Bloomfield T-4C 15A, T-4C, BT-4C User Manual

WELLS BLOOMFIELD, LLC

2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439

telephone: [phone]

fax: [phone]

www.wellsbloomfield.com

OPERATION MANUAL

ELECTRONIC

TOASTERS

201

for

POP-UP

Models:

T-4C

T-4C 15A

and

Model T-4C 15A

This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of

THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS U S ING OR

BAGEL

TOASTERS

Model:

BT-4C

Includes

INSTALLATION

USE & CARE

IMPORTANT: DO NOT DISCARD THIS MANUAL

this appliance. Additional manuals are available from your WELLS DEALER.

INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any

questions concerning installation, operation or maintenance of this equipment.

PRINTED IN UNITED STATES OF AMERICA

p/n 40091 Rev. G ECN-13372 M201 071026 cps

LIMITED WARRANTY STATEMENT

Unless otherwise specified, all commercial cooking
equipment manufactured by WELLS BLOOMFIELD, LLC is
warranted against defects in materials and workmanship for
a period of one year from the date of original installation or
18 months from the date of shipment from our factory,
whichever comes first, and is for the benefit of the original
purchaser only.
THIS WARRANTY IS THE COMPLETE AND ONLY
WARRANTY, EXPRESSED OR IMPLIED IN LAW OR IN
FACT, INCLUDING BUT NOT LIMITED TO, WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, AND/OR FOR DIRECT,
INDIRECT OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH WELLS BLOOMFIELD PRODUCTS.
This warranty is void if it is determined that, upon inspection
by an authorized service agency, the equipment has been
modified, misused, misapplied, improperly installed, or
damaged in transit or by fire, flood or act of God. It also
does not apply if the serial nameplate has been removed, or
if service is performed by unauthorized personnel. The
prices charged by Wells Bloomfield for its products are

based upon the limitations in this warranty. Seller’s
obligation under this warranty is limited to the repair of
defects without charge by a Wells Bloomfield factory
authorized service agency or one of its sub-service
agencies. This service will be provided on customer’s
premises for non-portable models. Portable models (a
device with a cord and plug) must be taken or shipped to
the closest authorized service agency, transportation
charges prepaid, for service. In addition to restrictions
contained in this warranty, specific limitations are shown in
the Service Policy and Procedure Guide. Wells Bloomfield
authorized service agencies are located in principal cities.
This warranty is valid in the United States and Canada and
void elsewhere. Please consult your classified telephone
directory, your foodservice equipment dealer or contact:

Service Department, Wells Bloomfield, LLC

P.O. Box 280, Verdi, Nevada 89439

phone [phone] or fax [phone]

for information and other details concerning warranty.

SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS

1. Resetting of safety thermostats, circuit breakers, over
load protectors, and/or fuse replacements are not
covered by this warranty unless warranted conditions
are the cause.

2. All problems due to operation at voltages or phase
other than specified on equipment nameplates are
not covered by this warranty.
Conversion to correct voltage and/or phase must be
the customer’s responsibility.

3. All problems due to electrical connections not made

in accordance with electrical code requirements
and wiring diagrams supplied with the equipment are

not covered by this warranty.

4. Replacement of items subject to normal wear, to
include such items as knobs, light bulbs; and, normal
maintenance functions including adjustments of
thermostats, adjustment of micro switches and
replacement of fuses and indicating lights are not
covered by warranty.

5. Damage to electrical cords and/or plug due to exposure
to excessive heat are not covered by this warranty.

6. Full use, care, and maintenance instructions supplied
with each machine. Noted maintenance and

preventative maintenance items, such as servicing and

cleaning schedules, are customer responsibility. Those
miscellaneous adjustments noted are customer
responsibility. Proper attention to preventative
maintenance and scheduled maintenance procedures
will prolong the life of the appliance.

7. Travel mileage is limited to sixty (60) miles from an
Authorized Service Agency or one of its sub-service
agencies.

8. All labor shall be performed during regular working
hours. Overtime premium will be charged to the buyer.

9. All genuine Wells replacement parts are warranted for
ninety (90) days from date of purchase on non­warranty equipment. This parts warranty is limited only
to replacement of the defective part(s). Any use of

non-genuine Wells parts completely voids any

warranty.

10. Installation, labor, and job check-outs are not

considered warranty and are thus not covered by this
warranty.

11. Charges incurred by delays, waiting time or operating

restrictions that hinder the service technician’s ability to
perform service are not covered by warranty. This
includes institutional and correctional facilities.

201 p/n 40091 OpM T-4C and BT-4C Toaster

SHIPPING DAMAGE CLAIM PROCEDURE

NOTE: For your protection, please note that equipment in

this shipment was carefully inspected and packaged by
skilled personnel before leaving the factory. Upon
acceptance of this shipment, the transportation company
assumes full responsibility for its safe delivery.
IF SHIPMENT ARRIVES DAMAGED:

1. VISIBLE LOSS OR DAMAGE: Be certain that any
visible loss or damage is noted on the freight bill or
express receipt, and that the note of loss or damage is
signed by the delivery person.

2. FILE CLAIM FOR DAMAGE IMMEDIATELY:

Regardless of the extent of the damage.

3. CONCEALED LOSS OR DAMAGE: if damage is
unnoticed until the merchandise is unpacked, notify the
transportation company or carrier immediately, and file
“CONCEALED DAMAGE” claim with them. This
should be done within fifteen (15) days from the date
the delivery was made to you. Be sure to retain the
container for inspection.

Wells Bloomfield cannot assume liability for damage or loss
incurred in transit. We will, however, at your request, supply
you with the necessary documents to support your claim.

xi

TABLE OF CONTENTS

WARRANTY xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS &GENERAL INFORMATION 3
AGENCY APPROVAL INFORMATION 3
INSTALLATION 4
OPERATION 5
CLEANING INSTRUCTIONS 6
TROUBLESHOOTING 7
PARTS & SERVICE 9
CUSTOMER SERVICE DATA 9

Thank You for purchasing this
Wells Bloomfield appliance.

Proper installation, professional
operation and consistent
maintenance of this equipment
will ensure that it gives you the
very best performance and a long,
economical service life.

This manual contains the
information needed to properly
install this equipment, and to use
and care for the equipment in a
manner which will ensure its
optimum performance.

SPECIFICATIONS

DIMENSIONS:

Cabinet 12”H x 13-1/8”W x 9-1/16”D

Bread Slot 1-1/8” x 5-1/4”

Slices per Load 1 to 4

ELECTRICAL:
MODEL VOLTS AMPS kW PLUG

T-4C 208V 11.5A 2.4 kW NEMA 6-15P

240V 10.0A 2.4 kW NEMA 6-15P

T-4C 15A 120V 15.0A 1.8 kW NEMA 5-15P
BT-4C 120V 13.3A 1.6 kW NEMA 5-15P

201 p/n 40091 OpM T-4C and BT-4C Toaster

1

FEATURES & OPERATING CONTROLS

SLIDE
KNOBS
(1 per 2

slots,

2 total)

DARKNESS

CONTROL

KNOBS

(1 per 2 slots,

2 total)

CRUMB

TRAY

Fig. 1 Toaster Features & Operating Controls

BREAD SLOTS

(4 total)

ELEMENTS
(2 per slot,

8 total)

CARRY

HANDLES

(1 each side)

POWER
CORD

BREAD GUIDES
(2 per slot,

8 total)

SLIDE
RACKS
(1 per 2

slots,

2 total)

INTERNAL COMPONENTS

BREAD SLOTS One to four pieces of bread, one slice of bread per slot.
Oversized to accept Texas toast, English muffin, bagel, etc.

BREAD GUIDES Hold bread at proper distance from elements
SLIDE RACKS Carriages hold bread slices for toasting

Controlled by slide knobs
ELEMENTS Provide toasting heat.

Note: Bagel toaster BT-4C toasts one side (cut side) only
One element in each pair is inert

DARKNESS Individually adjustable from very light to very dark
CONTROL Control time slide rack is down and elements are energized
KNOBS Each knob controls one pair of bread slots

SLIDE KNOBS Control slide racks. Initiate toasting timer when pushed
down. Each knob controls one slide rack (one pair of bread
slots)

POWER CORD Plugs into appropriate electrical receptacle
CARRY HANDLES Carry the toaster here

DO NOT carry the toaster by the bread slots!
CRUMB TRAY Crumbs accumulate here. Remove to dump crumbs

201 p/n 40091 OpM T-4C and BT-4C Toaster

2
