BLU Tank 4.5 User Manual

TANK 4.5 USER MANUAL

Table of Contents

Safety Information 3 Appearance and Key Functions 5 Installation and Charging 6

Safety Password 9 Call Functions 10 Contacts 12 Messaging 14 Internet Browser 16 Settings 16 Application Programs 20 Gallery 22 Camera 23 Music 24 Network Connections 25

Safety Information

Please carefully read the terms below:

Use Safely

Do not use your mobile phone where it might cause danger.

Transportation Safety

Please observe all transportation laws and regulations.

Please drive with both hands on the wheel.

DO NOT TEXT AND DRIVE

Hospitals

Please follow limitations.

Please turn off your mobile phone when near medical instruments.

Airports

Please follow all flight safety regulations and do not use your phone during flight.

Toxic Chemicals

Do not use your mobile phone around fuels or chemicals.

Explosion Hazard

Please observe related limitations and do not use your mobile phone around an area where explosions may occur.

Accessories and Batteries

Please use only Blu authorized accessories and batteries.

Backup

Please remember to make a backup or keep a written record of all important information saved in your mobile phone.

SOS Emergency Calls

Make sure your mobile phone is switched on and in a service area. In home screen, tap the phone key and dial 911

and send.

Appearance and Key Functions

Receiver

Speaker

Battery Cover USB

Camera

Power

Headphone

LCD

Back

Home

Volume

Installation and Charging

Figure 1

Figure 5

Figure 2

Figure 3

Figure 4

Battery Removal and Installation

The phone battery may be removed as per the following procedures:

1. Open the battery cover from the bottom notch (As per the arrow position shown in the figure)

2. Open from the gap at the bottom and open from two sides (As per the arrow position shown in the figure)

3. Put your fingernail deep into the gap and open the battery case (As per the arrow position shown in the figure)

4. The battery cover is fully removed.

Phone Battery Installation Steps:

1. Align the battery metal contact end to the contact of the phone body and insert the battery into the square slot of the phone body. Place the battery in place as per the arrow direction, as shown in Figure 5.

Figure 6

2. Place the battery cover slightly on the phone body and press the cover downward as per the direction shown in Figure 6 until it is fully engaged with the phone body.

Note: Be sure to power off the phone and remove the external power source before battery removal. It is absolutely

prohibited to take out the battery directly when the phone is powered on, otherwise, the SIM card and the phone may

be damaged.

Battery Charging

Plug in the charger and insert the charger interface into the charging jack of the phone, as shown in the figure:

Note: Please carry out the above operations carefully. Do not pull out the charger

improperly as it may damage the phone or the charger.

• The phone battery must be fully charged before use.

• Do not remove the battery or the SIM card during charging.

• The phone will be powered off automatically when the battery runs out of power.

SIM card Installation and Removal The metal contact surface of the SIM card may be easily worn.

Remove the SIM card carefully before inserting it into the phone. Power off the phone, remove the battery and other external power source. Insert the SIM card into the SIM card slot. Ensure that the metal surface of the SIM card faces downward when inserting it into the SIM card slot (As shown in the figure). When you need to take out the SIM card, please power off the phone and remove other external power source and battery then take out the SIM card.

Memory Card Installation and Removal

Memory Card Installation

Install the memory card as per the following procedures: Remove the battery cover and the battery. Push the memory card into the card slot as per the arrow direction shown in the figure.

Memory Card Removal

Remove the memory card as per the following procedures: Remove the battery cover and the battery. Pull the storage out from the card slot as per the arrow direction shown in the figure.
