Page 1

Model: BS029MS

Bluetooth Stereo System

with Audio Input for MP3 Players

For technical assistance or troubleshooting please

PLEASE READ THIS USER MANUAL COMPLETELY BEFORE

OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR

FUTURE REFERENCE.

call 1-855-719-8324 or visit www.sibrandssupport.com

Page 2

IMPORTANT SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS

WARNINGS

CAUTION

DO NOT OPEN

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampli that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade and/or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the o

10) Protect the POWER cord from being walked on or pinch particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sol d with the apparatus. When a cart is used, use caution when

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as POWER-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the ap dropped.

15) This appliance shall not be exposed to dripping or splashing water and that no object filled with liquid such as vases shall be placed on the apparatus.

16) CAUTION: Visible and Invisible Laser Radiation when open and interlock defeated.

DO NOT STARE INTO BEAM.

17) Rating label is located at the bottom o

18) "CAUTION" mark is also located at the bottom of enclosure.

bsolete outlet.

moving the cart/apparatus combination to avoid injury from tip -over.

paratus has been exposed to rain

f enclosure.

or moisture, does not operate normally, or has been

fiers)

• Caution: use of any controls, adjustments, or procedures other than those specified herein may result in hazardous

radiation exposure.

• Caution: danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• To prevent fire or shock hazard, do not use this plug with an extension cord, receptacle or other outlet unless the

blades can be fully inserted to

• Warning: to reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

• Warning: the batteries shall not be exposed to excessive heat from direct sunlight, fire, or other heat sources.

prevent blade exposure.

THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS

INTENDED TO ALERT THE

USER TO THE PRESENCE OF

NON-INSULATED "DANGEROUS

VOLTAGE" WITHIN THE

PRODUCT'S ENCLOSURE THAT

MAY BE OF SUFFICIENT

MAGNITUDE TO CONSTITUTE A

RISK OF ELECTRIC SHOCK TO

PERSONS.

WARNING: TO REDUCE THE

RISK OF ELECTRIC SHOCK, DO

NOT REMOVE THE FRONT OR

REAR COVER. NO USER

SERVICEABLE PARTS ARE

INSIDE. REFER SE

QUALIFIED SERVICE

PERSONNEL.

RVICING TO

THE EXCLAMATION POINT

WITHIN AN EQUILATERAL

TRIANGLE IS INTENDED TO

ALERT THE USER TO THE

PRESENCE OF IMPORTANT

OPERATING AND MAINTENANCE

(SERVICING) INSTRUCTIONS IN

THE LITERATURE

ACCOMPANYING THE

APPLIANCE.

Page 3

FCC WARNINGS

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

NOTE t to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in radio or television reception, which can to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment int

• Consult the dealer or an experienced radio/TV technician for help.

o an outlet on a circuit different from that to which the receiver is connected.

a particular installation. If this equipment does cause harmful interference to

be determined by turning the equipment off and on, the user is encouraged to try

Page 4

OVERVIEW OF THE SYSTEM CONTROLS

1. POWER button

2. POWER Indicator Light

3. Volume Control Knob

4. FUNCTION button

5. PLAY / PAUSE button

6. STOP button

7. NEXT / F.FWD button

8. PREV / F.REV button

9. PROGRAM button

10. REPEAT button

11. AM / FM button

12. Radio Tuning Knob

13. TIME SET button

14. HOUR button

15. MINUTE button

TOP

REMOTE

16. DISPLAY button

17. ALARM SET button

18. MUSIC / BUZZER button

19. ALARM ON / OFF button

20. DIMMER button

21. DBBS button

22. DBBS Indicator Light

23. Remote Sensor

24. CD Door

25. OPEN / CLOSE button

26. PLAY / PAUSE button (REMOTE)

27. NEXT / F.FWD button (REMOTE)

28. PREV / F.REV button (REMOTE)

29. STOP button (REMOTE)

30. REPEAT button (REMOTE)

Page 5

BATTERY COVER

Battery Installation for the Power Backup - Requires 2 AAA Batteries - (Not Included)

In the case of a Power failure, the Power backup will keep the Clock & Alarm times accurate

until the main power has been restored.

NOTE: The product will operate properly with or without batteries except in the case of power loss.

• Open the Battery Cover on the bottom of the unit.

• Insert 2 AAA batteries (not included) following the

• Close the Battery cover.

IMPORTANT:

• Be sure that the batteries are installed correctly.

• Wrong polarity (+ or -) may damage the unit and void the warranty.

• For best performance and longer operating time, we recommend using good quality S

Alkaline type batteries.

CAUTION

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbo

• If the unit is not going to be used for an extended period of time, remove the batteries from

the unit.

• Old or leaking batteries can cause damage to the unit and may void the warranty.

• Do not dispose of batteries in fire as batteri

n-zinc) or rechargeable (nickel-cadmium) batteries.

es may explode or leak.

polarity as indicated in the compartment.

+ / -

IMPORTANT:

• This unit operates on AC 120V~ 60Hz.

Do not attempt to operate this unit on any other power source. You could cause damage

•

to the unit and void your warranty. Please be sure the power outlet you plug this unit into is working and receives constant

•

unswitched power.

uper

Page 6

POWER

1. Plug the attached AC power cord into a 120V AC~ 60Hz wall outlet.

2. Press the POWER button (1) once to turn the unit ON. The Power Indicator Light (2) will turn ON. Press the POWER button (1) again to turn the unit OFF.

VOLUME

Adjust the Volume Control Knob (3) to the desired volume level.

PAIRING A BLUETOOTH DEVICE

Before using a Bluetooth device you must first Pair the device with the BS029MS.

1. Turn your Bluetooth device OFF entirely and then turn it back ON to refresh the device’s Bluetooth Memory.

2. Find the Bluetooth menu on your device and make sure the Bluetooth function is turned ON.

(refer to your device’s user manual for instructions on finding the Bluetooth menu)

3. Press the FUNCTION button (4) repeatedly until “BT” appears on the LCD screen.

4. On your device perform a Bluetooth “device discovery” to add the BS029MS as a new device.

5. When the BS029MS is discovered your device will display “BS029MS” in the Bluetooth menu.

6. If your Bluetooth device asks for a password, enter “0000” and the device will now pair with the

BS029MS and be ready to use. NOTE: the BS029MS will make a chime when your device has successfully paired.

7. If supported by your device, set the BS029MS as “authorized” in the Bluetooth menu.

LISTENING TO A BLUETOOTH DEVICE

After successfully pairing your Bluetooth device with the BS029MS, you can begin playing music simply by choosing the song you wish to hear on your device’s menu system (refer to your device’s user manual for instruction on playing music).

To Play or Pause music press the PLAY / PAUSE button (5) or (26) To Skip to the Next song press the NEXT / F.FWD button (7) or (27) To Skip to the Previous song press the PREV / F.REV button (8) or (28)

NOTE: All Playback controls (Play, Pause, Skip + / -, etc.) can also be controlled directly on your Bluetooth device.

Page 7

PLAYING A CD

1. Press the FUNCTION button (4) repeatedly until “CD” appears on the LCD screen.

2. Press the OPEN / CLOSE button (25) to open the CD door.

3. Insert a CD with the label facing Up.

4. Gently Close the CD door.

5. Press the PLAY / PAUSE button (5) or (26) to start CD playback from the first track.

6. Press the PLAY / PAUSE button (5) or (26) again to momentarily pause playback.

7. To Stop playback, press the STOP button (6) or (29).

SKIPPING TRACKS

• During CD play, press the PREV / F.REV button (8) or (28) to move to the previous

track Press the NEXT / F.FWD button (7) or (27) to move to the next track.

•

SEARCHING TRACKS

• During CD play press and hold the PREV / F.REV button (8) or (28) to scan Fast

Reverse through the current track.

•

Press and hold the NEXT / F.FWD button (7) or (27) to scan Fast Forward through the current track

PROGRAMMED PLAYBACK

1. Up to 20 tracks can be programmed to play in any desired sequence.

Press the PROGRAM button (9) until "PROG" flashes in display.

Press the NEXT / F.FWD button (7) or (27) or the PREV / F.REV button (8) or (28) to

select a desired track to be programmed. Press the PROGRAM button (9) to program the track.

Repeat steps 3 & 4 to program more tracks.

Press the PLAY / PAUSE button (5) or (26) to start playing.

To cancel program play, press the STOP button (6) or (29) twice.

REPEAT PLAY

• To Repeat a Single Track

o Press the REPEAT button (10) or (30) while the track you want to repeat is

playing. "REP 1" is shown in display.

o To repeat another track, press the PREV / F.REV button (8) or (28), or the

NEXT / F.FWD button (7) or (27) button.

o To cancel repeat play, press the REPEAT button (10) or (30) twice.

• To Repeat All Tracks o Press the REPEAT button (10) or (30) twice during play. "REP ALL"

appear in the display.

o All tracks will be played through in sequence and then the sequence will be

repeated continuously.

o To cancel repeat play, press the REPEAT button (10) or (30) once.

will

Page 8

PLAYING A NON-BLUETOOTH iPod, MP3 PLAYER, OR OTHER DEVICE

1. Connect a 3.5mm stereo audio cable from the headphone jack or other audio output on

your Non-Bluetooth device into the AUX INPUT on the rear of the BS029MS.

2. Adjust the volume control on the connected device to an acceptable level.

3. Use the controls of the connected device to control audio playback.

NOTE: When a 3.5mm cable is connected, the Bluetooth, CD, and Radio functions will be

automatically disconnected. To resume CD or Radio play, unplug the audio cable from the AUX Input on the player r

ear.

LISTEN TO AM/FM STEREO RADIO

1. Press the FUNCTION button (4) repeatedly to select the RADIO function.

2. Press the AM/FM button (11) to select AM or FM.

3. Turn the RADIO TUNING KNOB (12) to select the desired Radio station.

While in Radio Mode, the LCD Display will indicate the current station frequency.

To view the current time, press the DISPLAY button (16) the time will be shown on the LCD display and will disappear automatically.

NOTE: You cannot set the time or the alarm while the Radio is in use.

ANTENNAS

The AM & FM antennas are built-in to the cabinet of this player. To improve reception of radio stations simply move the entire player to another location until reception improves.

SETTING THE CLOCK

1. Turn the unit power OFF before setting the time.

2. To set the clock, press and hold the TIME SET button (13).

3. While holding the TIME SET button (13) press the HOUR (14) or the MINUTE (15) buttons respectively until the correct time is displayed. Release the TIME SET button (13) when the correct time appears in the LCD display.

SETTING THE ALARM

1. Turn the unit power OFF before setting the alarm.

2. Press and hold the ALARM SET button (17) to set the alarm time.

3. While holding the ALARM SET button (17) press the HOUR (14) or the MINUTE (15) buttons

respectively until the proper time is set.

4. Turn on the alarm function by pressing the ALARM ON / OFF button (19) until the Alarm

icon appears in the LCD Display.

5. To turn off the alarm, press the ALARM ON / OFF button (19) until the Alarm icon

disappears f

rom the LCD Display.

6. After setting the Alarm to your desired time, press the MUSIC / BUZZER button (18) to the

desired selection.

• If you are waking to CD press the MUSIC / BUZZER button (18) until “CD” appears in the

LCD Display.

• If you are waking to RADIO press the MUSIC / BUZZER button (18) until “

LCD Display.

• If you are waking to BUZZER press the MUSIC / BUZZER button (18) until only the Alarm

icon appears in the LCD Display.

♪” appears in the

7. To Stop the Alarm while it is playing, simply press the ALARM ON / OFF button (19) once.

Page 9

USING THE DIGITAL BASS BOOST FEATURE

CD player will not turn on

AC Cord not connected

Plug AC Cord into power

Disc will not play

Disc inserted incorrectly

Reinsert disc with label side

Erratic CD playback

Dirty or defective disc

Clean or replace disc

No sound

Plug not inserted property

Reinsert Speaker Plug into

Noise or Sound distorted on

Station not tuned properly

Retune AM or FM broadcast

• To enhance the low frequency bass sound, press the DBBS button (21). The DBBS Indicator Light (22) will turn ON.

• Press the DBBS button (21) again to turn the Digital Bass Boost OFF.

TROUBLESHOOTING GUIDE

SYMPTOM CAUSE SOLUTION

radio

properly

Defective compact disc CD compartment not closed Moisture condensation on

disc

Volume control set to

minimum

Defective compact disc Aux Input cable connected Remove Aux cable from input

outlet

facing up Try another compact disc Close CD compartment Wipe disc with soft cloth

Speaker jack Increase the volume Try another compact disc

jack.

for AM or FM

Unit is not positioned

correctly

station Rotate unit until best reception is obtained

Page 10

LIMITED 90-DAY WARRANTY

We warrant this product to be free from defects in material and workmanship under normal use for a ninety-day period from the original date of purchase from an authorized BLUESTREAM dealer.

Should you be missing any of the included accessories or other components (screws, pieces, etc.), please contact the Customer Support Center to secure a replacement. It is not necessary to bring the unit back to the store. When calling, please reference the parts list f Instruction Manual to help us accurately identify the missing parts and promptly provide replacements.

We will replace the unit free of charge should it become defective under this warranty, providing you, the original purchaser, have your original dated sales receipt.

To obtain warranty service or replacement within the ninety-day warranty period, please return the product with all parts and accessories along with your original dated store receipt to the original p contact the manufacturer for warranty replacement.

Our Customer Support Center is available Monday - Saturday (10:00AM to 7:00PM EST) for technical assistance or troubleshooting. To contact us, please call 1-855-719-8324, or visit www.sibrandssupport.com.

This warranty applies only under conditions of normal use. Our products are not intended for outdoor use.

There are no consumer serviceable parts contained in this product to service or repair the unit will immediately void all warranty coverage.

This warranty does not cover any product which has been subject to damage due to an act of nature, misuse, neglect, accident, abuse, commercial use, or modification of, or to, any part of the product, including the antenna. Damage to any external media such as smartphones, tablets, memory storage and/or other devices are not covered nor is the cost incurred in shipping the unit for warranty repair or exchange. Under no circ any loss (direct, indirect, incidental, foreseen, unforeseen, special or consequential) or for any damage arising out of, or in connection with, the use of this product.

UNDER NO CIRCUMSTANCES WILL BLUESTREAM BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.

This warranty does not cover re-manufactured, refurbished, or repaired units, or any products sold 'As Is'.

This warranty is valid only to the original purchaser of the Product in the United Stat Canada and grants specific legal rights.

lace of purchase and the unit will be exchanged at no charge. It is not necessary to

and any attempt by the owner

umstances shall BLUESTREAM be liable for

ound in the

es and

Page 11

This page is intentionally left blank

Page 12

Schoenfeld International Inc. and BLUESTREAM 5001 American Boulevard West Suite 275 Bloomington, Minnesota 55437
