Blodgett BTT-16E Parts List

October 29, 2009

PARTS LIST

ROUND ELECTRIC COUNTER TILTING KETTLE

BLODGETT MODEL: BTT-16E

BLODGETT OVEN CO ▪ 44 lakeside Ave ▪ Burlington, VT 05446

Tel. [phone] ▪ Fax [phone] ▪ www.blodgett.com

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL BTT-16E

2 2012-02-23

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL BTT-16E

ITEM Part Number DESCRIPTION QUANTITY
1 40756 Cover Assembly 1
2 41437 Pan Assembly 1
3 40259 Knob - Red 1
4 40745 Handle 1
5 43292 Acorn Nut 1
6 41815 Bearing 2
** 7 40330 Element, 2.5 kW, 208V 3
40331 Element, 2.5 kW, 220V, (380V) 3
40332 Element, 2.5 kW, 240V, (415V) 3
40333 Element, 2.5 kW, 277V, (480V) 3
40334 Element, 2.5 kW, 347V, (600V) 3
8 40428 Capillary Clamp 1
9 43367 Element Clamp 1
10 40744 Insulation Pin 1
11 40746 Bottom Cover 1
12 40335 Left Hand Console Cover 1
13 40283 Right Hand Console Cover 1
14 41004 High-Limit Thermostat 1
15 41883 Power Swi tch 1
16 40953 Pilot Lig h t - Amber 1
** 17 40848 Dial (F) 1
40849 Dial (C)
18 40994 Bezel 1
19 41005 Regulating Thermostat 1
20 40336 Operation Decal 1
21 42140 Component Mounting Plate 1
** 22 40943 Contactor - 208, 220, 240V 2

3 2012-02-23

PARTS LIST, ROUND ELECTRIC COUNTER TILTING KETTLE, MODEL BTT-16E

ITEM Part Number DESCRIPTION QUANTITY
40943 Contactor - 380, 415, 220/380, 240/415,

480V, 600V

23 40707 Terminal Block - End Selection 1

24 40708 Terminal Block - 208, 240, 380, 415, 480,

600V
40708 Terminal Block - 240/415, 220/380V 4
25 40840 Ground Lug 1
* ** 26 40974 Transformer, 380/220V, 50/60 Hz, 100VA 1
40974 Transformer, 415/240V, 50/60 Hz, 100VA 1
40980 Transformer 480/240V, 60 Hz, 100VA 1
40985 Transformer, 600/240V, 60 Hz, 100VA 1
* ** 27 41766 Fuse 600V,1 Amp. - 380, 415, 480 Units 2
41768 Fuse 600V, 8/10 Amp. - 600V 2
* 28 41769 Fuse Holder 600V, 30 Amp. 380, 415,

480, 600V Units

1

3

2

4 2012-02-23
