BL Galaxy Electrical Production specification
Surface Mount Fast Switching Diodes BAW567DW
FEATURES
z Fast switching speed.
z For general purpose switching application.
z Ultra-small surface mount package.
z High conductance.
Pb
Lead-free
APPLICATIONS
z For general purpose switching application. SOT-363
ORDERING INFORMATION
Type No. Marking Package Code
BAW567DW KAC SOT-363
MAXIMUM RATING @ Ta=25℃ unless otherwise specified
Symbol Characteristic Value Unit
V
R
I
F
P
D
R
θJA
Tj,T
stg
DC reverse voltage 75 V
Forward continuous current 150 mA
Power Dissipation 200 mW
Thermal Resistance, Junction to Ambient 625
Junction and Storage Temperature -55 to+150
ELECTRICAL CHARACTERISTICS
℃/W
℃
@ Ta=25℃ unless otherwise specified
Document number: BL/SSSDE018 www.galaxycn.com
Rev.A 1
BL Galaxy Electrical Production specification
Surface Mount Fast Switching Diodes BAW567DW
Parameter Symbol Test conditions MIN MAX UNIT
Reverse breakdown voltage V
Forward voltage V
Reverse voltage leakage current I
Junction Capacitance C
Reverse Recovery time t
(BR)R
F
R
J
rr
IR=2.5μA 75 - V
IF=1.0mA
I
=10mA
F
I
=50mA
F
I
=150mA
F
VR=75V
V
=20V
R
VR=0V,f=1.0MHz - 2.0 pF
IF=IR=10mA,Irr=0.1*IR,
R
=100Ω
L
-
- 4.0 ns
TYPICAL CHARACTERISTICS @ Ta=25℃ unless otherwise specified
0.715
0.855
1.0
1.25
2.5
0.025
V
μA
Document number: BL/SSSDE018 www.galaxycn.com
Rev.A 2
