Blue Coat Systems SGOS 4.x User Manual

Blue Coat® Systems ProxySG

SGOS 4.x Upgrade Guide

™

Blue Coat SGOS 4.x Upgrade Guide

Contact Information

Blue Coat Systems Inc. 650 Almanor Avenue Sunnyvale, California 94085

North America (USA) Toll Free: 1.866.362.2628 (866.36.BCOAT) North America Direct (USA): 1.408.220.2270 Asia Pacific Rim (Japan): 81.3.5425.8492 Europe, Middle East, and Africa (United Kingdom): +44 (0) 1276 854 101

bcs.info@bluecoat.com support@bluecoat.com www.bluecoat.com

Copyright© 1999-2005 Blue Coat Systems, Inc. All rights reserved worldwide. No part of this document may be reproduced by any means nor modified, decompiled, disassembled, published or distributed, in whole or in part, or translated to any electronic medium or other means without the written consent of Blue Coat Systems, Inc. The Software may not be modified, reproduced (except to the extent specifically allowed by local law), removed from the product on which it was installed, reverse engineer ed, decompiled, disassembled, or have its source code extracted. In addition to the above restrictions, the Software, or any part thereof, may not be (i) published, distributed, rented, leased , sold, sublice nsed, assigned or otherwise transferr ed, (ii) used for competitive analysis or used to create derivative works thereof,(iii) used for application development, or translated (iv) used to publish or distribute the results of any benchmark tests run on the Software without the express written permission of Blue Coat Systems, Inc., or (v) removed or obscured of any Blue Coat Systems, Inc. or licensor copyrights, trademarks or other proprietary notices or legends from any portion of the Software or any associated documentation. All right, title and interest in and to the Soft ware and documentation are and shall remain the exclusive property of Blue Coat Systems, Inc. and its licensors. Blue Coat Systems, Inc. specifications and documentation are subject to change without notice. Information contained in this document is believed to be accurate and reliable, however, Blue Coat Systems, Inc. assum e s no responsibility for its use. ProxySG™, ProxyAV™, CacheOS™, S GOS™, Spywar e Inter c eptor™, S cope ™ ar e trademarks of Blue Coat Syste ms, Inc. and CacheFlow®, Blue Coat®, Accelerating The Internet®, WinProxy®, Access Now®, Ositis®, Powering Internet Management®, and The Ultimate Internet Sharing Solution® are r egistered trademarks of Blue Coa t Systems, Inc. All other trademarks contained in this document and in the Software are the property of their respective owners.

BLUE COAT SYSTEMS, INC. DISCLAIMS ALL WARRANTIES, CONDITIONS OR OTHER TERMS, EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, ON SOFTWARE AND DOCUMENTATION FURNISHED HEREUNDER INCLUDING WITHOUT LIMITATION THE WARRANTIES OF DESIGN, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL BLUE COAT SYSTEMS, INC., ITS SUPPLIERS OR ITS LICENSORS BE LIABLE FOR ANY DAMAGES, WHETHER ARISING IN TORT, CONTRACT OR ANY OTHER LEGAL THEORY EVEN IF BLUE COAT SYSTEMS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. The Software and all related technical information, documents and materials are subject to export controls under the U.S. Export Administration Regulations and the export regulations of other countries.

Document Number: 231-02781 Document Revision: SGOS 4.1—6/17/05

Contact Information

Chapter 1: Upgrading—Overview

Changes Between SGOS 3.x and SGOS 4.x......................................................................................................5

About the Document Organization..................................................................................................................5

Related Blue Coat Documentation.......................................................................................... ..........................5

Document Conventions......................................................................................................................................6

Chapter 2: Upgrade Behavior, General

Upgrading ............................................................................................................................................................7

Restoring to Previous Versions................................................................................. ........................................ 8

Changing Between SGOS 4.x Versions .................................. ........................................................................10

Licensing.............................................................................................................................................................10

Hardware Supported........................................................................................................................................12

Documentation References ..............................................................................................................................12

Chapter 3: Feature-Specific Upgrade Behavior

Access Logging..................................................................................................................................................13

Authentication ...................................................................................................................................................17

Bandwidth Management..................................................................................................................................17

Compression ......................................................................................................................................................18

Content Filtering................................................................................................................................................19

CPU Monitoring ...............................................................................................................................................19

Endpoint Mapper and SOCKS Compression................................................................................................20

ICAP Patience Page...........................................................................................................................................20

Policy...................................................................................................................................................................21

Securing the Serial Port ....................................................................................................................................30

SmartFilter Version 4........................................................................................................................................30

SSL Key Management........................................................................... ............................................................30

Index

iii

Blue Coat SGOS 4.x Upgrade Guide

Chapter 1: Upgrading—Overview

Blue Coat® strongly recommends that you read this document before attempting to upgrade to SGOS

4.x from previous ProxySG operating systems. Existing features and policies might not perform as with previous versions, and upgrading to this

version might require some additional configuration tuning. This SGOS version provides high security for the network, so when downgrading to previous versions, not all configurations and policies are retained.

Changes Between SGOS 3.x and SGOS 4.x

Unlike SGOS 3.x, SGOS 4.x does not permit upgrades from SGOS 2.x or CacheOS 4.x. All systems must be upgraded to SGOS 3.2.4 before being upgraded to SGOS 4.x. For information on the correct upgrade path, see Table 2.1, “Upgrade Paths” on page 7.

If you attempt to download the next major release and you receive an error message saying that the download failed due to policy deprecations, your policy uses constructs that are no longer supported in SGOS 4.x. You must correct any policy syntax problems before upgrading.For information on checking on policy deprecation, see "Policy Deprecation" on page 22.

If the upgrade path is followed, most of the current settings on the ProxySG are maintained after the upgrade. New or transformed settings in SGOS 4.x are taken from the original settings wherever possible.

About the Document Organization

This document is organized for easy r efer ence, and is divided into the followi ng sections and chapters:

Table 1.1: Document Organization

Chapter Title Description

Chapter 1 – Introducing the Upgrade/Downgrade Guide

Chapter 2 – Upgrade Behavior, General This chapter discusses general upgrade issues, including the

Chapter 3 – Upgrade Behavior, Specifics This chapter identifies new features in SGOS 4.x and

Document Conventions

The following section lists the typographical and Command Line Interface (CLI) syntax conventions used in this manual.

Table 1.2: Typographic Conventions

Conventions Definition

Italics The first use of a new or Blue Coat-proprietary term.

Courier font Command line text that appears on your administrator

Courier Italics A command line variable that is to be substituted with a literal

Courier Boldface

{ } One of the parameters enclos ed within the braces must be

[ ] An optional parameter or parameters. | Either the parameter before or after the pipe character can or must

workstation.

name or value pertaining to the appropriate facet of your network system.

A ProxySG literal to be entered as shown.

supplied

be selected, but not both.

Chapter 2: Upgrade Beha vior, General

Upgrading

When upgrading to SGOS 4.x from SGOS 3.2.4 or higher, the ProxySG saves a copy of the original configurations. These configurations remain unaffected when configuring features going forward. If you downgrade to the previous SGOS version, the saved configuration is used and the ProxySG is restored to that stat e.

Following the upgrade path provided maintains most of the current settings, the exceptions being those features that were substantially enhanced in SGOS 4.x.

The only supported direct upgrade is from SGOS 3.2.4 and later. CacheOS 4.x and SGOS 2.x systems must first be upgraded to the SGOS 3.2.4 release. The following table provides the upgrade paths for these earlier version.

Table 2.1: Upgrade Paths

Current OS Direct Upgrade

to SGOS 3.2.4?

CA 1.0.00-CA3.1.15 No CA 3.1.16 CA 3.1.16 No CA 4.1.10 CA 3.5.00-CA3.5.07 No CA 3.5.08 CA 3.5.08 No CA 4.1.10 CA 4.0.00-CA4.1.09 No CA 4.1.10 CA 4.1.10 or greater No SG 2.1.07 CA 4.2.00 No CA 4.2.01 CA 4.2.01 or greater Yes None Can directly upgrade to SGOS 3.2.4 SA 1.0.00-SA2.0.x No SA 2.0.x SA 2.0.x No SA 4.1.10 SA 4.0.00-SA4.1.09 No SA 4.1.10 SA 4.1.10 or greater Yes None Can directly upgrade to SGOS 3.2.4. SG 2.0.00-SG 2.1.06 No SG 2.1.07 SG 2.1.07 or greater Yes None Can directly upgrade to SGOS 3.2.4.

Next OS version required

Comments

In SGOS 3.2.4 or greater, deprecation warnings are issued for CPL syntax that is abandoned in SGOS

4.x. Use of abandoned syntax causes CPL compiler errors, the policy will fail to install and the ProxySG will use the default policy of ALLOW or DENY for all traffic. Following the recommended upgrade process ensures that policy integrity and therefore network security, are maintained.

Blue Coat SGOS 4.x Upgrade Guide

Summary of Changes to the Upgrade Process

• The upgrade path must include a system that shows all possible deprecation warnings, so that

these can be corrected in advance of the upgrade, to avoid policy compilation failures after upgrading. Migrating through SGOS 3.2.4 or greater satisfies this requirement.

• If the currently installed policy issued deprecation warnings when compiled, downloads of

systems in which that syntax has been abandoned will fail with the error " ". Which error message you see depends on whether you were using the Management Console or the CLI.

From the Management Console:

Policy deprecation warnings exist. Please resolve them prior to upgrading to the next major release of system software

From the CLI:

WARNING: The installed policy contains deprecation warnings. Please fix these warnings prior to upgrading to the next major release, or use load upgrade ignore-warnings at your own risk. Upgrading to the next major release with deprecation warnings will cause the policy compilation to fail on boot.

This means that you cannot download major version upgrades while policy contains deprecated syntax.

Generally, the deprecation warnings indicate the appropriate corrective action. See "Policy Deprecation" on page 22 for instructions on how to view the deprecation warnings that indicate the syntax to be corrected.

Note: The Visual Policy Manager (VPM) automatically generates up-to-date CPL syntax. If the

deprecations warnings are issued from the VPM policy file, you should start VPM and reload the policy to get the latest version of the generated CPL.

You can force an upgrade while deprecation warnings are present using the CLI command

upgrade ignore-warnings

; however, policy compilation will fail after the upgrade and the ProxySG reverts to the default policy of ALLOW or DENY. Corrective action is requir ed to r e stor e normal operation.

• Any CPL local policy that performs operations such as ALLOW, DENY, Authenticate, or Redirect,

or that modifies Cookie/Set-Cookie headers, might interfere with the Notify User policy. Before using the VPM Notify User policy, remove all coaching/splash/notify policy from the CPL local policy file.

Restoring to Previous Versions

When upgrading from the SGOS 3.2.4 or higher release, a copy of the settings is saved prior to any transformations by SGOS 4.x so that the original settings are available if the ProxySG is downgraded to SGOS 3.2.4.

Keep in mind that changes made after upgrade are not preserved on a downgrade. After an upgrade and a downgrade, the state is exactly what it was before the upgrade.

load

Chapter 2: Upgrade Behavior, General

Redoing an Upgrade from SGOS 3.2.4

When the initial SGOS 4.x upgrade occurs, any compatible configurations are converted. This only happens the first time you upgrade; if you later downgrade to a pre-SGOS 4.x version by selecting an earlier image on your system, make configuration changes, and re-install SGOS 4.x, the new SGOS

3.2.4 changes are not propagated to SGOS 4.x.

To force the new system's configuration to be regenerated after changes are made to the older system's configuration, you will need to force the upgrade conversion to occur again. Use the

restore-sgos3-config command, which converts the current SGOS 3.x configuration to the SGOS

4.x configuration.

Note: Previous force commands, restore-sgos2-config and restore-cacheos4-config, are not

available in SGOS 4.x; they can only be run from earlier versions.

The

restore-sgos3-config command first checks if there are saved SGOS 3.2.4 settings on the

ProxySG. If not, the CLI command warns the administrator and exits. If saved SGOS 3 settings exist, the

restore-sgos3-config command warns the administrator that all

the current SGOS 4.x settings will be lost and that a restart will be initiated, waiting for positive confirmation before clearing all the current SGOS 4.x settings, and then initiating a restart. The restart (similar to a

restart regular) triggers the upgrade process, which copies over the SGOS 3 settings

and transforms them to the SGOS 4.x settings.

Redoing an Upgrade from SGOS 2.x or CacheOS 4.x

T o downgrade to captur e changes to the older version’s configuration, you must first launch the SGOS

3.x image, then select the SGOS 2.x or CacheOS 4.x version to launch. After you make the desired

changes, you must follow the upgrade path back to SGOS 3.2.4, using the

restore-cacheos4-config commands. (See Table 2.1 on page 7 for information on upgrade paths.)

The

restore-sgos2-config or restore-cacheos4-config command first checks if there are saved

SGOS 2.x or CacheOS 4.x settings on the ProxySG. If not, the CLI command warns the administrator and exits.

Important: Check for deprecation warnings after upgrading to 3.2.4 and before proceeding to SGOS

4.x.

If saved settings exist, the command warns the administrator that all the current next version settings will be lost and that a restart will be initiated, waiting for positive confirmation before clearing all the current next version settings, and then initiates a restart. The restart (similar to a triggers the upgrade process, which copies over the settings and transform them to the next version settings.

restore-sgos2-config or

restart regular)

Blue Coat SGOS 4.x Upgrade Guide

Changing Between SGOS 4.x Versions

When moving from one SGOS 4.x release to another SGOS 4.x release, the system maintains all settings. Changes made after an upgrade continue to be available after a subsequent downgrade as long as the setting is relevant to the downgraded release.

Note: When upgrading or downgrading between versions of SGOS 4.x, copies of version-specific

configurations are not retained. Instead, all configurations created in an upgrade are retained if the configuration is relevant to the downgrade version.

Care should be taken when using policy features introduced in a minor release. These cause compilation errors if you fall back to a previous version of the same major release in which those features were unsupported.

To prevent accidental fallbacks, you should remove unused system images (using the i

nstalled_systems delete number, from the (config installed-systems) prompt).

Licensing

In SGOS 4.x, a base license is issued for SGOS 4.x functionality, regardless of whether those features existed before SGOS 4.x or are new in SGOS 4.x.

If you upgrade from SGOS 3.x with a valid SGOS 4.x component license, the ProxySG li sts the licensed components with their expiry dates; those components that are not licensed enter a 60-day trial period.

If you upgrade from SGOS 3.x without a valid SGOS 4.x component license, all licensable components enter a trial period; the ProxySG attempts to download a license from the Blue Coat license download site once a day for the duration of the SGOS 4.x trial period.

There are three types of licensable components:

• Required—The SGOS base.

• Included—Additional features provided by Blue Coat.

• Optional— If applicable, any additional purchased features.

When the license key file is created, it consists of all three components. The SGOS base is a required component of the license key file. The following table lists the ProxySG licensable components, categorized by type.

Table 2.2: Licensable Components

Type Component Description

Required SGOS 4 Base

Included 3rd Party Onbox

Content Filtering

The ProxySG operating system, plus base features: HTTP, FTP, TCP-Tunnel, SOCKS, and DNS proxy. The following additional features are also included in the base license:

Allows use with third-party vendor databases: Intersafe, Optenet, Proventia, SmartFilter, SurfControl, Websense, and Webwasher.

Table 2.2: Licensable Components (Continued)

Type Component Description

Chapter 2: Upgrade Behavior, General

Included Websense

Offbox Content Filtering

Included ICAP Services External virus and content scanning with ICAP servers. Included Bandwidth

Management

Included Windows Media

Standard

Included Real Media

Standard

Included Apple QuickTime

Basic

Included Netegrity

SiteMinder

Included Oblix COREid Allows realm initialization and user authentication to COREid servers. Included Peer-to-Peer Allows you to recognize and manage peer -to-peer P2P activity relating to P2P

Included Compression

For Websense off-box support only.

Allows you to classify, control, and, if required, limit the amount of bandwidth used by different classes of network traffic flowing into or out of the ProxySG.

MMS proxy; no caching or splitting; content pass-through. Fu ll policy contr ol over MMS.

RTSP proxy; no caching or splitting; content pass-through. Full policy contr ol over RTSP.

Allows realm initialization and user authentication to SiteMinder serv ers.

file sharing applications.

Allows reduction to file sizes without losing any data

Optional SSL SSL Termination; includes an SSL termination card to be installed on the

appliance.

Optional IM • AOL Instant Messaging: AIM proxy with policy support for AOL Instant

Messenger.

• MSN Instant Messaging: MSN proxy with policy support for MSN Instant

Messenger.

• Yahoo Instant Messaging: Yahoo proxy with policy support for Yahoo

Instant Messenger.

Optional Windows Media

Premium

Optional Real Media

Premium

• MMS proxy; content caching and splitting.

• Full policy control over MMS.

• When the maximum concurrent streams is reached, all further streams are denied and the client receives a message.

• RTSP proxy; content caching and splitting.

• Full policy control over RTSP.

• When the maximum concurrent streams is reached, all further streams are denied and the client receives a message.
