Blodgett 961 Installation Manual
Gas Shut-Off Valves Category D
IMPORTANT: The National Fuel Gas Code (ANSI Z223.1) requires each outlet, including a valve, be closed gas tight with a threaded plug or
cap immediately after installation and until equipment is connected, and when equipment is disconnected from an outlet and the outlet is not to
be used again immediately.
Straight Valves - FIP x FIP (Reduced Port)
Part #
Description
92-2222 3/8'' FIP x 3/8'' FIP 10 3.0 $23.91
92-3232 1/2'' FIP x 1/2'' FIP 10 3.6 23.91
92-4242 3/4'' FIP x 3/4'' FIP 10 5.5 31.14
Straight Valves - FIP x FIP (Side Tapped)
Part #
92ST-3232 1/2'' FIP x 1/2'' FIP 10 4.5 $33.33
92ST-4242 3/4'' FIP x 3/4'' FIP 10 5.7 43.26
Description
Connector Valves - Flare x FIP
Part #
91-1032 3/8'' OD Flare x 1/2'' FIP 10 3.7 $28.05
91-2032 1/2'' OD Flare x 1/2'' FIP 10 4.0 28.05
91-3032 5/8'' OD Flare (15/16'' - 16 thread) x 1/2'' FIP 10 4.5 30.65
91-3042 5/8'' OD Flare (15/16'' - 16 thread) x 3/4'' FIP 10 5.8 39.37
Description
Full Port Valves - FIP x FIP
Part #
94-3232 1/2'' FIP x 1/2'' FIP 10 5.1 $29.37
94-4242 3/4'' FIP x 3/4'' FIP 10 7.5 43.12
94-5252 1'' FIP x 1'' FIP 6 7.8 61.83
94-6262 1-1/4'' FIP x 1-1/4'' FIP 6 11.6 100.78
94-7272 1-1/2'' FIP x 1-1/2'' FIP 6 15.7 136.06
94-8282 2'' FIP x 2'' FIP 2 8.0 200.87
Description
Carton
Qty.
Carton
Qty.
Carton
Qty.
Carton
Qty.
Approx. Carton
Wt. Lbs.
Approx. Carton
Wt. Lbs.
Approx. Carton
Wt. Lbs.
Approx. Carton
Wt. Lbs.
Price
Each Piece
Price
Each Piece
Price
Each Piece
Price
Each Piece
Flare Valves - Flare x Flare
Part #
91-1010 3/8'' OD x 3/8'' OD 10 3.6 $27.52
91-2020 1/2'' OD x 1/2'' OD 10 3.9 27.52
Easy to Use Handle
• Handles are ergonomically designed for smooth turns.
• Quarter-turn handle design makes for easy on/off operation.
• Most handles feature a lock-out for added safety.
Easier Installation
• Large wrench flats allow for quick, easy installation.
21
Description
Carton
Qty.
Approx. Carton
Wt. Lbs.
Reliable Long-Lasting Performance
• The forged brass body eliminates the possibility of leaks associated
with cast products.
• All valves are 100% leak tested.
• Valves are approved and design-certified by CSA for use with
natural, manufactured, mixed liquefied petroleum gases, and LP
gas-air mixtures.
1-800-DORMONT
www.dormont.com
Price
Each Piece
Gas Shut-Off Valves
Category D Fuel Gas Outlets
IMPORTANT: The National Fuel Gas Code (ANSI Z223.1) requires each outlet, including a valve, be closed gas tight with a threaded plug or
cap immediately after installation and until equipment is connected, and when equipment is disconnected from an outlet and the outlet is not to
be used again immediately.
Flare Valves - Flare x Flare Side Tapped
Part #
91ST-1010 3/8'' OD x 3/8'' OD 10 3.5 $38.10
Description
Carton
Qty.
Approx. Carton
Wt. Lbs.
Price
Each Piece
Angle Connector Valves - Flare x FIP
Part #
93-1032 3/8'' OD Flare x 1/2'' FIP Angle 10 5.1 $37.52
93-2032 1/2'' OD Flare x 1/2'' FIP Angle 10 5.3 45.64
93-3032 5/8'' OD Flare (15/16'' - 16 thread) x 1/2'' FIP Angle 10 5.6 56.46
93-3042 5/8'' OD Flare (15/16'' - 16 thread) x 3/4'' FIP Angle 10 6.0 71.20
Description
Carton
Qty.
Approx. Carton
Wt. Lbs.
Price
Each Piece
Fuel Gas Outlet – Model 961 For Indoor and Outdoor Installations
Part # Description Price
961-2234
961-3422C
961-2122N
961-2021N Model 961 Fuel Gas Outlet 1/2'' OD (M) flare plug 17.09
Fuel Gas Outlet Features:
• Easy and safe operation. When the manual valve is in the
closed (OFF) position, to make a connection, the user
simply pushes back the locking sleeve, inserts the appliance
connector plug, and releases the sleeve. No tools are
required for a leak-tight connection.
• Gas flows when the manual valve handle is turned to the
open (ON) position.
• An interlocking safety cam prevents release of the
appliance connector plug until the manual valve handle is in
the closed (OFF) position.
Model 961 Fuel Gas Outlet Connection with 1/2'' NPT (F)
90 deg. inlet and plug with 3/8'' NPT (F) outlet
Model 961 Fuel Gas Outlet Connection with 1/2'' NPT (F)
90 deg. inlet coupler
Model 961 Fuel Gas Outlet 3/8'' NPT (F) plug
• Capacity–42,000 BTU/HR. minimum at 0.3'' w.c.
pressure drop; 0.64 SG., natural gas.
• National Fuel Gas Code Reference 5.5.6.
• Temperature Protected—Built-in thermal
protection prevents gas flow if the gas connection
is exposed to temperatures in excess
of 200°F.
• To be used with Natural or Propane Gas.
$134.74
124.67
17.09
1-800-DORMONT
www.dormont.com
