Blizzard Lighting RGBW ToughPar Satellight User Manual Rev A

Download

TOUGHPA R

SUITABLE FOR OUTDOOR USE

Blizzard Lighting, LLC

www.blizzardlighting.com

Waukesha, WI USA

TABLE OF CONTENTS

ToughPar™ Satellight LED Wash Fixture 1

1. Getting Started 3

What’s In The Box? 3 Getting It Out Of The Box 3 Powering Up! 3 Getting A Hold Of Us 3 Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4

2. Meet The ToughPar™ Satellight 5

Features 5 DMX Quick Reference 5 The ToughPar™ Satellight Pin-up Picture 6

3. Setup 7

Fuse Replacement 7 Connecting A Bunch Of ToughPar™ Satellight PAR Cans 7 Data/DMX Cables 7 Cable Connectors 8 3-Pin??? 5-Pin??? Huh? 8 Take It To The Next Level: Setting up DMX Control 8 Fixture Linking (Master/Slave Mode) 9 Mounting/Rigging 9

4. Operating Adjustments 10

Navigating The Control Panel 10 Control Panel Menu Structure 11 Adjust the Starting DMX Address 12 Slave Mode 12 DMX Channel Mode 12 Built-in Programs 12 DMX Channel Values In-Depth 14 Troubleshooting 15 Dimensional Diagram 16

5. Appendix 17

A Quick DMX Lesson 17 Keeping Your ToughPar™ Satellight As Good As New 18 Returns (Gasp!) 18 Shipping Issues 18 Tech Specs 19

Page 2

1. GETTING STARTED

What’s In The Box?

• 1 x ToughPar™ Satellight Professional LED PAR Fixture

• 1 x IP Rated AC power cord with cable cap

• 1 x Set of IP Rated DMX in/out cables

• This Lovely User Manual

Optional Accessories (sold separately)

The following accessories are available for this xture. But the lone wolves that they are, they must

be purchased separately. Contact your authorized Blizzard Lighting dealer for pricing!

• DMX-EXT: 3-Meter IP-Rated DMX Extension Cable

• PWR-EXT: 3-Meter IP-Rated Power Extension Cable

Getting It Out Of The Box

Congratulations on purchasing one of the toughest PAR xtures anywhere! Now that you’ve got your

ToughPar™ Satellight (or hopefully, Satellight’s!), you should carefully unpack the box and check the contents to ensure that all parts are present and in good condition. If anything looks as if it has been damaged in transit, notify the shipper immediately and keep the packing material for inspec-

tion. Again, please save the carton and all packing materials. If a xture must be returned to the factory, it is important that the xture be returned in the original factory box and packing.

Powering Up!

All xtures must be powered directly off a switched circuit and cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0% to 100% switch.

AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the xture you receive is suitable for your local power supply. See the label on the xture or refer to the xture’s specications chart for more information. A xture’s listed current rating is its average current draw under normal conditions. Check the xture or device carefully to make sure that if a

voltage selection switch exists that it is set to the correct line voltage you will use.

Warning! Verify that the voltage select switch on your unit matches the line voltage

applied. Damage to your xture may result if the line voltage applied does not match the voltage indicated on the voltage selector switch. All xtures must be connected to circuits with a suitable Ground (Earthing).

Getting A Hold Of Us

If something is wrong, just give us a call or send an email. We’ll be happy to help, honest.

Blizzard Lighting N16 W23390 Stoneridge Dr. Ste E Waukesha, WI 53188 USA www.blizzardlighting.com 414-395-8365 Email: support@blizzardlighting.com

Disclaimer: The information and specications contained in this document are subject to change

without notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. You can download the latest version of this document from www.blizzardlighting.com.

Author: Date: Last Edited: Date:

J. Thomas 11/7/2013 J. Thomas 1/31/2014

Page 3

SAFETY INSTRUCTIONS

• Please keep this User Guide for future use. If you sell the unit to someone else, be sure that they also receive this User Guide.

• ALWAYS make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the de-

cal or rear panel of the xture.

• This product is intended for indoor use only.

• To prevent risk of re or shock, do not expose xture to rain or moisture.

• Make sure there are no ammable materials close to the unit while operating.

• The unit must be installed in a location with adequate ventilation, at least 20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are blocked.

• ALWAYS disconnect from the power source before servicing or replacing fuse and be sure to replace with same fuse size and type.

• ALWAYS secure xture using a safety chain. NEVER carry the xture by its

cord. Use its carrying handles.

• DO NOT operate at ambient temperatures higher than 104°F (40°C).

• In the event of a serious operating problem, stop using the unit immediately. NEVER try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center. Always use the same type spare parts.

• NEVER connect the device to a dimmer pack.

• Make sure the power cord is never crimped or damaged.

• Never disconnect the power cord by pulling or tugging on the cord.

• Avoid direct eye exposure to the light source while it is on.

Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact Blizzard Lighting at support@blizzardlighting.com.

Page 4

2. MEET THE TOUGHPAR™ SATELLIGHT LED PAR

CONTROL FEATURES

• RGBW color mixing via 9x 10W (4x 2.5w) R/G/B/W 4-in-1 LEDs

• Variable electronic dimming & strobe

• Built-in color & chase macros via DMX

• Built-in automated programs via master/slave

• RGBW color mixing ability in standalone mode

• RGBW w/32-bit dimming (5-Channel), & Extended w/32-bit dimming

(9-Channel) DMX Proles

ADDITIONAL FEATURES

• Rugged and well-built (It hits the gym regularly)

• 180° tilt head with dual secure locking knobs

• Constant current driver: 320mA

• Flicker-free constant-current 400hz LED driver

• Totally silent convection cooling

• IP Rated AC power cord with cable cap

• IP Rated DMX in/out cables

DMX Quick Reference: 9-Channel Mode

Channel What it does...

1 Dimmer

2 Red Intensity (0% <--> 100%)

3 Green Intensity (0% <--> 100%)

4 Blue Intensity (0% <--> 100%)

5 White Intensity (0% <--> 100%)

6 Strobe (slow <--> fast)

7 Static Colors + Color Jump w/Speed Control

8 Auto Color Fade w/Speed Control

9 32-bit Dimmer

DMX Quick Reference: 5-Channel Mode

Channel What it does...

1 Red Intensity (0% <--> 100%)

2 Green Intensity (0% <--> 100%)

3 Blue Intensity (0% <--> 100%)

4 White Intensity (0% <--> 100%)

5 32-bit Dimmer

Page 5

Figure 1: The ToughPar™ Satellight Pin-Up Picture

10-watt RGBW

4-in-1 LEDs

LED Display

Menu Buttons

A/B

Tempered Glass

Lens Cover

180 Degree Tilt

Fixture Head

Secure Grip

Locking Knobs

IP65-Rated

Cast Aluminum

Enclosure

AC Power Out

AC Power In

DMX Out

DMX In

Page 6

3. SETUP

Fuse Replacement

CAUTION! The ToughPar™ Satellight utilizes a high-output switch-

mode power supply with an internal fuse. Under normal operating

conditions, the fuse should not require replacement. The fuse is eld replaceable, however it is an advanced procedure suited to qualied

individuals. Should your ToughPar™ Satellight fuse require replacement, please contact Blizzard Lighting for instructions, or to return your unit for service.

Connecting A Bunch of ToughPar™ Satellight Fixtures

You will need a serial data link to run light shows using a DMX-512 controller or to run shows on two or more xtures set to sync in master/slave operating mode. The combined number of channels required by all the xtures on a serial data link determines the number of xtures the data link can support.

Fixtures on a serial data link must be daisy chained in one single line.

Also, connecting more than 32 xtures on one serial data link without

the use of a DMX optically-isolated splitter may result in deterioration of the digital DMX signal. The maximum recommended cable-run distance is 500 meters (1640

ft). The maximum recommended number of xtures on a serial data link is 32 xtures.

Data/DMX Cabling

To link xtures together you’ll need data cables. You should use data-

grade cables that can carry a high quality signal and are less prone to electromagnetic interference.

For instance, Belden© 9841 meets the specications for EIA RS-485

applications. Standard microphone cables will “probably” be OK, but note that they cannot transmit DMX data as reliably over long distances. In any event, the cable should have the following characteristics:

2-conductor twisted pair plus a shield

Maximum capacitance between conductors – 30 pF/ft. Maximum capacitance between conductor & shield – 55 pF/ft. Maximum resistance of 20 ohms / 1000 ft. Nominal impedance 100 – 140 ohms

Page 7

Cable Connectors

Cables must have a male XLR connector on one end and a female XLR connector on the other end. (Duh!)

CAUTION: Do not allow contact between the common and the x- ture’s chassis ground. Grounding the common can cause a ground

loop, and your xture may perform erratically. Test cables with an

ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.

3-Pin??? 5-Pin??? Huh?!?

If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. They are widely available over the internet and from specialty retailers If you’d like to build your own, the chart below details a proper cable conversion:

Conductor 3-Pin Female

(Output)

5-Pin Male (Input)

Ground/Shield Pin 1 Pin 1

DMX Data (-) Pin 2 Pin 2

DMX Data (+) Pin 3 Pin 3

Not Used. No Connection. No Connection.

Take It To The Next Level: Setting Up DMX Control

Step 1: Connect the male connector of the

DMX cable to the female connector (output) on the controller.

Step 2: Connect the female connector of the DMX cable to the rst xture’s male connector (input). Note: It doesn’t matter which

xture address is the rst one connected. We recommend connecting the xtures in

terms of their proximity to the controller,

rather than connecting the lowest xture number rst, and so on.

Step 3: Connect other xtures in the chain

from output to input as above. Place a DMX

terminator on the output of the nal xture

to ensure best communication.

Page 8

Fixture Linking (Master/Slave Mode)

1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of

the rst xture.

2. Connect the end of the cable coming from the

rst xture which will have a (female) 3 pin connector to the input connector of the next xture con-

sisting of a (male) 3 pin connector. Then, proceed to connect from the output as stated above to the

input of the following xture and so on.

A quick note: Often, the setup for MasterSlave and Standalone operation requires that

the rst xture in the

chain be initialized for this purpose via either settings in the control panel or DIP-switches.

Secondarily, the xtures

that follow may also require a slave setting.

Check the “Operating Adjustments” section in this manual for com-

plete instructions for this type of setup and conguration.

Mounting & Rigging

This xture may be mounted in any SAFE position provided there is

enough room for ventilation.

It is important never to obstruct the fan or vents pathway. Mount the

xture using a suitable “C” or “O” type clamp. The clamp should be rated to hold at least 10x the xture’s weight to ensure structural sta-

bility. Do not mount to surfaces with unknown strength, and ensure

properly “rated” rigging is used when mounting xutres overhead.

Adjust the angle of the xture by loosening both knobs and tilting the xture. After nding the desired position, retighten both knobs.

• When selecting installation location, take into consideration lamp replacement access (if applicable) and routine maintenance.

• Safety cables MUST ALWAYS be used.

• Never mount in places where the xture will be exposed to rain,

high humidity, extreme temperature changes or restricted ventilation.

Page 9

4. OPERATING ADJUSTMENTS

The Control Panel

All the goodies and different modes possible with the ToughPar™ Satellight LED are accessed by using its control panel. There are 2 control buttons below the 3 character LED display which allow you to navigate through the various control panel menus.

<A>

Function Button: Used to scroll through main menu functions.

<B>

Setup Button: Used to scroll through & select submenu items.

0 01

The control panel LED display shows the menu items you select from the menu map on page #11. Press the <A> button repeatedly until you reach the desired menu function. When a menu function is select-

ed, the display will immediately show the rst available option for this

selected menu function.

Use the <B> button to navigate the options. Press <A> to either scroll to the next currently displayed option, or return to scrolling the main menu (depending if there is, or is not, more than 1 option per each of the 3 digits currently on the LED display). If you do not press any key for 30 seconds, the state will be automatically saved and will

stop ashing.

Page 10

Control Panel Menu Structure

001 001 - 512 To choose the DMX address

PSA Sets the xture to run in slave mode

PA - PA5 - PA9 To choose 5 or 9 channel DMX mode

Pd - Pd0 - Pd4 To choose 32-bit dimming mode 0-4

P0 - P00 - P09 Red intensity from 0-9 (0% <--> 100%)

P1 - P10 - P19 Blue intensity from 0-9 (0% <--> 100%)

P2 - P20 - P29 Green intensity from 0-9 (0% <--> 100%)

P3 - P30 - P39 White intensity from 0-9 (0% <--> 100%)

P4 - P40 - P49 Strobe intensity from 0-9 (slow <--> fast)

P5 - P50 - P59 Color jump, speed 0-9 (slow <--> fast)

P6 - P60 - P69 Color fade, speed 0-9 (slow <--> fast)

Page 11

Adjust the Starting DMX Address

1.) To adjust the starting DMX channel, rst push the “A” button once so the 3rd (right) digit is ashing.

2.) Push the “B” button to adjust this digit to a value of 0-9.

3.) Repeating the same process, push the “A” button once so the 2rd (middle)

digit is ashing.

4.) Push the “B” button to adjust this digit to a value of 0-9.

5.) Repeating the same process, push the “A” button once so the 1st (left) digit

is ashing.

6.) Push the “B” button to adjust this digit to a value of 0-5.

7.) Pushing the “A” button once more will nalize your choice of the starting DMX address with the value being in the range of 001-512.

Slave Mode

1.) To set the xture in slave mode, press the “A” button until you reach “PSA” on the LED display. This xture is now set to slave mode and will automatically follow the rst unit in the DMX chain, aka the “Master”.

DMX Channel Mode

To set the xture to run in either 5-channel or 9-channel DMX mode:

1.) Push the “A” button until the LED display reads “PA-”.

2.) The right digit will be ashing. Use the “B” button to switch between the choices of “5” or “9”.

Dimming Mode

The ToughPar Satellight features ultra smooth icker-free 32-bit dimming with 5 user-selectable dimming curves. To manually set the xture to use one of these

5 dimming curve choices, simply do the following:

1.) Push the “A” button until the LED display reads “PD-”

2.) The right digit will be ashing. Use the “B” button to switch between the

choices of dimming curve number 0-4.

Built-in Programs

In built-in program mode, each of the 3 digits on the LED screen signify sepatate meanings.

Left Digit: Shows “P”, for “Program Mode” Middle Digit: Represents the built-in program 0-6. Right Digit: Modies the selected program.

Page 12

Program Mode

P00

Program 0-6

Red Intensity

1.) Push the “A” button until the LED display reads “P0-”.

2.) The right digit will be ashing. Use the “B” button to choose the intensity level from 0-9 (0% <--> 100%).

Green Intensity

1.) Push the “A” button until the LED display reads “P1-”.

2.) The right digit will be ashing. Use the “B” button to choose the intensity level from 0-9 (0% <--> 100%).

Blue Intensity

1.) Push the “A” button until the LED display reads “P2-”.

2.) The right digit will be ashing. Use the “B” button to choose the intensity level from 0-9 (0% <--> 100%).

White Intensity

1.) Push the “A” button until the LED display reads “P3-”.

2.) The right digit will be ashing. Use the “B” button to choose the intensity level from 0-9 (0% <--> 100%).

Options 0-9 Per

Each Program

White Strobe Mode

1.) Push the “A” button until the LED display reads “P4-”.

2.) The right digit will be ashing. Use the “B” button to choose the rate from 0-9 (slow <--> fast).

Color Jump Mode

1.) Push the “A” button until the LED display reads “P5-”.

2.) The right digit will be ashing. Use the “B” button to choose the speed from 0-9 (slow <--> fast).

Color Fade Mode

1.) Push the “A” button until the LED display reads “P6-”.

2.) The right digit will be ashing. Use the “B” button to choose the speed from 0-9 (slow <--> fast).

Page 13

DMX Values In-Depth (5-Channel Mode)

Channel Value What It Does

1 000 <--> 255 Red Intensity (0% <--> 100%)

2 000 <--> 255 Green Intensity (0% <--> 100%)

3 000 <--> 255 Blue Intensity (0% <--> 100%)

4 000 <--> 255 White Intensity (0% <--> 100%)

000 <--> 005 006 <--> 055 056 <--> 105 106 <--> 155 156 <--> 205 206 <--> 255

32-Bit Dimmer

As set in the control menu display Mode 0 = 8-bit, 256 dimming steps Mode 1 = 32-bit, 0-25% intensity range Mode 2 = 32-bit, 0-50% intensity range Mode 3 = 32-bit, 0-75% intensity range Mode 4 = 32-bit, full intensity dimming

DMX Values In-Depth (9-Channel)

Channel Value What It Does

1 000 <--> 255 Dimmer (0% <--> 100%)

2 000 <--> 255 Red Intensity (0% <--> 100%)

3 000 <--> 255 Green Intensity (0% <--> 100%)

4 000 <--> 255 Blue Intensity (0% <--> 100%)

5 000 <--> 255 White Intensity (0% <--> 100%)

000 <--> 010 011 <--> 255

000 <--> 014 015 <--> 024 025 <--> 034 035 <--> 044 045 <--> 054 055 <--> 064 065 <--> 074 075 <--> 084 085 <--> 094 095 <--> 104 105 <--> 114 115 <--> 124 125 <--> 134 135 <--> 144 145 <--> 154 155 <--> 164 165 <--> 255

000 <--> 015 016 <--> 255

000 <--> 005 006 <--> 055 056 <--> 105 106 <--> 155 156 <--> 205 206 <--> 255

Strobe

Strobe Off Strobe, 1-20 Hz (Slow <--> Fast)

Static Colors + Auto

Dimming Red Green Blue White Red + Green Red + Blue Red + White Green + Blue Green + White Blue + White Red + Green + Blue Red + Green + White Red + Blue + White Green + Blue + White Red + Green + Blue + White Auto Run (slow <--> fast)

Auto Mode

No Function Fade Speed (slow <--> fast)

32-Bit Dimmer

Page 14

Troubleshooting

Symptom Solution

Fixture AutoShut Off

Beam is Dim Check optical system and clean excess dust/grime. Also

No Light Output Check to ensure xture is operating under correct mode, IE

Chase Speed Too Fast/Slow

No Power Check fuse, AC cord and circuit for malfunction.

Blown Fuse Check AC cord and circuit for damage, verify that moving

Slow Movement Verify that 220V/110V switch is in the correct position, if

No Response to Audio

Fixture Not Responding / Responding Erraticly

Intermittant Lamp

Remote Doesn’t Work

Fixture Moving On Its Own

Check the fan in the xture. If it is stopped or moving

slower than normal, the unit may have shut itself off due to

high heat. This is to protect the xture from overheating.

Clear the fan of obstructions, or return the unit for service.

ensure that the 220V/110V switch is in the correct position, if applicable.

sound active/auto/DMX/Etc., if applicable. Contact service for more information.

Check to ensure proper setup of speed adjustment.

parts are not restricted and that unit’s ventilation is not obstructed

applicable. Also check that speed channels are set appropriately.

Verify that the xture is in “Sound Active” mode.

Adjust Audio Sensitivity, If Applicable.

Make sure all connectors are seated properly and securely. Use Only DMX Cables. Install a Terminator. Check all cables for defects.

Reset xture(s).

Check lamp for properly installation. Relamp, lamp may have reached end of life.

Verify remote control cable is installed properly and securely. Verify remote is correct type (CA-9 or other as applicable.)

Verify proper mode of operation. Is the xture in “Auto”

mode?

If your problem isn’t listed, or if problems persist,

please contact support: support@blizzardlighting.com.

Page 15

Dimensional Diagram

180° Tilt

9.06 in

230 mm

8.46 in

214.88 mm

Page 16

5. APPENDIX

A Quick Lesson On DMX

DMX (aka DMX-512) was created in 1986 by the United States Institute for Theatre Technology (USITT) as a standardized method for connecting lighting consoles to lighting

dimmer modules. It was revised in 1990 and again in 2000 to allow more exibility. The

Entertainment Services and Technology Association (ESTA) has since assumed control over the DMX512 standard. It has also been approved and recognized for ANSI standard clas-

sication.

DMX covers (and is an abbreviation for) Digital MultipleXed signals. It is the most common communications standard used by lighting and related stage equipment.

DMX provides up to 512 control “channels” per data link. Each of these channels was originally intended to control lamp dimmer levels. You can think of it as 512 faders on a lighting console, connected to 512 light bulbs. Each slider’s position is sent over the data link as an 8-bit number having a value between 0 and 255. The value 0 corresponds to the light bulb being completely off while 255 corresponds to the light bulb being fully on.

DMX data is transmitted at 250,000 bits per second using the RS-485 transmission standard over two wires. As with microphone cables, a grounded cable shield is used to prevent interference with other signals.

There are ve pins on a DMX connector: a wire for ground (cable shield), two wires for

“Primary” communication which goes from a DMX source to a DMX receiver, and two wires for a “Secondary” communication which goes from a DMX receiver back to a DMX source. Generally, the “Secondary” channel is not used so data ows only from sources to receivers. Hence, most of us are most familiar with DMX-512 as being employer over typical

3-pin “mic cables,” although this does not conform to the dened standard.

DMX is connected using a daisy-chain conguration where the source connects to the input of the rst device, the output of the rst device connects to the input of the next device,

and so on. The standard allows for up to 32 devices on a single DMX link.

Each receiving device typically has a means for setting the “starting channel number” that

it will respond to. For example, if two 6-channel xtures are used, the rst xture might

be set to start at channel 1 so it would respond to DMX channels 1 through 6, and the next

xture would be set to start at channel 7 so it would respond to channels 7 through 12.

The greatest strength of the DMX communications protocol is that it is very simple and robust. It involves transmitting a reset condition (indicating the start of a new “packet”), a start code, and up to 512 bytes of data. Data packets are transmitted continuously. As

soon as one packet is nished, another can begin with no delay if desired (usually another

follows within 1 ms). If nothing is changing (i.e. no lamp levels change) the same data will be sent out over and over again. This is a great feature of DMX -- if for some reason the

data is not interpreted the rst time around, it will be re-sent shortly.

Not all 512 channels need to be output per packet, and in fact, it is very uncommon to nd

all 512 used. The fewer channels are used, the higher the “refresh” rate. It is possible to get DMX refreshes at around 1000 times per second if only 24 channels are being transmitted. If all 512 channels are being transmitted, the refresh rate is around 44 times per second.

In summary, since its design and evolution in the 1980’s DMX has become the standard

for lighting control. It is exible, robust, and scalable, and its ability to control everything

from dimmer packs to moving lights to foggers to lasers makes it an indispensable tool for any lighting designer or lighting performer.

Page 17

Keeping Your ToughPar™ Satellight As Good As New

The xture you’ve received is a rugged, tough piece of pro lighting equipment, and as long as you take care of it, it will take care of you. That said, like anything, you’ll need to take care of it if you want it to operate as designed.

You should absolutely keep the xture clean, especially if you are using it in an

environment with a lot of dust, fog, haze, wild animals, wild teenagers or spilled drinks.

Cleaning the optics routinely with a suitable glass cleaner will greatly improve the quality of light output. Keeping the fans free of dust and debris will keep

the xture running cool and prevent damage from overheating.

In transit, keep the xtures in cases. You wouldn’t throw a prized guitar,

drumset, or other piece of expensive gear into a gear trailer without a case, and similarly, you shouldn’t even think about doing it with your shiny new light

xtures.

Common sense and taking care of your xtures will be the single biggest thing

you can do to keep them running at peak performance and let you worry about designing a great light show, putting on a great concert, or maximizing your client’s satisfaction and “wow factor.” That’s what it’s all about, after all!

Returns (Gasp!)

We’ve taken a lot of precautions to make sure you never even have to worry about sending a defective unit back, or sending a unit in for service. But, like any complex piece of equipment designed and built by humans, once in a while,

something doesn’t go as planned. If you nd yourself with a xture that isn’t behaving like a good little xture should, you’ll need to obtain a Return Authori-

zation (RA).

Don’t worry, this is easy. Just send an email to support@blizzardlighting.com, and we’ll issue you an RA. Then, you’ll need to send the unit to us using a trackable, pre-paid freight method. We suggest using USPS Priority or UPS.

Make sure you carefully pack the xture for transit, and whenever possible, use

the original box & packing for shipping.

When returning your xture for service, be sure to include the following:

1.) Your contact information (Name, Address, Phone Number, Email address).

2.) The RA# issued to you

3.) A brief description of the problem/symptoms.

We will, at our discretion, repair or replace the xture. Please remember that

any shipping damage which occurs in transit to us is the customer’s responsibility, so pack it well!

Shipping Issues

Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt.

Page 18

Tech Specs!

Weight & Dimensions

Length 9.06 inches (230mm)

Width 9.06 inches (230 mm)

Height 8.46 inches (214.88 mm)

Weight 7.8 lbs (3.5kg)

Power

Operating Voltage 100-240VAC, 50/60 Hertz

Fuse 250V, 3A

Power Consumption 62W, .82A, pf: .61

Light Source

LED 9x 10W 4-in-1 LEDs 100,000 hours.

Optical

Beam Angle 25 degree optics

Luminous Intensity

Lux/m Red Green Blue White All

1m 2,083 3,400 4,020 7,470 15,660

2m 860 1,070 1,200 2,150 4,860

Thermal

Max. Operating Temp. 104 degrees F (40 degrees C) ambient

Control

Protocol USITT DMX-512

DMX Channels 5 / 9 channel modes

Input 3-pin XLR Male

Output 3-pin XLR Female

Standalone, Master/Slave, Sound Active, Color

Other Operating Modes

Preset

Other Information

Rice is really great if you want to eat 2000 of something.

2-year limited warranty, does not cover mal

Warranty

function caused by damage to LED’s.

Page 19

Enjoy your product!

Our sincerest thanks for your purchase!

--The team @ Blizzard Lighting

Blizzard Lighting RGBW ToughPar Satellight User Manual Rev A

Specifications and Main Features

Frequently Asked Questions

User Manual
