifted with cranes, hoists or fork-lift trucks, ensure that
appropriate cages, metal baskets or pallets are used.

The cylinders must not be moved or handled with greasy hands or gloves. This is
particularly important in relation to cylinders containing oxidising gases.

Cap

Valve connection

Shoulder

Markings

Body

22

Filtration (optional)

EVERPURE 4C FILTER

On request, the unit can be fitted with an Everpure 4C filter.

MAIN FEATURES

This filter removes the odour and flavour of chlorine and
other contaminants that can alter the taste of the water.
The Precoat microfiltration system removes impurities and
particles with dimensions of 0.5 microns and above.

It also reduces the levels of any contaminants such
as asbestos fibres and micro-organisms such as
Cryptosporidium and Giardia.

It protects gaskets, pumps, tubes and valves against
blockages, corrosion and abrasions.

Approved by the Italian Ministry of Health and the Water
Regulations Advisory Scheme (UK), it is certified compliant
with the NSF/ANSI standards 42 and 53.

The cartridge should be changed every 6 MONTHS.

Its maximum capacity is 3000 gal.

* Filter replacement and sanitization. All of the
operations must be carried out exclusively by qualified
technical personnel. To view the video tutorial, scan the
QR code.

23

Filtration (optional)

UV sterilizing filter

Alongside the Everpure 4C filter, it is also
possible to have your water cooler fitted with a
UV-C (λ=254 nm) sterilizing filter.

The UV-C light emitted by the special 12W
mercury vapour lamp is lethal for all micro­organisms (bacteria, viruses, mould, algae,
etc.); for this reason, water treated with the
UV-C sterilizer will be microbiologically pure.

TECHNICAL PROFILE
Material AISI 304
Power rating 110V– 60Hz
Power consumption 20Wh
Max water capacity 1.30 gal/min
Minimum pressure 0,5 bar
Maximum pressure 9 bar
Radiation > 30000 μWs/cm²
Green LED ON = lamp lit
Maximum capacity of the lamp 9000 h (max 12

months)

The UV sterilizer is made entirely in Italy and
complies with Italian and European quality
and safety guidelines.

CAUTION!

The light emitted by the ultra­violet lamp may cause serious
burns to the eyes and skin.

The replacement can only
be performed by qualified
personnel.

* Replacement of the external lamp. All of the
operations must be carried out exclusively by qualified
technical personnel. To view the video tutorial, scan the
QR code.

* Replacement of the internal lamp. All of the
operations must be carried out exclusively by qualified
technical personnel. To view the video tutorial, scan the
QR code.

24

Sanitization – Notes

The unit should be sanitized at first
installation, or when the hydraulic
components are being replaced, or when
the filter is being changed, or in any case
at least once a year.

This operation must be carried out by
the BLUPURA Reseller or by qualified
technical personnel who have
completed specific training courses on
hygiene and sanitization.

To sanitize the unit, we recommend the
use of hydrogen peroxide (oxygenated
water), 5% diluted in drinking water.

* Filter replacement and sanitization. All of the
operations must be carried out exclusively by qualified
technical personnel. To view the video tutorial, scan the
QR code.

25

Ordinary maintenance

External cleaning of the unit

Cleaning and user maintenance shall not be made by children without
supervision. To clean the unit, use the BLUSTEEL ULTRAMICROFIBRA cloth (code

190094), which is specifically designed for our products. Alternatively, you can use
a soft cloth and a dedicated product for the cleaning of stainless steel. To remove
limescale, use DAILY CLEANER SPRAY (cod. 190109) and rinse after use.

DO NOT USE alcohol- or solvent-based products or excessively acidic solvents
that can ruin the surface of the steel.

Cleaning the drip tray

When it is necessary to clean the drip tray, use a diluted limescale cleaner (citric
acid or similar).

The drip tray can also be washed in the dishwasher.

Cleaning the dispensing nozzles

On a daily basis, spray a diluted hydrogen peroxide solution (e.g. Cooler Clean)
onto the nozzles.

DO NOT USE a jet of water to clean the unit, or detergents with abrasives. Light
scratches can be removed with CREAMY CLEANER (cod. 190104).

26

Service history

Installation

Technician Date Notes Signature

Maintenance

Technician Date Notes Signature

27

160455 - Rev. 00 - 15/01/2018 - 20:20

Warranty conditions

This unit is guaranteed by BLUPURA for a period of two years from the date of
purchase.

The warranty entitles the owner to the free-of-charge repair of the unit by our
company or the free-of-charge replacement of any parts that have been shown to
have manufacturing defects.

The warranty does not include normal wear-and-tear to the components, or any
damage caused to the components due to negligent or improper use, or due to
a non-standard installation.

The warranty shall not be applicable if the unit has been tampered with or if
repairs have been carried out by unauthorized persons.

For the conditions not specified here, please refer to the Blupura Srl WARRANTY
CONDITIONS.

For any returns or repairs, please contact CUSTOMER SERVICE and request the
RMA for returning the goods.

Blupura srl

- Registered office -

Via F.lli Brancondi, 56

60025 Loreto (AN) Italy

- Headquarters -

Via Erideo Marinucci, 2/4

62019 Recanati (MC) Italy

Tel [phone]

Fax [phone]

[e-mail]
www.blupura.com
