Blodgett BTT-12E User Manual

BTT-12E
SQUARE ELECTRIC TABLETOP BRAISING PAN
INSTALLATION – OPERATION – MAINTENANCE
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone: (802) 658-6600 Fax: (802) 864-0183
S00042 Rev A (5/04)
1
IMPORTANT NOTES FOR INSTALLATION AND OPERATION
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
WARNING: Improper installation, operation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing, operating or servicing this equipment.
NOTICE: Contact the factory, the factory representative or local service company to perform maintenance and repairs.
Adequate clearances must be maintained for servicing and proper operation.
Intended for commercial use only. Not for household use.
Do not attempt to operate this unit in the event of a power failure.
This manual should be retained for future reference.
It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This manual should be retained for future reference.
2
TABLE OF CONTENTS
DESCRIPTION PAGE
Important Notes for Installation and Operation .............................................................. 2
Installation and Service Connections ............................................................................. 4
1.0 Installation Instructions ......................................................................................... 5
2.0 Operation Instructions .......................................................................................... 6
3.0 Cleaning Instructions ............................................................................................ 7
4.0 Troubleshooting ..................................................................................................... 8
3
INSTALLATION AND SERVICE CONNECTIONS
ELECTRICAL CHARACTERISTICS
BTT-12E
MODEL
43.3
25.0
208V
40.9
23.6
220V
37.5
21.7
240V
13.7
AMPS PER LINE
380V
12.5
415V
10.8
480V
kW
9.0
PHASE
1 3
600V
8.7
N/A
N/A
N/A
N/A
12.5 [318]
10 [254] 1.25 [32]
POUR PATH
FLOOR POUR PATH
0.63 [16]
0.75 [19]
MIN. CLEARANCE
TILT POSITIONER
18 [457]
12.5
4X WELD NUTS
5/16-18UNC
14.50 [368]
2.25 [57]
13[330]
20[508]
10.5[267]
33.25[845]
7[178] ID
16.75[425] ID
29[737]
24[610] ID
25.75[654]
5.5[140]
H12.5[318]
4[102]
2[51]
DIMENSIONS ARE IN INCHES [MM]
Electrical connection to be as specified on data plate.
4
1.0 INSTALLATION INSTRUCTIONS
1. Position appliance on counter allowing sufficient rear clearance from wall to tilt freely and completely without obstruction.
2. Mark four corner locations of appliance base, as shown below.
3. Remove appliance from counter and locate position of four holes as per drawing detailed below. Drill four 7/16" diameter holes.
4. Apply a continuous bead of Silastic or other equivalent sealant along the complete perimeter edge of the appliance base.
5. Use 5/16-18 Hex Cap Screws with suitable flat washers to bolt down. Screw length must be 1-1/4 long plus counter top thickness.
6. Wipe off excess sealant.
7. A control box with power supply equivalent to Electrical Rating of appliance should be located conveniently nearby.
8. A waterproof electrical connection for power supply to console housing must be provided.
9. Ground appliance to terminal provided inside console housing.
10. Turn power ON and check for proper operation.
5
2.0 OPERATION INSTRUCTIONS
THERMOSTAT SETTINGS
Simmering
1 - 4
(200 F)
Sautéing
5 - 6
(225 - 275 F)
Searing
7 - 8
(300 - 350 F)
Pan Frying
8 - 9
(325 - 375 F)
Grilling
9 - 10
(350 - 425 F)
1. Ensure that unit has been electrically connected and that circuit breakers are on.
2. Place power switch in “ON” position.
3. Set the thermostat dial to high (#10).
4. Preheat the unit and allow it to cycle thus equalizing heat across the entire surface.
5. Cooking should be done at various temperature settings on the dial as determined by the user.
6. Water will boil faster with the optional cover on.
7. Check that braising pan optional level bar, on right side of control panel, moves in and out easily. This bar provides two set positions, level and slightly tilted.
8. At end of cooking, return thermostat to “OFF” position, turn power switch “OFF”, remove food and allow to soak for ease of cleaning.
6
3.0 CLEANING INSTRUCTIONS
NOTICE: As a safety precaution disconnect the power supply during cleaning and servicing.
WARNING: Do not get water in electrical components.
1. The BTT-12E should be cleaned after each use.
2. Soak cooking surface with water and a mild soap to remove any food stuck to
surface.
3. Wash entire unit surface with mild detergent and water. Rinse entire unit and dry.
4. Check that pour spout, strainer, cover and sides of unit are cleaned as above.
7
4.0 TROUBLESHOOTING
NOTE: Never grease or oil the pivot bearings as this may cause problems with tilting. Bearings are oilite and never require lubrication.
Unit will not operate:
1. Power supply not “ON”.
2. Defective thermostat or elements.
Pan difficult to tilt:
1. Tilt knob not disengaged.
2. Dirt in oilite bearings causing them to bind.
8
