Page 1
ALUMINIUM
5W FLEXIBLE
COB LIGHT
(280 LUMENS)
280
LUMENS
AI
MANUFACTURED FROM
aluminium
0
360
ADJUSTABLE
HEAD
COB
LED
MAGNETI C
BASE
BATTERY
INCLU DED
USB
CHARGI NG
Page 2
GeneraL Information
Thank you for purchasing a BlueSpot product, you can find further information on our range at
www.BlueSpot.uk.com. Please ensure that you are using the product correctly and that all guidance
and cautions are followed in accordance with the instructions. Please retain these instructions for
future reference.
Safe use
Please make sure that you read these instructions carefully in order to avoid injury when using the COB
light. Follow all health and safety rules and regulations. If in doubt and available please contact a more
knowledgeable source.
DO NOT use if damaged.
• BE AWARE this product is not waterproof.
• BE AWARE it is not possible to change the light source.
• ALWAYS check the light for any damage before use. Check for damage to the cable, lens or light
casing. If light is damaged do not use as this may cause damage to property or cause injury.
• ALWAYS inspect the USB cable for wear or damage before using the light. Ensure all the connections are secure.
• ALWAYS dress appropriately and wear the correct PPE equipment if required.
• ALWAYS ensure the light is disconnected from the power source when not in use.
• ALWAYS ensure the light has been turned off and disconnected from the power supply before
performing any maintenance or storing.
• Allow the light to cool down fully before cleaning or performing any maintenance.
• Before storing the light ensure that it has cooled down completely and is dry. Store the light in a
cool dry area that is out of reach of children.
• Position the light where it is not likely to be knocked or cause a hazard while working.
• Maintain the lamp in good and clean condition for best and safest performance.
• Keep the work area clean and uncluttered.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• DO NOT use the light if the glass shield on the front has been broken or has been removed.
01
Page 3
Safe use (continued)
• DO NOT use the light in damp or wet locations.
• DO NOT allow children to use the light.
• NEVER use the light near flammable, combustible or explosive liquids, solids, gases or equipment.
• NEVER proceed to use the light if you have found damage to the USB cable.
• NEVER direct the light into yours, another person’s or animal’s eyes. This could cause eye
damage.
These instructions are intended as a guide only.
Introduction
The Electralight Aluminium 5W Flexible COB Light (280 Lumens) features two modes (Full & power save)
in addition to the main COB there is a smaller LED inspection torch for focusing in on tight spaces. The
light also features a red light function which can be turned on by holding the power button for 3 seconds.
The light has a 360° adjustable head to meet a range of lighting angles. The magnetic base is ideal for
securing to metallic surfaces allowing for hands free use. Complete with a USB charging lead and a
2200mAh rechargeable lithium battery.
280
LUMENS
AI
MANUFACTURED FROM
aluminium
0
360
ADJUSTABLE
HEAD
COB
LED
02
MAGNETI C
BASE
BATTERY
INCLU DED
USB
CHARGI NG
Page 4
Specifications
Model
Output
Max Run Time
Charging Time
Power Source
Input Voltage
Power
Temperature Range
Dimension
Weight
1. Power button
2. COB light
3. LED light
4. Magnetic base
5. USB charging port
6. 360° adjustable head
65317
300 lumens
3-10 hours
4-5 hours
3.7V 2200mAh rechargeable lithium battery
DC5V
5W
-20° to 50°
257mm (height) x 33mm (depth)
110G
Parts Diagram
5
6
4
1
2
3
03
Page 5
Operation
ALWAYS check the light for any damage before use. Check for damage to the cable, lens or light casing.
If light is damaged do not use as this may cause damage to property or cause injury.
1. Before using the lamp for the first time the battery must be fully charged.
2. If you would like to use the light hands free you can secure the light to a metallic surface using
the magnetic base.
3. Set the light into the desired angle using the 360° adjustable head.
4. To turn the light on use the button on the front of the light. To adjust the brightness of the light or
to use the light on the top instead of the main light press the button again.
5. The button will glow green to show that the light is switched on.
6. To turn the light off press the button until it is no longer green.
Charging
The Electralight Aluminium 5W Flexible COB Light includes a rechargeable battery. To recharge the
battery follow the instructions below –
1. Connect the USB wire to the back of the light via the charging port.
2. Ensure the USB wire is securely connected to the light.
3. Connect the USB wire to a power supply.
4. It should take approximately 4-5 hours for the light to fully charge.
5. When the light is charged carefully disconnect the USB lead from the power supply and also from
the light.
DO NOT leave the battery without charge for an extended period as this risks damaging the battery.
Cleaning & Maintenance
Allow the light to cool down fully before cleaning or performing any maintenance.
Clean the light case externally (not the glass/lens) with a moist cloth.
NEVER use solvents or abrasives to clean the light.
If necessary clean the glass/lens with a soft cloth.
04
Page 6
Storage
ALWAYS ensure the light is disconnected from the power source when not in use.
Before storing ensure the light has cooled down completely and is dry. Store the light in a cool dry area
that is out of reach of children.
Disposal
Do not dispose electrical products together with household waste. Please use the correct recycling
facilities. If unsure of correct recycling, ask your local authority or retailer for advice.
• Contact your local waste disposal authority for information on how to correctly dispose of tools.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required,
it must be disposed of in an environmentally protective way. Contact your local solid waste
authority for recycling information.
Storage
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging
should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the
environment. When the product becomes completely unserviceable and requires disposal,
drain any fluids (if applicable) into approved containers and dispose of the product and
fluids according to local regulations.
CONTACT
Find out more about the BlueSpot Lifetime Guarantee at www.BlueSpot.uk.com
Tel: 0800 093 0115
Email: [email protected]
Orme Business Centre, Greenacres Road, Oldham, OL4 3NT
05
