www.blaupunkt.com

Car Radio | CD | USB | SD | Bluetooth

Toronto 420 BT 1 011 202 420 / 1 011 202 421 San Francisco 320 1 011 202 320 / 1 011 202 321

www.blaupunkt.com

Operating and installation instructions

Controls

3 5 621 8

4 7

button

Unlock the detachable control panel

MENU button

Short press: Call up/close menu Long press: Start scan function

On/O button

Short press: Switch on car sound system In operation: Mute car sound system (Mute) Long press: Switch o car sound system

Volume control

CD tray

Display

Rotary control

In the menu: Change menu level, select menu item, change setting Radio mode: Set frequency, start station/PTY seek tuning CD/MP3/WMA/iPod mode: Track selection, fast forward/reverse Browse mode in MP3/WMA/iPod mode: ID3 category (iPod only), select folder and track

button (Eject)

Eject a CD

Microphone (Toronto 420 BT only)

12131617 14

USB port

;

Front AUX-IN socket

button (only Toronto 420 BT)

11 10

Ending/rejecting a phone call

button (Toronto 420 BT only)

Short press: Answering a call, speed dial Long press: Open the phone book of the cell phone or activate voice dialing

Keys 1 - 5

Infrared receiver

SRC button

Select memory bank or audio source

DIS button

Short press: Switch display Long press: Switch display brightness

SD card slot

Access only with detached control panel

Contents

Safety notes ...................................................... 4

Symbols used ..............................................................4

Road safety ..................................................................4

General safety notes .................................................4

Declaration of conformity ......................................5

Cleaning notes .................................................. 5

Disposal notes................................................... 5

Scope of delivery .............................................. 5

Optional equipment

(not part of the scope of delivery) .......................5

Placing the device in operation ....................... 5

Attaching/detaching the control panel ............5

Display language (only Toronto 420 BT) ........... 6

Setting the reception area .....................................6

Switching on/o ........................................................ 6

Volume .......................................................................... 6

Display brightness ..................................................... 7

Switching demo mode on/o ...............................7

Tra  c information ............................................ 7

Radio mode ....................................................... 7

RDS.................................................................................. 7

Changing to radio mode or selecting

a memory bank ..........................................................8

Tuning into a station ................................................ 8

Storing stations or calling stored stations ........ 8

Scanning stations ...................................................... 8

Storing stations automatically (Travelstore) .... 9

PTY .................................................................................. 9

Con guring the display .........................................10

CD/MP3/WMA/iPod mode .............................. 10

Basic information .....................................................10

Changing to CD/MP3/WMA/iPod mode .........11

Inserting/ejecting a CD .........................................11

Connecting/removing a USB data carrier .......11

Inserting/removing the memory card ............. 12

Selecting tracks ........................................................12

Fast searching ...........................................................12

Interrupting playback ............................................12

Scanning all tracks ..................................................12

Playing tracks in random order ..........................13

Repeatedly playing individual tracks or

directories ..................................................................13

Con guring the display .........................................13

Browse mode ............................................................ 14

Searching by track names

(not in iPod mode) ..................................................15

Bluetooth®

(Toronto 420 BT only) ..................................... 15

Bluetooth® menu .....................................................15

Pairing and connecting a device .......................16

Telephone functions...............................................17

Bluetooth® streaming mode................................20

Phone book functions ...........................................20

Additional functions in

the Bluetooth® menu ............................................. 21

External audio sources ................................... 23

Front AUX-IN socket ................................................23

Sound settings ................................................ 23

Calling and exiting the "AUDIO" menu ............23

Making settings in the "AUDIO" menu .............24

Setting the 3-band equaliser ...............................25

User settings ................................................... 26

Calling the user menu and selecting

a menu .........................................................................26

Making settings in the "TUNER" menu ............27

Making settings in the "DISPLAY" menu .........28

Making settings in the "VOLUME" menu ........29

Making settings in the "CLOCK" menu ............30

Making settings in the "VARIOUS" menu ........30

Factory settings .............................................. 31

Useful information ......................................... 32

Warranty .....................................................................32

Service .........................................................................32

Technical data .................................................32

Installation instructions ................................33

Safety notes5Safety notes | Cleaning notes | Disposal notes | Scope of delivery | Placing the device in operation

Safety notes

The car sound system was manufactured according to the state of the art and established safety guidelines. Even so, dangers may occur if you do not observe the safety notes in these instructions.

These instructions contain important information to easily and safely install and operate the car sound system.

• Read these instructions carefully and completely before using the car sound system.

• Keep the instructions at a location so that they are always accessible to all users.

• Always pass on the car sound system to third parties together with these instructions.

In addition, observe the instructions of the devices used in conjunction with this car sound system.

Symbols used

These instructions employ the following symbols:

DANGER!

Warns about injuries

CAUTION!

Warns about damaging the CD drive

DANGER!

Warns about high volume

The CE mark con rms the compliance with EU directives.

쏅 Identi es a sequencing step

• Identi es a listing

Road safety

Observe the following notes about road safety:

• Use your device in such a way that you can always safely control your vehicle. In case of doubt, stop at a suitable location and operate your device while the vehicle is standing.

• Remove or attach the control panel only

while the vehicle is standing.

• Always listen at a moderate volume to pro- tect your hearing and to be able to hear acoustic warning signals (e.g. police sirens). During mute phases (e.g. when changing the audio source), changing the volume is not audible. Do not increase the volume during this mute phase.

General safety notes

Observe the following notes to protect yourself against injuries:

• Do not modify or open the device. The device contains a Class 1 laser that can cause injuries to your eyes.

• Do not increase the volume during mute phases, e.g. when changing the audio source. Changing the volume is not audible during a mute phase. Do not increase the volume during mute phases, e.g. when changing the audio source.

Use as directed

This car sound system is intended for installation and operation in a vehicle with 12 V vehicle system voltage and must be installed in a DIN slot. Observe the performance limits in the technical data. Repairs and installation, if necessary, should be performed by a specialist.

Installation instructions

You may only install the car sound system yourself if you are experienced in installing car sound systems and are very familiar with the electrical system of the vehicle. For this purpose, observe the installation instructions at the end of these instructions.

Declaration of conformity

The Blaupunkt AudioVision GmbH & Co. KG declares that the car sound system San Francisco 320 complies with the basic requirements and the other relevant regulations of the directive 2004/108/EEC and the car sound system Toronto 420 BT complies with the basic requirements and the other relevant regulations of the directive 1999/5/EC.

The declaration of conformity can be found on the Internet under www.blaupunkt.com.

Cleaning notes

Solvents, cleaning and scouring agents as well as dashboard spray and plastics care product may contain ingredients that will damage the surface of the car sound system.

• Use only a dry or slightly moistened cloth for cleaning the car sound system.

• If necessary, clean the contacts of the control panel regularly using a soft cloth moistened with cleaning alcohol.

Disposal notes

Do not dispose of your old unit in the household trash!

Use the return and collection systems available to dispose of the old device.

Scope of delivery

The scope of delivery includes: 1 Car sound system 1 Operating/installation instructions 1 Case for the control panel 1 Support frame 1 Antenna connection adapter Extended scope of delivery

(for 1011202321 / 1011202421 only): 1 Handheld remote control (incl. battery) 1 Connecting cable chamber A 1 Connecting cable chamber B

Optional equipment (not part of the scope of delivery)

Use only accessories approved by Blaupunkt. Information is available from your Blaupunkt specialised dealer or on the Internet under www.blaupunkt.com.

Placing the device in operation

Caution! Transport securing screws

Before the startup of the car sound system, ensure that the transport securing screws are removed (see the chapter "Installation instructions").

Attaching/detaching the control panel

The car sound system is equipped with a detachable control panel (release panel) to protect your equipment against theft. In the delivery state, the control panel is in the supplied case. To start operating the radio after installation, you must  rst attach the control panel (see the section "Attaching the control panel" in this chapter).

Always take the control panel with you when leaving the vehicle. The car sound system is worthless to a thief without this control panel.

Caution Damage to the control panel

Never drop the control panel. Transport the control panel so that it is protected

against impacts and the contacts cannot become dirty.

Do not expose the control panel to direct sunlight or another heat source.

Avoid direct skin contact with the control panel's electrical contacts.

Placing the device in operation

Attaching the control panel

쏅 Push the control panel into the bracket at the

right edge of the device.

쏅 Push the control panel carefully into the left

bracket until it clicks into place.

Removing the control panel

쏅 Press the

panel. The left side of the control panel detaches

from the device and is secured by the bracket against falling out.

쏅 Move the control panel slightly to the left until

it disengages from the right bracket.

쏅 Carefully remove the control panel from the

left bracket.

Note:

The car sound system automatically switches o as soon as the control panel is removed.

button 1 to unlock the control

Display language (only Toronto 420 BT)

For the Toronto 420 BT, you can de ne whether the language for messages on the display is English or German. The setting is performed in the user menu (see the chapter "User settings", section "Making settings in the "DISPLAY" menu", menu item " LANGUAGE").

Setting the reception area

This car sound system is designed for operation in di erent regions with di erent frequency ranges and station technologies. The factory default of the reception area is "EUROPE". In addition, the reception areas "USA", "SOUTH AMERICA" and " THAILAND" are available.

Note:

If you operate the car sound system outside of Europe, you may  rst have to set a suitable reception area in the user menu (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu item "TUNER AREA").

Switching on/o

Switching on/o with the On/O button

쏅 For switch-on, press the On/O button

The car sound system switches on.

쏅 To switch o the device, press and hold down

the On/O button onds.

The car sound system switches o .

Note:

If you switch on the car sound system while the vehicle ignition is switched o , it automatically switches o after 1 hour to preserve the vehicle battery.

Switching on/o via vehicle ignition

The car sound system will switch o /on simultaneously with the ignition if the device is correctly connected to the vehicle's ignition as shown in the installation instructions and you did not switch the device o by pressing the On/O button 3.

for longer than 2 sec-

Volume

Adjusting the volume

You can adjust the volume in steps from 0 (o ) to 50 (maximum).

쏅 Turn the volume control

volume.

Note:

If a telephone or navigation system is connected with the car sound system as described in the installation instructions (pin 2 of chamber A), the car sound system is muted in case of a telephone call or navigation announcement so that you can hear the playback of the telephone or navigation system undisturbed. During muting, the display shows "TELEPHONE".

Muting the car sound system (Mute)

쏅 Brie y press the On/O button

the car sound system or to reactivate the previous volume.

While it is muted, the display shows "MUTE".

to change the

to mute

Placing the device in operation | Tra c information | Radio mode

Display brightness

You can manually switch the display brightness between daytime mode and night-time mode or switch automatically with the driving lights of the vehicle.

Note:

The manual or automatic switching of the display brightness is selected in the user menu (see the chapter "User settings", section "Making settings in the "DISPLAY" menu", menu item "DIMMER").

쏅 Press the DIS button

to start scanning.

for approx. 2 seconds

Switching demo mode on/o

The demo mode shows the functions of the car sound system as scrolling text on the display. By pressing any button, the demo mode is interrupted and you can operate the device.

The demo mode can be switched on and o in the user menu (see the chapter "User settings", section "Making settings in the "VARIOUS" menu", menu item "DEMO MODE").

Tra  c information

In the reception area "EUROPE", an FM station can identify tra c reports by means of an RDS signal. If priority for tra c reports is switched on, a traf c report is automatically switched through, even if the car sound system is currently not in radio mode.

If priority is switched on, the display shows the tra c jam symbol ( during a switched-through tra c announcement.

The priority is activated and deactivated in the user menu (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu item "TRAFFICINFO").

Notes:

• The volume is increased for the duration of the switched-through tra c announcement. You can adjust the minimum volume

). "TRAFFIC" is displayed

for tra c announcements (see the chapter "User settings", section "Making settings in the "VOLUME" menu", menu item "TRAFFIC VOL").

• To cancel a switched-through tra c announcement, press the SRCbutton @.

Radio mode

RDS

Many FM stations broadcast an RDS (Radio Data System) signal in addition to their programme in the reception area "EUROPE" that allows the following additional functions:

• The station name is shown on the display.

• The car sound system recognises tra c announcements and news broadcasts and can automatically switch them through in other operating modes (e.g. in CD mode).

• Alternate frequency: If RDS is activated, the car sound system automatically selects the best receivable frequency for the station that is currently set.

• Regional: At certain times, some radio stations divide their programme into regional programmes providing di erent content. If the REGIONAL function is activated, the car sound system changes only to those alternate frequencies on which the same regional programme is being broadcast.

The functions RDS and REGIONAL are activated and deactivated in the user menu (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu items "RDS" and " REGIONAL").

Note:

If you adjust a di erent reception area than "EUROPE", RDS is automatically switched o . The station name continues to be shown on the display. If you want to use radio stations with RDS features in your region, switch on RDS in the user menu.

Radio mode

Changing to radio mode or selecting a memory bank

The following memory banks are available in the di erent reception areas:

Region Memory banks

EUROPE FM1, FM2, FMT, MW, LW USA FM1, FM2, FMT, AM, AMT SOUTH AMERICA FM1, FM2, FMT, AM, AMT THAILAND FM1, FM2, FMT, AM, AMT

쏅 Press the SRCbutton

desired memory bank is displayed.

Notes:

• Up to 5 stations can be stored in each memory bank.

• You can disable certain memory banks that you do not want to use (see chapter "User settings", section "Making settings in the "TUNER" menu", menu item "BAND SELECTION"). Deactivated memory banks are skipped during the source selection with the SRCbutton @.

repeatedly until the

Tuning into a station

There are various ways of tuning into a station:

Starting station seek tuning

쏅 Turn rotary control 7 one notch counter-

clockwise or clockwise to start station seek tuning.

The display brie y shows "SEARCH AUTO". The radio tunes into the next receivable station.

Notes:

• For the reception area "EUROPE": In the FM waveband, only tra c information stations are tuned into if the priority for tra c information ( ) is switched on.

• The sensitivity of seek tuning can be adjusted (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu item "SENSITIVITY").

Tuning into stations manually

쏅 Press the rotary button

manual station tuning. The display brie y shows "SEARCH MANUAL".

쏅 Turn the rotary control 

quency in increments.

Note:

The manual station tuning is automatically exited approx. 15 seconds after the last frequency change, and the station seek tuning is started by turning the rotary control 7.

once to activate

to change the fre-

Storing stations or calling stored stations

쏅 Select the desired memory bank. 쏅 If necessary, set the desired station.

쏅 Press the station button 1 - 5

2 seconds to store the current station under the button.

- or -

쏅 Brie y press the station button 1 - 5

up the stored station.

for approx.

to call

Scanning stations

With the scan function, you can scan either every receivable station or every stored station of the current waveband.

Note:

You can adjust the scan time for each station (see the chapter "User settings", section "Making settings in the "VARIOUS" menu", menu item "SCAN TIME").

Scanning all receivable stations of the waveband

쏅 Press the MENU button

onds to start scanning. During the scan, the display alternately dis-

plays "SCAN" and the current frequency as well as memory bank or station name.

쏅 Brie y press the MENU button

tinue listening to the station that is currently being scanned.

for approx. 2 sec-

to con-

Radio mode

Scanning all stored stations of the waveband

쏅 Press the rotary control

onds to start the scanning. During the scan, the display alternately dis-

plays the current frequency as well as memory bank and location or station name.

쏅 Brie y press the rotary control

listening to the station that is currently being scanned.

for approx. 2 sec-

to continue

Storing stations automatically (Travelstore)

With Travelstore, you can automatically search for and store the 5 FM stations o ering the strongest reception in the region in one memory bank. Any previously stored stations in this memory bank are deleted in the process.

With Travelstore, you can store 5 FM stations in the FMT memory bank in all reception areas. In the reception areas "USA", "SOUTH AMERICA" and "THAILAND", you can also store 5 AM stations in the AMT memory bank.

쏅 Select a memory bank of the desired wave-

band, e.g. FM1 or AM.

쏅 Press the SRC button @ for approx. 2 sec-

onds. The tuner starts the automatic station seek

tuning; the display shows "FM TSTORE" or "AM TSTORE". After the storing is completed, the radio plays the station at memory location 1 of the FMT or AMT level.

Notes:

• For the reception area "EUROPE": If the

priority for tra c information is switched on ( ), only tra c information stations are stored.

• If the FMT or AMT memory bank is deac-

tivated (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu item "BAND SELECTION"), it is automatically reactivated if you initiate the Travelstore function.

PTY

In the reception areas "EUROPE" and "USA", an FM station can transmit its current programme type, e.g. CULTURE, POP, JAZZ, ROCK, SPORT or SCIENCE. Hence, the PTY function allows a targeted search for broadcasts of a certain programme type, e.g. for rock or sports broadcasts. Note that PTY is not supported by all stations.

Note:

The PTY function is only available if it has been activated (see the chapter "User settings", section "Making settings in the "TUNER" menu", menu item "PTY").

Selecting a programme type

To select a programme type. read the section "Making settings in the "TUNER" menu", menu item "PTY TYPES" in the chapter "User settings".

Note:

In the reception area "EUROPE", you can adjust the language in which the programme types are displayed (see the chapter "User settings", section "Making settings in the " TUNER" menu", menu item "PTY LANGUAGE").

Searching for stations

Prerequisite: PTY function is switched on.

쏅 Press the rotary control

The display brie y shows "SEARCH PTY".

쏅 Turn rotary control

clockwise or clockwise to start the PTY seek tuning.

During the seek tuning, "SEARCH" and the currently selected programme type are shown on the display.

As soon as a station with the desired programme type is found, it remains being tuned into.

Notes:

• If no station with the selected programme type is found, "NO PTY" is brie y displayed and 2 beeps can be heard. The radio will then retune to the station that it played last.

twice.

one notch counter-

Radio mode | CD/MP3/WMA/iPod mode

• If the tuned radio station or another station on the broadcasting network broadcasts your selected programme type at a later point in time, the car sound system will automatically switch from the currently tuned station or from the current audio source (e.g. CD) to the station whose programme type matches the one you selected. Note that this function is not supported by all stations.

Con guring the display

쏅 Press the DIS button A to toggle between

these displays:

Display Meaning

ABCDEF Station name

FM1 P1 89.90

FM1 P1 08:40

Memory bank/memory location/frequency

Memory bank/memory location/time

CD/MP3/WMA/iPod mode

Basic information

CD/MP3/WMA mode

This car sound system can be used to play audio CDs (CDDA) and CD-R/RWs with audio, MP3 or WMA  les as well as MP3 or WMA  les on USB data carriers and SD(HC)/MMC memory cards.

Notes:

• To ensure proper functioning, use only CDs with the Compact-Disc logo.

• Blaupunkt cannot guarantee the  awless function of copy-protected CDs and all CD blanks, USB data carriers and memory cards available on the market.

Note the following information when preparing an MP3/WMA data carrier:

• Naming of tracks and directories: – Max. 32 characters without the  le exten-

sion ".mp3" or ".wma" (the use of more

characters reduces the number of tracks and folders that the car sound system can recognise)

– No umlauts or special characters

• CD formats: audio CD (CDDA), CD-R/RW, Ø: 12 cm

• CD data formats: ISO 9669 Level 1 and 2, Joliet

• CD burn speed: Max. 16x (recommended)

• USB format/ le system: Mass storage device/ FAT16/32

• Memory card  le system: FAT16/32

• File extension of audio  les:

– .MP3 for MP3  les – .WMA for WMA  les

•WMA  les only without Digital Rights Management (DRM) and created with Windows Media Player version 8 or later

• MP3 ID3 tags: Version 1 and 2

• Bitrate for creating audio  les:

– MP3: 32 to 320 kbps – WMA: 32 to 192 kbps

• Maximum number of  les and directories: Up to 30,000  les/500 directories depending on the data structure

iPod mode

You can connect numerous iPod and iPhone models to the car sound system via the USB port in the front of the device and the USB port at the rear and control the audio playback from the car sound system.

Notes:

• Blaupunkt cannot guarantee the  awless function of all iPod and iPhone models.

• If an iPhone and iPod are connected at the same time, the devices are charged via the USB ports. If two iPhones are connected at the same time, charging is not possible.

Use a suitable adapter cable to connect your iPod or iPhone with the USB port of the car sound system.

CD/MP3/WMA/iPod mode

Changing to CD/MP3/WMA/iPod mode

쏅 Press the SRCbutton @ repeatedly until the

desired audio source is displayed:

• "CD": Inserted CD.

• "SD(HC)": Inserted memory card

• "USB FRONT" or "USB REAR": USB data carrier connected to the front or rear.

• "IPOD FRONT" or "IPOD REAR": iPod connected to the front or rear

• "AUX": Connected external audio source.

Notes:

• The respective audio source can be selected only if a corresponding CD is inserted or a corresponding device is connected.

• A connected iPod is initially selected under "USB" and, as soon as the iPod is recognised, under "IPOD".

• If the car sound system  rst has to read the data of a connected device or data carrier before the playback, the display shows "READING". The duration of the reading depends on the data volume and design of the device or data carrier. If the device or data carrier is defective or the transferred data cannot be played back, a corresponding message appears on the display (e.g. "CD ERROR").

Inserting/ejecting a CD

Inserting a CD

Risk of severe damage to the CD drive!

Noncircular contoured CDs (shape CDs) and CDs with a diameter of 8 cm (mini CDs) must not be used.

We accept no responsibility for any damage to the CD drive that may occur as a result of the use of unsuitable CDs.

Note:

You must not hinder or assist the drive as it automatically draws in the CD.

쏅 Insert the CD with its printed side up into the

CD tray

until you feel a slight resistance.

The drive automatically draws in the CD and checks its data. Afterwards, the playback starts in CD or MP3 mode.

Note:

If the inserted CD cannot be played back, "CD ERROR" is brie y displayed and the CD is automatically ejected after approx. 2 seconds.

Ejecting a CD

Note:

You must not hinder or assist the drive as it ejects the CD.

쏅 Press the

CD.

Notes:

• If a CD is ejected and not removed, the

• You can also eject CDs while the car sound

button 8 to eject an inserted

drive will automatically draw it back in again after approx. 10 seconds.

system is switched o or whilst another audio source is activated.

Connecting/removing a USB data carrier

Note:

You can connect USB data carriers to the USB port at the front of the device as well as the rear USB port.

Connecting a USB data carrier

쏅 Switch o the car sound system so that the

data carrier will be correctly registered.

쏅 First, pull the protective cap of the USB port

to the front until it moves out of the port and fold it to the right to connect a data carrier to the USB port at the front of the device.

쏅 Connect the USB data carrier. 쏅 Turn on the car sound system.

CD/MP3/WMA/iPod mode

If the USB data carrier is initially selected as audio source, the data are read  rst.

Notes:

• If the connected USB data carrier cannot be seen, "USB ERROR" is brie y displayed.

• The time required for reading in the data depends on the design and size of the USB data carrier.

Removing a USB data carrier

쏅 Switch o the car sound system so that the

data carrier will be correctly unregistered. 쏅 Disconnect the USB data carrier. 쏅 After you pulled o the data carrier from the

USB port at the front of the device, close the

protective cap of the USB port

Inserting/removing the memory card

Inserting the memory card

쏅 Detach the control panel. 쏅 Insert the memory card with its labelled side

up and its contacts  rst into the card slotB

until it clicks into place. 쏅 Attach the control panel.

After switch-on, the device automatically

selects the inserted memory card as audio

source. The data of the memory card are be-

ing read. Afterwards, the playback starts in

MP3 mode.

Notes:

• If the inserted memory card cannot be played, "SD ERROR" is brie y displayed.

• The time required for reading the card depends on the design and size of the memory card.

Removing the memory card

쏅 Detach the control panel. 쏅 Push on the memory card until it disengages. 쏅 Pull the memory card out of the card slot 쏅 Attach the control panel.

Selecting tracks

쏅 Turn rotary control 7 one notch counter-

clockwise or clockwise to change to the previous/next track.

Notes:

• If you turn rotary control notches counter-clockwise or clockwise, you jump forward or reverse by the corresponding number of tracks.

• If the current track plays longer than 3 seconds and you turn rotary control one notch counter-clockwise or clockwise, the tracks starts playing again.

Fast searching

쏅 Press the rotary control 7 once.

The display brie y shows "CUE/REVIEW".

쏅 Turn the rotary control

position has been reached.

Note:

If you press the rotary control display brie y shows "TRACK SELECT". By turning the rotary control 7, you select a di erent track.

until the desired

Interrupting playback

쏅 Press the 3 button > to interrupt the

playback ("PAUSE") or to continue it.

Scanning all tracks

The scan function scans all available tracks.

쏅 Press the rotary control

onds to start the scan, or brie y to continue playing the currently scanned track.

During the scan, the display alternately displays "SCAN" and the current track number or  le name.

Note:

The scan time can be adjusted (see the chapter "User settings", section "Making settings

in the "VARIOUS" menu", menu item "SCAN TIME").

for approx. 2 sec-

several

twice, the

CD/MP3/WMA/iPod mode

Playing tracks in random order

쏅 Press the 5 MIX button > to change among

the playback modes:

Opera-

Display Meaning

tion CD/

MIX ALL Mixing tracks

iPod

MIX FOLDER

MP3/ WMA

MIX ALL

Gen. MIX OFF Regular playback

If the MIX function is switched on, the icon MIX (mix all tracks) or MIX current folder) is shown on the display.

Mixing tracks of the current folder

Mixing tracks of the data carrier

(mix tracks of

Repeatedly playing individual tracks or directories

쏅 Press the 4 RPT button > to change among

the playback modes:

Opera-

Display Meaning

tion CD/

REPEAT TRACK

iPod

REPEAT TRACK

MP3/ WMA

REPEAT FOLDER

Gen. REPEAT OFF

If the REPEAT function is switched on, the icon

(repeat tracks) or (repeat

folders) is shown on the display.

Repeating tracks

Repeating folders

Regular playback

Con guring the display

쏅 Press the DIS button A once or several times

to toggle between these displays:

Opera-

Display / icon Meaning

tion

TRACK 01 00:15

TRACK 01 03:37

TRACK 01 08:40

ABCDEF / ABCDEF / ABCDEF / ABCDEF /

MP3/

ABCDEF /

WMA/

PLAY TIME 00:15

iPod

TOTAL TIME 03:37

ALL INFO /

¹ Track name, artist and album name must be

stored as ID3 tag to be able to display them.

² The  le name is displayed only in MP3/WMA

mode.

³ The genre information is available only on

iPod mode.

Note:

With every track change, the  le name is brie y shown in MP3/WMA mode and the track name in iPod mode before the display switches to the de ned display.

Track number and playing time

Track number and duration

Track number and time

File name ² Track name¹ Artist¹ Album ¹ Genre ³ Playing time Track dura-

tion All informa-

tion as scrolling text

CD/MP3/WMA/iPod mode

Browse mode

In Browse mode, you can directly search for and select a certain track on the MP3/WMA data carrier or iPod without interrupting the current playback.

Browse mode in MP3/WMA mode

In MP3/WMA mode, you can select and play a track from a directory of the data carrier.

쏅 Brie y press the 1LIST button

the browse mode in MP3/WMA mode. The display shows the

 rst or current folder on the data carrier and the icon are displayed.

Notes:

• The  rst folder is displayed only if the browse mode has been called for the  rst time after inserting or connecting the data carrier. Afterwards, the current folder is displayed whenever the browse mode is called.

• The browse mode remains switched on for 5 minutes without con rming a selection.

• You can exit the browse mode at any time by pressing the 1LISTbutton

쏅 Turn the rotary control

ent folder.

쏅 Press the rotary control

tracks of the selected folder. The  rst track of the folder and the

shown on the display.

Note:

To return to the folder list, turn the rotary con-

until the "<<<" option is selected and

trol press the rotary control 7.

쏅 Turn the rotary control

ent track.

쏅 Press the rotary control

The playback starts. You are exiting the browse mode.

to call up

icon. The

to select a di er-

to display the

icon are

to select a di er-

to play the track.

Browse mode in iPod mode

In iPod mode, you can select and play the tracks via the categories "ARTISTS", "ALBUMS", "GENRES" or "PLAYLISTS".

쏅 Press the 2 ID3 button

to call up the

Browse mode in the iPod mode. The display shows the

icon. The

 rst category, "ARTISTS", is displayed.

Notes:

• Press the 2 ID3 button

for approx. 2 seconds to directly call up the "PLAYLISTS" category.

• The browse mode remains switched on for 5 minutes without con rming a selection.

• You can exit the browse mode at any time by pressing the 2 ID3 button

쏅 Turn the rotary control

to select the

category "ALBUMS" , "GENRES"

or "PLAYLISTS" .

쏅 Press the rotary control

to display the

available folders of the category. The  rst folder of the selected category is

shown on the display (e.g. "JAZZ" in the " GENRES" category).

Note:

To return to the list of categories, turn the rotary control

until the "<<<" option is

selected and press the rotary control 7.

쏅 Turn the rotary control

to select a di er-

ent folder.

쏅 Press the rotary control

to display the

available tracks of the folder. The  rst track of the folder is shown on the

display.

Note:

To return to the folder list, turn the rotary control 7 until the "<<<" option is selected and press the rotary control 7.

쏅 Turn the rotary control

to select a di er-

ent track.

CD/MP3/WMA/iPod mode | Bluetooth®

쏅 Press the rotary control 7 to play the track.

The playback starts. You are exiting the browse mode.

Searching by track names (not in iPod mode)

On MP3/WMA data carriers, you can  nd a track based on its  le name and start the playback.

쏅 Press the 1 LIST button

onds to start the search function. You can now enter a  le name with up to

16 characters:

Notes:

• You do not have to enter the complete  le name. You can enter only the  rst characters of the  le name and select the desired track from the list of tracks found.

• You can exit the search function at any time by brie y pressing the 1 LIST button

쏅 Turn the rotary control

ter for the respective position.

쏅 Press the rotary control

position.

쏅 Press the 1 LIST button

onds to start the search. All tracks corresponding to the  le name en-

tered are listed.

쏅 If necessary, turn the rotary control

select a track.

쏅 Press the rotary control

back.

for approx. 2 sec-

to select a charac-

to go to the next

for approx. 2 sec-

to start the play-

Bluetooth® (Toronto 420 BT only)

You can connect the Toronto 420 BT via Bluetooth® with other Bluetooth®-ready devices, such as cell phones or MP3 players. This allows you to use the car sound system with its integrated microphone as hands-free system for connected cell phones and control the audio output of other Bluetooth® devices and play them back via the loudspeakers of the car sound system (Bluetooth® streaming).

Note:

You can also connect an external microphone for hands-free calling (see the chapter "Installation instructions").

Bluetooth® technology is a wireless connection of short range. For this reason, Bluetooth® devices must be located near the car sound system (in the vehicle) to establish and maintain a connection. To establish a Bluetooth® connection, you must  rst pair the car sound system and the Bluetooth® device. When you pair the devices, a Bluetooth® connection is subsequently established automatically. This connection remains in e ect as long as the Bluetooth® device is within range. If the connection is interrupted, e.g. because you moved the cell phone outside the range, the connection is automatically re-established as soon as you are back within range. You can connect only one cell phone and streaming device with the car sound system at a time. If you connect a new device with the car sound system, the connection to a currently connected device may automatically be interrupted. However, the car sound system leaves up to 5 di erent Bluetooth® devices paired, and you can quickly and easily connect any of these devices with the car sound system again.

Bluetooth® menu

In the Bluetooth® menu, you  nd all the functions for pairing, connecting and managing Bluetooth® devices.

Bluetooth®

Calling the Bluetooth® menu

쏅 Brie y press the MENU

button to open

the user menu.

쏅 Turn the rotary control

until the "BLUE-

TOOTH" menu item is selected.

쏅 Press the rotary control

to open the Blue-

tooth® menu.

쏅 Turn the rotary control

until the desired

menu item is selected.

쏅 Perform the setting (see the following sec-

tions).

쏅 Brie y press the MENU button

to exit the

menu.

Notes:

• The Bluetooth® menu is automatically exited approx. 60 seconds after the last button activation and you are returned to the display of the current audio source.

• To go back to the next higher-level menu, turn the rotary control

until the "<<<" option is selected and press the rotary control 7.

• If a Bluetooth® process is running (e.g. re-establishing the connection to the last connected device), the functions of the Bluetooth® menu are blocked. If you attempt to open the Bluetooth® menu during this time, "LINK BUSY" brie y appears on the display. If you want to cancel the Bluetooth® process and open the Bluetooth® menu, press the

button <.

Pairing and connecting a device

Note:

You can pair up to 5 Bluetooth® devices with this car sound system. Before you can pair a sixth device, you must  rst unpair one of the 5 already paired devices (see ch. "Additional functions in the Bluetooth® menu", section "Managing paired devices"). If you should attempt to pair a sixth Bluetooth® device, "PHONE LIST FULL – PLEASE DELETE ENTRIES FROM LIST" is displayed.

Pairing and connecting a cell phone

Note:

If a connection with a cell phone currently exists, this connection is automatically disconnected if you pair and connect another cell phone.

쏅 In the Bluetooth® menu, select the "PAIRING"

menu item.

쏅 Press the rotary control

to open the menu.

The "MOBILE PHONE" menu item is selected.

쏅 Press the rotary control

to register a cell

phone. The display shows "PAIRING" and the Blue-

tooth® symbol

is  ashing. The car sound system can now be recognised by a Bluetooth® cell phone for approx. 2 minutes and connected.

쏅 Search the car sound system from your cell

phone (Bluetooth® name: "BP 420 BT"). As soon as the car sound system is located

by the cell phone and is to be connected, the display brie y shows "ENTER PIN" and the currently stored PIN (by default "1234").

쏅 Establish the connection from your cell

phone. Enter the PIN displayed by the car sound system.

The display may show "PAIRED", followed by "CONNECTED", as soon as the car sound system and the cell phone are paired and connected.

Notes:

If no connection can be established, the display brie y shows "CONNECT FAILED".

Pairing and connecting a Bluetooth® streaming device

Note:

If a connection with a streaming device currently exists, this connection is automatically disconnected if you pair and connect another streaming device.

Bluetooth®

쏅 In the Bluetooth® menu, select the "PAIRING"

menu item.

쏅 Press the rotary control

to open the menu.

The "MOBILE PHONE" menu item is selected.

쏅 Turn the rotary control

to select the

"STREAMING" menu item.

쏅 Press the rotary control

to register a

streaming device. The display shows the currently stored

PIN (default "1234"). If required, enter the PIN of the streaming device:

쏅 Turn the rotary control

to select a digit for

the respective position.

쏅 Press the rotary control

to go to the next

position.

Notes:

• To return to the previous position for the PIN entry, turn the rotary control

until the "<<<" option is selected, and press the rotary control 7.

• Not all streaming devices require the entry of a PIN on the car sound system. For some streaming devices, you have to enter the PIN of the car sound system instead. For these devices, press only the rotary control

repeatedly until you reach beyond the last position, thereby con rming the current PIN, and then enter this PIN on the streaming device.

The display shows "PAIRING" and the Bluetooth® symbol

is  ashing. The car sound system can now be recognised by the streaming device for approx. 2 minutes and connected.

쏅 Search the car sound system from your stream-

ing device (Bluetooth® name: "BP 420 BT") and establish the connection. Enter the PIN of the car sound system, if necessary.

The display may show "PAIRED", followed by "CONNECTED", as soon as the car sound system and the streaming device are paired and connected.

Notes:

• If no connection can be established, the display brie y shows "CONNECT FAILED".

• After switch-on, the car sound system automatically attempts to reconnect the device connected last. If the connection attempt fails, the display brie y shows "CONNECTION LOST". If necessary, attempt to re-establish the connection from the streaming device.

Telephone functions

Answering/rejecting an incoming phone call

With an incoming call, the display alternately shows "INCOMING CALL" and the number of the caller. The current audio source is muted and a ring tone is played via the loudspeakers of the car sound system.

Note:

If the number of the caller is not being transmitted, the display shows "PRIVATE NUMBER" instead of the number. If the number of the caller is stored together with a name, the name of the entry and the number are displayed (see the section "Storing a phone number in the car sound system" in this chapter).

쏅 Press the

"CALL" and the duration of the ongoing call are displayed.

쏅 Press the

to end the current call. The display shows "CALL END".

Notes:

• During the call, you can adjust the volume with the volume control device with a short press of the On/O button 3.

• You can adjust the volume for the call playback in the user menu (see the chapter "User settings", section "Making settings in the "VOLUME" menu", menu item "HANDSFREE VOL").

button = to answer the call.

< button to reject the call or

or mute the

Bluetooth®

Making a call

쏅 In the Bluetooth® menu, select the "DIAL NEW

NUMBER" menu item.

쏅 Press the rotary control 7 to open the entry

menu. You can now enter a phone number with up

to 20 digits:

쏅 Turn the rotary control

to select a digit for

the respective position.

쏅 Press the rotary control

to go to the next

position.

Note:

To return to the previous position in the entry menu, turn the rotary control

until the "<<<" option is selected, and press the rotary control 7.

쏅 Press the

button = to call the number

entered. "CALLING" and the dialed number are alter-

nately shown on the display. As soon as your calling party answers the call,

the display shows "CALL" and the time of the current phone call.

Upon ending the call, the display brie y shows "CALL END".

Calling an entry in the phone book

Note:

This function is available only if the phone book of the connected cell phone was transferred to the car sound system (see the chapter "Phone book functions").

쏅 In the Bluetooth® menu, select the "PHONE-

BOOK" menu item.

쏅 Press the rotary control

to open the phone

book. The display shows the  rst phone book entry.

Note:

If the phone book has not yet been transferred, the display brie y shows "PHONEBOOK NOT AVAILABLE".

쏅 Turn the rotary control

to select a di er-

ent entry.

쏅 Press the rotary control

or the but-

ton = to call the number. "CALLING" and the dialed number are alter-

nately shown on the display.

Note:

You can also call an entry in the phone book via speed dial (see the section "Speed dial for phone book entries" in this chapter).

Making a call with voice dial

Note:

This function is only available if the connected cell phone supports voice dial.

쏅 In the Bluetooth® menu, select the "VOICE

DIAL" menu item.

쏅 Press the rotary control

or the but-

ton = to activate voice recognition. The car sound system is muted and the dis-

play shows "SPEAK NOW".

쏅 Say the name of the desired calling partner.

Notes:

• If no Bluetooth® connection is established when voice recognition is activated, the display brie y shows "VOICE DIAL FAILED – NO BT CONNECTION".

• If the spoken name is not being recognised or the time for the voice recognition has already expired, the display brie y shows "DIAL FAILED".

• You can cancel the voice recognition by pressing the

button <.

• Please note that the duration of the voice recognition is limited and depending on the respective cell phone.

• You can also activate the voice recognition via speed dial (see the section "Speed dial for voice dial" in this chapter).

Bluetooth®

Storing a phone number in the car sound system

You can store phone numbers in the car sound system and make calls using the speed dial (see the following section). A phone number is stored for the currently connected telephone and is available only for this tel-

Speed dial for any phone number or for the number dialed last or a stored number

With speed dial, you can make a call without  rst having to select the corresponding function in the Bluetooth® menu.

To call the number dialed last,

ephone. The car sound system can store up to  ve numbers for up to  ve paired devices.

쏅 Enter the phone number as described in the

section "Making a call".

쏅 Press the desired memory button 1-5

for

approx. 2 seconds to store only the number.

- or -

쏅 Press the rotary control

for approx. 2 sec-

onds to enter a name for the entry. You can now enter a name with up to 15 char-

To call a stored number,

acters:

쏅 Turn the rotary control

to select a charac-

ter for the respective position.

쏅 Press the rotary control

to go to the next

position.

Note:

To return to the previous position in the entry menu, turn the rotary control

until the "<<<" option is selected, and press the rotary control 7.

쏅 Press the desired memory button

for approx. 2 seconds to store the

1 -5

To call any number,

number and name. The display brie y shows "NUMBER SAVED".

Afterwards, you are returned to the Bluetooth® menu and the "DIAL NEW NUMBER" menu item.

Notes:

• A number previously stored on the memory button is replaced.

• If a telephone is unpaired, the numbers stored for this telephone are automatically deleted.

쏅 press the

button =.

The display shows the number dialed last.

Note:

If no cell phone is currently connected, the Bluetooth® menu is opened. The "PAIRING" menu item is selected.

쏅 Press the

button = to call the number.

"CALLING" and the dialed number are alternately shown on the display.

쏅 press the 쏅 Press a memory button 1 - 5

button =.

to call the

number stored.

Note:

If no number is stored under the selected memory button, the display brie y shows "NO NUMBER".

쏅 Press the

button = to call the number.

"CALLING" and the dialed number are alternately shown on the display.

쏅 press the 쏅 Press the On/O button

button =.

to open the entry menu and enter a number (enter the phone number as described in the section "Making a call").

쏅 Press the

button = to call the number.

"CALLING" and the dialed number are alternately shown on the display.

Bluetooth®

Speed dial for phone book entries

Note:

This function is only available

• if the phone book of the connected cell phone was transferred to the car sound system (see the chapter "Phone book functions").

• if the speed dial is set for phone book entries (see the chapter "Additional functions in the Bluetooth® menu", section "Setting the button function for speed dial").

To select an entry of the phone book with the speed dial and call it,

쏅 press the

onds. The display shows the  rst phone book entry.

쏅 If necessary, select another entry as described

in the section "Calling an entry in the phone book".

쏅 Press the button = to call the number.

"CALLING" and the dialed number are alternately shown on the display.

Speed dial for voice dial

Note:

This function is only available

• if the connected cell phone supports voice dial.

• if the speed dial is set for voice dial (see the chapter "Additional functions in the Bluetooth® menu", section "Setting the button function for speed dial").

To activate the voice recognition with the speed dial,

쏅 press the button = for approx. 2 sec-

onds. The car sound system is muted and the dis-

play shows "SPEAK NOW".

쏅 Say the name of the desired calling partner.

button = for approx. 2 sec-

Bluetooth® streaming mode

Starting the Bluetooth® streaming mode

쏅 Press the SRC

"BT-STREAM" appears on the display. The playback starts.

Notes:

• The Bluetooth® streaming mode can be selected only if a suitable streaming device is connected.

• If the connection to the streaming device is lost during playback, the display brie y shows "CONNECTION LOST" and the car sound system changes to the previous audio source.

Selecting tracks

쏅 Turn rotary control

clockwise or clockwise to change to the previous/next track.

Interrupting playback

쏅 Press the 3 button > to interrupt the

playback ("PAUSE") or to continue it.

button repeatedly until

one notch counter-

Phone book functions

Transferring the phone book of the cell phone to the car sound system

You can transfer the phone book of the connected cell phone to the car sound system to call entries of the phone book using the car sound system.

Notes:

• The car sound system accepts only entries from the memory of the telephone and not from the SIM card inserted in the telephone.

• The transfer does not delete the phone book from the cell phone.

The car sound system can store the phone books of the paired telephones with a total of up to 960 entries. If several numbers are stored on the telephone for one contact (e.g. landline, cell phone number, o ce number and similar), each number is stored as a separate entry by the car sound system.

Bluetooth®

Each entry consists of a name and a number, each up to 20 characters on digits.

Note:

Do not switch o the car sound system while transferring the phone book. If you do or if the power supply of the car sound system should be interrupted for any reason, you have to restart the transfer.

쏅 In the Bluetooth® menu, select the "DOWN-

LOAD P–BOOK" menu item.

again.

but-

쏅 Press the rotary control

The display shows "CONFIRM".

쏅 Press the rotary control

"PHONEBOOK DOWNLOADING – PLEASE WAIT" appears on the display.

After the download is complete, the display brie y shows "DOWNLD COMPLETE".

Notes:

• To cancel the transfer, press the ton <.

• If the transfer of the phone book fails, the display brie y shows "DOWNLOAD FAILED".

• If the transfer of the phone book exceeds the storage capacity of the car sound system, the display brie y shows "PHONEBOOK FULL". The phone book entries transferred so far remain stored.

• If you supplemented or changed entries on your cell phone since the last transfer, you can update the phone book on the car sound system by transferring it again. If the storage capacity of the car sound system is exceeded in the process,  rst delete the already transferred phone book (see the next section) or unpair another cell phone, if necessary, so that its phone book is also deleted from the car sound system (see the chapter "Additional functions in the Bluetooth® menu", section "Managing paired devices").

• If you insert a CD during an ongoing transfer, the playback does not start until the transfer is completed.

Deleting the phone book of the cell phone from the car sound system

You can delete the phone book of the connected cell phone.

Note:

The telephone remains connected.

쏅 In the Bluetooth® menu, select the "DELETE

P–BOOK" menu item.

again.

쏅 Press the rotary control

The display shows "CONFIRM".

쏅 Press the rotary control

Additional functions in the Bluetooth® menu

Changing the Bluetooth® PIN

The factory-set Bluetooth® PIN of the car sound system is "1234"; e.g. it must be entered on the cell phone when pairing a cell phone. This PIN can be changed.

쏅 In the Bluetooth® menu, select the "PIN EDIT"

menu item.

쏅 Press the rotary control

menu. You can now enter the PIN:

쏅 Turn the rotary control

the respective position.

쏅 Press the rotary control

position.

Note:

To return to the previous position in the entry menu, turn the rotary control the "<<<" option is selected, and press the rotary control 7.

to open the entry

to select a digit for

to go to the next

until

Bluetooth®

Managing paired devices

In the Bluetooth® menu, you can manage the paired Bluetooth® devices (cell phones and streaming devices such as MP3 player). In the device lists for cell phones and streaming devices, the Bluetooth® names or addresses of the paired devices are displayed. You can do the following:

• Disconnecting the connection to the currently connected Bluetooth® device

• Establishing a connection to one of the paired Bluetooth® devices

• Unpairing Bluetooth® devices

쏅 In the Bluetooth® menu, select the menu item

"PHONE LIST" or "STREAMING LIST".

쏅 Press the rotary control

to open the menu.

The  rst device on the list is displayed.

Note:

If no device is paired, "EMPTY LIST" is brie y displayed.

쏅 Turn the rotary control

to select a di erent

device or the "DELETE ALL" option. You have the following options: To connect the displayed device,

쏅 press the

button =.

As soon as the device is connected, "CON-

NECTED" is brie y displayed and you are re-

turned to the Bluetooth® menu.

Note:

If no connection can be established, the

display brie y shows "CONNECT FAILED". If

the device is already connected, the display

brie y shows "CONNECT EXIST". To disconnect the connection to the displayed

device,

쏅 press the

button <.

The display brie y shows "DISCONNECTED"

and you are returned to the Bluetooth® menu.

Note:

If the device was not connected, the display

brie y shows "NO CONNECTION".

To unpair the displayed device,

쏅 press the

button < for approx. 2 sec-

onds. The display brie y shows "DELETED" and you

are returned to the Bluetooth® menu.

Note:

If a telephone is unpaired, the numbers stored for this telephone and a phone book transferred from this cell phone are automatically deleted.

To unpair all the cell phones or streaming devices,

쏅 select the "DELETE ALL" menu item. 쏅 Press the rotary control

The display shows "CONFIRM".

쏅 Press the rotary control

or the but-

ton = again. The display brie y shows "EMPTY LIST".

Setting the button function for speed dial

You can select whether the long press of the button = opens the phone book or activates voice dial.

쏅 In the Bluetooth® menu, select the "SOFTKEY"

menu item. Next to "SOFTKEY", the current "P–BOOK" set-

ting for phone book or "VOICE" for voice dial is displayed.

쏅 Press the rotary control 7 to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

External audio sources | Sound settings

External audio sources

Front AUX-IN socket

Danger! Increased risk of injury from

connector.

In case of an accident, the protruding connector in the front AUX-IN socket may cause injuries. The use of straight plugs or adapters leads to an increased risk of injury.

For this reason, we recommend using angled jack plugs, e.g. the Blaupunkt accessories cable (7 607 001 535).

As soon as an external audio source, such as a portable MP3 player is connected to the front AUX-IN socket button @. "AUX" then appears on the display.

;

, it can be selected with the SRC

Notes:

• You can enter an individual name for the AUX source that is shown on the display in AUX mode (see the chapter "User settings", section "Making settings in the "VARIOUS" menu", menu item "AUX EDIT").

• You can play back an AUX source at the same time with one of the internal audio sources of the car sound system. Hence, you can play back the announcements of a navigation device connected to the front AUX-IN socket the car sound system while listening to the radio or a CD at the same time. In addition, you can adjust the volume levels of both audio sources to each other. For more details, please read the section "Making settings in the "VARIOUS" menu", menu items "AUX MIX" and "AUX MIX GAIN" in the chapter "User settings".

;

via the loudspeakers of

Sound settings

The following sound settings can be changed in the "AUDIO" menu:

• Adjusting bass and treble

• Setting the left/right volume distribution (Balance) or front/rear (Fader)

• Adjusting the increase of bass at low volume (Loudness)

• Selecting a sound pro le (Sound Preset)

• Setting level and frequency of the preampli er output (Sub-Out)

• Setting the 3-band equaliser

• Adjusting the time delay for switching in an external ampli er

Calling and exiting the "AUDIO" menu

쏅 Brie y press the MENU button 2 to open

the user menu.

쏅 Turn the rotary control

menu item is selected.

쏅 Press the rotary control

"AUDIO" menu.

쏅 Turn the rotary control

menu item is selected. 쏅 Perform the setting (see the next section). 쏅 Brie y press the MENU button

menu.

Notes:

• The menu is automatically exited approx. 60 seconds after the last button activation and you are returned to the display of the current audio source.

• To go back to the next higher-level menu, turn the rotary control 7 until the "<<<" option is selected and press the rotary control 7.

until the "AUDIO"

to open the

until the desired

to exit the

Sound settings

Making settings in the "AUDIO" menu

BASS

Bass level. Settings: –7 to +7.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

level is set.

쏅 Press the rotary control

setting.

TREBLE

Treble. Settings: –7 to +7.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

level is set.

쏅 Press the rotary control

setting.

BALANCE

Left/right volume distribution. Settings: L9 (left) to R9 (right).

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

volume distribution is set.

쏅 Press the rotary control

setting.

FADER

Front/rear volume distribution. Settings: R9 (rear) to F9 (front).

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

volume distribution is set.

쏅 Press the rotary control

setting.

to change the

until the desired

to con rm the

to change the

until the desired

to con rm the

to change the

until the desired

to con rm the

to change the

until the desired

to con rm the

LOUDNESS

Increase of bass at low volume. Settings: ON, OFF.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

PRESET EQ (sound pro le)

Selecting equalizer presettings. Settings: PRESET EQ POP, PRESET EQ ROCK, PRESET EQ CLAS (classic), PRESET EQ OFF (sound pro le o ; no presetting).

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

SUB-OUT

Setting the level and frequency of the preampli er output.

쏅 Press the rotary control 쏅 Turn the rotary control

to open the menu.

to change be-

tween the following menu items:

– FREQUENCY

(settings: 80/120/160 Hz)

– GAIN

(settings: 0 to +7)

쏅 Press the rotary control

to change the

setting for the selected menu item.

쏅 Turn the rotary control

to set the level or

frequency.

쏅 Press the rotary control

to con rm the

setting.

Sound settings

AMP DELAY

Setting the delay with which a connect ampli er is switched in.

and OFF (no delay)

쏅 Press the rotary control

Settings: 0.5/1.0/1.5/2.0/2.5 seconds

to change the

setting.

쏅 Turn the rotary control

until the desired

delay is set.

쏅 Press the rotary control

to con rm the

setting.

Setting the 3-band equaliser

The radio features a 3-band equaliser. For each of the three treble, middle and bass bands, you can select a frequency as well as adjust the level. In addition, you can adjust the quality factor for bass and middle.

The equaliser also provides an adjustable increase of the bass at low volume (X-bass).

Opening the "EQUALIZER" menu

쏅 In the "AUDIO" menu, select the "EQUALIZER"

menu item. 쏅 Press the rotary control 쏅 Turn the rotary control

tween the following menu items:

– EQUALIZER – EQ TREBLE – EQ MIDDLE – EQ BASS – EQ X-BASS

Note:

The submenus in the "EQUALIZER" menu are

not automatically exited after the last key has

been activated. After the setting, press the

MENU button

to exit the menu.

to open the menu.

to change be-

EQUALIZER

Switching the equalizer on or o . Settings: ON, OFF.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

EQ TREBLE

Adjusting treble frequency and level of the equalizer.

쏅 Press the rotary control 쏅 Turn the rotary control

to open the menu.

to change be-

tween the following menu items:

– FREQUENCY

(settings: 10/12.5/15/17.5 kHz)

– GAIN

(settings: –7 to +7)

쏅 Press the rotary control

to change the

setting for the selected menu item.

쏅 Turn the rotary control

to set the level or

frequency.

쏅 Press the rotary control

to con rm the

setting.

EQ MIDDLE

Adjusting centre frequency and level of the equalizer.

쏅 Press the rotary control 쏅 Turn the rotary control

to open the menu.

to change be-

tween the following menu items:

– FREQUENCY

(settings: 0.5/1.0/1.5/2.5 kHz)

– GAIN

(settings: –7 to +7)

– Q-FACTOR

(settings: 0.5/0.75/1.0/1.25)

쏅 Press the rotary control

to change the

setting for the selected menu item.

Sound settings | User settings

쏅 Turn the rotary control7 to set the level,

frequency or Q-factor.

쏅 Press the rotary control

setting.

EQ BASS

Adjusting bass frequency and level of the equalizer.

쏅 Press the rotary control 쏅 Turn the rotary control

tween the following menu items:

– FREQUENCY

(settings: 80/100/200 Hz)

– GAIN

(settings: –7 to +7)

– Q-FACTOR

(settings: 1.0/1.25/1.5/2.0)

쏅 Press the rotary control

setting for the selected menu item.

쏅 Turn the rotary control

frequency or Q-factor.

쏅 Press the rotary control

setting.

EQ X-BASS

Adjusting the frequency and level for the increase of bass at low volume.

쏅 Press the rotary control 쏅 Turn the rotary control

tween the following menu items:

– FREQUENCY

(settings: 60/80/100 Hz)

– GAIN

(settings: 0 to +3)

쏅 Press the rotary control

setting for the selected menu item.

쏅 Turn the rotary control

frequency.

쏅 Press the rotary control

setting.

to con rm the

to open the menu.

to change be-

to change the

to set the level,

to con rm the

to open the menu.

to change be-

to change the

to set the level or

to con rm the

User settings

Calling the user menu and selecting a menu

쏅 Brie y press the MENU 2 button to open

the user menu.

In the user menu, the user settings can be found in the following menus:

• TUNER

• AUDIO (see chapter "Sound settings")

• DISPLAY

• VOLUME

• CLOCK

• VARIOUS

• BLUETOOTH (Toronto 420 BT only, see the chapter "Bluetooth®")

쏅 Turn the rotary control

menu is selected.

쏅 Press the rotary control

selected menu.

쏅 Turn the rotary control

menu item is selected.

쏅 Perform the setting (see the following

sections).

쏅 Brie y press the MENU button

menu.

Notes:

• The menu is automatically exited approx. 60 seconds after the last button activation and you are returned to the display of the current audio source.

• To go back to the next higher-level menu, turn the rotary control 7 until the "<<<" option is selected and press the rotary control 7.

until the desired

to open the

until the desired

to exit the

User settings

Making settings in the "TUNER" menu

TRAFFICINFO (tra c information) (only for reception area EUROPE)

Only possible in FM radio mode: Switching priority for tra c announcements on or o . Settings: ON, OFF.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

If priority is switched on for tra c information, the display shows the icon

BAND SELECTION

Activating or deactivating memory banks. Memory banks that can be deactivated:

Region Memory banks

EUROPE FM2, FMT, MW, LW USA FM2, FMT, AM, AMT SOUTH AMERICA FM2, FMT, AM, AMT THAILAND FM2, FMT, AM, AMT

Settings in each case: ON, OFF.

쏅 Press the rotary control 쏅 Turn the rotary control

memory bank is set.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

the settings ON (activate memory bank) and OFF (deactivate memory bank).

쏅 Press the rotary control

setting.

Deactivated memory banks are skipped during the source selection with the SRCbutton

to change the

to change be-

to con rm the

to open the menu.

until the desired

to change the

to toggle between

to con rm the

Notes:

• In the factory default, all AM memory

banks are deactivated.

• If a memory bank is deactivated, the sta-

tions stored in this memory bank are retained.

REGIONAL (only for reception area EUROPE)

Only possible in FM radio mode: Switching REGIONAL function on or o . Settings: ON, OFF.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

SENSITIVITY

Setting the sensitivity of station seek tuning. Settings: LO (–; low), HI (+; high).

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

RDS

Switching the RDS function on or o . Settings: ON, OFF.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

Note:

If the reception area "USA", "SOUTH AMERICA" or "THAILAND" is selected, RDS is automatically switched o . The station name continues to be shown on the display.

User settings

PTY

Switching the PTY function on or o . Settings: ON, OFF.

쏅 Press the rotary control 7 to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

PTY TYPES

Only possible with activated PTY function: Select a programme type.

Note:

As soon as a programme type has been selected, this programme type is shown as menu item in the menu instead of "PTY TYPES".

쏅 Press the rotary control 7 to change the

setting.

쏅 Turn the rotary control

to change be-

tween the available programme types.

쏅 Press the rotary control

to con rm the

selected programme type.

PTY LANGUAGE (only for reception area EUROPE)

Only possible with activated PTY function: Select a language for the display of the programme types. Settings: ENGLISH, DEUTSCH (German), FRANCAIS (French).

쏅 Press the rotary control 쏅 Press the rotary control

to open the menu.

to change be-

tween the languages.

쏅 Turn the rotary control

to select a lan-

guage.

쏅 Press the rotary control

to con rm the se-

lected language.

TUNER AREA (reception area)

Select the reception area for the radio reception. Settings: EUROPE, USA, SOUTH AMERICA, THAILAND.

쏅 Press the rotary control 쏅 Turn the rotary control

to open the menu.

to change be-

tween the reception areas.

쏅 Press the rotary control

to select a recep-

tion area. The display shows "PLEASE CONFIRM".

쏅 Press the rotary control

to con rm the

selected reception area.

Making settings in the "DISPLAY" menu

DIMMER

Select automatic or manual switching of the display brightness for day or night. Settings: AUTO (display brightness is automatically switched by switching the driving lights on or o ), MANUAL (display brightness can be switched manually).

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

Automatic switching of the display brightness is possible only If your car sound system is installed as described in the installation instructions and your vehicle features the corresponding connection.

SCROLLING

Select the display of scrolling text (e.g. when displaying MP3  le names with more than 15 characters) either as single display or continued display. Settings: 1X (single display), ON (continued display).

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

to change the

to change be-

to con rm the

to change the

to change be-

to con rm the

User settings

LANGUAGE (only for Toronto 420 BT)

Select the language for the display. Settings: ENGLISH, DEUTSCH (German).

쏅 Press the rotary control 7 to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

Making settings in the "VOLUME" menu

ON VOLUME

Setting the power-on volume. Settings: ON VOLUME (power-on volume; 1–50) or LAST VOLUME (volume set last before switching o the car sound system).

Danger! High volume

pectedly high if the LAST VOLUME setting is selected and a high volume was set the last time the radio was switched o .

Always set the device to a moderate volume.

Upon selecting "LAST VOLUME":

Upon selecting "ON VOLUME":

The power-on volume can be unex-

쏅 Press the rotary control 쏅 Turn the rotary control

to open the menu.

to switch between the menu items "LAST VOLUME" and "ON VOLUME" (power-on volume).

쏅 Press the rotary control

to con rm the

setting.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control 쏅 Press the rotary control

to set the volume.

to con rm the

setting.

TRAFFIC VOL (tra c information volume) (reception area EUROPE only)

Setting the minimum volume for tra c announcements. Settings: 1 – 50.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control 쏅 Press the rotary control

to set the volume.

to con rm the

setting.

HANDSFREE VOL (for Toronto 420 BT only and with connected cell phone)

Adjusting the level for handsfree volume. Settings: –5 to +5.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to set the level

adjustment.

쏅 Press the rotary control

to con rm the

setting.

BEEP (button beep)

Switching the con rmation beep on or o . Settings: ON, OFF.

Note:

When storing radio stations, a con rmation beep sounds even if the OFF setting is selected.

쏅 Press the rotary control

to change the

setting.

쏅 Turn the rotary control

to change be-

tween the settings.

쏅 Press the rotary control

to con rm the

setting.

User settings

Making settings in the "CLOCK" menu

PERM CLOCK

Switch the permanent display of the time on or o . Settings: ON, OFF.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

If the permanent display of the time is switched on, the time is shown on the display. The display of the respective audio source is shown only after pressing a button. Approximately 15 seconds after the button is pressed last, the time is displayed again.

HOUR MODE

Selecting the 12 or 24-hour time. Settings: 12, 24.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

SET

Setting the time.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

the hours.

쏅 Turn the rotary control

to set the minutes.

쏅 Press the rotary control

time set.

Note:

When you set the time in 12-hour mode (HOUR MODE 12), an "AM" is displayed before the time for the time before noon or a "PM" for the time after noon.

to change the

to change be-

to con rm the

to change the

to change be-

to con rm the

to change the

clockwise to set

counter-clockwise

to con rm the

Making settings in the "VARIOUS" menu

DEMO MODE

Switching the demo mode on or o . Settings: ON, OFF.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

In demo mode, the features of the radio are shown as scrolling text on the display.

MIX AUX

Switching the combined playback of the AUX source with another audio source on or o . Settings: ON, OFF.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

With the AUX MIX ON setting, an audio source connected to the front AUX-IN socket back simultaneously with the respective active internal audio source of the car sound system (e.g. radio or CD).

AUX MIX GAIN (AUX MIX Level)

Adjusting the level of the AUX source with combined playback of the AUX source and another audio source (AUX MIX ON). Settings: –5 to +5.

쏅 Press the rotary control

setting.

쏅 Turn the rotary control

adjustment.

쏅 Press the rotary control

setting.

This setting allows raising or lowering the level of the AUX source to adjust it to the level of the other active audio source.

to change the

to change be-

to con rm the

to change the

to change be-

to con rm the

;

is played

to change the

to set the level

to con rm the

User settings | Factory settings

AUX EDIT

Entry of an individual 15-digit name for the AUX source. Possible characters: space, 0 – 9, A – Z.

쏅 Press the rotary control 7 to open the menu. 쏅 Press the rotary control

setting.

For each of the 15 characters:

쏅 Turn the rotary control7 to set the charac-

ter.

쏅 Press the rotary control

setting.

You automatically change to the next character and  nally return to the menu.

The name entered is shown on the display as soon as you select the AUX source.

SCAN TIME

Setting the scan time in seconds. Settings: 4/8/12/16/60 SEC.

쏅 Press the rotary control 7 to change the

setting.

쏅 Turn the rotary control

tween the settings.

쏅 Press the rotary control

setting.

VERSION

Displaying the version of the CPU and software of the radio.

쏅 Press the rotary control 쏅 Turn the rotary control

the display of the version number of CPU (P) and software (E).

NORMSET

Restoring the original factory settings of the car sound system.

쏅 Press the rotary control

The display shows "PLEASE CONFIRM".

쏅 Press the rotary control

the resetting.

to change the

to con rm the

to change be-

to con rm the

to open the menu.

to toggle between

again to con rm

The car sound system switches o and is reset to the factory settings. If a CD has been inserted in the CD drive, the car sound system automatically switches on again.

Factory settings

Important factory settings in the user menu:

Menu item Factory setting

TUNER AREA EUROPE

FM1 / FM2 / FMT ON

MW* / LW* OFF

AM** / AMT** OFF

RDS ON

REGIONAL* OFF

TRAFFICINFO* OFF

SENSITIVITY HI

PTY OFF

ON VOLUME LAST VOLUME

TRAFFIC VOL* 20

BEEP ON

SCAN TIME 8 SEC

DIMMER MANUAL

HOUR MODE 24

CLOCK SET 00:00

* Only in reception area "EUROPE" ** Only in reception areas "USA", "SOUTH AMERICA"

and "THAILAND"

In the user menu, you can restore the original factory settings of the car sound system (see the chapter "User settings", section "Making settings in the "VARIOUS" menu", menu item "NORMSET").

Useful information | Technical data

Useful information

Warranty

We provide a manufacturer's warranty for products bought within the European Union. For devices purchased outside the European Union, the warranty terms issued by our respective responsible domestic agency are valid. The warranty terms can be called up from www.blaupunkt.com.

Service

In some countries, Blaupunkt o ers a repair and pick-up service.

Information about the availability of this service in your country can be found at www.blaupunkt.com.

If you want to take advantage of this service, you may request a pick-up service for your car sound system via the Internet.

Technical data

Voltage supply

Operating voltage: 10.5 – 14.4 V

Current consumption

In operation: < 10 A 10 sec. after switch-o : < 3.5 mA

Ampli er

Output power: 4 x 22 watts sine at

14.4 V at 4ohms.

4 x 50 watts max. power

Tuner

Wavebands in Europe/Thailand: FM: 87.5 – 108 MHz AM (MW): 531 – 1,602 kHz LW (Europe only): 153 – 279 kHz

Wavebands in South America: FM: 87.5 – 107.9 MHz AM (MW): 530 – 1,710 kHz

FM frequency response: 30 – 15,000 Hz

Frequency range: 20 – 20,000 Hz

Pre-amp out

4 channels: 2 V

Input sensitivity

Front AUX-IN: 300 mV / 10 kΩ

Dimensions and weight

W x H x D: 178 x 50 x 160 mm Weight: approx. 1.70 kg

Wavebands in the US: FM: 87.7 – 107.9 MHz AM (MW): 530 – 1,710 kHz

Subject to changes

Installation instructions

Safety instructions

When carrying out installation work and making connections please observe the following safety instructions:

• Disconnect the negative terminal of the bat-

tery! When doing so, please observe the vehicle manufacturer’s safety instructions.

• Make sure you do not damage vehicle compo-

nents when drilling any holes.

• The cross sections of the positive and negative

cables must not be less than 1.5 mm².

• Do not connect the vehicle’s plug connec-

tors to the radio!

You can obtain the adapter cable required for your vehicle type from any BLAUPUNKT dealer.

• Depending on the model, your vehicle may

di er from the description provided here. We accept no responsibility for any damages due to incorrect installation or connection or for any consequential damages.

If the information provided here is not suitable for your speci c installation requirements, please contact your Blaupunkt dealer, your vehicle manufacturer or our telephone hotline.

When installing an ampli er, you must  rst connect the device earth connections before connecting the plugs for the line-out jacks.

Earth connection of external devices may not be connected to earth of car sound system (housing).

Supplied mounting hardware

1 011 202 320 / 1 011 202 420:

1 011 202 321 / 1 011 202 421:

Installation instructions

Available as an optional accessory

7 607 621 …

Installation kits

7 608 … …

12V

0° - 30°

+/– 10°

Installation instructions

Antenna connection

Antenna

Preamp Out (4x)

Rear USB

Microphone In (Bluetooth®, Toronto 420 BT only)

182

165

Removal

1-20

12V

Installation instructions

C-1 C-2 C-3

234

345

Aut. antenna / Ampli er +12V

Remote Control +12V

10 Ampere

max. 150 mA

1 Sub Out GND 1 Speaker out RR+ 2 Radio Mute 2 Speaker out RR– 3 Sub Out 3 Speaker out RF+ 4 Permanent +12V 4 Speaker out RF– 5 Aut. antenna +12V * 5 Speaker out LF+ 6 Illumination 6 Speaker out LF– 7 Kl.15/Ignition 7 Speaker out LR+ 8 Ground 8 Speaker out LR–

C1 C2 C3

1 NC 7 Telephone AF + 13 NC 2 NC 8 Telephone AF – 14 NC 3 NC 9 Radio Mute 15 NC 4 NC 10 Remote Control +12V * 16 NC 5 NC 11 Remote Control IN 17 NC 6 NC 12 Remote Control GND 18 NC 19 NC 20 NC

Sub Out GND Sub Out

Radio Mute

4 Ohm

Installation instructions

Relais

+12V

Kl. 15 +12V

+12V

12V

Subject to changes!

Supported iPod/ iPhone devices

Our product can support below listed iPod/ iPhone generations:

• iPod touch (4th generation)

• iPod touch (3rd generation)

• iPod touch (2nd generation)

• iPod touch (1st generation)

• iPod classic

• iPod with video

• iPod nano (6th generation)

• iPod nano (5th generation)

• iPod nano (4th generation)

• iPod nano (3rd generation)

• iPod nano (2nd generation)

• iPod nano (1st generation)

• iPod

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

"Made for iPod" and "Made for iPhone" mean that an electronic accessory has been designed to connect speci cally to iPod, iPhone respectively, and has been certi ed by the developer to meet Apple performance standards.

Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

Please note that the use of this accessory with iPod, iPhone may a ect wireless performance. iPhone, iPod are trademarks of Apple Inc., registered in the U.S. and other countries.

This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft.

personal use only.

Please keep the  lled-in radio pass in a safe place!

01/12

Passport

Name: ......................................................................................................................

Type: ......................................................................................................................

Serial no.: BP ...............................................................................................................

1 011 202 _ _ _

Blaupunkt AudioVision GmbH & Co. KG

Robert-Bosch-Straße 200

D-31139 Hildesheim

http://www.blaupunkt.com

Blaupunkt 420 BT, 320 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
