BlueExpert Technology BED002, BED401 Users Manual

IVT BlueSoleil™ User Manual Version: 1.4.9

This document describes how to use IVT BlueSoleil.

IVT BlueSoleil™ User Manual

Contents

BlueSoleil™ Introduction............................................................................3

2 BlueSoleil™ Graphical User Interface .........................................................4

2.1 Start BlueSoleil™ ......................................................................................4

2.2 Exit BlueSoleil™ ........................................................................................4

2.3 BlueSoleil™ Main Window ...........................................................................5

2.3.1 My Device Icon ................................................................................................................................5

2.3.2 Remote Bluetooth Device Icons.......................................................................................................6

2.3.3 Bluetooth Service Icons................................................................................................................... 7

2.4 Service Window.........................................................................................8

2.4.1 My Service Icons............................................................................................................................10

3 Personal Area Networking........................................................................ 12

3.1 Introduction ........................................................................................... 12

3.2 Connect Two Computers........................................................................... 12

3.3 Computer with PAN acting as a TCP/IP Gateway .......................................... 18

3.3.1 Connect to the Internet using ICS..................................................................................................19

3.3.2 Settings on the PAN server............................................................................................................20

3.4 PAN Configuration ................................................................................... 22

3.4.1 My PAN Service.............................................................................................................................22

4 Dial-Up Networking..................................................................................23

4.1 Introduction ........................................................................................... 23

4.2 Connect to a Dial-up Gateway from a Computer........................................... 23

5 Bluetooth Serial Port................................................................................27

5.1 Introduction ........................................................................................... 27

5.2 Connect Two Computers........................................................................... 27

5.3 Use SPP to Print a Document..................................................................... 30

5.4 SPP Configuration.................................................................................... 32

5.4.1 My SPP Service .............................................................................................................................32

6 Bluetooth File Transfer.............................................................................33

6.1 Introduction ........................................................................................... 33

6.2 Transfer files to/from a Computer .............................................................. 33

6.3 FTP Configuration .................................................................................... 39

6.3.1 My FTP Service.............................................................................................................................39

7 LAN Access...............................................................................................40

7.1 Introduction ........................................................................................... 40

7.2 Access a Local Area Network (LAN) ............................................................ 40

8 Object Push..............................................................................................46

8.1 Introduction ........................................................................................... 46

8.2 Transfer Objects from a Computer to a Bluetooth Cellular Phone .................... 46

8.3 Transfer Objects from a Bluetooth Cellular Phone to a Computer .................... 51

8.4 Transfer Objects between Two Computers................................................... 55

8.5 Configure OPP Service.............................................................................. 56

8.5.1 My OPP Service ............................................................................................................................56

9 Synchronization .......................................................................................57

9.1 Introduction ........................................................................................... 57

9.2 Exchange PIM Data with a Cellular Phone.................................................... 57

IVT BlueSoleil™ User Manual

9.3 Set up SYNC Connection between Two Computers ....................................... 59

9.4 Synchronization Configuration................................................................... 63

9.4.1 My Synchronization Service...........................................................................................................63

10 Hardcopy Cable Replacement ................................................................ 64

10.1 Introduction......................................................................................... 64

10.2 Print a Document Using a Bluetooth Printer .............................................. 64

11 Human Interface Device........................................................................ 67

11.1 Introduction......................................................................................... 67

11.2 Connect a Computer to a Bluetooth Mouse ............................................... 67

11.3 Connect a Computer to a Bluetooth Keyboard........................................... 70

12 Connection Shortcut.............................................................................. 73

12.1 Introduction......................................................................................... 73

12.2 How to use Connection Shortcut ............................................................. 73

13 Bluetooth Glossary ................................................................................ 76

IVT BlueSoleil™ User Manual

1 BlueSoleil Introduction

BlueSoleil is a Windows-based Bluetooth Wireless software suite from IVT. It is fully compliant to the latest Bluetooth SIG specifications. BlueSoleil incorporates Bluetooth and computer technologies to enable users to wirelessly access computing devices, form

networks, and exchange information.

BlueSoleil V1.4.8 includes nine Bluetooth profiles. The following table indicates which of these profiles is available for client and server devices.

Profile Description Client Server

PAN Personal Area Networking √ √

SPP Serial Port √ √

DUN Dial-Up Networking √

LAP LAN Access √ √

FTP File Transfer √ √

HID Human Interface Device √

HCRP Hardcopy Cable Replacement √

OPP Object Push √ √

SYNC Synchronization √ √

BIP Basic Imaging √ √

AV AV √ √

HS Headset √ √

FAX FAX √

BlueSoleil supports more than ten Bluetooth chip-sets and HCI interfaces including USB, UART, PCMCIA and Compact Flash.

IVT BlueSoleil supports:

♦ Windows 2000/XP ♦ Windows 98SE/Me

This manual describes how to use BlueSoleil:

♦ How to start and exit BlueSoleil. ♦ How to navigate the Main Window and Service Window.

♦ How to use the Bluetooth profiles.

IVT BlueSoleil™ User Manual

2 BlueSoleil™ Graphical User Interface

2.1 Start BlueSoleil™

After installing BlueSoleil™, there are two ways to start the program:

1. A BlueSoleil™ shortcut icon on the Windows desktop.

2. An IVT BlueSoleil program group entry in the Windows’ Start | Programs menu. Double-click the BlueSoleil shortcut icon on the desktop or click the BlueSoleil™ menu

item on the Start | Programs | IVT BlueSoleil menu to start the BlueSoleil™

software.

The BlueSoleil™ icon will be displayed at the bottom right corner of the Windows desktop (Figure 2.1).

Figure 2.1: BlueSoleil™ icon

The BlueSoleil Main Window pops up as shown in Figure 2.2.

2.2 Exit BlueSoleil

To exit BlueSoleil, right-click the BlueSoleil™ icon at the bottom right corner of the Windows task bar and select Exit on the pop-up menu.

Note: Selecting the Close button at the top right corner of the BlueSoleil™ window only

hides the BlueSoleil™ window.

IVT BlueSoleil™ User Manual

2.3 BlueSoleil™ Main Window

The BlueSoleil™ Main Window displays all surrounding Bluetooth devices. From the

BlueSoleil™ Main Window users can search for surrounding Bluetooth devices and can

execute connect/ disconnect functions.

Remote Device Service

Local Device lcon

Figure 2.2: BlueSoleil™ Main Window

The main elements in the BlueSoleil™ Main Window are:

♦ My Device Icon ♦ Remote Bluetooth Device Icons ♦ Bluetooth Service Icons

2.3.1 My Device Icon

This icon represents the client computer. It is called the ‘My Device icon’ or ‘center ball’ in this document.

Functions:

3. Hover the mouse over the My Device icon to display the client Bluetooth device name

and address.

4. Double-click to start/ stop searching for surrounding Bluetooth devices.

5. Right-click to display the pop-up menu with related operations.

IVT BlueSoleil™ User Manual

2.3.2 Remote Bluetooth Device Icons

The icons in the table below represent the remote Bluetooth devices.

Device Type Icon

Headset

Keyboard

LAN Access Point

Laptop

Mobile

Modem

Mouse

Personal Computer

PDA

Printer

Scanner

Unknown device

The following colors are used to indicate the status of the remote Bluetooth device:

IVT BlueSoleil™ User Manual

♦ White (Idle)

This is the normal status of the device.

♦ Yellow (Selected)

The device has been selected by the user.

♦ Green (Connected)

The device has been connected.

Functions:

6. Single-click to select.

7. Double-click to get the services remote Bluetooth device supports.

8. Right-click to display the pop-up menu with related operations.

2.3.3 Bluetooth Service Icons

The Bluetooth Service Icons represent the Bluetooth services supported by the remote device.

Bluetooth Service Icon

Personal Area Networking

Dial-up Networking

Serial Port

LAN Access

File Transfer

Information Synchronization

Object Push

Printer

Human Interface Device

FAX

IVT BlueSoleil™ User Manual

Basic lmaging

Headset

The following colors are used to indicate the status of the Bluetooth service:

♦ White (Idle)

This is the normal status.

♦ Pink (Available)

The Bluetooth service is available for the selected device.

♦ Yellow (Selected)

The service icon has been selected by the user.

♦ Green (Connected)

The service is connected.

Functions:

9. Hover the mouse over the icon to display the service name.

10. Single-click to select the service.

11. Double-click to connect.

12. Click to display the pop-up menu with related operations.

Figure 2.3: Bluetooth PAN Service Icon

2.4 Service Window

Select menu View | Service Window and the Service Window appears.

This window displays the Bluetooth services the ‘my Bluetooth device’ provides to remote Bluetooth devices. These services are called ‘my Bluetooth services’.

IVT BlueSoleil™ User Manual

Main Elements:

♦ My Service Icons

Figure 2.4: BlueSoleil™ Service Window

IVT BlueSoleil™ User Manual

2.4.1 My Service Icons

These icons represent ‘my Bluetooth services’.

My Bluetooth Service Icon

Personal Area Networking

Serial Port A

Serial Port B

Object Push

File Transfer

Information Synchronization

LAN Access

AV Headset

Basic Image

IVT BlueSoleil™ User Manual

Headset AG

The following colors indicate the status of the Bluetooth service:

♦ White (Idle)

Normal status.

♦ Pink (Started)

My Bluetooth service is started.

♦ Green (Connected)

A remote device has connected to my Bluetooth service.

Functions:

13. Single-click to select.

14. Double-click to start/stop a service.

15. Right-click to display the pop-up menu with related operations.

IVT BlueSoleil™ User Manual

3 Personal Area Networking

3.1 Introduction

The Bluetooth Personal Area Networking (PAN) is a Bluetooth application, which enables devices to form an ad-hoc network or to access a remote network through a network access point.

The PAN application can be used in the following scenarios:

♦ Two or more computers (or PDAs) can be connected through PAN and can

visit each other using Windows Network Places or any application based on

TCP/IP.

♦ A computer (or PDA) can access a Local Area Network or the Internet

through a PAN Network Access Point (NAP) bridge.

♦ A computer with PAN installed acts as a TCP/IP gateway.

Each of these scenarios is now covered in more detail.

3.2 Connect Two Computers

This section outlines the steps involved in connecting two computers, Computer A and Computer B.

Computer A: Computer B:

Notebook/ Laptop PIII, 800MHz, 128M Desktop, PIII, 600MHz, 128M

A Bluetooth USB dongle A Bluetooth USB dongle

Windows 2000 Windows 2000

IVT BlueSoleil™ IVT BlueSoleil™

Step 1: Insert Bluetooth USB dongles in both computers.

Step 2: Start BlueSoleil™ in both computers.

Step 3: Set device name of each computer to anything you want. Here they

are named Computer A and Computer B.

♦ In the BlueSoleil™ Main Window of Computer A, click Tools |

My Bluetooth Device. Enter ‘Computer A’ in the device name field in the My Bluetooth Device window.

♦ Repeat for Computer B.

Step 4: Set the Security Level.

♦ Click Tools | Configurations | Security, the Security

Configuration panel pops up.

♦ On the Security Configuration panel, select High in Security

Level.

Note: If you check the Fixed Passkey and input a Bluetooth passkey, this passkey will

be used as the default passkey. The other computer will then have to provide the same passkey during the connection procedure if it wants to connect to this computer.

IVT BlueSoleil™ User Manual

Figure 3.1: Security Configuration

Step 5: Start the PAN service on Computer A.

♦ In the BlueSoleil Main Window, click View | Service

Window.

♦ In the Service Window, right-click the Personal Area Networking

icon. Choose Start Service. (Figure 3.2)

Figure 3.2: Start PAN Service on Computer A

IVT BlueSoleil™ User Manual

Step 6: Search for Computer A on Computer B.

♦ Double-click the My Device Icon (center ball). The surrounding

discovered Bluetooth devices appear.

♦ Check to see if Computer A appears. If it does not appear,

double-click the My Device Icon again. Repeat the operation until you find Computer A.

Step 7: Find the PAN service on Computer A.

♦ Double-click the Computer A device icon on Computer B. ♦ Enter the Bluetooth passkey (if security is set to High on either

side) to start the authenticating process. The Enter Bluetooth Passkey window pops up on Computer A. Input any characters

or numbers, e.g. “12”. The Enter Bluetooth Passkey window

pops up on Computer B. Input exactly the same characters or numbers as you input for Computer A, e.g. “12”. (Figure 3.3)

♦ Once authentication is complete, the PAN service is found.

Figure 3.3: Input passkey

Figure 3.4: PAN service is found

Step 8: Connect to Computer A.

IVT BlueSoleil™ User Manual

♦ Right-click the PAN service icon; select Connect on the pop-up

menu. (Figure 3.5)

♦ The connection is established successfully (Figure 3.6). Wait

until the valid IP address is shown on the bottom right status bar on both Computer A and Computer B.

Figure 3.5: Connect to PAN Service

IVT BlueSoleil™ User Manual

Figure 3.6: Connection is established successfully.

Step 9: Computer A and Computer B are now connected. On Computer B,

go to Windows | My Network Places to find Computer A and

copy files. Figure 3.7 shows where to input Computer A’s name. In Figure 3.7, Computer A is named ‘mike’.

Figure 3.7: Find Computer A in My Network Places

Step 10: To disconnect the PAN connection, disconnect from either Computer

IVT BlueSoleil™ User Manual

A or from Computer B.

♦ On Computer B, right-click on the PAN service icon and choose

Disconnect. (Figure 3.8)

♦ On Computer A, right-click on the PAN service icon and choose

Stop Service. (Figure 3.9)

Figure 3.8: Disconnect the PAN service from Computer B

IVT BlueSoleil™ User Manual

Figure 3.9: Stop the PAN service on Computer A

Advanced Usage:

♦ Computer A is now the center node. Other computers, for example,

Computers C, D and E, can connect to Computer A with BlueSoleil™ following the same steps as those for Computer B.

♦ Computer A, B, C, D and E can access each other using the Windows

Network Places. This forms a Bluetooth ad-hoc networking environment.

Note: Computer A can currently only support up to 7 connections.

Also it takes about 1 minute before an IP address can be obtained on the client side (Computer B) unless a DHCP server is running on the server side (Computer A).

3.3 Computer with PAN acting as a TCP/IP Gateway

The following sections outline how to enable Computer B to access the Internet through Computer A.

Computer A: Computer B:

Notebook/ Laptop, PIII, 800MHz, 128M Desktop, PIII, 600MHz, 128M

A Bluetooth USB dongle A Bluetooth USB dongle

Windows 2000 Windows 2000

IVT BlueSoleil™ IVT BlueSoleil™

Network Adapter connecting to the

Internet

IVT BlueSoleil™ User Manual

Step 1: Enable Internet access sharing on Computer A.

♦ See “Section 3.2: Connect Two Computers”, and complete Steps

1 to 7.

♦ Refer to steps outlined in “Section 3.4.1 Connect to the Internet

using ICS”, to set up Internet sharing.

Step 2: Computer B can now access the Internet.

Advanced Usage:

♦ Computer A is now the center node of the network. Other computers with

BlueSoleil™ installed, for example, Computers C, D and E, can connect to Computer A following the same steps as those for Computer B.

♦ Computers A, B, C, D and E can access each other using the Windows My

Network Places and form a Bluetooth ad-hoc networking. Computers B, C,

D and E can then access the Internet through Computer A.

Note: Computer A can currently only support up to 7 connections. Also it takes about 1

minute before an IP address can be obtained, unless Computer A is connected to a DHCP server.

3.3.1 Connect to the Internet using ICS

The PAN server can share a network connection with PAN clients with Windows ICS. ICS (Internet Connection Sharing) uses NAT (Network Address Translation) to share a network connection. PAN clients use internal network addresses (192.168.0.x). ICS is suitable for both dial-up and LAN connections.

For more detailed information about ICS and NAT, please refer to the Microsoft Windows help topic “Internet Connection Sharing”.

IVT BlueSoleil™ User Manual

3.3.2 Settings on the PAN server

Step 1: Right-click the My Network Places icon and select Properties.

(Figure 3.10)

Figure 3.10: Select Properties on My Network Places

Step 2: Right-click the connection through which you access the Internet,

and then select Properties. (錯誤! 找不到參照來源。)

Figure 3.11: Click the connection through which you access the Internet

Step 3: On the Sharing tab, select the Enable Internet Connection

Sharing check box. Figure 3.12 shows how to enable Internet

Connection Sharing for a local area connection on Windows 2000. Figure 3.13 shows how to enable Internet Connection Sharing for a dial-up connection on Windows 2000.

IVT BlueSoleil™ User Manual

Figure 3.12: Internet Connection Sharing for a Local Area Connection on Windows 2000

Step 4: If this connection is a dial-up one, and you want automatic dialing

when another computer in your home network attempts to access

external resources, then check the Enable on-demand dialing check box. Click OK.

Figure 3.13: Internet Connection Sharing for a Dial-up Connection on Windows 2000

Step 5: A message window appears as shown in Figure 3.14. Click Yes. The

IP address of the BT network adapter is changed to 192.168.0.1 and a DHCP server is started on BT network adapter.

IVT BlueSoleil™ User Manual

Figure 3.14: Confirm Enabling Internet Connection Sharing

Note: The Internet Connection Sharing wizard will set the IP address of the BT network

adapter to 192.168.0.1, and a DHCP server will be run on Computer A. PAN clients in the Bluetooth network can be set statically or dynamically to any IP address in the range

192.168.0.2 to 192.168.0.253.

3.4 PAN Configuration

3.4.1 My PAN Service

In the BlueSoleil™ Service Window, right-click the Personal Area Networking icon. On the

pop-up menu, select Properties to configure my PAN service. (Figure 3.15)

Setting Items:

♦ Auto start this service when my Bluetooth starts

Check this option to automatically start my PAN service the every time BlueSoleil™ is started.

Figure 3.15: Service Configuration

IVT BlueSoleil™ User Manual

4 Dial-Up Networking

4.1 Introduction

The Bluetooth Dial-up Networking (DUN) service allows a Bluetooth-enabled client to access the Internet wirelessly through a modem on another Bluetooth device or a cellular phone. The other Bluetooth device or the cellular phone is called the gateway (server) as it provides access to the public network.

The DUN profile can be used in the following scenario:

♦ A Bluetooth computer accesses the Internet through a Bluetooth cellular

phone or Bluetooth modem.

4.2 Connect to a Dial-up Gateway from a Computer

This section outlines the steps involved in a computer (client) accessing the Internet through a Bluetooth cellular phone.

Computer A: Bluetooth Cellular Phone:

Notebook/ Laptop, PIII, 800MHz, 128M Sony Ericsson T68 cellular phone

A Bluetooth USB dongle

Windows XP

IVT BlueSoleil™

Step 1: Insert the Bluetooth USB dongle in the computer.

Step 2: Start BlueSoleil™ in the computer.

Step 3: Set device name of the computer to anything you want. Here it is

named Computer A.

♦ In the BlueSoleil™ Main Window of Computer A, click Tools |

My Bluetooth Device. Enter ‘Computer A’ in the device name

field in the My Bluetooth Device window.

Step 4: Set the Sony Ericsson T68 to be discoverable so that Computer A

can find the T68.

♦ Press the Menu button on the T68 and scroll until you reach the

Connect menu option, select Connect and scroll until you find Bluetooth. Select this option and scroll until you see Discoverable. Press the Yes button to confirm the selection.

♦ The T68 will now enable itself to receive connection requests

from other devices.

Step 5: Add Computer A to the paired device list in the T68.

♦ Press the Menu button on the T68 and scroll until you reach the

Connect menu option, select Connect and scroll until you find Bluetooth. Select this option and scroll until you see Discover. Press the Yes button to confirm the selection.

♦ The T68 will now start searching devices. Once the T68 finds

“ComputerA” on the screen, select it by pressing the Yes button. The Add to paired device? message appears on the

+ 56 hidden pages

BlueExpert Technology BED002, BED401 Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
