Clad Collection
DESIGNED IN 2016
ASSEMBLY NOTES | REV 00
GOTCHA COVERED.
Sometimes we fall hard for a good mix of materials. Like beautiful,
warm wood meeting the cool, smooth toughness of steel.
NEED A HAND?
Contact us at service@bludot.com or
844.425.8368 for assistance.
Parts & Hardware
QTY
Pt. 1082
12
QTY
1
Pt. 9021
QTY
Leg
2 | 844. 425.836 8 CLAD COLLECTION
4
QTY
Case
1
Step 01
ATTACH LEGS.
Leg Attachment. Once the legs have been
attached, the case should be lifted and
brought upright in order to prevent leg
damage.
Pt. 1082
Pt. 9021
SERVICE@BLUDOT.COM | 3ASSEMBLY NOTES
Step 02
DOOR ADJUSTMENT.
Hinges work in pairs. If you adjust one
hinge, chances are you will have to adjust
all the hinges.
1
3
2
If door needs adjustment from
TOP TO BOTTOM, Use Screw #1.
If door needs adjustment from
SIDE TO SIDE, Use Screw #2.
If door needs adjustment from
FRONT TO BACK, Use Screw #3.
1
2
3
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulated for wood
furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
