Page 1
BLUE LINE CORNER ROLLER
USA
BLUE LINE
BLUE LINE
Page 2
BLUE LINE CORNER ROLLER
The Blue Line Corner Roller is designed for embedding paper joint tape into the 90
internal angles on vertical and horizontal joints. The Blue Line Corner Roller is used after
the Blue Line Automatic Taper.
0
> Ensure that the Blue Line Corner Roller is free from any dry joint compound.
> Check that both the stainless steel rollers and pivot pin move freely.
1. Dip the Blue Line Corner Roller head in a bucket of clean water. This will reduce
initial friction and tape drag.
2. Whilst standing directly in front of the internal, place the Blue Line Corner Roller in
the center of the internal joint. Roll gently down the internal to crease paper tape.
3. Roll the Blue Line Corner Roller up the internal increasing the pressure to the top.
4. Roll the full length of the internal several times with enough pressure to force any
excess joint compound out from behind the paper tape.
5. When rolling angles between walls and ceilings hold the Blue Line Corner Roller at
45 to the internal.
6. Remove excess joint compound with a Blue Line Corner Finisher and let the
internal dry before final coating.
(CR-1)
(CR-2)
(CR-3)
(CR-4)
0
BEFORE USE
USING THE BLUE LINE CORNER ROLLER
CR-1
CR-2
CR-3
CR-4
Page 3
Your Blue Line Corner Roller should be cleaned after every use to maximize lifespan and
maintain optimal performance.
1. Clean the Blue Line Corner Roller with a hose and stiff brush.
2. Ensure all joint compound is removed from roller and pivot pin.
We have established a network of authorized warranty repair facilities in the western,
central and eastern United States as well as Canada.
Your Blue Line Drywall Tools LLC authorized warranty repair facility has a professional
workshop with trained staff to carry out all your servicing needs.
Easy to install maintenance kits are available from your Blue Line Drywall Tools LLC
distributor. All parts are available, some may require ordering.
We recommend Readymix Jointing Compounds. Chemically fast setting compounds may
only be used in the Blue Line Drywall Tools Pump, Flat Boxes, Nail Spotters, and Corner
Box. Chemically fast setting compounds must not be used in the Automatic Taper. Always
clean and lubricate your Blue Line Drywall Tools to maintain maximum efficiency.
(CR-5)
CLEANING
WARRANTY REPAIRS
SERVICING
SPARE PARTS
CARE OF YOUR TOOLS
Tip: Place the Blue Line Corner Roller in a bucket of clean water when not in use on
the job site to prevent the joint compound from drying on the rollers between uses.
CR-5
USA
BLUE LINE
BLUE LINE
USA
Page 4
USA
BLUE LINE
BLUE LINE
USA
For more information, call the order desk at (800) 423-1806
1250 South Wilson Way, Suite B-10 • Stockton, California 95205 • (800) 423-1806 • (209) 942-1351 • Fax (209) 942-2817
www.bluelineusa.com
