OneTouch
Aluminum
Blind
owner's handbook
Page 2
Page 3
One
INSTALLATION INSTRUCTIONS
Step 1. Check Package Contents
Missing part? Call 800-264-1190
Mounting hardware kit includes the following:
Part Quantity
a Mounting Bracket 2 (shades up to 36” wide)
3 (shades 36” to 54” wide)
4 (shades 54” to 72” wide)
b 11/8” Screws 2 per bracket
[Note: one extra screw of each noted size is included for convenience]
Step 2. Tools Required
Screwdriver, tape measure, pencil, drill, step ladder, scissor.
Note: use #6 plastic anchors for dry wall or plaster mounting.
Step 3. Bracket Location and Installation
Your blind may be installed either inside the window frame or
outside the window frame.
A mounting bracket should be positioned about 1” to 3” from
each end of the head rail. For wider shades that require 3 or
more brackets, these should be spaced evenly between the two
outermost brackets. Always position the brackets such that there
is no interference with the mechanisms inside the head rail. The
procedure outlined below will assure proper bracket placement.
Touch
Aluminum
Blind
For Outside Mounting:
Clip the brackets onto the head rail as described above. Hold the
blind level at the height desired and center it over the window
opening. Mark the exact location of each bracket with a pencil.
Remove the brackets from the head rail and position the top of
each bracket at the marked location and screw each bracket into
the wall or window molding using the 1” screws, pre-drill the
screw holes using a 4" drill bit.
3
Page 4
For Inside Mounting:
Clip the brackets onto the head rail as described above. Hold
the blind in place and make a pencil mark at the rear of each
bracket where it contacts the inside of the window frame.
Remove the brackets from the head rail and align them with the
marks. Attach each bracket using the 1” screws, pre-drill the
screw holes using a 4" drill bit.
Step 4. Securing the Head Rail
Lift the head rail into position such that the front edge of each
bracket is under the inner front edge of the head rail. Push the head
rail upward until the flexible tab at the bottom of each bracket snaps
onto the back of the head rail. Check carefully to assure that each
bracket is properly secured.
Step 5. Attach Handle / How to Operate
Attach the handle to the bottom rail as illustrated.
Always rotate the slats to the “open” horizontal position before
raising or lowering. This assures smooth operation and increases
the life of the blind.
To lower blind: Grip the Bottom-Rail/Handle and slowly pull
straight down.
To raise blind: Put one hand under the Bottom Rail (palm facing
up) and lift with a slow steady tempo until the
desired height is reached.
To tilt the slats: Lower and raise the handle slowly. This is a
learned technique, but takes only a few seconds
to master
CLEANING YOUR BLINDS
Dusting: use a soft cloth, feather duster, cylindrical dust brushes
specifically designed for blinds or vacuum using the soft brush
4
Page 5
One
Touch
Aluminum
Blind
attachment. Washing: use a cloth, sponge or soft brush and a mild
detergent.
Use warm or cold water, not hot water. Place toweling on the
floor and/or window sill and wash the blind in sections. Smaller
blinds can be washed in a sink or tub; blinds can also be gently
hose washed outdoors. Rinse off suds thoroughly. Drain the head
rail and bottom rail; remove end caps if necessary. Towel dry to
avoid water marks. To have your blinds cleaned professionally,
check the local telephone directory for a venetian blind cleaning
service or laundry.
REPLACEMENT PARTS
In the event that replacement parts are ever needed, you may call:
1-800-264-1190
Please be sure to provide the following information, if possible:
• The complete model or catalog number of your product
• A description of the product
• A description of the part needed
LIMITED LIFETIME WARRANTY
The enclosed product is warranted to the original residential retail
purchaser as long as the product remains in the original window.
Covered:
Lifetime: Entire product against manufacturing defects (i.e. a flaw
in the product design, materials, or workmanship that causes the
product to no longer function)
3 years: Cords including internal cords such as those found in
cordless blinds.
5 years: All fabric
Not Covered:
Normal Wear and Tear
Any product that fails due to: abuse • exposure to salt air
• improper installation • accident • extraordinary use • improper
operation • alterations • improper cleaning • misapplication
• damage from pests/insects/pets • improper handling • misuse
Natural wood products that have: loss of color intensity
• yellowing or cracking of plastic parts or foam wood product
• variations in color, grain, or texture • warping of wood slats in high
humidity areas
Costs associated with: product removal • transportation to and
from the retailer • brand label removal • product re-measure
• incidental or consequential damages • product reinstallation
• shipping
In the event there are multiple blinds/shades in the same room, only
the defective blind/shade will be replaced.
To Report Shipping Damage:
If damage occurred during shipping, call place of purchase and
report within 7 calendar days or else you may be denied credit for
your damaged product.
5
Page 6
To Obtain Service:
If you suspect this product has a manufacturing defect in materials
or workmanship:
1. Locate the sales receipt
2. Call place of purchase.
Any unauthorized returns will not be accepted.
Warranty Remedy:
THIS SHALL BE YOUR SOLE REMEDY UNDER THIS LIMITED
WARRANTY.
If this product is found to have a manufacturing defect in materials
or workmanship, we will (at our discretion) do one of the following:
• repair the product
• replace the product
• refund the cost of the product
Colors vary from lot to lot and may not exactly match sample
swatch or previous purchases. Discontinued items or color
selections will be replaced with the closest equivalent current
product.
YOUR RIGHTS UNDER STATE LAW:
This lifetime limited warranty gives you specific legal rights, and you
may have other rights, which vary from state to state. Some states
do not allow limitations on how long a warranty lasts, so the above
limitations may not apply to you.
No agent, representative, dealer, or unauthorized employee has
the authority to increase or alter the obligation of this warranty. This
lifetime limited warranty supersedes any previous versions.
