Bloomfield 8851 Single Warmer, 8852 Dual Warmer Operation Manual

10 Sunnen Drive

St. Louis, MO 63143

telephone: [phone]

fax: [phone]

www.wellsbloomfield.com

BLOOM FIELD I N D U STRIES

763

OPERATION MANUAL

For

Hot Plate-Style

Decanter Warmer

MODELS

Model 8702

Model 8851

Model 8852

8708 Dual In-Line Warmer

8851 Single Warmer

8852 Dual Warmer

Includes:

Installation
Use & Care

NOTE: All warmers shown with optional 8900-Series
Glass Decanters (available separately).

p/n 2M-77719 Rev. B M763 110811

NOTE: For your protection, please note that equipment in
this shipment was carefully inspected and packaged by
skilled personnel before leaving the factory.
Upon acceptance of this shipment, the transportation
company assumes full responsibility for its safe delivery.

IF SHIPMENT ARRIVES DAMAGED:

1. VISIBLE LOSS OR DAMAGE: Be certain that any
visible loss or damage is noted on the freight bill
or express receipt, and that the note of loss or damage
is signed by the delivery person.

2. FILE CLAIM FOR DAMAGE IMMEDIATELY:
Regardless of the extent of the damage.

3. CONCEALED LOSS OR DAMAGE: if damage is
unnoticed until the merchandise is unpacked, notify the
transportation company or carrier immediately, and file
“CONCEALED DAMAGE” claim with them. This
must be done within fifteen (15) days from the date the
delivery was made to you. Be sure to retain the
container for inspection.

Wells Bloomfield cannot assume liability for damage or loss
incurred in transit. We will, however, at your request, supply
you with the necessary documents to support your claim.

WARRANTY STATEMENT

SERVICE POLICY AND PROCEDURE GUIDE

ADDITIONAL WARRANTY EXCLUSIONS

SHIPPING DAMAGE CLAIMS PROCEDURE

1. Resetting of safety thermostats, circuit breakers,
overload protectors, or fuse replacements unless
warranted conditions are the cause.

2. All problems due to operation at voltages other than
specified on equipment nameplates; conversion to
correct voltage must be the customer’s responsibility.

3. All problems due to electrical connections not made in
accordance with electrical code requirements and
wiring diagrams supplied with the equipment.

4. Replacement of items subject to normal wear, to include
such items as knobs and light bulbs. Normal maintenance

functions including adjustment of thermostats, microswitches,

and replacement of fuses and indicating lights are not

covered under warranty.

5. All problems due to inadequate water supply, such as

fluctuating, or high or low water pressure.

6. All problems due to mineral/calcium deposits, or

contamination from chlorides/chlorines. De-liming is
considered a preventative maintenance function and is
not covered by warranty.

All electrical equipment manufactured by WELLS
BLOOMFIELD is warranted against defects in materials and
workmanship for a period of one year from the date of original
installation or eighteen (18) months from the date of shipment
from our factory, whichever comes first, and is for the benefit
of the original purchaser, except that:
a. airpots carry a 30 day parts warranty only.
b. dispensers; i.e., tea and coffee carry a 90 days parts
warranty only, decanters excluded.

THE FOREGOING OBLIGATION IS EXPRESSLY GIVEN IN
LIEU OF ANY OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, WHICH ARE HEREBY EXCLUDED.

BLOOMFIELD INDUSTRIES DIVISION / SPECIALTY
EQUIPMENT MANUFACTURING CORPORATION SHALL
NOT BE LIABLE FOR INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES FROM ANY
CAUSE WHATSOEVER.

This warranty is void if it is determined that upon inspection by
an Authorized Service Agency that the equipment has been
modified, misused, misapplied, improperly installed, or
damaged in transit or by fire, flood or act of God.

It also does not apply if the serial nameplate has been
removed or unauthorized service personnel perform service.
The prices charged by Wells Bloomfield for its products are
based upon the limitations in this warranty. Seller’s obligation
under this warranty is limited to the repair of defects without
charge by a Wells Bloomfield Authorized Service Agency or
one of its sub-agencies. This service will be provided on
customer’s premises for non-portable models. Portable
models (a device with a cord and plug) must be taken or
shipped to the closest Authorized Service Agency,
transportation charges prepaid, for services.

In addition to restrictions contained in this warranty, specific
limitations are shown below (Additional Warranty Exclusions).
Wells Bloomfield Authorized Service Agencies are located in
principal cities.

This warranty is valid in the United States and void elsewhere.
Please consult your classified telephone directory or your food
service equipment dealer; or, for information and other details
concerning warranty, write to:

Service Parts Department

Wells Bloomfield, LLC
10 Sunnen Dr. P.O. Box 430129
St. Louis, MO 63143 USA

Phone: [phone] Fax: [phone]

7. Full use, care and maintenance instructions are supplied
with each machine. Those miscellaneous adjustments
noted are customer responsibility. Proper attention will
prolong the life of the machine.

8. Travel mileage is limited to sixty (60) miles from an
authorized Service Agency or one of its sub-agencies.

9. All labor shall be performed during normal working hours.
Overtime premium shall be charged to the customer.

10. All genuine Bloomfield replacement parts are warranted
for ninety (90) days from date of purchase on
non- warranted equipment.

Any use of non-genuine Wells Bloomfield parts
completely voids any warranty.

11. Installation, labor and job check-out are not considered
warranty.

12. Charges incurred by delays, waiting time or operating
restrictions that hinder the service technicians ability
to perform services are not covered by warranty.
This includes institutional and correctional facilities.

xi

xi

763 p/n 2M-77719 OpManual Decanter Warmers

TABLE OF CONTENTS

W

ARRANTY STATEMENT xi
SPECIFICATIONS 1
FEATURES & OPERATING CONTROLS 2
PRECAUTIONS & GENERAL INFORMATION 3
AGENCY LISTING INFORMATION 3
INSTALLATION INSTRUCTIONS 4
OPERATION 5
CLEANING INSTRUCTIONS 5

EXPLODED VIEWS, PARTS LISTS & WIRE DIAGRAMS
8852 6
8708

7

8851 8

Thank You for purchasing this

Wells Bloomeld appliance.

Proper installation, professional
operation and consistent
maintenance of this appliance will
ensure that it gives you the very
best performance and a long,
economical service life.

This manual contains the
information needed to properly
install this appliance, and to use,
care for the appliance in a man­ner which will ensure its optimum
performance.

SPECIFICATIONS

MODEL STYLE VOLTS 1ø WATTS AMPS POWER SUPPLY CORD

8708

8708DSU

Dual Step-Up

8708DSUUK CW 3100

8851

8851S

Single

8851SUK CW 3100

8852

8852D

Dual

8852DUK CW 3100

120 VAC

220-240V 0.8

200

120 VAC

220-240V 0.44

100

1.7 NEMA-5-15P

0.8 NEMA-5-15P

120 VAC 200 1.7 NEMA-5-15P

220-240V 200 0.8

CEE 7/VII

CEE 7/VII

CEE 7/VII

763 p/n 2M-77719 OpManual Decanter Warmers

Decanter warmers operate at a warming temperature of approximately 185ºF ± 10ºF (85 ºC ± 6ºC).

1

FEATURES AND OPERATING CONTROLS

POWER CORD

WARMER PLATE

WARMER SWITCH

OPTIONAL DECANTER
(SHOWN FOR POSITION
ONLY)

SLIP-RESISTANT FEET

IL2044a

Fig. 1 Features & Operating Controls
Model 8852 shown. Features are similar for all models.

2

763 p/n 2M-77719 OpManual Decanter Warmers
