Blaupunkt HIR2, H8, H4, H16, H11 User Manual

12V VEHICLE LIGHTING

5000K & 6000K
LED HEADLAMP

H4 H7 H8/H11/H16

HB4 HIR2

Operating and Installation Instructions

Enjoy it.

CAUTIONS

Safety Notes

This product has been manufactured according to
established safety guidelines. However, dangers may still
occur if the safety notes in this manual is not observed.
This manual is intended to familiarize the user with
the product’s important functions. Read this carefully,
prior to install the product. Keep this manual in an
easily accessible location. In addition, do observe the
instructions of the devices used in conjunction with
the product.

General Safety

Headlamp is intended for installation and operation

•
in a vehicle with 12V vehicle system voltage and can
be used in headlights with H4 halogen lamps.

Ensure headlamp does not have defects before

•
installation.

•

Keep the headlamp away from children.

•

Keep the headlamp away from ammable areas
or liquids.

The headlamp should be stored in dry and low

•
humidity place.

•

Avoid skin contact with the high temperature/
working headlamp when replacing headlamp. Allow
headlamp to drop to room temperature before
replacing the headlight.

Do not modify product, or expose product to dust,

•
grease stains, or scratch the surface of the headlamp.

Do not look directly at the operating headlamp, it

•
may cause eye damage.

•

After installation, ensure below are working correctly

1. Correct light/beam pattern

2. Indicators are working

3. Wiring are connected correctly

4. Covers are installed back to the car correctly

This manual may be updated from time to time without
any notice.

Disclaimer

In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages to property or life and whatsoever arising out
of or connected with the use or misuse of our products.
USA & CANADA: This product is not intended for sale in
the United States and Canada. If purchased in the U.S. or
Canada, this product is purchased on as-is basis. No
warranty, whether expressed or implied is provided in
the U.S. or Canada.

1

STRUCTURE & FUNCTIONS

H4

H7

H8/H11/H16

Applicable to : Reector headlight
Product Name : 134250W (5000K), 134260W (6000K)
Technology : LED
Power : 26W±10%, 26W±10%
Operating Voltage : 13.2V
Luminous Flux : 2100lm ±20%, 1900lm ±20%
Water Resistant Rating : IP65
Lifespan : 3000 hour
Colour Temperature : 5000K & 6000K
Base : P43t

Applicable to : Projector, reector & fog headlight
Product Name : 197250W (5000K), 197260W (6000K)
Technology : LED
Power : 26W±10%
Operating Voltage : 13.2V
Luminous Flux : 2300lm ±20%
Water Resistant Rating : IP65
Lifespan : 3000 hour
Colour Temperature : 5000K & 6000K
Base : PX26D

Applicable to : Projector, reector & fog headlight
Product Name : 136650W (5000K), 136660W (6000K)
Technology : LED
Power : 26W±10%
Operating Voltage : 13.2V
Luminous Flux : 2300lm ±20%
Water Resistant Rating : IP65
Lifespan : 3000 hour
Colour Temperature : 5000K & 6000K
Base : PGJ19-1/2/3/5

2

SPECIFICATIONS

HB4

Applicable to : Projector, reector & fog headlight
Product Name : 100650W (5000K), 100660W (6000K)
Technology : LED
Power : 26W±10%
Operating Voltage : 13.2V
Luminous Flux : 2300lm ±20%
Water Resistant Rating : IP65
Lifespan : 3000 hour
Colour Temperature : 5000K & 6000K
Base : P22D

HIR2

Applicable to : Projector & reector headlight
Product Name : 101250W (5000K), 101260W (6000K)
Technology : LED
Power : 26W±10%
Operating Voltage : 13.2V
Luminous Flux : 2300lm ±20%
Water Resistant Rating : IP65
Lifespan : 3000 hour
Colour Temperature : 5000K & 6000K
Base : PX22D

TROUBLESHOOTING

If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt
authorized dealer if problem persist.

Problems

One of the headlamp
doesn’t work
Both headlamps doesn’t
work

Dim Headlight

Causes

The headlamp has burned-out.

Fuse has blown.
Incorrect wiring connections.

No power to the circuit, bad
ground or failed switch.
Broken alternator or power
supply problem.
Weak car battery.

Solutions

Replace with a new headlamp.

Replace with a new fuse.
Examine if positive and negative power connectors
are connected correctly.
Examine if wiring for power, ground or switch are
connected correctly.
Examine if power supply voltage is correct.

Recharge the weak car battery or replace with a
new car battery.

3

PRE-INSTALLATION INSTALLATION INSTRUCTION

Open the hood of the vehicle.

1.

Find the installed location of the original

2.

halogen bulb.

Remove the halogen bulb from headlight

3.

housing.

4

Install the headlamp into headlight

1.

housing and turn clockwise to secure it.

Connect the headlamp cable to vehicle

2.

wiring hardness.

Warning cancellar adaptor may be needed in

•
case warning signal light up after installation.

Remove bulb, turn it 180° & reinstall in case bulb

•
does not light up.

Fit for 12V vehicle only.

•

136660W H8/H11/H16 6000K

Designed and engineered by Blaupunkt Competence Centre

134260W H4 6000K

1 581 19 014 35 01

197260W H7 6000K

1 581 19 015 35 01

1 581 19 016 35 01

100660W HB4 6000K

1 581 19 017 35 01

101260W HIR2 6000K

1 581 19 018 35 01

134250W H4 5000K

1 581 19 019 35 01

197250W H7 5000K

1 581 19 020 35 01

136650WH8/H11/H16 5000K

1 581 19 021 35 01

100650W HB4 5000K

1 581 19 022 35 01

101250W HIR2 5000K

1 581 19 023 35 01
