NEO XL, STUDIO X6

User Manual

2 / 23

Content

1 General Information ................................................................................................................................ 4

1.1 Profile .............................................................................................................................................................. 4

1.2 Safety warning and Attentions ......................................................................................................................... 4

2 Your phone ................................................................................................................................................ 6

2.1 Phone overview ............................................................................................................................................... 6

2.2 Functions of Keys ............................................................................................................................................ 6

2.3 Functions of icons ............................................................................................................................................ 6

3 Getting started .......................................................................................................................................... 7

3.1 Installing the SIM Card and the Battery .......................................................................................................... 7

3.2 Installing Memory Card ................................................................................................................................... 7

3.3 Charging the Battery ........................................................................................................................................ 7

3.4 Linking to the Networks and devices............................................................................................................... 8

3.5 Using the onscreen keypad .............................................................................................................................. 9

3.6 Dialing Calls .................................................................................................................................................... 9

4 Using the Menus ...................................................................................................................................... 11

4.1 Play Store ....................................................................................................................................................... 11

4.2 Amazon .......................................................................................................................................................... 11

4.3 Amazon Kindle .............................................................................................................................................. 11

4.4 Apps & Games ............................................................................................................................................... 11

4.5 BLU Help ...................................................................................................................................................... 11

4.6 Calculator ....................................................................................................................................................... 11

4.7 Calendar ......................................................................................................................................................... 11

4.8 Camera ........................................................................................................................................................... 12

4.9 Chrome .......................................................................................................................................................... 12

4.10 Clock .............................................................................................................................................................. 13

4.11 Contacts ......................................................................................................................................................... 13

4.12 Downloads ..................................................................................................................................................... 13

4.13 Drive .............................................................................................................................................................. 13

4.14 Email .............................................................................................................................................................. 13

4.15 File Manager .................................................................................................................................................. 14

4.16 Flashlight ....................................................................................................................................................... 14

4.17 FM Radio ....................................................................................................................................................... 14

4.18 Gallery ........................................................................................................................................................... 14

4.19 Gmail ............................................................................................................................................................. 14

3 / 23

4.20 Google ........................................................................................................................................................... 14

4.21 Google Settings .............................................................................................................................................. 14

4.22 Hangouts ........................................................................................................................................................ 14

4.23 Maps .............................................................................................................................................................. 14

4.24 McAfee Security ............................................................................................................................................ 14

4.25 Messaging ...................................................................................................................................................... 15

4.26 Music ............................................................................................................................................................. 15

4.27 NextRadio ...................................................................................................................................................... 16

4.28 Opera ............................................................................................................................................................. 16

4.29 Phone ............................................................................................................................................................. 16

4.30 Photos ............................................................................................................................................................ 16

4.31 Play Movies & TV ......................................................................................................................................... 16

4.32 Play Music ..................................................................................................................................................... 16

4.33 Search ............................................................................................................................................................ 16

4.34 Settings .......................................................................................................................................................... 16

4.35 SIM Toolkit .................................................................................................................................................... 17

4.36 Sound Recorder ............................................................................................................................................. 18

4.37 Voice search ................................................................................................................................................... 18

4.38 Weather .......................................................................................................................................................... 18

4.39 YouTube ......................................................................................................................................................... 18

5 Appendix ................................................................................................................................................. 19

4 / 23

1 General Information

1.1 Profile

Please read this pamphlet carefully in order to make your phone in perfect condition.

Our company may change this mobile phone without prior written notice and reserves the final

right to interpret the performance of this mobile phone.
Due to different software and network operators, display on your phone may be different, refer
to your phone for details.

1.2 Safety warning and Attentions

Safety warning

 ROAD SAFETY COMES FIRST

Do not use a hand-held phone while driving. Use hands-free fittings when calls are

unavoidable while driving. In some countries, dialing or receiving calls while driving is illegal!

 SWITCH OFF IN AIRCRAFT

Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and
risky.
Please make sure that your mobile phone is powered off in flight.

 SWITCH OFF BEFORE ENTERING RISKY AREAS

Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky
areas. Turn off your mobile phone before entering a place susceptible to explosion, such as an oil
station, oil tank, chemical plant or a place where a blasting process is under way.

 OBSERVE ALL SPECIAL REGULATIONS

Follow any special regulations in force in any area such as hospitals and always switch off
your phone whenever it is forbidden to use it or, when it may cause interference or danger. Properly
use your mobile phone near medical apparatuses, such as pacemakers, hearing aids and some other
electronic medical devices, as it may cause interference to such apparatuses.

 INTERFERENCE

The conversation quality of any mobile phone may be affected by radio interference. An
antenna is built inside the mobile phone and located below the microphone. Do not touch the
antenna area during a conversation, lest that the conversation quality deteriorate.

 QUALIFIED SERVICE

Only qualified personnel may install or repair phone equipment. Installing or repairing the
mobile phone on your own may bring great danger and violates the warranty rules.

 ACCESSORIES AND BATTERIES

Use only approved accessories and batteries.

 USE SENSIBLY

Use only in a normal and proper manner.

 EMERGENCY CALLS

Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then
press the Dial key. Give your location and state your situation briefly. Do not end the call until told
to do so.

Note: Just like all other mobile phones, this mobile phone does not necessarily support all the
features described in this manual due to network or radio transmission problems. Some networks
even do not support the emergency call service. Therefore, do not rely solely on the mobile phone

5 / 23

for critical communications such as first aid. Please consult the local network operator.

Precautions

This mobile phone is well designed with fine art. Please exercise special care when using it.
The following suggestions will help your mobile phone survive the warranty period and extend its
service life:

 Keep the mobile phone and all its fittings beyond children's reach.
 Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may

corrode electronic circuits.

 Do not use or store the mobile phone in dusty places, lest that active parts of the mobile phone be

damaged.

 Do not store the mobile phone in a high-temperature place. High temperature will shorten the life

of electronic circuits and damage the battery and some plastic parts.

 Do not store the mobile phone in a chilly place. Otherwise, moistures will be formed inside the

mobile phone to damage electronic circuits when the mobile phone is moved to a constant
temperature place.

 Do not throw, knock or shock the mobile phone, as that will destroy the internal circuits and

high-precision components of the mobile phone.

6 / 23

2 Your phone

2.1 Phone overview

2.2 Functions of Keys

The mobile phone provides the following keys:
 Power key

Power key situates on the right side of the phone. While using the phone, you can press this key
to lock screen; if you press and hold this key, a phone-options dialog would pop out. Here, you
can select to power off or reboot.

 Volume key

Volume key situates on the right side of the phone. You can press it to adjust ringer volume.

2.3 Functions of icons

 Menu icon

Touch this icon to enter the recent run of the application．
 Home icon

Touch it to open home screen. If you’re viewing the left or right extended Home screen, touch

it can enter the home screen.
 Back icon

Touch this icon to return to the previous screen;

7 / 23

3 Getting started

3.1 Installing the SIM Card and the Battery

A SIM card carries useful information, including your mobile phone number, PIN (Personal
Identification Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI
(International Mobile Subscriber Identity), network information, contacts data, and short messages
data.

Note:

After powering off your mobile phone, wait for a few seconds before removing or inserting A
SIM card.

Exercise caution when operating A SIM card, as friction or bending will damage the SIM card.

Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.

Installation

 Hold the power key for a while and select power off to power off the mobile phone
 Take the back cover away.
 Insert the SIM Card into the SIM Card slot lightly with the corner cutting of the card aligning

to the notch of the slot and the gold plate of the card facing download, till the SIM Card
cannot be further pushed in.

3.2 Installing Memory Card

 The Memory Card is a pluggable mobile storage card inside the mobile phone.
 To install the Memory Card, Insert the Memory card into the Memory card slot lightly with

the corner cutting of the card aligning to the notch of the slot and the gold plate of the card
facing download, till the Memory card cannot be further pushed in.

Note:

The SD card is a miniature object. Keep it out of the reach of children for avoid children

swallow it!

3.3 Charging the Battery

 Your mobile phone can monitor and display the battery state.
 Normally the remaining energy of the battery is indicated by the battery level icon at the

upper right corner of the display screen.

 When the battery energy is insufficient, the mobile phone prompts "Battery is low".

Using a travel adapter:

 Install the battery into the mobile phone before charging the battery.
 Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure

that the adapter is fully inserted.

 Insert the plug of the travel charger to an appropriate power outlet.
 During charging, charging icon will be displayed．

Note:

Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable
are inserted in the right direction. Inserting them in a wrong direction may cause charging failure
or other problems.

8 / 23

Before the charging, ensure that the standard voltage and frequency of the local mains supply match
the rated voltage and power of the travel charger.

Optimizing battery life

You can extend your battery’s life between charges by turning off features that you don’t need.
You can also monitor how applications and system resources consume battery power.

To guarantee the optimal performance of your battery, please stick to the following rules:

 Turn off radios that you aren’t using. If you aren’t using GPRS, use the Setting application to

turn them off.

 Turn down screen brightness and set a shorter screen timeout.
 If you don’t need them, turn off automatic syncing for Gmail, Calendar, Contacts, and other

applications.

Note: On the Home screen, press Menu icon and touch System Settings >Battery. The Battery
Use screen lists the applications that have been using the battery. Then each application or service
that used battery power during that time is displayed, in order of the amount of power they used.
Touch an application in the Battery Use screen to learn details about its power consumption.
Different applications offer different kinds of information.

3.4 Linking to the Networks and devices

Your phone can connect to a variety of networks and devices, including mobile networks for
voice and data transmission, Wi-Fi data networks, and Bluetooth devices, such as headsets. You can
also connect your phone to a computer to share your phone’s mobile data connection via USB.

Connecting to mobile networks

When you assemble your phone with a SIM card, your phone is configured to use your
provider’s mobile networks for voice calls and for transmitting data.
Connecting to Wi-Fi networks

Wi-Fi is a wireless networking technology that can provide Internet access at distances of up to
100 meters, depending on the Wi-Fi router and your surroundings.

Touch Settings > Wireless & networks >Wi-Fi. Check Wi-Fi to turn it on. The phone scans for
available Wi-Fi networks and displays the names of those it finds. Secured networks are indicated
with a Lock icon.

Note: If the phone finds a network that you connected to previously, it connects to it
automatically.

Touch a network to connect to it. If the network is open, you are prompted to confirm that you
want to connect to that network by touching Connect. If the network is secured, you’re prompted to
enter a password or other credentials.
Connecting to Bluetooth devices

Bluetooth is a short-range wireless communications technology that devices can use to transfer
information over a distance of about 8 meters. The most common Bluetooth devices are headphones
for making calls or listening to music, hands-free kits for cars, and other portable devices, including
laptops and cell phones.
Touch Settings> Wireless & networks >Bluetooth. Check Bluetooth to turn it on.

You must pair your phone with a device before you can connect to it. Once you pair your

phone with a device, they stay paired unless you unpaired them.

9 / 23

Your phone scans for and displays the IDs of all available Bluetooth devices in range. If the
device you want to pair with isn’t in the list, make it discoverable.

Using the touch screen．

 Touch-screen tips

 Touch

To act on items on the screen, such as application and settings icons, to type letters and
symbols using the onscreen keyboard, or to press onscreen buttons, you simply touch them with
your finger.

 Touch & hold

Touch & hold an item on the screen by touching it and not lifting your finger until an action
occurs. For example, to open a menu for customizing the Home screen, you touch an empty area on
the Home screen until the menu opens.

 Drag

Touch & hold an item for a moment and then, without lifting your finger, move your finger on
the screen until you reach the target position.

 Swipe or slide

To swipe or slide, you quickly move your finger across the surface of the screen, without
pausing when you first touch it (so you don’t drag an item instead). For example, you slide the
screen up or down to scroll a list.
 Lock screen

When Screen lock in Security setting is enabled, press Power key to lock the handset. This
helps to prevent accidental touching of keys and as well as power saving. When Sleep function in
Display setting is enabled, after the handset device has been idle for preset period, the screen will be
locked automatically to save power.

 Unlock screen

Press Power key to switch on the handset device. The lock screen appears. Touch and slide to
up to unlock screen.

3.5 Using the onscreen keypad

You enter text using the onscreen keyboard. Some applications open the keyboard automatically.

In others, you touch a text field where you want to enter text to open the keyboard.
 To enter text

Touch a text field, and the onscreen keyboard opens. Some applications open the keyboard

automatically. In others, you touch a text field where you want to enter text to open the keyboard.

 Touch the keys on the keyboard to type.

The characters you’ve entered appear in the text field, with suggestions for the word you are
typing below.

 Use the Delete icon to erase characters to the left of the cursor.

After finishing typing, touch Back icon to close the keyboard.

3.6 Dialing Calls

 Dialing a call to a number in the contacts

Touch the contacts icon or the phone application icon on the Home screen, then select the
Contacts tab. Swipe or slide upward/downward to pick out the target contact. Then you can touch
the dial icon to originate a call.

10 / 23

 Dialing a call to a number in call log

Touch the Phone icon or the phone application icon on the Home screen, then select the recents
tab. Swipe or slide upward/downward to pick out and touch the target contact. Then you can
originate a call.

 Answering incoming calls

Drag the Answer icon towards right to answer an incoming call.

Touch the End icon to end the current conversation.

To reject an incoming call, drag the End icon towards left.

 Managing multiple calls

If you accept a new call when you’re already on a call, you can drag the Answer icon towards
right to answer the current calls.

11 / 23

4 Using the Menus

4.1 Play Store

Please log in or create your Google account first, then you can download application as you

need.

4.2 Amazon

Please log in or create your Amazon account first, then you can use this function through the

Amazon shopping．

4.3 Amazon Kindle

You can use Amazon Kindle through this function，This is an e-book reader application.

4.4 Apps & Games

Please log in or create your account first, then you can download application as you need.

4.5 BLU Help

You can use this function to enter the BLU homepage．

4.6 Calculator

You can use this Calculator to solve simple arithmetic problems or use its advanced operators
to solve more complex equations.

Enter numbers and arithmetic operators on the basic screen; Drag the basic screen to the left to

open the advanced screen; Touch clear to delete the last number or operator you entered. Touch &
hold clear to delete everything in the display.

4.7 Calendar

You can open Calendar to view events you’ve created.

Touch the Calendar icon in the main menu interface. Events from each account you’ve added
to your phone and configured to synchronize calendars are displayed in Calendar.

Creating an event

You can use Calendar on your phone to create events. In any calendar view, touch the upper
right corner of the icon and touch new event to open an event details screen for a new event.

Enter a name, time, and optional additional details about the event. You can touch add
reminder menu to add more reminders. In the Guests field, you can enter the email addresses of
everyone you want to invite to the event. Separate multiple addresses with commas, if the people to
whom you send invitations use Google Calendar, they’ll receive an invitation in Calendar and by
email. On the top of the event details screen and touch Done and the event is added to your
calendar.

Synchronizing and displaying calendars

When you add a Google Account or Microsoft Exchange ActiveSync account to your phone
that includes a calendar service, and you configure that account to synchronize calendar events to
the phone, the events from that calendar are added and kept up to date in Calendar on the phone.

In calendar screen, touch the upper right corner of the icon and touch Calendars to display >

Calendars, here, you can set whether calendars are stored on the phone or visible. The Calendars
screen displays all the calendars you’ve added or subscribed to for each account that is configured

12 / 23

to synchronize events to your phone, organized by account. Touch the name of an account to show
or hide its calendars on your phone. An icon to the right of each calendar indicates whether its
events are synchronized in the phone and whether they are visible in Calendar.
Change Calendar settings

You can change the following settings for how Calendar displays event and how it notifies you
of upcoming events. Open a Calendar view, touch the upper right corner of the icon and touch
settings.

4.8 Camera

Touch the Camera icon in the main menu interface or on the home screen, camera opens in
Landscape mode, ready to take a picture. In this mode, you can touch the bottom icon to take a
photo, touch the icon beside start icon to switch between camera and video mode.

4.9 Chrome

You can use Chrome to view web pages and search for information on the web.

When you open Chrome your homepage opens. The web address (URL) of the current page is
displayed at the top of the window.

To go to a webpage or search the web

Touch the URL box at the top of the Chrome screen. Enter the address (URL) of a webpage.
Or enter terms you want to search for. As you enter text, your web search engine makes suggestions
of web pages and queries.
To refresh the current page
Touch the upper right corner of the icon and an option interface appears, then you can touch
Refresh icon to update the current web page.
To find text on a webpage

Touch the upper right corner of the icon and an option interface appears > Find in page. Enter
the text you’re looking for. As you type, the first word with matching characters is highlighted on
the screen, and subsequent matches are boxed. Touch the left or right arrow to scroll to and
highlight the previous or next matching word.
Copy text from webpage

Use your finger to long press the text you want to copy. It will pop up some options, select the
Select text option to select the text you want, and then touch the icon at the right top corner of the
screen to copy or share the text.

Navigate among webpage

You can open links on a webpage, navigate back and forward, and review your browsing
history, just as in any web browser.
To open a link: Touch a link to open it. Links that you touch are highlighted in orange until the
webpage they refer to opens in the window.

To go back and forward among the pages you’ve opened: Press back key or touch forward icon.
To view your Browser history: As you browse the web, Browser keeps track of the pages you
visit, to help you find your way back later. Touch the icon which situates at the right of the URL box,
then touch History tab, and then you can view your browser history.
Downloading files

You can download files and even applications from webpage. The files that you download are
stored on your SD card.

13 / 23

To download a file, Different webpage offer different mechanisms for downloading pictures,
documents, applications, and other files. Touch & hold an image or a link to a file or to another
webpage. In the menu that opens, touch Save. If the file is in a format supported by an application
on the phone, it is downloaded to your SD card. Main menu > Downloads, you can find a list of
downloaded files. If you want to delete a file, just touch and hold the target file, and an option box
will pop out, here, you can select delete to delete an unnecessary file.
Working with bookmarks
Open a web page to bookmark, touch the upper right corner of the icon> Bookmarks, here, you
can view bookmarks displayed.

Touch & hold a bookmark, an option box will pop out. There, you can perform the following
operations on bookmarks: Open in new tab, Open in incognito tab and Delete bookmark．

4.10 Clock

Touch the Clock icon in the main menu interface or on the home screen. Clock opens with the
date and time displayed on your Home screen wallpaper.

You can set an alarm by modifying an existing alarm or by adding a new one.

Note: Alarms that are set are underlined.

4.11 Contacts

Touch the Contacts icon in the main menu interface or on the home screen．
In the contacts screen, touch the upper right corner of the icon and you can perform the

following operations:

Delete contact: Select this function, then you can mark the target contacts. To delete all

contacts, you just need to touch select all at the top of contacts screen. Last, touch OK and confirm
to delete contacts.

Contacts to display: you can select the contacts on different group to display.
Import/Export: you can import/export the contacts from SIM card or storage;
Accounts: you can sync with your account.
Settings: you can set the display options in this interface.
Share visible contacts: you can share your visible contacts via various ways.

4.12 Downloads

Through this function, you can view a list of files and applications which you downloaded

from the webpage.

4.13 Drive

You can create new or log in exist account through this function.

4.14 Email

You can use the Email application to read and send email.

Touch email icon to access it. If the Email account has not been set up, you can set up an Email

account in a few steps.

 Account setup

Enter an Email address and the account’s password.

 Account settings

 Set inbox checking frequency.
 Set Sync Email from this account.

14 / 23

 Set Automatically download attachments when connected to Wi-Fi.

 Compose and sending Email

To compose and send an Email：

1. Touch the create icon to compose a new Email.

2. Enter Email address(es) for intended recipient(s).

3. Touch the upper right corner of the icon → Attach file to attach a file.

4. Touch the upper right corner of the icon → Add Cc/Bcc to add copy or blind copy this

Email to other contacts.

5. After completing the Email, Touch send icon to send the Email. Touch folder icon to check
the account status. For each Email account there are eight default folders, i.e., Inbox, Starred,
Unread, VIP, Drafts, Outbox, Sent and Trash folders. To view sent Emails, open Sent folder and tap
refresh icon.

4.15 File Manager

The phone supports the SD card. You can use the File Management to conveniently manage

various directories and files on the SD card.

4.16 Flashlight

Touching the switch, you can turn on or off the flashlight.

4.17 FM Radio

Please plug in the compatible earphone to the device and then turn on the radio. The earphone

cable can be used as FM Antenna. Please adjust appropriate volume when listening to the radio.
Continue to use higher volume is harmful for your ear.

4.18 Gallery

Both pictures and videos taken by camera or stored in SD card can be scanned through this

function.

4.19 Gmail

You can create new or log in exist account through this function.

4.20 Google

You can search and view something in your phone or webpage after connect with internet

through this function.

4.21 Google Settings

You can set parameters of Google through this function.

4.22 Hangouts

This is a chat tool of Google, you should create new or log in exist Google account to use this

function.

4.23 Maps

You can use Google maps through this function.

4.24 McAfee Security

McAfee Security is a mobile security application, with which you can protect your mobile
phone.

15 / 23

4.25 Messaging

You can use Messaging to exchange text messages (SMS) and multimedia messages (MMS)

with your friends on their mobile phones.

 Sending a message

1. Touch message icon on the home screen and touch add new message icon to edit a new
message.

2. Enter a contact’s name or call number in the recipient field. As the information is entered,

all matching contacts appear. Touch a suggested contact or multiple contacts as message
recipient(s).

3. Touch Enter message to compose your message. Touch the upper right corner of the icon
to select insert quick text.

4. After completing the message, touch Send icon which beside template icon to send your
message.

 Message template

Message templates can save your time in editing message with similar format. To create a

message template:

1. Touch message icon on the home screen and touch the icon and the bottom right hand

corner to enter settings.

2. Touch Text Message enter Edit quick text add new quick text.

4.26 Music

Music plays audio files that are stored on your phone’s SD card, so before you open Music,
you must copy audio files from your computer onto the SD card. Music supports a wide variety of
audio file formats, so it can play music that you purchase from online stores, music that you copy
from your CD collection, and so on.

To open Music and view your music library

Touch the Music icon in the main menu interface or on the Home screen.

When you copy music to your SD card, Music searches the card for music files and builds a
catalog of your music, based on information about each file that is stored in the file itself. This can
take from a few seconds to several minutes, depending on how many files you have copied onto the
SD card . When the catalog is complete, the Music library screen opens, with tabs that you can
touch to view your music library organized by Artists, Albums, Songs or Playlists.

Play music

You can listen to music by using the phone’s built-in speaker, through a wired headset, or
through a wireless Bluetooth stereo headset.

Touch a song in your library to listen to it. The Playback screen opens and the song you
touched starts to play. The Playback screen contains several icons that you can touch to control the
playback of songs. On the right-top of playback screen, you can find three function icons. You can
touch them to open the current playlist, shuffle the current playlist or repeat the current playlist /
repeat the current track (touch twice). Three function icons which situates just above the process bar
can be used to control the playing process of the music application. Their functions can be defined
as the following: switch to last song (touch) /rewind (touch & hold), play/pause and switch to next
song (touch)/ fast forward (touch & hold).

16 / 23

To delete a song from the SD card

You can delete music from the storage card. Touch & hold a song in a library list. In the menu
that opens, touch Delete.

4.27 NextRadio

You can listen to FM radio on your phone with NextRadio.

4.28 Opera

You can use Opera to view web pages and search for information on the web.

4.29 Phone

Touch the Phone icon on the Home screen or in main menu interface. Three tabs are listed at

the bottom of the screen. Select the phone tab and you can find a dial pad screen where you

can input phone number to originate a call.

Note: During a conversation, you can’t originate a new call by open the dial pad, enter

number and press dial key. If you press dial key, the current conversation would hold.

4.30 Photos

You can log in your Google account view your photos and videos.

4.31 Play Movies & TV

You can create new or log in exist Google account to see a movie film-watch.

4.32 Play Music

You can play songs of the SD card and you can create a new Google account or log in

existence, purchase and play Google Play Music Store songs.

4.33 Search

You can search any application in your phone or website after connected to internet.

4.34 Settings

The Settings application contains most of the tools for customizing and configuring your

phone.

【WIRELESS & NETWORK】

You can use Wireless & Network settings to manage your SIM card, configure and
manage connections to networks and devices by using Wi-Fi. You also can set Bluetooth, data
usage, airplane mode, default SMS app, tethering & portable hotspot，VPN ,mobile networks
and USB internet in this interface.

【DEVICE】

 Display
 You can set MiraVision, Wallpaper, Brightness level, Adaptive brightness, Sleep,

Daydream, Font size and Auto-rotate screen in this interface.

 Sound & notification

There are four profiles: General, Silent, Meeting and Outdoor. You can set the profiles

according to different conditions.

 Storage

17 / 23

Use the Storage settings to monitor the used and available space on your phone and on your
SD card and to manage your SD card.

 Battery

You can set CPU power saving mode and view your battery status, battery level and battery
use in this interface.

 Apps

You can use the Applications settings to view details about the applications installed on your
phone, to manage their data and force them to stop, to view and control currently running services,
and to view the storage used by applications, etc.

 User

With this feature you can add or remove the phone users.

【PERSONAL】

 Location

You can set Mode as you need. Management your Google Location requests etc through this

function.

 Security

You can set the parameters about security through this function.

 Accounts

You should add account first before using this function.

 Language & input

Use the Language & Keyboard settings to select the language for the text on your phone and for

configuring the input method.

 Backup & reset

You can backup your data and reset your phone in this interface.

【SYSTEM】

 Date & time

You can use Date & Time settings to set your preferences for how dates are displayed. You can

also use these settings to set your own time and time zone, rather than obtaining the current time
from the network, etc.

 Scheduled power on & off

You should set a certain time, when the time arrive, the phone would power on/off

automatically.

 Accessibility

You use the Accessibility settings to configure any accessibility plug-ins you have installed on
your phone.

 Printing

You can connect to printer and print something you need through this function.

 About device

This function enables you to view some phone related information.

4.35 SIM Toolkit

STK service is the tool kit of SIM card. This phone supports the service function .The specific
items are depended by SIM card and network. Service menu will be auto added to the phone menu
when supported by network and SIM card.

18 / 23

4.36 Sound Recorder

Use this function to record audio files. Two function icons at the bottom of the Recorder screen

are corresponding to start /stop recording, review record file.

4.37 Voice search

You can search any application in your phone or website through voice after connected to

internet.

4.38 Weather

First, add one or more cities. And view the weather in various cities.

4.39 YouTube

You can enter YouTube interface through this access.

19 / 23

5 Appendix

Appendix 1：Troubleshooting

If you find exceptions when operating the mobile phone, restore the factory settings and then refer
to the following table to solve the problem. If the problem persists, contact the distributor or service
provider.

Fault

Cause

Solution

SIM
card

error

The SIM card

is damaged.

Contact your network service provider

The SIM card

is not in

position.

Check the SIM card

The metal

face of the

SIM card is

polluted.

Clean the SIM card with a clean cloth

Poor received
signal quality

Signals are
obstructed.

For instance,

radio waves

cannot be

effectively

transmitted
nearby a high
building or in

a basement.

Move to a place where signals can be effectively transmitted

Line

congestions

occur when

you use the
mobile phone
in high-traffic

hours

Avoid using the mobile phone in high-traffic hours

The mobile

phone cannot

be powered on

The battery

energy is

exhausted.

Charge the battery

20 / 23

Calls cannot be

dialed

Call barring is

activated

Cancel call barring

The mobile

phone cannot

connect the

network

The SIM card

is invalid

Contact your network service provider

The mobile

phone is not

in a service

area of the

GSM network

Move to the network operator's service area

The signal is

weak

Move to a place where the signal quality is high

The battery

cannot be

charged

The charging

voltage does

not match the

voltage range

indicated on

the charger

Ensure the charging voltage matches the voltage range

indicated on the charger

An improper

charger is

used

Use the charger specially designed for the mobile phone

Poor contact

Ensure the charger plug is in good contact with the mobile

phone

21 / 23

FCC Regulations:

This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This mobile phone has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiated radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

-Consult the dealer or an experienced radio/TV technician for help.

FCC Note:
Caution: Changes or modifications not expressly approved by the party responsible for compliance
could void the user‘s authority to operate the equipment.

22 / 23

RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications Commission of the United States.

During SAR testing, this device was set to transmit at its highest certified power level in all tested
frequency bands, and placed in positions that simulate RF exposure in usage against the head with
no separation, and near the body with the separation of 10 mm. Although the SAR is determined at
the highest certified power level, the actual SAR level of the device while operating can be well
below the maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.

The exposure standard for wireless devices employing a unit of measurement is known as the
Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg.

This device is complied with SAR for general population /uncontrolled exposure limits in
ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods and
procedures specified in IEEE1528.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this
model phone is on file with the FCC and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: YHLBLUNEOXL.

For this device, the highest reported SAR value for usage against the head is 0.18 W/kg, for usage
near the body is 0.53 W/kg.

While there may be differences between the SAR levels of various phones and at various positions,
they all meet the government requirements.

SAR compliance for body-worn operation is based on a separation distance of 10 mm between the
unit and the human body. Carry this device at least 10 mm away from your body to ensure RF
exposure level compliant or lower to the reported level. To support body-worn operation, choose the
belt clips or holsters, which do not contain metallic components, to maintain a separation of 10
mm between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not tested and
certified, and use such body-worn accessory should be avoided.

23 / 23

ISED Notice

This device complies with Innovation, Science and Economic Development Canada license-exempt
RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.

Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

IC: 11492A-NEOXL

ISED Radiation Exposure Statement

This EUT is compliance with SAR for general population/uncontrolled exposure
limits in ISED RSS-102 and had been tested in accordance with the measurement
methods and procedures specified in IEEE 1528 and IEC 62209. This equipment
should be installed and operated with minimum distance 1.0 cm between the
radiator and your body. This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or transmitter.

Cet appareil est conforme aux limites d'exposition DAS incontrôlée pour la population
générale de la norme CNR-102 Innovation, Sciences et Développement économique Canada
et a été testé en conformité avecles méthodes de mesure et procédures spécifiées dans IEEE 1528 et
IEC 62209. Cet appareil doit être installé et utilisé avec une distance minimale de 1.0 cm entre
l’émetteur et votre corps. Cet appareil et sa ou ses antennes ne doivent pas être
co-localisés ou fonctionner en conjonction avec tout autre antenne ou transmetteur.
