Page 1
180
adjustable base
Rechargeable
Li-ion battery
1200m
Ah
Main COB LED
worklight
160
LUMENS
3 WATT COB &
LED RECHARGEABLE
WORKLIGHT
LED torch
50
LUMENS
MAGNETIC
USB
CHARGING
Page 2
General Information
Thank you for purchasing a Blue Spot Tools product, you can find further information on our range at
www.BlueSpot.uk.com. Please ensure that you are using the product correctly and that all guidance
and cautions are followed in accordance with the instructions. Please retain these instructions for
future reference.
Safe use
Please make sure that you read these instructions carefully in order to avoid injury when using the
worklight. Follow all health and safety rules and regulations. If in doubt and available please contact a
more knowledgeable source.
DO NOT use if damaged.
• BE AWARE this product is not waterproof.
• BE AWARE it is not possible to change the light source.
• ALWAYS check the light for any damage before use. Check for damage to the cable, lens or light
casing. If light is damaged do not use as this may cause damage to property or cause injury.
• ALWAYS inspect the USB cable for wear or damage before using the light. Ensure all the connections are secure.
• ALWAYS dress appropriately and wear the correct PPE equipment if required.
• ALWAYS ensure the light is disconnected from the power source when not in use.
• ALWAYS ensure the light has been turned off and disconnected from the power supply before
performing any maintenance or storing.
• Allow the light to cool down fully before cleaning or performing any maintenance.
• Before storing the light ensure that it has cooled down completely and is dry. Store the light in
a cool dry area that is out of reach of children.
• Position the light where it is not likely to be knocked or cause a hazard while working.
• Maintain the lamp in good and clean condition for best and safest performance.
• Keep the work area clean and uncluttered.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• DO NOT use the light if the glass shield on the front has been broken or has been removed.
01
Page 3
SAFE USE
• DO NOT use the light in damp or wet locations.
• DO NOT allow children to use the light.
• NEVER use the light near flammable, combustible or explosive liquids, solids, gases or equipment
• NEVER proceed to use the light if you have found damage to the USB cable.
• NEVER direct the light into yours, another person’s, or animal’s eyes. This could cause
eye damage.
These instructions are intended as a guide only.
Introduction
Main COB LED
worklight
160
LUMENS
MAGNETIC
USB
CHARGING
180
adjustable base
Rechargeable
Li-ion battery
1200mAh
LED torch
50
LUMENS
The Electralight 3 Watt COB & LED Rechargeable Worklight (160 Lumens) is ideal for professional users.
The main COB LED work light operates at 160 lumens and the top of the torch body also features an LED
50 lumen torch. The magnetic base is ideal for securing to metallic surfaces and there is also a hanging
hook on the rear of the worklight allowing for hands-free use. The light is also adjustable through 180°
for even greater hands-free usability. Complete with a USB charging lead and a 1200mAh rechargeable
lithium battery.
02
Page 4
Specifications
Model
Output
Max Run Time
Charging Time
Power Source
Input Voltage
Power
Temperature Range
Dimension
Weight
65318
160 lumens
2.5 hours
3 hours
3.7V 1200mAh rechargeable lithium battery
5V
3W
-20° - 50°C
155 x 40 x 30mm
131.8g
Operation
ALWAYS check the light for any damage before use. Check for damage to the cable, lens or light casing.
If light is damaged do not use as this may cause damage to property or cause injury.
1. Before using the lamp for the first time the battery must be fully charged.
2. If you would like to use the light hands free you can secure the light to a metallic surface using
the magnetic base.
3. Set the light into the desired angle using the 180° adjustable base.
4. To turn the light on use the button on the front of the light.
5. To turn the light off press the button until the light is no longer on.
03
Page 5
Charging
The Electralight 3 Watt COB & LED Rechargeable Worklight (160 Lumens) includes a rechargeable
battery. To recharge the battery follow the instructions below –
1. Connect the USB wire to the back of the light via the charging port.
2. Ensure the USB wire is securely connected to the light
3. Connect the USB wire to a power supply. There will be a green light that lights up when charging.
4. It should take approximately 3 hours for the light to fully charge.
5. When the light is charged carefully disconnect the USB lead from the power supply and also from
the light.
DO NOT leave the battery without charge for an extended period as this risks damaging
the battery.
Cleaning & Maintenance
Allow the light to cool down fully before cleaning or performing any maintenance.
Clean the light case externally (not the glass/lens) with a moist cloth.
NEVER use solvents or abrasives to clean the light.
If necessary clean the glass/lens with a soft cloth.
Storage
ALWAYS ensure the light is disconnected from the power source when not in use.
Before storing ensure the light has cooled down completely and is dry. Store the light in a cool dry area
that is out of reach of children.
Disposal
Do not dispose electrical products together with household waste. Please use the correct recycling
facilities. If unsure of correct recycling, ask your local authority or retailer for advice.
• Contact your local waste disposal authority for information on how to correctly dispose of tools.
04
Page 6
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required,
it must be disposed of in an environmentally protective way. Contact your local solid waste
authority for recycling information.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment. When the product becomes completely unserviceable and requires
disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
CONTACT
Find out more about the Blue Spot Tools Lifetime Guarantee at www.BlueSpot.uk.com
Tel: 0800 093 0115
Email: sales@bluespot.uk.com
Orme Business Centre, Greenacres Road, Oldham, OL4 3NS
05
