Blomberg MHE 2020 Instruction Manual

General discription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Microwave power settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Quick-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Minute timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Microwave function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Automatic Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Care & Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

After-sales services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Important safety instructions.

Read careffully and keep for future reference.

CONTENTS

GENERAL DESCRIPTION

Turntable

Wheel

support

Control Panel

Door open

button

Identification

label

• THE TURNTABLE :

ensures equal cooking of food throughout with no need to intervene.

- It may be used as a cooking dish.

- Rotation is controlled by the drive shaft and the wheel support.

- The turntable rotates in both directions.

- If it does not turn, verify that all components are properly positioned.

• THE WHEEL SUPPORT :

Do not try to rotate the roller ring manually, as you could damage the drive system.

If it does not turn smoothly, make sure that there is nothing in the well beneath the

turntable.

• MICROWAVE OUTPUT POWER : 750 W

INSTALLATION

• Make sure that your oven has not suffered any damage during transport (defor-

med door or door seal, etc.). If you see any signs of damage, contact your dea-

ler before use.

• Check the power voltage. If there is a PERMANENT undervoltage (200-210 volts),

consult your electrical installer.

Location

• The appliance should be installed at a distance of 85 cm above the floor.

• Place the oven on a flat and horizontal surface, away from any source of heat or steam.

• Make sure that nothing obstructs the ventilation louvers at the back of the

appliance.

• Make sure the electrical plug will be accessible after installation.

• Do not use your appliance immediately (wait approx. 1-2 hours) after transfer from a cold place to a warm place as condensation may cause a malfunction.

• Your installation must be protected by a 10 Amp thermal fuse.

• It is mandatory to use a power point with a ground terminal, connected in accordan-

ce with current safety regulations.

• In your electrical installation, provide a device that is accessible to the installer, capable of separating the appliance from the mains power and whose contact opening is at least 3 mm at all of the poles.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Electrical connection

Before connection

INSTALLATION

h 360

4x25 mm

600

310

560 min

600

360

350

370

592
