NPN Silicon AF Transistors |
BCX54/BCX55/BCX56 |
|||
|
|
|
|
|
FEATURES |
|
|
|
|
|
|
|
||
z For AF driver and output stages |
Pb |
|||
z High collector current |
||||
Lead-free |
||||
|
zLow collector-emitter saturation voltage
zComplementary types:BCX51…BCX53(PNP)
SOT-89
ORDERING INFORMATION
Type No. |
Marking |
Package Code |
|
|
|
BCX54 |
BA |
SOT-89 |
BCX54-10 |
BC |
SOT-89 |
BCX54-16 |
BD |
SOT-89 |
BCX55 |
BE |
SOT-89 |
BCX55-10 |
BG |
SOT-89 |
BCX55-16 |
BM |
SOT-89 |
BCX56 |
BH |
SOT-89 |
BCX56-10 |
BK |
SOT-89 |
BCX56-16 |
BL |
SOT-89 |
|
|
|
MAXIMUM RATING @ Ta=25 unless otherwise specified
Symbol |
Parameter |
|
Value |
Unit |
|
|
|
|
|
|
|
|
Collector-Base Voltage |
BCX54 |
45 |
|
|
VCBO |
|
BCX55 |
60 |
V |
|
|
|
BCX56 |
100 |
|
|
|
|
|
|
|
|
|
Collector-Emitter Voltage |
BCX54 |
45 |
|
|
VCEO |
|
BCX55 |
60 |
V |
|
|
|
BCX56 |
80 |
|
|
|
|
|
|
|
|
VEBO |
Emitter-Base Voltage |
|
5 |
V |
|
|
|
|
|
|
|
IC |
DC Collector Current |
|
1 |
A |
|
|
|
|
|
|
|
ICM |
Peak Collector Current |
|
1.5 |
A |
|
|
|
|
|
|
|
IB |
Base current |
|
100 |
mA |
|
|
|
|
|
|
|
IBM |
Peak base current |
|
200 |
mA |
|
|
|
|
|
|
|
Ptot |
Total power dissipation,TS=130 |
|
1 |
W |
|
|
|
|
|
|
|
Tj,Tstg |
Junction and Storage Temperature |
|
-65 to+150 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Document number: BL/SSSTG033 |
www.galaxycn.com |
Rev.A |
1 |
BL Galaxy Electrical
Production specification
|
NPN Silicon AF Transistors |
BCX54/BCX55/BCX56 |
|
|||||
|
|
|
|
|
|
|
|
|
|
ELECTRICAL CHARACTERISTICS @ Ta=25 unless otherwise specified |
|
|
|||||
Parameter |
Symbol |
Test conditions |
|
MIN |
MAX |
UNIT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IC=100μA IB=0 |
BCX54 |
45 |
|
|
|
Collector-base breakdown voltage |
V(BR)CBO |
|
BCX55 |
60 |
|
V |
|
|
|
|
|
|
BCX56 |
100 |
|
|
|
|
|
|
IC=10mA IB=0 |
BCX54 |
45 |
|
|
|
Collector-emitter breakdown voltage |
V(BR)CEO |
|
BCX55 |
60 |
|
V |
|
|
|
|
|
|
BCX56 |
80 |
|
|
|
Emitter-base breakdown voltage |
V(BR)EBO |
IE=10μA IC=0 |
|
5 |
|
V |
|
|
|
|
|
|
|
|
|
|
|
Collector cut-off current |
ICBO |
VCB=30V IE=0 |
|
|
100 |
nA |
|
|
|
|
|
|
|
|
|||
VCB=30V IE=0,TA=150 |
|
20 |
μA |
|
||||
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
VCE=2V IC=5mA |
|
25 |
|
|
|
DC current gain |
hFE |
VCE=2V IC=150mA |
40 |
250 |
|
|
||
|
|
|
VCE=2V IC=500mA |
25 |
|
|
|
|
Collector-emitter saturation voltage |
VCE(sat) |
IC=500mA IB=50mA |
|
0.5 |
V |
|
||
|
|
|
|
|
|
|
||
Base-emitter voltage |
VBE |
IC=500mA ,VCE=2V |
|
1 |
V |
|
||
|
|
|
|
|
|
|
|
|
Transition frequency |
fT |
VCE=10V, IC=50mA, |
100 |
|
MHz |
|
||
f=20MHz |
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
TYPICAL CHARACTERISTICS @ Ta=25 unless otherwise specified |
|
|
|
Document number: BL/SSSTG033 |
www.galaxycn.com |
Rev.A |
2 |
