Blizzard Lighting COBZilla Bright White 5X5 Matrix User Manual

Download

Bright White 5X5 Matrix

Blizzard Lighting, LLC

www.blizzardlighting.com

Wisconsin, USA

TABLE OF CONTENTS

COBZilla™ Bright White 5X5 Matrix 1

1. Getting Started 3

What’s In The Box? 3 Getting It Out Of The Box 3 Powering Up! 3 Getting A Hold Of Us 3 Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4

2. Meet The COBZilla™ Bright White 5X5 Matrix 5

Features 5 DMX Quick Reference 5 The COBZilla™ Bright White 5X5 Matrix Pin-up Picture 6

3. Setup 7

Fuse Replacement 7 Connecting A Bunch Of COBZilla™ Bright White 5X5 Matrix 7 Data/DMX Cables 7 Cable Connectors 8 3-Pin??? 5-Pin??? Huh? 8 Take It To The Next Level: Setting up DMX Control 8 Fixture Linking (Master/Slave Mode) 9 Mounting/Rigging 9

4. Operating Adjustments 10

Navigating The Control Panel 10 Control Panel Menu Structure 11 DMX Mode 12 Master/Slave Mode 12 Sound Active Mode 12 Standalone (Program) Mode 12 Character Mode 12 DMX Channel Values In-Depth 13 Troubleshooting 15

5. Appendix 16

A Quick DMX Lesson 16 Keeping Your COBZilla™ Bright White 5X5 Matrix New 17 Returns (Gasp!) 17 Shipping Issues 17 Tech Specs 18

Page 2

1. GETTING STARTED

What’s In The Box?

• 1 x COBZilla™ Bright White 5X5 Matrix

• This Lovely User Manual

• An Ever So Needed IEC Power Cord

• 4 Pcs Mounting Hardware

Getting It Out Of The Box

Congratulations on purchasing one of the newest, brightest, most impressive bright white LED Panels on the market! Now that you’ve got your COBZilla™ Bright White 5X5 Matrix (or hopefully, COBZilla’s™!), you should carefully unpack the box and check the contents to ensure that all parts are present and in good condition. If anything looks as if it has been damaged in transit, notify the shipper immediately and keep the packing material for

inspection. Again, please save the carton and all packing materials. If a xture must be returned to the factory, it is important that the xture be returned in the original factory

box and packing.

Powering Up!

All xtures must be powered directly off a switched circuit and cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0% to 100% switch.

AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the xture you receive is suitable for your local power supply. See the label on the xture or refer to the xture’s specications chart for more information. A xture’s listed current rating is its average current draw under normal conditions. Check the xture or device

carefully to make sure that if a voltage selection switch exists that it is set to the correct line voltage you will use.

Warning! Verify that the voltage select switch on your unit matches the line volt-

age applied. Damage to your xture may result if the line voltage applied does not match the voltage indicated on the voltage selector switch. All xtures must

be connected to circuits with a suitable Ground (Earthing).

Getting A Hold Of Us

If something is wrong, just give us a call or send an email. We’ll be happy to help, honest.

Blizzard Lighting N16 W23390 Stoneridge Dr. Suite E Waukesha, WI 53188 www.blizzardlighting.com 414-395-8365 Email: support@blizzardlighting.com

Disclaimer: The information and specications contained in this document are subject

to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. You can download the latest version of this document from www. blizzardlighting.com.

Author: Date: Last Edited: Date:

J. Henry 01/02/2014 J. Henry 01/03/2014

Page 3

SAFETY INSTRUCTIONS

• Please keep this User Guide for future use. If you sell the unit to someone else, be sure that they also receive this User Guide.

• ALWAYS make sure that you are connecting to the proper voltage, and that the line voltage you are connecting to is not higher than that stated on the de-

cal or rear panel of the xture.

• This product is intended for indoor use only.

• To prevent risk of re or shock, do not expose xture to rain or moisture.

• Make sure there are no ammable materials close to the unit while operating.

• The unit must be installed in a location with adequate ventilation, at least

20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are

blocked.

• ALWAYS disconnect from the power source before servicing or replacing fuse and be sure to replace with same fuse size and type.

• ALWAYS secure xture using a safety chain. NEVER carry the xture by its

cord. Use its carrying handles.

• DO NOT operate at ambient temperatures higher than 104°F (40°C).

• In the event of a serious operating problem, stop using the unit immediately. NEVER try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center. Always use the same type spare parts.

• NEVER connect the device to a dimmer pack.

• Make sure the power cord is never crimped or damaged.

• Never disconnect the power cord by pulling or tugging on the cord.

• Avoid direct eye exposure to the light source while it is on.

Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact Blizzard Lighting at support@blizzardlighting.com.

Page 4

2. MEET THE COBZilla™ Bright White 5X5 Matrix

CONTROL FEATURES

• 25 individually controllable Cool White (Chip-On Board) LED’s

• Variable electronic strobe

• Variable electronic dimmer

• Built-in automated programs via master/slave including letters and numbers

• Sound Active via DMX

ADDITIONAL FEATURES

• Rugged and well-built (yet, super thin! It works out regularly!)

• Lux: 5,600 @ 1m, 2,000 @ 2m

• Light source: 25 x 3 watt 700ma COB LED’s

DMX Quick Reference (1-Channel Mode)

Channel What It Does

1 Dimmer 0%-100%

DMX Quick Reference (4-Channel Mode)

Channel What It Does

1 Dimmer 0%-100%

2 Built-In Programs

3 Program Speed

4 Strobe

DMX Quick Reference (25-Channel Mode)

Channel What It Does

1-25 Individual Pixel Control Dimmer

0%-100%

DMX Quick Reference (28-Channel Mode)

Channel What It Does

1 Dimmer 0%-100%

2-26 Pixel Control 1-25

27 Built-In Programs

Character / Number Mode

28 Program Speed

Character / Number Choice

Page 5

Figure 1: The COBZilla™ Bright White 5X5 Matrix Pin-Up Picture

25 High Power Cool White COB LED’s

Tough Steel Enclosure

Figure 2: The Rear Connections

Fixture Link Bracket Mount

Safety Cable Attachment Point

DMX In

DMX Out

Page 6

LED Control Panel

Adjustment

Knobs

AC Power IN/ Power Out

3. SETUP

Fuse Replacement

CAUTION! The COBZilla™ Bright White 5X5 Matrix utilizes a high-

output switch-mode power supply with an internal fuse. Under normal operating conditions, the fuse should not require replacement. The

fuse is eld replaceable, however it is an advanced procedure suited to qualied individuals. Should your COBZilla™ Bright White 5X5

Matrix™ fuse require replacement, please contact Blizzard Lighting for instructions, or to return your unit for service.

Connecting A Bunch of COBZilla™ Bright White 5X5 Matrix Fixtures

You will need a serial data link to run light shows using a DMX-512 controller or to run shows on two or more xtures set to sync in master/slave operating mode. The combined number of channels required by all the xtures on a serial data link determines the number of xtures the data link can support.

Fixtures on a serial data link must be daisy chained in one single line.

Also, connecting more than 32 xtures on one serial data link without

the use of a DMX optically-isolated splitter may result in deterioration of the digital DMX signal. The maximum recommended cable-run distance is 500 meters (1640

ft). The maximum recommended number of xtures on a serial data link is 32 xtures.

Data/DMX Cabling

To link xtures together you’ll need data cables. You should use data-

grade cables that can carry a high quality signal and are less prone to electromagnetic interference.

For instance, Belden© 9841 meets the specications for EIA RS-485

applications. Standard microphone cables will “probably” be OK, but note that they cannot transmit DMX data as reliably over long distances. In any event, the cable should have the following characteristics:

2-conductor twisted pair plus a shield

Maximum capacitance between conductors – 30 pF/ft. Maximum capacitance between conductor & shield – 55 pF/ft. Maximum resistance of 20 ohms / 1000 ft. Nominal impedance 100 – 140 ohms

Page 7

Cable Connectors

Cables must have a male XLR connector on one end and a female XLR connector on the other end. (Duh!)

CAUTION: Do not allow contact between the common and the x- ture’s chassis ground. Grounding the common can cause a ground

loop, and your xture may perform erratically. Test cables with an

ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other.

3-Pin??? 5-Pin??? Huh?!?

If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. They are widely available over the internet and from specialty retailers If you’d like to build your own, the chart below details a proper cable conversion:

Conductor 3-Pin Female

(Output)

5-Pin Male (Input)

Ground/Shield Pin 1 Pin 1

DMX Data (-) Pin 2 Pin 2

DMX Data (+) Pin 3 Pin 3

Not Used. No Connection. No Connection.

Take It To The Next Level: Setting Up DMX Control

Step 1: Connect the male connector of the

DMX cable to the female connector (output) on the controller.

Step 2: Connect the female connector of the DMX cable to the rst xture’s male connector (input). Note: It doesn’t matter which

xture address is the rst one connected. We recommend connecting the xtures in

terms of their proximity to the controller,

rather than connecting the lowest xture number rst, and so on.

Step 3: Connect other xtures in the chain

from output to input as above. Place a DMX

terminator on the output of the nal xture

to ensure best communication.

Page 8

Fixture Linking (Master/Slave Mode)

1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of

the rst xture.

2. Connect the end of the cable coming from the

rst xture which will have a (female) 3 pin connector to the input connector of the next xture con-

sisting of a (male) 3 pin connector. Then, proceed to connect from the output as stated above to the

input of the following xture and so on.

A quick note: Often, the setup for MasterSlave and Standalone operation requires that

the rst xture in the

chain be initialized for this purpose via either settings in the control panel or DIP-switches.

Secondarily, the xtures

that follow may also require a slave setting.

Check the “Operating Adjustments” section in this manual for com-

plete instructions for this type of setup and conguration.

Mounting & Rigging

This xture may be mounted in any SAFE position provided there is

enough room for ventilation.

It is important never to obstruct the fan or vents pathway. Mount the

xture using a suitable “C” or “O” type clamp. The clamp should be rated to hold at least 10x the xture’s weight to ensure structural sta-

bility. Do not mount to surfaces with unknown strength, and ensure

properly “rated” rigging is used when mounting xutres overhead.

Adjust the angle of the xture by loosening both knobs and tilting the xture. After nding the desired position, retighten both knobs.

• When selecting installation location, take into consideration lamp replacement access (if applicable) and routine maintenance.

• Safety cables MUST ALWAYS be used.

• Never mount in places where the xture will be exposed to rain,

high humidity, extreme temperature changes or restricted ventilation.

Page 9

4. OPERATING ADJUSTMENTS

The Control Panel

All the goodies and different modes possible with the COBZilla™ Bright White 5X5 Matrix are accessed by using the control panel on the rear

of the xture. There are 4 control buttons below the LED display

which allow you to navigate through the various control panel menus.

<MODE>

Is used to navigate to the previous higher-level menu item.

<SETUP>

Scrolls through individual menu options

<UP>

Scrolls through menu items and numbers in Ascending order.

<DOWN>

Scrolls through menu items and numbers in Descending order.

The Control Panel LED Display shows the menu items you select from the menu map on page #11. When a menu function is selected, the

display will show immediately the rst available option for the selected

menu function. To select a menu item, press <MODE>.

Press the <MODE> button repeatedly until you reach the desired menu function. Use the <SETUP> button to navigate the menu options. Press the <MODE> button to select the menu function currently displayed, or to enable a menu option. To return to the previous option or menu without changing the value, press the <MODE> button.

Page 10

Control Panel Menu Structure

<MODE> d001 DMX Mode

<SETUP> 1-ch 4-ch, 1, 4, 25, 28-Channel Modes 25ch, 28ch

<MODE> Soud Sound Active Mode <SETUP> SU.00-31 Sound Sensitivity

<MODE> Char Character Mode

<SETUP> LEtt Individual Letter Mode <SETUP> PA A-Z

nUbe Individual Number Mode

<SETUP> PA 0-9

<MODE> TEST Test Mode

<MODE> AUTO Auto Play

<MODE> Pr01-27 Built In Programs

<MODE> SLAv Slave Mode

Page 11

DMX Mode

Allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with DMX, please read the DMX Primer on page #16.

1.) The COBZilla™ Bright White 5X5 Matrix is capable of operating with 1, 4, 25, or 28 DMX channels. To select the channel mode that you desire,

First press the <MODE> button to select d001 on the LED Readout.

Then press the <SETUP> button to select channel mode, 1-ch, 4-ch,

25ch or 28ch. Use the <UP> or <DOWN> to select desired channel.

Auto, Master/Slave, Sound Active & Character Modes:

Allows a single or Master/Slaved units to run factory installed programs at user selectable speeds.

1.) To set the xture in Auto mode, select AUTO using the <MODE> button.

2.) To use the xture’s built-in programs, select Pr.01-27, using the

<MODE> button then the <UP> and <DOWN> buttons to choose desired program. Press the <MODE> button to exit out of the menu.

3.) Each xture is a master by default. To set the xture as a slave, use the

<MENU> button to reach SLAv, then press the <SETUP> button select a mode. SLAv 1 -1, 1 - 2, 2 -1, 2 - 2. Using the <UP> and

<DOWN> buttons. When the user joins four devices, as shown below, the

devices will work as one unit.

Host

1-2

2-1 2-2

4.) Press the <MODE> button to exit out of the menu.

Sound Active Mode:

1.) To use sound active mode, select SouD by pressing <MODE>.

2.) Press the <SETUP> button to change built-in program SU.00-31 by

using the <UP> and <DOWN> buttons.

3.) Press the <MODE> button to exit out of the menu.

Character Mode (Individual Letters and Numbers Mode):

Allows a single xture to display a variety of individual letters or numbers without a DMX controller. (Would be really cool with multiple xtures! Hint... Hint...)

1.) Press the <MODE> button to reach ChAr. Then press the <SETUP> but-

ton to select Letter mode or Number mode.

2.) Use the <SETUP> button to select which letter or number you want the

xture to display. Use the <UP> and <DOWN> buttons to select PA A - Z under Lett or PA 0 - 9 under nUbe.

3.) Press the <MODE> button to save and exit.

Page 12

DMX Values In-Depth (1-Channel Mode)

Channel Channel Value Does...

1 000 <-> 255 Dimmer 0%-100%

DMX Values In-Depth (4-Channel Mode)

Channel Channel Value Does...

1 000 <-> 255 Dimmer 0%-100%

000 <-> 011 012 <-> 023 024 <-> 035 036 <-> 047 048 <-> 059 060 <-> 071 072 <-> 083 084 <-> 095 096 <-> 107

3 000 <-> 255 Program Speed

4 000 <-> 255 Strobe Rate

108 <-> 119 120 <-> 131 132 <-> 143 144 <-> 155 156 <-> 167 168 <-> 179 180 <-> 191 192 <-> 203 204 <-> 215 216 <-> 227 228 <-> 239 240 <-> 251 251 <-> 255

Built-In Programs

Program 1 Program 2 Program 3 Program 4 Program 5 Program 6 Program 7 Program 8 Program 9 Program 10 Program 11 Program 12 Program 13 Program 14 Program 15 Program 16 Program 17 Program 18 Program 19 Program 20 Program 21 Sound Active

DMX Values In-Depth (25-Channel Mode)

Channel Channel Value Does...

Individual Pixel

1-25

0%-100%

000 <-> 255

Page 13

DMX Values In-Depth (28-Channel Mode)

Channel Channel Value Does...

1 000 <-> 255 Dimmer 0%-100%

Individual Pixel Control

1-25

000 <-> 255

0%-100%

001 <-> 010

011 <-> 021

022 <-> 032 033 <-> 043 034 <-> 054 055 <-> 065 066 <-> 076 077 <-> 087 088 <-> 098

099 <-> 109 110 <-> 120 121 <-> 131 132 <-> 142 143 <-> 153 154 <-> 164 165 <-> 175 176 <-> 186 187 <-> 197 198 <-> 208 209 <-> 219 220 <-> 230 231 <-> 241 242 <-> 252 253 <-> 255

Channel 3 - 022 <-> 252

000 <-> 009 010 <-> 019 020 <-> 029 030 <-> 039 040 <-> 049 050 <-> 059 060 <-> 069 070 <-> 079 080 <-> 089 090 <-> 099 100 <-> 109 110 <-> 119 120 <-> 129 130 <-> 139 140 <-> 149 150 <-> 159 160 <-> 169 170 <-> 179 180 <-> 189 190 <-> 199 200 <-> 209 210 <-> 219 220 <-> 229 230 <-> 239 240 <-> 249 250 <-> 255

00 <-> 27 28 <-> 55 56 <-> 83 84 <-> 111 112 <-> 139 140 <-> 167 168 <-> 195 196 <-> 223 224 <-> 251 252 <-> 255

Built-In Programs

Letters (Set this channel rst, then change Channel 4)

Numbers (Set this channel rst, then change Channel 4)

Speed of Programs

Characters / Numbers

A B C D E F G H I J K L (Channel 3 is between 001 <-> 010) M N O P Q R S T U V W X Y Z

0 1 2 3 4 (Channel 3 is between 011 <-> 021) 5 6 7 8 9

Page 14

Troubleshooting

Symptom Solution

Fixture AutoShut Off

Beam is Dim Check optical system and clean excess dust/grime. Also

No Light Output Check to ensure xture is operating under correct mode, IE

Chase Speed Too Fast/Slow

No Power Check fuse, AC cord and circuit for malfunction.

Blown Fuse Check AC cord and circuit for damage, verify that moving

Slow Movement Verify that 220V/110V switch is in the correct position, if

No Response to Audio

Fixture Not Responding / Responding Erraticly

Intermittant Lamp

Remote Doesn’t Work

Fixture Moving On Its Own

Check the fan in the xture. If it is stopped or moving

slower than normal, the unit may have shut itself off due to

high heat. This is to protect the xture from overheating.

Clear the fan of obstructions, or return the unit for service.

ensure that the 220V/110V switch is in the correct position, if applicable.

sound active/auto/DMX/Etc., if applicable. Contact service for more information.

Check to ensure proper setup of speed adjustment.

parts are not restricted and that unit’s ventilation is not obstructed

applicable. Also check that speed channels are set appropriately.

Verify that the xture is in “Sound Active” mode. Adjust Audio Sensitivity, If Applicable.

Make sure all connectors are seated properly and securely. Use Only DMX Cables. Install a Terminator. Check all cables for defects.

Reset xture(s).

Check lamp for properly installation. Relamp, lamp may have reached end of life.

Verify remote control cable is installed properly and securely. Verify remote is correct type (CA-9 or other as applicable.)

Verify proper mode of operation. Is the xture in “Auto”

mode?

If your problem isn’t listed, or if problems persist,

please contact support: support@blizzardlighting.com.

Page 15

5. APPENDIX

A Quick Lesson On DMX

DMX (aka DMX-512) was created in 1986 by the United States Institute for Theatre Technology (USITT) as a standardized method for connecting lighting consoles to lighting

dimmer modules. It was revised in 1990 and again in 2000 to allow more exibility. The

Entertainment Services and Technology Association (ESTA) has since assumed control over the DMX512 standard. It has also been approved and recognized for ANSI standard clas-

sication.

DMX covers (and is an abbreviation for) Digital MultipleXed signals. It is the most common communications standard used by lighting and related stage equipment.

DMX provides up to 512 control “channels” per data link. Each of these channels was originally intended to control lamp dimmer levels. You can think of it as 512 faders on a lighting console, connected to 512 light bulbs. Each slider’s position is sent over the data link as an 8-bit number having a value between 0 and 255. The value 0 corresponds to the light bulb being completely off while 255 corresponds to the light bulb being fully on.

DMX data is transmitted at 250,000 bits per second using the RS-485 transmission standard over two wires. As with microphone cables, a grounded cable shield is used to prevent interference with other signals.

There are ve pins on a DMX connector: a wire for ground (cable shield), two wires for

“Primary” communication which goes from a DMX source to a DMX receiver, and two wires for a “Secondary” communication which goes from a DMX receiver back to a DMX source. Generally, the “Secondary” channel is not used so data ows only from sources to receivers. Hence, most of us are most familiar with DMX-512 as being employer over typical

3-pin “mic cables,” although this does not conform to the dened standard.

DMX is connected using a daisy-chain conguration where the source connects to the input of the rst device, the output of the rst device connects to the input of the next device,

and so on. The standard allows for up to 32 devices on a single DMX link.

Each receiving device typically has a means for setting the “starting channel number” that

it will respond to. For example, if two 6-channel xtures are used, the rst xture might

be set to start at channel 1 so it would respond to DMX channels 1 through 6, and the next

xture would be set to start at channel 7 so it would respond to channels 7 through 12.

The greatest strength of the DMX communications protocol is that it is very simple and robust. It involves transmitting a reset condition (indicating the start of a new “packet”), a start code, and up to 512 bytes of data. Data packets are transmitted continuously. As

soon as one packet is nished, another can begin with no delay if desired (usually another

follows within 1 ms). If nothing is changing (i.e. no lamp levels change) the same data will be sent out over and over again. This is a great feature of DMX -- if for some reason the

data is not interpreted the rst time around, it will be re-sent shortly.

Not all 512 channels need to be output per packet, and in fact, it is very uncommon to nd

all 512 used. The fewer channels are used, the higher the “refresh” rate. It is possible to get DMX refreshes at around 1000 times per second if only 24 channels are being transmitted. If all 512 channels are being transmitted, the refresh rate is around 44 times per second.

In summary, since its design and evolution in the 1980’s DMX has become the standard

for lighting control. It is exible, robust, and scalable, and its ability to control everything

from dimmer packs to moving lights to foggers to lasers makes it an indispensible tool for any lighting designer or lighting performer.

Page 16

Keeping Your COBZilla™ Bright White 5X5 Matrix As Good As New

The xture you’ve received is a rugged, tough piece of pro lighting equipment, and as long as you take care of it, it will take care of you. That said, like anything, you’ll need to take care of it if you want it to operate as designed.

You should absolutely keep the xture clean, especially if you are using it in an

environment with a lot of dust, fog, haze, wild animals, wild teenagers or spilled drinks.

Cleaning the optics routinely with a suitable glass cleaner will greatly improve the quality of light output. Keeping the fans free of dust and debris will keep

the xture running cool and prevent damage from overheating.

In transit, keep the xtures in cases. You wouldn’t throw a prized guitar,

drumset, or other piece of expensive gear into a gear trailer without a case, and similarly, you shouldn’t even think about doing it with your shiny new light

xtures.

Common sense and taking care of your xtures will be the single biggest thing

you can do to keep them running at peak performance and let you worry about designing a great light show, putting on a great concert, or maximizing your client’s satistfaction and “wow factor.” That’s what it’s all about, after all!

Returns (Gasp!)

We’ve taken a lot of precautions to make sure you never even have to worry about sending a defective unit back, or sending a unit in for service. But, like any complex piece of equipment designed and built by humans, once in a while,

something doesn’t go as planned. If you nd yourself with a xture that isn’t behaving like a good little xture should, you’ll need to obtain a Return Authori-

zation (RA).

Don’t worry, this is easy. Just send an email to support@blizzardlighting.com, and we’ll issue you an RA. Then, you’ll need to send the unit to us using a trackable, pre-paid freight method. We suggest using USPS Priority or UPS.

Make sure you carefully pack the xture for transit, and whenever possible, use

the original box & packing for shipping.

When returning your xture for service, be sure to include the following:

1.) Your contact information (Name, Address, Phone Number, Email address).

2.) The RA# issued to you

3.) A brief description of the problem/symptoms.

We will, at our discretion, repair or replace the xture. Please remember that

any shipping damage which occurs in transit to us is the customer’s responsibility, so pack it well!

Shipping Issues

Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt.

Page 17

Tech Specs!

Weight & Dimensions

Length 17.75 inches (451 mm)

Depth 11.5 inches (292.1 mm) including bracket

Height 17.75 inches (451 mm)

Weight 12.95 lbs (5.86 kg)

Power

Operating Voltage 100-240V AC, 50-60 Hertz

Fuse 2A 125V

110W

Power Consumption

.38A Inrush, 1.70A Max. Operating

Power Factor: .63

Light Source

COB 25x 3W 700ma, 50,000 hours.

Optical

Beam Angle 55 degrees

Luminous Intensity 5,600 Lux @ 1m

2,000 Lux @ 2m

Thermal

Max. Operating Temp. 104 degrees F (40 degrees C) ambient

Control

Protocol USITT DMX-512

DMX Channels 1/4/25/28

Input 3-Pin XLR Male

Output 3-Pin XLR Female

Auto, Master/Slave, Sound Active, Charac-

Other Operating Modes

WATCH OUT! It’s Godzilla!!! WAIT~ No, IT’S.... COBZilla™

Even though Godzilla was only a mystical Japanese creature that destroyed villages and anything in it’s path, The COBZilla™ will brighten anything in it’s path and will make people stand in a wonder of awe, much like Godzilla!

ter Mode

2-year limited warranty, does not cover

Warranty

malfunction caused by damage to LED’s.

Page 18

This page intentionally left blank.

Page 19

Enjoy your product!

Our sincerest thanks for your purchase!

--The team @ Blizzard Lighting

Blizzard Lighting COBZilla Bright White 5X5 Matrix User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
