BL Galaxy Electrical Production specification
Surface Mount Fast Switching Diodes BAW56DW
FEATURES
z Fast switching speed.
z For general purpose switching application.
z Ultra-small surface mount package.
z High conductance.
z Two “BAW56” circuits in one package.
Pb
Lead-free
APPLICATIONS SOT-363
z For general purpose switching application.
ORDERING INFORMATION
Type No. Marking Package Code
BAW56DW KJC SOT-363
MAXIMUM RATING @ Ta=25℃ unless otherwise specified
Symbol Characteristic Value Unit
V
V
V
V
V
I
I
I
P
R
Tj,T
FM
O
FSM
RM
RRM
RWM
R
R(RMS)
D
θJA
stg
Non-repetitive peak reverse voltage 100 V
Peak repetitive reverse voltage
Working peak reverse voltage
DC reverse voltage
RMS Reverse voltage 53 V
Forward continuous current(MAX) 300 mA
Average rectified output current 150 mA
Non-Repetitive peak forward surge current
@t=1.0μs
@t=1.0s
Diode Power Dissipation 200 mW
Thermal Resistance, Junction to Ambient 625
Junction and Storage Temperature -65 to+150
75 V
2.0
1.0
A
℃/W
℃
Document number: BL/SSSDE019 www.galaxycn.com
Rev.A 1
BL Galaxy Electrical Production specification
Surface Mount Fast Switching Diodes BAW56DW
ELECTRICAL CHARACTERISTICS @ Ta=25℃ unless otherwise specified
Parameter Symbol Test conditions MIN MAX UNIT
Reverse breakdown voltage V
Forward voltage V
Reverse voltage leakage current I
Total Capacitance C
Reverse Recovery time t
(BR)R
F
R
T
rr
IR=2.5μA 75 - V
IF=1.0mA
I
=10mA
F
I
=50mA
F
I
=150mA
F
VR=75V
VR=75V,Tj=150℃
V
=25V,Tj=150℃
R
V
=20V
R
VR=0V,f=1.0MHz - 2.0 pF
IF=IR=10mA,Irr=0.1*IR,
R
=100Ω
L
-
- 4.0 ns
TYPICAL CHARACTERISTICS @ Ta=25℃ unless otherwise specified
0.715
0.855
1.0
1.25
2.5
50
30
25
V
μA
μA
μA
nA
Document number: BL/SSSDE019 www.galaxycn.com
Rev.A 2
