BLT/BLP-E Series
ELECTRIC BRAISING PAN
INSTALLATION - OPERATION - MAINTENANCE
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 USA
Manufacture Service Questions: 866-518-3977
PART NUMBER 170806 REV B (04/11)
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND
AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
POST IN A PROMINENT LOCATION
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS INFORMATION
SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUPPLIER. AS A MINIMUM,
TURN OFF THE GAS AND CALL YOUR GAS COMPANY AND YOUR AUTHORIZED SERVICE
AGENT. EVACUATE ALL PERSONNEL FROM THE AREA.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN
CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING
AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
NOTIFY CARRIER OF DAMAGE AT ONCE
IT IS THE RESPONSIBILITY OF THE CONSIGNEE TO INSPECT THE CONTAINER UPON
RECEIPT OF SAME AND TO DETERMINE THE POSSIBILITY OF ANY DAMAGE, INCLUDING
CONCEALED DAMAGE. WE SUGGEST THAT IF YOU ARE SUSPICIOUS OF DAMAGE TO
MAKE A NOTATION ON THE DELIVERY RECEIPT. IT WILL BE THE RESPONSIBILITY OF THE
CONSIGNEE TO FILE A CLAIM WITH THE CARRIER. WE RECOMMEND THAT YOU DO SO
AT ONCE.
IMPORTANT - READ FIRST - IMPORTANT
CAUTION: BE SURE OPERATORS READ, UNDERSTAND AND FOLLOW THE OPERATING INSTRUCTIONS, CAUTIONS,
AND SAFETY INSTRUCTIONS IN THIS MANUAL.
WARNING: THIS UNIT IS INTENDED FOR USE IN THE COMMERCIAL HEATING, COOKING AND HOLDING OF WATER
AND FOOD PRODUCTS, PER THE INSTRUCTIONS CONTAINED IN THIS MANUAL. ANY OTHER USE COULD
RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT AND WILL VOID WARRANTY.
WARNING: ELECTRICALLY GROUND THE PAN AT THE TERMINAL PROVIDED. FAILURE TO GROUND UNIT COULD
RESULT IN ELECTROCUTION AND DEATH.
WARNING: THE BRAISING PAN MUST BE INSTALLED BY PERSONNEL WHO ARE QUALIFIED TO WORK WITH
ELECTRICITY. IMPROPER INSTALLATION COULD RESULT IN PERSONAL INJURY OR EQUIPMENT DAMAGE.
CAUTION: STAND AWAY FROM HOT WATER OR FOOD PRODUCTS WHILE TILTING THE PAN DIRECT CONTACT COULD
RESULT IN SEVERE BURNS.
WARNING: WHEN TILTING BRAISING PAN FOR PRODUCT TRANSFER:
1) WEAR PROTECTIVE OVEN MITT AND PROTECTIVE APRON.
2) USE CONTAINER DEEP ENOUGH TO CONTAIN AND MINIMIZE SPLASHING.
3) PLACE CONTAINER ON STABLE, FLAT SURFACE, AS CLOSE TO PAN AS POSSIBLE.
4) STAND TO SIDE OF PAN WHILE POURING — NOT DIRECTLY IN POUR PATH OF HOT CONTENTS.
5) RETURN PAN BODY TO LEVEL POSITION AFTER CONTAINER IS FILLED OR TRANSFER IS COMPLETE.
6) DO NOT OVER FILL CONTAINER. AVOID DIRECT SKIN CONTACT WITH HOT CONTAINER AND ITS
CONTENTS.
WARNING: DO NOT HEAT AN EMPTY PAN FOR MORE THAN FIVE MINUTES AT A SETTING HIGHER THAN 300˚F.
WARNING: AVOID ANY EXPOSURE TO THE STEAM ESCAPING FROM THE COVER VENT. DIRECT CONTACT COULD
RESULT IN SEVERE BURNS
WARNING: AVOID ALL DIRECT CONTACT WITH HOT EQUIPMENT SURFACES. DIRECT SKIN CONTACT COULD RESULT
IN SEVERE BURNS.
WARNING: AVOID ALL DIRECT CONTACT WITH HOT FOOD OR WATER IN THE BRAISING PAN. DIRECT CONTACT
COULD RESULT IN SEVERE BURNS.
WARNING: IF THE PAN CONTAINS ITEMS IN SAUCE OR MELTED FAT, THEY COULD SLIDE FORWARD SUDDENLY
DURING TILTING AND CAUSE HOT LIQUID TO SPLASH OUT.
WARNING: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY THE MANUFACTURER OR ITS
AUTHORIZED DISTRIBUTORS VOIDS ALL WARRANTIES AND MAY CAUSE BODILY INJURY OR EQUIPMENT
DAMAGE. SERVICE PERFORMED BY OTHER THAN FACTORY AUTHORIZED PERSONNEL WILL VOID ALL
WARRANTIES.
WARNING: TURN OFF ELECTRIC POWER BEFORE WORKING ON INTERNAL COMPONENTS.
WARNING: BEFORE ANY CLEANING OPERATION, TURN THE THERMOSTAT TO “OFF” TO CUT OFF POWER TO THE
HEATING ELEMENTS. BEFORE CLEANING ANY PART OTHER THAN THE INSIDE OF THE PAN, DISCONNECT
THE ELECTRICAL SUPPLY AT THE CIRCUIT BREAKER OR FUSE BOX.
OM-BLT/BLP-GE 1
IMPORTANT - READ FIRST - IMPORTANT
WARNING: BE CAREFUL TO AVOID CONTACT WITH CLEANING PRODUCTS IN ACCORDANCE WITH SUPPLIER AND
MANUFACTURER RECOMMENDATIONS. MANY CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. READ THE WARNINGS AND FOLLOW DIRECTIONS ON THE CLEANER LABEL.
CAUTION: NEVER LEAVE A CHLORINE SANITIZER IN CONTACT WITH STAINLESS STEEL FOR LONGER THAN 30
MINUTES. LONGER CONTACT CAN CAUSE CORROSION.
WARNING: DO NOT USE ANY FUSE WITH A HIGHER AMP RATING THAN THE RATING SPECIFIED FOR THAT CIRCUIT.
WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS AND ELECTRICAL EQUIPMENT. NEVER USE A HIGH
PRESSURE HOSE TO CLEAN THE BRAISING PAN.
WARNING: BEFORE REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC POWER SUPPLY.
IMPORTANT: SERVICE PERFORMED BY OTHER THAN FACTORY AUTHORIZED PERSONNEL WILL VOID WARRANTIES.
2 OM-BLT/BLP-E
Table of Contents
Important Operator Warnings ......................................................page 1-2
References.................................................................................... page 3
Equipment Description............................................................... page 4-5
Inspection and Unpacking ............................................................ page 6
Installation .................................................................................. page 7-8
Initial Start-Up................................................................................ page 8
Operation ................................................................................ page 9-10
Sequence of Operation ................................................................ page 11
Cleaning.................................................................................. page 12-13
Maintenance................................................................................. page 14
Troubleshooting............................................................................ page 15
Parts Lists .............................................................................. page 16-22
Schematics/Wiring Diagram ................................................ page 23-26
Service Log ............................................................................ page 27-28
References
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
NFPA/70 - The National Electrical Code
NSF INTERNATIONAL
789 N. Dixboro Road
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
NSF/ANSI - Standard 4
UNDERWRITERS LABORATORIES, INC.
333 Pngsten Road
Northbrook, Illinois 60062
UL/ANSI - Standard 197
OM-BLT/BLP-GE 3
Equipment Description
The BLT/BLP is a stainless steel, electrically heated Braising Pan which is equipped
with integrated heating elements, a hand operated or motor powered tilting
mechanism, electrical controls and a hinged cover. The Braising Pan serves as a
braising unit, griddle, fry pan, oven, kettle, bain-marie, or food warmer and server. It
can also be adapted for use as a non-pressure steamer.
The pan body is constructed of heavy-duty stainless steel, welded into a solid piece.
It has a polished interior and exterior finish. A pouring lip is welded to the top of the
front wall. The cooking surface is a stainless steel clad plate fitted with clampedon electrical heating elements. The elements are positioned to ensure uniform heat
transfer over the entire surface.
Pans are mounted on an open-leg frame which is fabricated from tubular stainless
steel.
An easily operated worm and gear mechanism tilts the pan body and provides precise
control for pouring or dumping its contents.
This tilting mechanism is located in a stainless steel console to right of the pan body.
For power tilt units a three position switch on the front of the control console gives the
operator positive, smooth-acting control of tilt. To facilitate cleaning, the pan body can
be tilted past the vertical position.
Heating elements and other electrical components are enclosed for safety. The
thermostat, heating indicator light and tilting switch are contained in a compact
control console which is mounted to the right of the pan body.
The thermostat provides automatic control of cooking temperature. Turning the
thermostat dial starts and stops heating and sets the pan temperature. Only one
electrical connection is required to install the unit.
A vented, heavy gauge, one-piece, stainless steel cover with a rear condensate drip
shield on the underside is standard on the braising pan. A fully enclosed torsion bartype counter-balance provides easy operation to open the cover to maintain it open
at any position. The cover opens to the back. It is hinged to the frame, so it moves
independently from the pan body.
The following sizes and options are available:
Model
30E-BLT
40E-BLT
30E-BLP
Left to Right Front to Rear Depth
26-1/4” (667 mm) 28-1/4" (718 mm) 10" (25 mm) Manual
35-3/4” (908 mm) 28-1/4" (718 mm) 10" (25 mm) Manual
26-1/4" (667 mm) 28-1/4" (718 mm) 10" (25 mm) Power
PAN DIMENSIONS (inside)
Tilt
4 OM-BLT/BLP-E
40E-BLP
35-3/4" (908 mm) 28-1/4" (718 mm) 10" (25 mm) Power
Optional Tangent Draw-off
Equipment Description
The following optional equipment may be added to any floor model listed above:
1. Fill faucet - swing spout single or double pantry
2. Fill faucet - 48” or 60” spray hose assembly - single or double pantry
3. Caster mounting kit
4. Flanged Feet Kit
5. Draw-Off Valve (can not be field installed)
6. Steamer insert set
7. Steamer pan carrier
8. Pouring Lip Strainer
9. Strainer for 2” TDO valve
OM-BLT/BLP-GE 5
Inspection & Unpacking
CAUTION
SHIPPING STRAPS ARE UNDER TENSION
AND CAN SNAP BACK WHEN CUT.
CAUTION
UNIT WEIGHS 420 TO 560 LB (190 TO 255
KG). FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR
EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A
FORKLIFT, DOLLY, OR PALLET JACK) TO
REMOVE THE UNIT FROM THE SKID AND
MOVE IT TO THE PLACE OF INSTALLATION.
The unit is strapped to a skid, and shipped
in a heavy cardboard carton. (Shown is a
40-gallon model with optional right side
mounted, double pantry faucet assembly.)
The unit will arrive completely assembled, wrapped in protective plastic on a heavy skid,
in a heavy cardboard carton. Immediately upon receipt, inspect the carton for damage.
Report any apparent shipping damage or an incorrect shipment to the delivery agent.
When installation is to begin, get someone to assist in removing the carton. Lift it straight
up and away from the unit. Do not simply raise it and push backwards - it will break
the cover assembly vent handle. Write down the model number, serial number, and
installation date of your unit, and keep this information for future reference. Space for
these entries is provided at the top of the Service Log in this manual.
Cut the straps holding the unit on the skid, and lift the unit straight up off the skid.
6 OM-BLT/BLP-E
Installation
CAUTION
BEFORE ANY ELECTRICAL CONVERSION,
VERIFY THAT THE BRANCH CIRCUIT
WIRING IS ADEQUATE TO HANDLE ANY
INCREASE IN AMPERAGE REQUIREMENTS.
REFER TO THE ELECTRICAL
SPECIFICATIONS LISTED BELOW.
WARNING
INSTALLATION OF THE BRAISING PAN
MUST BE DONE BY PERSONNEL QUALIFIED
TO WORK WITH ELECTRICITY. IMPROPER
INSTALLATION CAN RESULT IN INJURY TO
PERSONNEL AND/OR DAMAGE
TO EQUIPMENT.
Electronic spark ignition
Internal wiring for the Braising Pan is supplied complete. When you receive the unit, it
is ready for connection. A wiring diagram is located inside the control box on the right
side of the pan, as well as in this manual.
Your pan was performance-tested at the factory to confirm that all controls and
heating elements were functioning correctly.
Installation is as follows:
1. Set the unit in place and level it by turning the adjustable feet. Crank the pan
body to a completely horizontal position. Check levelness by placing a spirit level
on the bottom of the pan. The unit must be level to avoid uneven cooking across
the pan.
2. Make a waterproof connection with the incoming power line at the electrical
service entrance at the bottom of the connection box at rear of control console.
A BX connection is NOT recommended. ELECTRICALLY GROUND THE UNIT at the
proper terminal.
3. Provide the proper electrical supply as specified on the electrical information
plate. Comply with local codes and the National Electrical Code ANSI/NFPA 7latest edition.
4. Use only copper wire, rated at least 75ºC and of proper gage. See chart below.
5. Standard equipment is shipped ready for 208V, 240V, or 480V, 3-phase
operation. Refer to the wiring diagram located on the inside cover of the control
box and the instructions below for conversion to single-phase operation.
A jumper wire and “conversion” label are included with the unit. They can be
found in a plastic bag attached to the trunnion assembly inside the control box.
Electrical Requirements
Note: Use only copper wire rated for 75°c or higher
Model
30E-BLT
30E-BLP
40E-BLT
40E-BLP
Power
Kw Amps
11.5 56 6 48 6 32 8 28 10 17 14 14 14
11.5 56 6 48 6 32 8 28 10 17 14 14 14
15.3 74 4 64 4 43 8 37 8 22.5 12 19 14
15.3 74 4 64 4 43 8 37 8 22.5 12 19 14
208 Volt,
Single Phase
Wire
(AWG)
240 Volt,
Single Phase
Amps
(AWG)
Wire
208 Volt,
3-Phase
Amps
Wire
(AWG)
240 Volt,
3-Phase
Amps
Wire
(AWG)
400 Volt,
3-Phase, 4 Wire
Amps
Wire
(AWG)
480 Volt,
3-Phase
Amps
Wire
(AWG)
OM-BLT/BLP-GE 7
Installation
6. For conversion from 3-phase to 1-phase
a. Verify that the branch circuit wiring is adequate for any increased
amperage requirements. (See table on previous page)
b. 1-phase requires two jumper wires. One jumper wire exists on the terminal
block for 3- phase input. The second jumper wire is located in a plastic bag
inside the control box.
c. Attach jumper wires to terminal block as per wiring diagram for 1 phase
supply.
d. Complete “conversion label” (supplied in bag) and adhere it to the control
box near the UL data plate.
WARNING
WATER IS EXTREMELY HOT AND CAN CAUSE
SEVERE BURNS. AVOID CONTACT WITH HOT
WATER WHEN EMPTYING UNIT.
Initial Start-Up
Now that your braising pan has been installed, you should test it to ensure that the
unit is operating correctly.
1. Remove all literature and packing materials from the interior and exterior of the
unit.
2. Turn on the electrical power to the unit.
3. Put enough water into the pan to cover its bottom to a depth of 1/4” to 1/2” (6 to
13 mm). With the pan body in the horizontal position, note how the water covers
the pan bottom. This is a good method to use for confirming that the unit is
properly leveled.
4. Set the thermostat to 235˚F. The heating indicator light should come on to show
that the pan is heating. Heating should continue until the water boils.
5. To shut the unit down, turn the thermostat dial to “OFF.”
6. Turn the tilting handwheel clockwise to pour out the water and to confirm that
the pan body can be tilted smoothly from horizontal to vertical. For power tilt
models, push the UP/DOWN switch to confirm operation of tilting system.
8 OM-BLT/BLP-E
If the unit functions as described above, it is ready for use. If it does not, contact your
local Authorized Service Agency.
Operation
WARNING
KEEP THE AREA AROUND BRAISING PAN
FREE AND CLEAR OF COMBUSTIBLE
MATERIALS.
CAUTION
KEEP FLOORS IN BRAISING PAN WORK
AREA CLEAN AND DRY. IF SPILLS OCCUR,
CLEAN IMMEDIATELY TO AVOID THE
DANGER OF SLIPS OR FALLS.
CAUTION
REPLACE THE HOLE PLUG BEFORE
CLEANING OTHERWISE WATER COULD
ENTER THE ELECTRICAL CONTROL BOX
AND DAMAGE THE PARTS.
WARNING
WHEN TILTING BRAISING PAN
FOR PRODUCT TRANSFER:
1) USE CONTAINERS DEEP ENOUGH
TO CONTAIN AND MINIMIZE
PRODUCT SPLASHING.
2) PLACE CONTAINER ON A STABLE,
FLAT SURFACE, AS CLOSE TO THE
BRAISING PAN AS POSSIBLE.
3) STAND TO THE SIDE OF THE PAN
WHILE POURING — NOT DIRECTLY IN THE
POUR PATH OF HOT CONTENTS.
4) RETURN PAN BODY TO UPRIGHT
POSITION AFTER CONTAINER IS FILLED OR
TRANSFER IS COMPLETE.
5) DO NOT OVERFILL CONTAINER.
AVOID DIRECT SKIN CONTACT WITH HOT
CONTAINER AND CONTENTS.
A. Controls
Operator controls for the braising pans are:
1. Power ON Switch and Power ON indicator located on the control console.
2. The thermostat dial, located on the control console to the right of the
pan body. This dial is used to turn the thermostat on or off and to set the
thermostat for pan temperatures between 175° and 400°.
3. Heating indicator light located on the control console, lights when the
burners have ignited.
4. A handwheel controls the worm and gear mechanism that smoothly tilts
the pan body and holds it in the desired position.
5. For power tilt units a switch is located on the control panel. It is used to
raise and lower the pan body.
B. Operating Procedure
1. To Tilt Pan Body
a. Manual Tilt Model Turn the tilting handwheel clockwise to tilt the pan body, or
counterclockwise to return the pan body to horizontal. 23 complete
turns of the handwheel will tilt the body 90 degrees to vertical.
b. Power Tilt Model -
1. Press the power tilt switch marked “up” to raise the pan or
“down” to lower the pan.
2. The spring loaded switch will return to the OFF (middle) position
when you release it.
3. If the power tilt mechanism stops working (see the
Troubleshooting section) and you must raise or lower the pan
body without delay, you can tilt the body by hand. Remove the
small plug on top of the control box and fit the provided tool
into the hole. Turn the tool clockwise to lower it. It may take
several minutes to move the pan to the desired position, but the
operation can be speeded up by substituting a reversible drill
with a 1/4” hexagonal driver bit in place of the tool.
Tilting pan body
2. Set the thermostat dial to the desired temperature between 100 and 400˚F.
The Heat Indicator Light shows that the pan is heating. When the light
cycles on and off, it indicates that the pan is holding at the set temperature.
During these cycles you may hear the contactors in the control box make a
clicking sound. This is normal.
3. For best results when braising or frying, preheat the pan before putting
in any food. For an even temperature across the pan, preheat at a setting
of 300˚F or less for 15 minutes, or through several on/off cycles of the
thermostat.
OM-BLT/BLP-GE 9
Operation
CAUTION
DO NOT HEAT AN EMPTY PAN FOR
MORE THAN FIVE MINUTES AT A
SETTING HIGHER THAN 300°F.
DAMAGE TO THE PAN COULD RESULT.
CAUTION
DO NOT OVERFILL THE BRAISING PAN
WHEN COOKING, HOLDING OR
CLEANING. KEEP LIQUIDS AT LEAST 2-3”
(5-8 cm) BELOW THE PAN BODY RIM TO
ALLOW CLEARANCE FOR STIRRING,
BOILING PRODUCT AND
SAFE TRANSFER.
WARNING
AVOID ANY EXPOSURE TO THE STEAM
ESCAPING FROM THE COVER VENT.
DIRECT CONTACT COULD RESULT IN
SEVERE BURNS.
WARNING
ITEMS IN SAUCE OR MELTED FAT CAN
SLIDE FORWARD SUDDENLY DURING TILTING
AND SPLASH THE HOT LIQUID.
C. Cooking
1. To simmer or slowly heat an item, set the dial at 210°F or lower. Put the
cover down to minimize moisture loss, or leave it up to help dry or reduce the
product. Set the thermostat higher to cook or drive off moisture faster. You
may adjust the thermostat to any setting to cook the item exactly as required.
2. Leave the cover vent open to let excess steam escape. For long simmering
operations, you may wish to close the vent to retain moisture.
3. To check progress when the cover is closed, lift the handle of the vent
cover slightly, and move it quickly to either side.
4. Standing to one side of the pan (to avoid the steam that will be released)
grasp the nearer corner of the cover handle and raise the cover. The cover
will stay in the open position until you push it down.
5. To pour product, remove grease, or assist in cleaning, first raise the cover,
then tilt the pan forward by turning the tilting handwheel. When you stop
turning the wheel, the pan body will hold its position.
6. To return the pan to the horizontal position, turn the wheel counterclockwise.
WARNING
AVOID ALL DIRECT CONTACT WITH HOT
EQUIPMENT SURFACES. DIRECT SKIN
CONTACT COULD RESULT IN SEVERE
BURNS. AVOID ALL DIRECT CONTACT WITH
HOT FOOD OR WATER IN THE BRAISING PAN.
DIRECT CONTACT COULD RESULT IN
SEVERE BURNS.
7. To turn the pan off, turn the thermostat to the “OFF” position.
D. Routine Clean-Up
After each use, turn the thermostat to “OFF” and clean all food contact surfaces
to ensure proper sanitation. At the end of the day, or at least once every 24
hours, turn off the heat and shut off electric power to the unit and clean both
the interior and exterior of the pan. See Page 12 for more detailed cleaning
instructions.
10 OM-BLT/BLP-E
Sequence of Operation
The following “action-reaction” outline is provided to help you understand how the braising
pan actually functions.
When you start up the pan by turning the thermostat from “OFF” to a desired temperature,
the thermostat switch closes. This causes the contactors to close, and allows power to flow
to the heating elements and the indicator light.
When the pan temperature reaches the value set on the thermostat dial, the thermostat
switch opens and causes the contactors to open. This stops the flow of power to the heating
elements and the indicator light. As soon as the thermostat senses that the pan is cooling
below the set temperature, the thermostat closes, the contactors close, and the heaters and
indicator light come on again.
This on and off cycle continues, maintaining the pan at the set temperature. This is why the
indicator light on and off cycling is seen during normal operation. If the pan temperature
exceeds 425°F for any reason, a high-limit thermostat shuts off the power until the pan
cools. At that point, the thermostat automatically resets to permit normal operation to start
again.
Turning the thermostat to “OFF” shuts down all control and heating circuits.
The thermostat controls heating by alternating between feeding full power and completely
cutting power off. The pan heats as fast as it can until it reaches the set temperature, no
matter what that temperature is. Turning the thermostat to a higher setting will cause
heating to continue longer, until the pan reaches a higher temperature, but it cannot make
the pan heat any faster.
Manual tilt models, turning the hand wheel rotates a worm, which turns a gear wheel on
one of the trunnions supporting the pan body. Turning the gear produces the tilting action.
Power tilt models, pushing the up/down switch operates a gear motor which turns worm
and gear wheel as described above.
For all braising pans, the power to the heaters is cut off when the pan is tilted past a slight
inclination of 10° degrees. It is acceptable to cook with the pan tilted forward at a small
angle (about 5 - 7 degrees) to let liquids collect to front of pan or allow them to drain out of
the draw off valve.
OM-BLT/BLP-GE 11
Cleaning
WARNING
KEEP WATER AND SOLUTIONS OUT OF
CONTROLS AND ELECTRICAL EQUIPMENT.
DO NOT USE A HIGH PRESSURE HOSE TO
CLEAN THE CONTROL CONSOLE,
ELECTRICAL CONNECTIONS, ETC.
CAUTION
MOST CLEANERS ARE HARMFUL TO THE
SKIN, EYES, MUCOUS MEMBRANES AND
CLOTHING. PRECAUTIONS SHOULD BE
TAKEN TO WEAR RUBBER GLOVES,
GOGGLES OR FACE SHIELD AND
PROTECTIVE CLOTHING. CAREFULLY READ
THE WARNINGS AND FOLLOW THE
DIRECTIONS ON THE LABEL OF THE
CLEANER TO BE USED.
WARNING
BEFORE ANY CLEANING OPERATION,
TURN THERMOSTAT DIAL TO “OFF” TO
CUT ANY POWER TO THE HEATING
ELEMENTS. BEFORE CLEANING ANY PART
OTHER THAN THE INSIDE OF THE PAN,
DISCONNECT ELECTRICAL SUPPLY AT
CIRCUIT BREAKER OR FUSE BOX.
A. Suggested Tools
1. A good stainless steel cleaner
2. Brushes in good condition
3. Cloth for cleaning controls
4. Chlorine sanitizer
5. Heavy Duty Cleaner (if required)
B. Procedure
1. Clean all food-contact surfaces soon after use. It is best to clean the pan
before it has completely cooled. If the unit is in continuous use, completely
clean and sanitize both the inside and outside at least once every 12 hours.
2. To remove any large amount of food left in the pan, tilt the pan all the way
up and flush it with lukewarm water. Do not damage the surface of the pan
by scraping it with a metal tool. Scratches make the surface more difficult
to clean, and provide ideal breeding places for bacteria.
3. Following the supplier’s directions, make up a warm solution of the cleaner.
Carefully wash the inside and outside of the pan body with the cleaning
solution.
4. Use a cloth moistened with cleaning solution to clean controls, the control
console, and electric conduit.
5. Rinse the pan very well with lukewarm water, and drain it completely.
6. As part of the daily cleaning program, clean all inside and outside surfaces
that may have been soiled. Remember to check such parts as the undersides of the cover, the electrical console and other more remote spots.
Clean between the pan body and the consoles using a brush.
Use a brush, sponge, cloth, plastic or
rubber scraper, or plastic wool to clean.
Don’t use metal implements or steel wool.
Do not spray water directly on burners
and gas combustion chambers.
12 OM-BLT/BLP-E
7. Controls and the control console may be cleaned with a damp cloth or
sprayed with a garden hose spray connected to city water supply. Do not
use a pressure sprayer directly on the unit or electrical parts.
8. To remove materials stuck to the equipment, use a brush, sponge, cloth,
plastic or rubber scraper, or plastic wool with the cleaning solution. To
make washing easier, let the cleaning solution sit in the unit and soak
into the residue, or heat the solution briefly. Do not use any gritty cleaner
or metal tool that might scratch the surface. Scratches make the surface
harder to clean, and also provide places for bacteria to grow. Do not use
steel wool. Small bit of steel wool left in the surface of the unit can cause
rusting and pitting.
9. The outside of the unit may be polished with a recognized stainless steel
cleaner such as Zepper from the Zep Manufacturing Company.
10. When the equipment needs to be sanitized, use a sanitizing solution
equivalent to one that supplies 100 parts per million available chlorine.
Get advice about the best sanitizing agent from you supplier of sanitizing
products.
Cleaning
CAUTION
NEVER LEAVE A CHLORINE SANITIZER IN
CONTACT WITH STAINLESS STEEL
SURFACES FOR LONGER THAN 30 MINUTES.
LONGER CONTACT CAN CAUSE CORROSION.
CAUTION
KEEP CAUSTIC COMPOUNDS SUCH AS
FRYER BOILOUT CLEANERS AWAY FROM
ALUMINUM PARTS OF THE LID HINGE
SYSTEM AND THE COUNTERBALANCE
ASSEMBLY. HIGHLY CAUSTIC COMPOUNDS
COULD DAMAGE THIS MATERIAL.
11. Following supplier instructions, apply the sanitizing agent after the unit has
been cleaned and drained. Thoroughly drain off the sanitizer.
12. After the unit has been cleaned, sanitized and drained, let all surfaces air
dry unless the unit must be used again right away.
13. It is recommended that the unit be sanitized just before use. Follow the
directions of the sanitizer supplier.
14. About once a week (more often if the water is very hard), use a heavy
duty cleaner to remove any mineral deposits or film left by hard water or
foods. Follow the supplier’s directions very carefully, and rinse the unit off
thoroughly, as soon as cleaning is finished.
15. If especially difficult cleaning problems persist, contact your cleaning
product supplier for help. The supplier has a trained technical staff with
laboratory facilities to serve you.
OM-BLT/BLP-GE 13
Maintenance
WARNING
ELECTRIC POWER ALWAYS SHOULD BE
SHUT OFF BEFORE WORK IS DONE ON
INTERNAL COMPONENTS.
WARNING
DISCONNECT ELECTRICAL POWER FROM
THE UNIT BEFORE ATTEMPTING TO GREASE
THE TRUNNION BEARINGS.
Your braising pan is designed to require minimum maintenance, but certain parts
may need replacement after prolonged use. After installation, no user adjustment
should be necessary. If a service need arises, only authorized personnel should
perform the work.
Service personnel should check the unit at least once a year. This periodic maintenance should include inspecting electrical wires and connections, cleaning the
inside of the control console, and possible adjustment of the pilot light. (Units with
standing pilot ignition only) At least twice a year, grease the two trunnion bearings
and worm gear.
We recommend the use of number two grade LGI lithium grease. Add grease through
the zerk fittings on the gear hosing until grease flows out of the bearings around trunnion shaft. Also, add grease in the gear to cover arc that is in contact with the worm
gear. Clean up excess grease.
A Service Log is provided with the warranty information at the back of this manual.
Each time service is performed on your equipment, enter the date on which the work
was done, what was done, and who did it. Keep the manual with the equipment for
quick and easy reference.
14 OM-BLT/BLP-E
Troubleshooting
Your braising pan will operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in
the event of a problem. If the actions suggested do not solve the problem, call your qualified Service Representative. If an item on
the list is followed by X, the work should only be performed by a qualified service representative.
WARNING
ELECTRICAL POWER MUST BE SHUT OFF BEFORE WORK IS DONE ON INTERNAL COMPONENTS.
USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY THE MANUFACTURER OR THEIR AUTHORIZED
DISTRIBUTOR CAN CAUSE INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.
SERVICE PERFORMED BY OTHER THAN FACTORY-AUTHORIZED PERSONNEL WILL VOID ALL WARRANTIES.
SYMPTOM WHO WHAT TO CHECK
(X indicates work that should only be performed by a qualified service representative)
Pan will not heat, but
indicator light comes on.
Pan will not heat, and
indicator light will not
light.
Pan continues to heat
after it reaches desired
temperature.
Pan does not reach
desired temperature.
Rapid clicking noise
(chattering).
Authorized
Service Rep Only
User a. That power supply is on.
Authorized
Service Rep Only
User a. Thermostat dial setting. Turn down if too high.
Authorized
Service Rep Only
User a. Thermostat dial setting. Turn up if too low.
Authorized
Service Rep Only
User a. For low voltage.
Authorized
Service Rep Only
a. Heating elements for short circuit. X
b. Fuses, accessible by removing caps on the side of the control box.
c. For loose or broken wires. X
d. Thermostat functioning, by listening for a click when the switch
opens or closes. X
e. Contactor functioning. X
b. Thermostat functioning. X
c. Thermostat calibration. X
d. Contactor, to determine if it is de-energized. X
b. Heating elements for ground short or open (burned out) element. X
c. Thermostat functioning, by listening for a click when the switch
opens or closes. X
d. Thermostat calibration. X
e. Contactor functioning. X
b. Contactor for dirt or corrosion on the contacts. X
Uneven cooking due
to “ hot spots.”
Uneven cooking due
to “ cold spots.”
Pan is hard to tilt
(Manual Tilt Models).
Pan will not tilt
(Power Tilt Models).
User a. That the pan body is level.
Authorized
Service Rep Only
User a. Gears for foreign materials, lubrication and alignment.
User a. That electrical power supply is on.
Authorized
Service Rep Only
a. For open (burned out) heating element. X
b. For overheated actuator motor. Wait 15 minutes for motor to cool,
then operate the power tilt.
c. For blown fuse on motor control circuit - Replace fuse with approved
equal. X
d. For damaged DC rectier and operating relays. X
e. Correct setting of upper and lower limit switches. X
OM-BLT/BLP-GE 15
Key Description Part #
1 CASTER KIT (SET OF 2 WITH
BRAKE AND 2 W/O BRAKE)
1 CASTER WITH BRAKE (W/O
FOOT ADAPTER)
1 CASTER WITHOUT BRAKE
(W/O FOOT ADAPTER)
NOT SHOWN
2 FOOT ADAPTER 146516
3 FLANGED FOOT
(W/O FOOT ADAPTER)
4 BULLET FOOT
(W/O FOOT ADAPTER)
5 FRICTION RING 146520
170810
146513
146515
146521
146628
Parts List
Stand & Foot Assembly
16 OM-BLT/BLP-E
Key Qty Description Part #
1 1 COVER &
COUNTERBALANCE
ASSEMBLY,
30 GALLON - NO KNOB
1 1 COVER &
COUNTERBALANCE
ASSEMBLY,
40 GALLON - NO KNOB
3 4 STUD WELD,
1/4”-20 X 1-1/4”
4 4 WASHER, LOCK 3/8” 005618
158643
158658
012589
Parts List
Cover & Counterbalance Assemblies
5 4 SCREW, HEX HEAD CAP
3/8”-16 X 1”
6 4 NUT, HEX 3/8”-16 005619
7 4 DOME NUTS, 1/4-20 090567
8 2 SCREW, TRUSS HEAD,
#10-32 X 3/8”
9 1 VENT COVER ASSY. 158642
005612
004173
OM-BLT/BLP-GE 17
Parts List
8
9
17
13
3
5
18
1
2
20
21
18 OM-BLT/BLP-E
Parts List
OM-BLT/BLP-GE 19
Parts List
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number,
quantity, and when applicable, voltage and phase.
KEY DESCRIPTION PART NO.
1 STAND ASSEMBLY - 30 144848
1 STAND ASSEMBLY - 40 144332
2 PAN WELDMENT - 30 145654
2 PAN WELDMENT - 40 144789
3 KNOB THERMOSTAT 003908
4 OPERATING THERMOSTAT 002180
5 LIGHT, AMBER 116384
6 TILT SWITCH 143319
7 CONTACTOR 148102
8 GOUND TERMINAL 119829
9 TERMINAL BLOCK 003888
10 FUSE HOLDER 077854
11 FUSE, 3 AMP 077853
12 TRANSFORMER - 208/240V 137441
12 TRANSFORMER - 480V 137694
13 POWER SWITCH 155546
14 HIGH LIMIT THERMOSTAT 142755
15 ELEMENT - 208V 145656
15 ELEMENT - 240V 146185
15 ELEMENT - 480V 149114
16 COVER ELEMENT HOUSING - 30 146186
KEY DESCRIPTION PART NO.
16 COVER ELEMENT HOUSING - 40 144343
17 RIGHT SIDE COVER 145688
18 LEFT TRUNNION COVER ASSEMBLY 144776
19 TILT SWITCH BRACKET ASSEMBLY 145689
20 CONTROL BOX ASSEMBLY 147313
21 ELECTRICAL BOX ASSEMBLY 147315
22 TERMINAL BLOCK BOX 146205
23 TERMINAL BLOCK BOX BOTTOM 146207
x TRANSFORMER, POWER TILT 480V 051469
x OVERLAY, MANUAL TILT 170800
x OVERLAY, POWER TILT 170801
x HARNESS, CONTROL 148538
x HARNESS, POWER 208/240V 148539
x HARNESS, POWER 480V 149291
x HARNESS, ELEMENTS 30 208/240V 148560
x HARNESS, ELEMENTS 30 480V 149293
x HARNESS, ELEMENTS 40 208/240V 148561
x HARNESS, ELEMENTS 40 480V 149292
x- Item not depicted/called out in drawing or photograph
20 OM-BLT/BLP-E
Key Qty Description Part #
1 1 GEAR CARRIER 002624
2 1 SHAFT, HANDWHEEL 144834
3 1 GEAR, WORM 128001
4 1 GEAR SECTOR 009829
5 1 KEY GIB 012031
6 1 HANDWHEEL 139152
7 2 PIN ROLL 012614
8 2 SCREW SET SOCKET 012060
9 2 BEARING ROLLER 002790
10 2 BEARING SLEEVE 137239
11 1 PLUG PIPE 010286
14 1 FITTING GREASE 90
(NOT SHOWN)
15 1 BUSHING SNAP
(NOT SHOWN)
16 2 WASHER LOCK 005618
17 2 SCREW HEX HEAD CAP 005612
012195
000453
Parts List
Manual Tilt Assembly
OM-BLT/BLP-GE 21
Key Qty Description Part #
1 1 ELECTRIC TILT SHAFT 144791
2 1
3 1 SHAFT COUPLING 144615
4 1 GEAR CARRIER ASSY 137880
4a 1 CARRIER GEAR 002624
4b 2 BEARING ROLLER 002790
4c 2 BEARING SLEEVE 137239
4d 1 PLUG PIPE 010286
4e 1 FITTING GREASE 90 012195
5 1 GEAR, WORM 128001
6 1 GEAR SECTOR 009829
6a 2 SCREW SET SOCKET 012060
7 1 KEY GIB 012031
8 1 PIN ROLL 012614
9 1 MOTOR BRACKET 146114
10 1 REAR MOTOR BRACKET 146117
11a 1 FUSE HOLDER [MOTOR] 077840
11b 1 FUSE 144856
11c 1 RECTIFIER 145660
11d 2
12 5 NUT HEX HEAD 1/4”-20 005601
13 5 WASHER LOCK 1/4” 005655
14 3
15 2 SCREW HEX HEAD CAP 005609
16 2 WASHER LOCK 3/8” 005618
17 2
18 1
- 1 HOLE PLUG-1” 146369
- 1
- 1
- 2
- 1
- 1
POWER LIFT MOTOR
[204/240 VOC]
RELAY [24VAC, DPST,
N0]-2 REQ’D
SCREW HEX HEAD CAP
1/4”-20 X 2-1/2” LONG
SCREW HEX HEAD CAP
3/8”-16 X 1” LONG
ELECTRIC TILT SHAFT KEY
MANUAL OVERRIDE
CRANK
POWER TILT SWITCH,
RECESSED ROCKER NO
INDICATOR
TILT LIMIT SWITCH
(POWER TILT UP/DN )
WIRE HARNESS,LOW
VOLTAGE
WIRE HARNESS-HIGH
VOLTAGE
144794
119814
052584
005612
013386
145659
144857
002982
146197
148769
Parts List
Power Tilt Assembly
22 OM-BLT/BLP-E
Schematics
30 Gallon Manual Tilt
OM-BLT/BLP-GE 23
Schematics
30 Gallon Power Tilt
24 OM-BLT/BLP-E
Schematics
40 Gallon Manual Tilt
OM-BLT/BLP-GE 25
Schematics
40 Gallon Power Tilt
26 OM-BLT/BLP-E
Service Log
Model No: Purchased From:
Serial No: Location:
Date Purchased: Date Installed:
Purchase Order No: For Service Call:
Date Maintenance Performed Performed By
OM-BLT/BLP-GE 27
Service Log
Model No: Purchased From:
Serial No: Location:
Date Purchased: Date Installed:
Purchase Order No: For Service Call:
Date Maintenance Performed Performed By
28 OM-BLT/BLP-E
OM-BLT/BLP-GE 29
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: 866-518-3977
PART NUMBER 170806 REV B (04/11)
Loading...
