Blodgett B12C-B Parts List
SAFFIRE SERIES
SECTIONAL RANGE
REPLACEMENT PARTS LIST
Model B36A-BBB
Model B36A-TTT
Model B36A-BBB-SU
Model B36A-HHH
Model B36A-CCC
Model B36A-GRAD
BLODGETT OVEN COMPANY , 44 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: (802) 860-3700 (800) 331-5842 Fax: (802) 860-3732
www.blodgett.com
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items specified are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
www.blodgett.com
JUNE 14, 2004 2 SECTIONAL RANGES
IMPORTANT: When ordering parts, please provide the model, gas
type and serial number of the unit. The identification plate is located
on the back center of the unit.
Location of Serial Plate
MODELS COVERED
Flush 35K-Open-Burner Models:
B12N-B, B12C-B, B24N-BB, B24C-BB, B36N-BBB, B36C-BBB, B36D-BBB, &
B36A- BBB45K-
Open-Burner Models:
B36N-XX, B36C-XX, B36D-XX, & B36A-XXStep-Up 35K-
Open-Burner Models:
B24N-BB-SU, B24C-BB-SU, B36N-BBB-SU, B36C-BBB-SU, B36D-BBB-SU, &
B36A-BBB-SU
Charbroiler Models:
B24N-CC, B24C-CC, B36N-CCC, B36C-CCC, B36D-CCC, B36A-CCC, B48N-CCCC,
B48D-CCCC, & B48A-CCCC
Standard Griddle Models:
B12N-G, B12C-G, B24N-GG, B24C-GG, B36N-GGG, B36C-GGG, B36D-GGG,
B36A-GGG, B48N-GGGG, B48D-GGGG, & B48A-GGGG
Thermostatic Griddle Models:
B24N-TT, B24C-TT, B36N-TTT, B36C-TTT, B36D-TTT, B36A-TTT, B48N-TTTT, B48D-TTTT,
& B48A-TTTT
Hot-Top Models:
B12N-H, B12C-H, B24N-HH, B24C-HH, B36N-HHH, B36C-HHH, B36D-HHH, & B36A-HHH
Graduated Hot-Top Models:
B36N-GRAD, B36C-GRAD, B36D-GRAD, & B36A-GRAD
TO OBTAIN LITERATURE:
Blodgett Literature Department
800-331-5842, x2035
Fax: 802-860-3755
Email: literature@blodgett.com
or
www.blodgett.com
JUNE 14, 2004 3 SECTIONAL RANGES
TABLE OF CONTENTS
FRONT RAIL PARTS ...................................................................................... PAGE 4
LEG AND CASTER PARTS........................................................................... PAGE 5
35K OPEN BURNER EXTERNAL AND STRUCTURAL PARTS............. PAGE 6 & 7
35K OPEN BURNER GAS TRAIN PARTS ................................................. PAGE 8 & 9
45K OPEN BURNER PARTS......................................................................... PAGE 10 & 11
CHARBROILER EXTERNAL AND STRUCTURAL PAR TS ..................... PAGE 12 & 13
CHARBROILER AND ST ANDARD GRIDDLE GAS TRAIN PARTS ..... PAGE 14
GAS CONNECTION PARTS.......................................................................... PAGE 15
GRIDDLE EXTERNAL AND STRUCTURAL PARTS ................................ PAGE 16 & 17
THERMOSTATIC GRIDDLE GAS TRAIN PARTS .................................... PAGE 18 & 19
UNIFORM HOT TOP PARTS......................................................................... PAGE 20 & 21
GRADUATED HOT TOP PARTS.................................................................. PAGE 22 & 23
OVEN BASE PARTS....................................................................................... PAGE 24 & 25
CONVECTION OVEN BLOWER PARTS .................................................... PAGE 26
MODULAR COUNTERTOP BASE PARTS................................................. PAGE 27
CABINET BASE PARTS ................................................................................ PAGE 28
FLUE RISER PARTS....................................................................................... PAGE 29 & 30
SIDE PANEL AND BATTERY ASSEMBLY PARTS.................................. PAGE 31
EXCLUSIVE TO ST ANDING PILOT OVENS.............................................. PAGE 32
JUNE 14, 2004 4 SECTIONAL RANGES
FRONT RAIL PARTS
Models Key Part Number Description
B12-B, B12-B-SU, B12-H 1 Z1184889 ASM, RAIL, 12" OPN.GRAD TOP
(with belly bar)
Z1184767 ASM, RAIL, 12" OPN.GRAD TOP
(with slot for sauce pans)
B24-BB, B24-BB-SU, B24-HH 1 Z1184890 ASM, RAIL, 24" OPN.GRAD TOP
(with belly bar)
Z1184765 ASM, RAIL, 24" OPN.GRAD TOP
(with slot for sauce pans)
B36-BBB, B36-BBB-SU, B36-GRAD, B36-HHH, B36-XX
1 Z1184891 ASM, RAIL, 36" OPN.GRAD TOP
(with belly bar)
Z1184763 ASM, RAIL, 36" OPN.GRAD TOP
(with slot for sauce pans)
B12-G 2 Z1184402 ASM, RAIL, 12" GRI/CHR
(with belly bar)
B24-CC, B24-GG, B24-TT 2 Z1184403 ASM, RAIL, 24" GRI/CHR
(with belly bar)
B36-CCC, B36-GGG, B36-TTT 2 Z1184404 ASM, RAIL, 36" GRI/CHR
(with belly bar)
B48-CCCC, B48-GGGG, B348-TTTT 2 Z1184405 ASM, RAIL, 48" GRI/CHR
(with belly bar)
NO DRAWING AVAILABLE
JUNE 14, 2004 5 SECTIONAL RANGES
LEG & CASTER PARTS
1
2
3
4
5
Key Part Number Qty Description
1 Z1172650 4 LEG PAD (3/4 X 10 HOLE)
2 Z1146500 16 1/4 LOCK WASHER
3 Z1146201 16 1/4 X 30 X 3/4 HEX HEAD
4 Z1174260 1 LEG PACKAGE
(set of four legs, not including bolts, leg pads, or lock washers)
Z1174262 1 EARTHQUAKE LEGS SS (set of four)
5 Z1174265 1 CASTER PACKAGE
(two casters with brake and two without brake)
NOTE: Does not include bolts, lock washers, or leg pads
Step-Up 35K-Open-
JUNE 14, 2004 6 SECTIONAL RANGES
35K-OPEN-BURNER EXTERNAL AND STRUCTURAL PARTS
9
Flush 35K-Open-Burner Models
6
2
3
10
8
7
4
5
4
14
4
11
12
13
15
17
16
18
1
Burner Models
36"-Wide Models Shown
JUNE 14, 2004 7 SECTIONAL RANGES
35K-OPEN-BURNER EXTERNAL AND STRUCTURAL PARTS
Key Part Number Quantity* Description
FOR MODELS: 12" 24" 36"
1 Z1183978 1 - - TRAY ASSEMBLY, 12" CRUMB
Z1183974 - 1 - TRAY ASSEMBLY, 24" CRUMB
Z1183972 - - 1 TRAY ASSEMBLY, 36" CRUMB
2 Z1184192 2 4 6 KNOB
3 Z1184729 1 - - VALVE PANEL, 12C-B (cabinet base)
Z1184730 1 - - VALVE PANEL, 12N-B (modular-countertop base)
Z1184727 - 1 - VALVE PANEL, 24C-BB (cabinet base)
Z1184728 - 1 - VALVE PANEL, 24N-BB (modular-countertop base)
Z1183614 - - 1 VALVE PANEL, 36A/D-BBB (oven base)
Z1184610 - - 1 VALVE PANEL, 36C-BBB (cabinet base)
Z1184609 - - 1 VALVE PANEL, 36N-BBB (modular-countertop base)
4 Z1184760 2 - - BURNER REST, 12
Z1184759 - ** - BURNER REST, 24
Z1184758 - - ** BURNER REST, 36
5 Z1183883 1 - - SUPPORT, 12 PILOT (for flush-top models)
Z1183882 - 1 - SUPPORT, 24 PILOT (for flush-top models)
Z1183601 - - 1 SUPPORT, 36 PILOT (for flush-top models)
6 Z1180872 1 2 3 BRACKET, PILOT SUPPORT (for flush-top models)
7 Z1183888 1 - - TRIM, 12 FLUE RISER
Z1183886 - 1 - TRIM, 24 FLUE RISER
Z1183531 - - 1 TRIM, 36 FLUE RISER
8 Z1183900 1 - - TRIM, 42 DEEP 12 FLUE RISER
Z1183898 - 1 - TRIM, 42 DEEP 24 FLUE RISER
Z1183589 - - 1 TRIM, 42 DEEP 36 FLUE RISER
9 Z1183500 1 2 3 CAST IRON GRATE, SECTIONAL
10 Z1184847 1 2 3 WELDED GRATE, SECTIONAL
11 Z1183501 - 4 6 CAST IRON GRATE, SECTIONAL HALF
(for step-up models)
2 Z1184870 - 4 6 WELDED GRATE, SECTIONAL HALF (for step-up models)
13 Z1184672 - 1 - SUPPORT W/A, STEP-UP 24" GRATE
JUNE 14, 2004 8 SECTIONAL RANGES
35K-OPEN-BURNER GAS TRAIN PARTS
Flush 35K-Open-Burner Models
1
6
8
2
7
5
9
10
1
2
3
4
3
12
8
12
4
10
5
Step-Up 35K-Open-Burner Models
7
13
11
36"-Wide Models Shown
JUNE 14, 2004 9 SECTIONAL RANGES
35K-OPEN-BURNER GAS TRAIN PARTS
Key Part Number Quantity* Description
FOR MODELS: 12" 24" 36"
1 Z1183923 1 - - MANIFOLD W/A, 2 BURNER OPEN TOP
Z1183922 - 1 - MANIFOLD W/A, 4 BURNER OPEN TOP
Z1183593 - - 1 MANIFOLD W/A, 6 BURNER OPEN TOP
2 Z1179222 2 4 6 NIPPLE, EXTENSION
3 Z1178202 2 4 6 VALVE, HI-OFF, NAT/LP
4 Z1179188 1 2 3 EXTENSION, ORIFICE
Z1008737 2 4 6 ORIFICE, NAT GAS
NOTE: If operating above 2000 ft, contact Blodgett Technical Service for appropriate orifice size
Z1008752 2 4 6 ORIFICE, PROPANE
NOTE: If operating above 2000 ft, contact Blodgett Technical Service for appropriate orifice size
5 Z1182193 2 4 6 BURNER ASSEMBLY, OPEN TOP
(shutter - Z1182157, screen- Z1146237)
Z1182195 1 2 3 FITTING, 1/2" COMP 1/4" NPT
connects rear-burner gas tube to valve
6 Z1182192 1 2 3 TUBE, REAR BURNER
7 Z1182191 1 2 3 ORIFICE FITTING
8 Z1166004 1 2 3 FITTING, DOUBLE PILOT, 3/16" TUBE
9 Z1183605 1 2 3 PILOT TUBE W/A REAR
10 Z1183603 1 2 3 PILOT TUBE W/A FRONT
11 Z1177106 - 2 3 TUBE ASM, REAR BURNER PILOT
or rear pilots of step-up models
12 Z1184646 - 1 2 TUBE, REAR BURNER STEP-UP
for left rear burner of step-up models, and center rear
burner of 36"-wide step-up model
13 Z1184647 - 1 1 TUBE, REAR BURNER STEP-UP
for right rear burner of step-up models
NOTE: *Quantity of part used may depend on width of section (12", 24", or 36").
JUNE 14, 2004 10 SECTIONAL RANGES
45K-OPEN-BURNER PARTS
8
15
13
14
12
7
6
16
10
11
9
1
2
17
18
4
3
5
4
