BLU DeeJay User Manual
DeeJay
User Manual
2
Contents
1 About your Mobile Phone .............................. 8
1.1 Appearance ........................................... 8
1.2 Key instructions .................................... 9
1.3 Icons......................................................11
2 Getting started ............................................... 12
2.1 The Battery ......................................... 12
2.1.1 Install & remove a battery ...... 13
2.1.2 Charging ............................... 13
2.2 SIM card installation .......................... 14
2.3 Memory card installation ................... 15
2.4 Storage Management......................... 15
2.5 Power on and off ................................ 16
3 Call functions ................................................... 17
3.1 Make a call .......................................... 17
3.1.1 Make a domestic call .............. 17
3.1.2 Make an extension call ........... 18
3.1.3 Make an international call ....... 18
3.1.4 Make a call from Mobile Phone
book 18
3.1.5 Redial a call by recent call lists 19
3.2 Answer a call ....................................... 19
3
3.3 Reject a call ......................................... 19
3.4 Call options .......................................... 20
4 Menu functions ............................................... 20
4.1 Messages ............................................. 20
4.1.1 SMS ...................................... 20
4.1.2 MMS ..................................... 25
4.1.3 Voice mail server .................... 28
4.1.4 Broadcast Message ................ 28
4.2 Multimedia ........................................... 29
4.2.1 Image Viewer ........................ 29
4.2.2 Audio Player .......................... 29
4.2.3 Sound Recorder ..................... 29
4.2.4 FM Radio ............................... 29
4.3 Organizer ............................................. 30
4.3.1 Calendar ............................... 30
4.3.2 To do .................................... 31
4.3.3 Alarm .................................... 31
4.3.4 World Clock ........................... 31
4.4 Settings ................................................ 32
4.4.1 Phone Setup .......................... 32
4.4.2 Network Setting ................... 33
4.4.3 Security Setup ....................... 34
4
4.4.4 Restore Factory settings .......... 37
4.4.5 Sound effect .......................... 37
4.5 User profiles ........................................ 38
4.6 Services ................................................ 38
4.7 Shortcuts ............................................. 38
4.8 File Manager........................................ 39
4.9 Phonebook ........................................... 39
4.9.1 Quick Search ......................... 40
4.9.2 Search Entry .......................... 40
4.9.3 Add new contact .................... 40
4.9.4 Copy All ................................ 41
4.9.5 Delete ................................... 42
4.9.6 Caller group........................... 42
4.9.7 Extra Number ........................ 42
4.9.8 Settings ................................ 43
4.9.9 Caller Picture ......................... 43
4.9.10 Call Ring Tone........................ 43
4.10 Call center ........................................... 44
4.10.1 Call history ............................ 44
4.10.2 General call settings ............... 44
5 Battery information ...................................... 47
6 Safety information ........................................ 49
5
6.1 Operating environment...................... 49
6.2 Electronic devices ............................... 49
6.2.1 Pacemaker ............................ 50
6.2.2 Hearing aids .......................... 50
6.2.3 Other medical devices ............ 51
6.2.4 Vehicles ................................ 51
6.3 Potentially dangerous situations ...... 52
7 Care and maintenance ................................. 53
Preface
Thank you very much for your choice of this product designed
by our company!
Our Mobile Phone complies with the Telecommunication
industries standards of both the People's Republic of China
and Europe.
The product described in this guide is approved for use on
the GSM networks, and has the GPRS functions.
GSM network is a global cellular communications system of
international standards.
Allow you to receive an international telephone call used as in
6
your homeland.
However, before using these advanced network functions,
you must firstly apply for these required services.
In order to better use your mobile phone, we suggest you to
carefully read this statement to know all the functions well.
Note: Due to the cellular network settings and the services
provided, some functions may be unavailable, please query
local service providers.
For your safety
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in
this manual.
ROAD SAFETY
Always keep your hands free to operate the vehicle while
driving. Park the vehicle before using your Mobile Phone.
SWITCH OFF IN AIRCRAFT
Using of wireless telephones in aircraft may disrupt the
operation of the aircraft. It is dangerous and illegal. Insure
switching off the Mobile Phone before going aboard.
7
SWITCH OFF IN HOSPITALS
Follow any restrictions or rules. Switch off the Mobile Phone
near medical equipment.
SWITCH OFF WHEN REFUELING
Switch off the Mobile Phone at a refueling point or any fuel or
chemicals places.
SWITCH OFF NEAR BLASTING POINT
Don‟t use the Mobile Phone where blasting is in progress.
Observe restrictions, and follow any regulations or rules.
INTERFERENCE
All wireless Mobile Phones may be susceptible to interference,
which could affect the performance.
USE NORMALLY
Use in the normal position explained in the product
documentation. Don't touch the antenna unnecessarily.
ENHANCEMENTS AND BATTERIES
Use only the approved enhancements and batteries. Do not
connect incompatible products.
EMERGENCY CALLS
Ensure the Mobile Phone is switched on and in service. Enter
the emergency number, and then press the key. It will give
your location. Do not end the call until the permission.
8
MODEL
Model
DeeJay
1 About your Mobile
Phone
1.1 Appearance
9
Size
44.5*102.8*15.2 mm
Weight
70g(battery included)
BATTERY
Type
Lithium battery
Standard Voltage
3.7 V
Restrictions on
Charging voltage
4.5 V
Rated capacity
800 mAh
CHARGER
Model
DeeJay
Input
110-220V
Output
5.0V
Earphone cable
specif ication
IO
Operating
Temperature
-30° ~ + 50°C
Keypad name
Keypad Function Introduce
Left-soft-key
Enter the main menu~ Carries out the screen left
under angle guidance symbol to demonstrate the
function.
1.2 Key instructions
10
Right-soft-key
Enter the phone book~ Carrie
Set out the screen right under angle guidance
symbol to demonstra te the function.
Direction key
up
It‟s used to choose the all function
down
Left
right
OK
Dial Key
Received the incoming call
Dial the telephone number
Electric-key
Short Press: end the call and
refuse the ca ll
Long Press : Turn on or Tur n off
the mobile phone
0, ~9
User can type the numeric when
the mobile is standby
* Short press~ Dials the telephone
number by the host card way~
*
#
Long press ~ cut the realization +,
P, W
11
*
#
Short press~ Dials the telephone
number by the host card way~
and enter #
Long press ~ cut the realization
quiet/normal mode
Icon
Description
Signal Intensity
Battery Capacity
Connected to the GSM/GPRS networks
Unread SMS
Has been set up and activated the alarm
Prompted calls will be set to signal
mode.( General pattern)
Prompted calls set to vibration mode.
（Conference mode）
1.3 Icons
ICONS Detail
12
Prompted calls for the setting rings and
vibration mode.（Outdoor model）
Prompted calls after the signal is set to
vibration mode
Headset status
Missed call records
2 Getting started
2.1 The Battery
The lithium battery can be charged and discharged hundreds
of times. Please use the approved batteries, and only use the
battery charger approved by the Mobile Phone producer to
charge your battery.
13
2.1.1 Install & remove a battery
Remove:
(1)Slide forward the bottom off the back cover to remove.
(2) Lift the battery from its slot and take it out.
Install:
(1) Place the battery into the battery slot.
(2) Slide the back cover toward the top of the Mobile Phone
to lock the cover into its place.
2.1.2 Charging
To plug in the power charger, the charger cable plug at the
bottom of the Mobile Phone
Note:
1. It is beneficial to the battery to charge it until full at the
first three times.
2. When charging, don‟t remove or take out off the battery
to avoid the battery circuit to burn out.
3. While charging, it is normal that the Mobile Phone and
charger will become hot.
14
Warning: Provides charging temperature range
-5 ℃ to 55 ℃, over this range, please do not use the
charging equipment. And be sure to use the charger
provided by the supplier. Use of an unapproved
charger may be dangerous and breach of warranty
of the equipment approval and terms.
4. If the battery is completely empty, it may take a period of
time before the charging icon appears on the display.
Notice:
The socket-outlet shall be installed near the equipment
and shall be easily accessible。
2.2 SIM card installation
Turn off the Mobile Phone, and take out the battery.
Keep the gold color side of the SIM card downward, and slide
it gently to the right place.
15
2.3 Memory card installation
Power off the Mobile Phone, and take out the battery or any
other electrical supply.
Keep the golden color side of the Memory card downward,
and push it gently to the right place.
Before take out off the memory card, be sure to Power off the
Mobile Phone and remove the battery first.
2.4 Storage Management
To manage the memory card storage space.
1. The computer and synchronize
Note: This Mobile Phone does not support USB boot function;
all operations are on the computer need to use the card
reader.
You can enter after the discovery has a number of preset
folders, for normal use, set the relevant documents were
deposited with the corresponding directory, that is, which
corresponds to MP3 folder My music, photos corresponding
16
album Folder, corresponding folders, pictures corresponding
Images folder. Sound recording, self-Tone Audio
corresponding folder.
2. Format
If you format the memory card, all files saved in it will be lost.
By two ways you can format your Memory card:
Format by Mobile Phone: enter File Manager—>select
Memory card —>select Format.
Format by computer: Please complete the format work as
following steps:
(1) Right-click "My Computer" and choose "management",
after entering the option "store" -> "Disk Management";
(2) In the memory card on the disk where the right-click and
choose "format";
2.5 Power on and off
Press and hold key to turn on/off the Mobile Phone.
And if you have set PIN or Mobile Phone code, input it
correctly.
17
3 Call functions
3.1 Make a call
When the network supplier's symbol appears when the
display monitors, you might dial or answer the mobile phone.
Under readiness for action, display monitor top left-hand
corner information strip demonstration network signal
strength (when has 4 information strip expressed signal is
strongest).After the user inserts SIM cards, may realize the
double caliper also to wait for an opportunity.
3.1.1 Make a domestic call
Enter the Mobile Phone number including the area code.
Press Key to make a call.
18
3.1.2 Make an extension call
When making an extension call, press and hold 0 key to get
“P” that is a prefix of extension numbers. It will dial
automatically in several seconds since you dialed the mobile
phone exchange.
viz.: area code—telephone exchange numbers—P—extension
numbers, then press key.
3.1.3 Make an international call
Enter the country code, the area code and the Mobile Phone
number, press key to dial. ”+” is needed when input
country code, and it can be got by pressing and holding 0 key.
Dial to Hong Kong, Macao and Taiwan Mobile Phone ibid.
3.1.4 Make a call from Mobile Phone
book
Enter the telephone directory tabulation, the telephone
Loading...
