JET AXIAL FAN

Axis-Jet

EN

USER’S MANUAL

www.blaubergventilatoren.de

CONTENTS

Safety requirements .....................................................................................................................................................................2

Purpose ................................................................................................................................................................................................ 4

Delivery set ........................................................................................................................................................................................ 4

Designation key .............................................................................................................................................................................. 4

Technical data .................................................................................................................................................................................. 5

Design and operating principle ........................................................................................................................................... 10

Mounting and set-up .................................................................................................................................................................. 11

Connection to power mains .................................................................................................................................................. 12

Commissioning ............................................................................................................................................................................... 14

Technical maintenance .............................................................................................................................................................. 15

Troubleshooting ............................................................................................................................................................................. 16

Storage and transportation regulations .......................................................................................................................... 17

Manufacturer’s warranty ........................................................................................................................................................... 18

Certificate of acceptance .......................................................................................................................................................... 19

Seller information .......................................................................................................................................................................... 19

Installation certificate .................................................................................................................................................................. 19

Warranty card ...................................................................................................................................................................................19

Axis-Jet

This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the Axis-Jet unit and
all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
The information in this user’s manual is correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to
incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any information
search system or translated into any language in any form without the prior written permission of the Company.

SAFETY REQUIREMENTS

• Please read the user’s manual carefully prior to installing and operating the unit.

• All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical
norms and standards must be observed when installing and operating the unit.

• The warnings contained in the user’s manual must be considered most seriously since they contain vital personal safety information.

• Failure to follow the rules and safety precautions noted in this user’s manual may result in an injury or unit damage.

• After a careful reading of the manual, keep it for the entire service life of the unit.

• While transferring the unit control, the user’s manual must be turned over to the receiving operator.

UNIT INSTALLATION AND OPERATION SAFETY PRECAUTIONS

• Disconnect the unit from power mains prior
to any installation operations.

• The unit must be grounded!

• Unpack the unit with care.

• While installing the unit, follow the safety
regulations specific to the use of electric
tools.

2

Axis-Jet

• Do not change the power cable length at
your own discretion.

• Do not bend the power cable.

• Avoid damaging the power cable.

• Do not put any foreign objects on the power
cable.

• Do not use damaged equipment or cables
when connecting the unit to power mains.

www.blaubergventilatoren.de

• Do not lay the power cable of the unit in
close proximity to heating equipment.

• Do not operate the unit outside the
temperature range stated in the user’s
manual.

• Do not operate the unit in aggressive or
explosive environments.

• Do not touch the unit controls with wet
hands.

• Do not carry out the installation and
maintenance operations with wet hands.

• Do not allow children to operate the unit.

• Do not store any explosive or highly
flammable substances in close proximity to
the unit.

• Do not open the unit during operation.

• Do not block the air duct when the unit is
switched on.

• Do not wash the unit with water.

• Protect the electric parts of the unit against
ingress of water.

• Disconnect the unit from power mains prior
to any technical maintenance.

• When the unit generates unusual sounds,
odour, or emits smoke, disconnect it from
power supply and contact the Seller.

• Do not direct the air flow produced by the
unit towards open flame or ignition sources.

• In case of continuous operation of the unit,
periodically check the security of mounting.

• Do not sit on the unit and avoid placing
foreign objects on it.

THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.

DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.

• Use the unit only for its intended purpose.

3

www.blaubergventilatoren.de

Axis-Jet

PURPOSE

THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED

PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT

THE APPROPRIATE TRAINING.

THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED

PERSONNEL AFTER THE APPROPRIATE BRIEFING.

THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORIZED

ACCESS BY UNATTENDED CHILDREN.

Jet axial fans are designed for general purpose ventilation of underground and semiopened car parks, ventilation of tunnels, smoke
extraction in case of fire as a part of smoke extraction system. The fans generate a high-speed and high-pressure directed air jet. The
unit is rated for continuous operation. Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals,
sticky substances, fibrous materials, coarse dust, oil particles or environments favourable for the formation of hazardous substances (toxic
substances, dust, pathogenic germs). Relative humidity of transported air must not exceed +20 °C at an ambient humidity of 80 %.

DELIVERY SET

NAME NUMBER

Fan
User’s manual
Packing box

1 pc.
1 pc.
1 pc.

DESIGNATION KEY

Designation example: Axis-Jet -K I -315 M-2/4 -R- U-200/2

Casing insulation

_: without sound-insulation

I: sound-insulated casing

Diameter [mm]

315; 355; 400; 450; 500; 560; 630

_: standard motor

M, S: model with a high-power motor

2 (for single-speed motors)

2/4 (for double-speed motors)

U: unidirectional

Climatic category

U: moderate climate (-40…+40 °C)

HL: cold climate (-60…+40 °C)

UHL: moderate and cold climate (-60…+40 °C)

T: tropical climate (-10…+50 °C)

M: maritime moderately cold climate (-40…+40 °C)

O: general climatic modification (except maritime climate) (-60…+50 °C)

OM: general maritime climatic modification (-40…+40 °C)

V: universal climatic modification (-60…+50 °C)

Fire resistance limit/hrs

200/2: 200 °C/2 hrs
300/2: 300 °C/2 hrs
400/2: 400 °C/2 hrs

Model

Jet axial fan

Casing type

K: round

Motor

Pole number

Air ow

R: reversible

_: max. +55 °C

4

Axis-Jet

www.blaubergventilatoren.de

TECHNICAL DATA

The unit is rated as a Class I electrical appliance.
Ingress protection rating against access to hazardous parts and water ingress is IP55 for the motor and IP54 for the unit.
The fan design is constantly being improved, thus some models may be slightly different from those described in this manual.

UNIDIRECTIONAL FAN REVERSIBLE FAN

ØD1

Model

Unidirectional

Axis-Jet-KI-KI-315-U 414 302 355 425 1654 1763

Axis-Jet-KI-KI-355-U 467 302 420 482 1954 2079

Axis-Jet-KI-KI-400-U 515 351 460 525 2004 2129

Axis-Jet-KI-KI-450-U 565 351 500 575 2004 2129

Axis-Jet-KI-KI-500-U 603 371 580 620 2004 2145

Axis-Jet-KI-KI-560-U 663 446 620 678 2093 2247

Axis-Jet-KI-KI-630-U 733 550 710 748 2193 2357

Reversible

Axis-Jet-KI-KI-315-R 414 302 355 425 1654 1872

Axis-Jet-KI-KI-355-R 467 302 420 482 1954 2202

Axis-Jet-KI-KI-400-R 515 351 460 525 2004 2253

Axis-Jet-KI-KI-450-R 565 351 500 575 2004 2253

Axis-Jet-KI-KI-500-R 603 371 580 620 2004 2290

Axis-Jet-KI-KI-560-R 663 446 620 678 2093 2400

Axis-Jet-KI-KI-630-R 733 550 710 748 2193 2520

Ø D1 A B H L1 L2

Dimensions [mm]

ØD1

5

www.blaubergventilatoren.de

Axis-Jet

Ø, mmAir ow

direction

Unidirectional

315

Reversible

Number

of

speeds

Axis-Jet-KI-315-2-U-...

Axis-Jet-KI-315-2-U-...-200/2

Axis-Jet-KI-315-2-U-...-300/2

Axis-Jet-KI-315-2-U-...-400/2

1

Axis-Jet-KI-315M-2-U-...

Axis-Jet-KI-315M-2-U-...-200/2

Axis-Jet-KI-315M-2-U-...-300/2

Axis-Jet-KI-315M-2-U-...-400/2

Axis-Jet-KI-315-2/4-U-...

Axis-Jet-KI-315-2/4-U-...-200/2

Axis-Jet-KI-315-2/4-U-...-300/2

Axis-Jet-KI-315-2/4-U-...-400/2

2

Axis-Jet-KI-315M-2/4-U-...

Axis-Jet-KI-315M-2/4-U-...-200/2

Axis-Jet-KI-315M-2/4-U-...-300/2

Axis-Jet-KI-315M-2/4-U-...-400/2

Axis-Jet-KI-315-2-R-...

Axis-Jet-KI-315-2-R-...-200/2

1

Axis-Jet-KI-315-2-R-...-300/2

Axis-Jet-KI-315-2-R-...-400/2

Axis-Jet-KI-315-2/4-R-...

Axis-Jet-KI-315-2/4-R-...-200/2

2

Axis-Jet-KI-315-2/4-R-...-300/2

Axis-Jet-KI-315-2/4-R-...-400/2

Model

Voltage

[V]

Frequency

[Hz]

Power

[kW]

Max.

air ow

[m/h]

Thrust

(Impulse)

[N]

Air speed

[m/s]

RPM

[min

3~400 50 0.55 4000 22 14.3 2880

3~400 50 0.75 4800 30 17.2 2880

3~400 50 0.55/0.11

3~400 50 0.8/0.2

4000/

2000

4800/

2400

22/5.6

30/7.6

14.3/

7.1

17.2/

8.6

2880/

1440

2880/

1440

3~400 50 0.55 4000 22 14.3 2880

3~400 50 0.55/0.11

4000/

2000

22/5.5

14.3/

7.1

2880/

1440

*Smoke extraction mode: once for two hours

Operating

temperature

-1

]

[°C]*

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

Fire

resistance

355

Unidirectional

Reversible

Axis-Jet-KI-355-2-U-...

Axis-Jet-KI-355-2-U-...-200/2

Axis-Jet-KI-355-2-U-...-300/2

Axis-Jet-KI-355-2-U-...-400/2

1

Axis-Jet-KI-355M-2-U-...

Axis-Jet-KI-355M-2-U-...-200/2

Axis-Jet-KI-355M-2-U-...-300/2

Axis-Jet-KI-355M-2-U-...-400/2

Axis-Jet-KI-355-2/4-U-...

Axis-Jet-KI-355-2/4-U-...-200/2

Axis-Jet-KI-355-2/4-U-...-300/2

Axis-Jet-KI-355-2/4-U-...-400/2

2

Axis-Jet-KI-355M-2/4-U-...

Axis-Jet-KI-355M-2/4-U-...-200/2

Axis-Jet-KI-355M-2/4-U-...-300/2

Axis-Jet-KI-355M-2/4-U-...-400/2

Axis-Jet-KI-355-2-R-...

Axis-Jet-KI-355-2-R-...-200/2

1

Axis-Jet-KI-355-2-R-...-300/2

Axis-Jet-KI-355-2-R-...-400/2

Axis-Jet-KI-355-2/4-R-...

Axis-Jet-KI-355-2/4-R-...-200/2

2

Axis-Jet-KI-355-2/4-R-...-300/2

Axis-Jet-KI-355-2/4-R-...-400/2

3~400 50 0.75 5900 36 16.6 2880

3~400 50 1.1 6900 48 19.4 2880

3~400 50 0.8/0.2

3~400 50 1.1/0.25

5900/

2900

6900/

3400

36/9

48/12

16.6/

8.2

19.5/

9.6

2880/

1440

2880/

1440

3~400 50 1.1 5900 35 16.6 2880

3~400 50 1.1/0.25

5900/

2900

35/9

16.6/

8.2

2880/

1440

*Smoke extraction mode: once for two hours

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

6

Axis-Jet

www.blaubergventilatoren.de

Ø, mmAir ow

direction

Unidirectional

400

Reversible

Number

of

speeds

Axis-Jet-KI-400-2-U-...

Axis-Jet-KI-400-2-U-...-200/2

Axis-Jet-KI-400-2-U-...-300/2

Axis-Jet-KI-400-2-U-...-400/2

1

Axis-Jet-KI-400M-2-U-...

Axis-Jet-KI-400M-2-U-...-200/2

Axis-Jet-KI-400M-2-U-...-300/2

Axis-Jet-KI-400M-2-U-...-400/2

Axis-Jet-KI-400-2/4-U-...

Axis-Jet-KI-400-2/4-U-...-200/2

Axis-Jet-KI-400-2/4-U-...-300/2

Axis-Jet-KI-400-2/4-U-...-400/2

2

Axis-Jet-KI-400M-2/4-U-...

Axis-Jet-KI-400M-2/4-U-...-200/2

Axis-Jet-KI-400M-2/4-U-...-300/2

Axis-Jet-KI-400M-2/4-U-...-400/2

Axis-Jet-KI-400-2-R-...

Axis-Jet-KI-400-2-R-...-200/2

1

Axis-Jet-KI-400-2-R-...-300/2

Axis-Jet-KI-400-2-R-...-400/2

Axis-Jet-KI-400-2/4-R-...

Axis-Jet-KI-400-2/4-R-...-200/2

2

Axis-Jet-KI-400-2/4-R-...-300/2

Axis-Jet-KI-400-2/4-R-...-400/2

Model

Voltage

[V]

Frequency

[Hz]

Power

[kW]

Max.

air ow

[m/h]

Thrust

(Impulse)

[N]

Air speed

[m/s]

RPM

[min

3~400 50 1.1 8500 57 18.8 2880

3~400 50 2.2 9900 77 21.9 2880

3~400 50 1.1/0.25

3~400 50 2.2/0.5

8500/

4200

57/14

9900/

4900 77/19

18.8/

9.3

21.9/

10.9

2880/

1440

2880/

1440

3~400 50 1.5 8400 55 18.6 2880

3~400 50 1.5/0.37

8400/

4200

55/13.9

18.6/

9.3

2880/

1440

*Smoke extraction mode: once for two hours

Operating

temperature

-1

]

[°C]*

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

Fire

resistance

7

www.blaubergventilatoren.de

Axis-Jet

Ø, mmAir ow

direction

Unidirectional

450

Reversible

Number

of

speeds

Axis-Jet-KI-450-2-U-...

Axis-Jet-KI-450-2-U-...-200/2

Axis-Jet-KI-450-2-U-...-300/2

Axis-Jet-KI-450-2-U-...-400/2

Axis-Jet-KI-450M-2-U-...

Axis-Jet-KI-450M-2-U-...-200/2

1

Axis-Jet-KI-450M-2-U-...-300/2

Axis-Jet-KI-450M-2-U-...-400/2

Axis-Jet-KI-450S-2-U-...

Axis-Jet-KI-450S-2-U-...-200/2

Axis-Jet-KI-450S-2-U-...-300/2

Axis-Jet-KI-450S-2-U-...-400/2

Axis-Jet-KI-450-2/4-U-...

Axis-Jet-KI-450-2/4-U-...-200/2

Axis-Jet-KI-450-2/4-U-...-300/2

Axis-Jet-KI-450-2/4-U-...-400/2

Axis-Jet-KI-450M-2/4-U-...

Axis-Jet-KI-450M-2/4-U-...-200/2

2

Axis-Jet-KI-450M-2/4-U-...-300/2

Axis-Jet-KI-450M-2/4-U-...-400/2

Axis-Jet-KI-450S-2/4-U-...

Axis-Jet-KI-450S-2/4-U-...-200/2

Axis-Jet-KI-450S-2/4-U-...-300/2

Axis-Jet-KI-450S-2/4-U-...-400/2

Axis-Jet-KI-450-2-R-...

Axis-Jet-KI-450-2-R-...-200/2

Axis-Jet-KI-450-2-R-...-300/2

Axis-Jet-KI-450-2-R-...-400/2

Axis-Jet-KI-450M-2-R-...

Axis-Jet-KI-450M-2-R-...-200/2

1

Axis-Jet-KI-450M-2-R-...-300/2

Axis-Jet-KI-450M-2-R-...-400/2

Axis-Jet-KI-450S-2-R-...

Axis-Jet-KI-450S-2-R-...-200/2

Axis-Jet-KI-450S-2-R-...-300/2

Axis-Jet-KI-450S-2-R-...-400/2

Axis-Jet-KI-450-2/4-R-...

Axis-Jet-KI-450-2/4-R-...-200/2

Axis-Jet-KI-450-2/4-R-...-300/2

Axis-Jet-KI-450-2/4-R-...-400/2

Axis-Jet-KI-450M-2/4-R-...

Axis-Jet-KI-450M-2/4-R-...-200/2

2

Axis-Jet-KI-450M-2/4-R-...-300/2

Axis-Jet-KI-450M-2/4-R-...-400/2

Axis-Jet-KI-450S-2/4-R-...

Axis-Jet-KI-450S-2/4-R-...-200/2

Axis-Jet-KI-450S-2/4-R-...-300/2

Axis-Jet-KI-450S-2/4-R-...-400/2

Model

Voltage

[V]

Frequency

[Hz]

Power

[kW]

Max.

air ow

[m/h]

Thrust

(Impulse)

[N]

Air speed

[m/s]

RPM

[min

3~400 50 1.5 10700 71 18.7 2880

3~400 50 2.2 11900 88 20.8 2880

3~400 50 3 12800 106 22.4 2880

3~400 50 1.5/0.37

3~400 50 2.2/0.5

3~400 50 2.5/0.65

10700/

5300

11900/

5900

12800/

6400

71/18

88/22

106/26

18.7/

9.3

20.8/

10.3

22.4/

11.2

2880/

1440

2880/

1440

2880/

1440

3~400 50 1.5 10100 63 17.6 2880

3~400 50 2.2 11500 82 20 2880

3~400 50 3 12200 96 21.3 2880

3~400 50 1.5/0.37

3~400 50 2.2/0.5

3~400 50 2.5/0.65

10100/

5000

11500/

5700

12200/

6000

63/16

82/20

96/24

17.6/

8.8

20/

10

21.3/

10.4

2880/

1440

2880/

1440

2880/

1440

*Smoke extraction mode: once for two hours

Operating

temperature

-1

]

[°C]*

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

Fire

resistance

8

Axis-Jet

www.blaubergventilatoren.de

Ø, mmAir ow

direction

Unidirectional 2

500

Reversible 2

Unidirectional 2

560

Reversible 2

Number

of

speeds

Axis-Jet-KI-500-2/4-U-...

Axis-Jet-KI-500-2/4-U-...-200/2

Axis-Jet-KI-500-2/4-U-...-300/2

Axis-Jet-KI-500-2/4-U-...-400/2

Axis-Jet-KI-500M-2/4-U-...

Axis-Jet-KI-500M-2/4-U-...-200/2

Axis-Jet-KI-500M-2/4-U-...-300/2

Axis-Jet-KI-500M-2/4-U-...-400/2

Axis-Jet-KI-500-2/4-R-...

Axis-Jet-KI-500-2/4-R-...-200/2

Axis-Jet-KI-500-2/4-R-...-300/2

Axis-Jet-KI-500-2/4-R-...-400/2

Axis-Jet-KI-500M-2/4-R-...

Axis-Jet-KI-500M-2/4-R-...-200/2

Axis-Jet-KI-500M-2/4-R-...-300/2

Axis-Jet-KI-500M-2/4-R-...-400/2

Axis-Jet-KI-560-2/4-U-...

Axis-Jet-KI-560-2/4-U-...-200/2

Axis-Jet-KI-560-2/4-U-...-300/2

Axis-Jet-KI-560-2/4-U-...-400/2

Axis-Jet-KI-560M-2/4-U-...

Axis-Jet-KI-560M-2/4-U-...-200/2

Axis-Jet-KI-560M-2/4-U-...-300/2

Axis-Jet-KI-560M-2/4-U-...-400/2

Axis-Jet-KI-560-2/4-R-...

Axis-Jet-KI-560-2/4-R-...-200/2

Axis-Jet-KI-560-2/4-R-...-300/2

Axis-Jet-KI-560-2/4-R-...-400/2

Axis-Jet-KI-560M-2/4-R-...

Axis-Jet-KI-560M-2/4-R-...-200/2

Axis-Jet-KI-560M-2/4-R-...-300/2

Axis-Jet-KI-560M-2/4-R-...-400/2

Model

Voltage

[V]

Frequency

[Hz]

Power

[kW]

3~400 50 3.1/0.8

3~400 50 4.4/1.1

3~400 50 2.5/0.65

3~400 50 4.4/1.1

3~400 50 4.4/1.1

3~400 50 8/2

3~400 50 4.4/1.1

3~400 50 6/1.5

Max.

air ow

[m/h]

16600/

8200

18800/

9400

14100/

7000

16000/

8000

21400/

10600

24500/

12200

18200/

9000

21000/

10500

Thrust

(Impulse)

[N]

143/36

183/45

103/25

132/33

185/46

245/61

134/33

177/44

Air speed

[m/s]

RPM

[min

-1

]

Operating

temperature

[°C]*

-25...+55 °C 55 °C

23.6/

11.6

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

26.7/

13.3

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

20/

10

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

22.7/

11.3

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

*Smoke extraction mode: once for two hours

-25...+55 °C 55 °C

24.2/
12

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

27.6/

13.8

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

20.5/

10.2

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

23.7/

11.9

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

*Smoke extraction mode: once for two hours

Fire

resistance

Unidirectional 2

630

Reversible 2

Axis-Jet-KI-630-2/4-U-...

Axis-Jet-KI-630-2/4-U-...-200/2

Axis-Jet-KI-630-2/4-U-...-300/2

Axis-Jet-KI-630-2/4-U-...-400/2

Axis-Jet-KI-630M-2/4-U-...

Axis-Jet-KI-630M-2/4-U-...-200/2

Axis-Jet-KI-630M-2/4-U-...-300/2

Axis-Jet-KI-630M-2/4-U-...-400/2

Axis-Jet-KI-630-2/4-R-...

Axis-Jet-KI-630-2/4-R-...-200/2

Axis-Jet-KI-630-2/4-R-...-300/2

Axis-Jet-KI-630-2/4-R-...-400/2

Axis-Jet-KI-630M-2/4-R-...

Axis-Jet-KI-630M-2/4-R-...-200/2

Axis-Jet-KI-630M-2/4-R-...-300/2

Axis-Jet-KI-630M-2/4-R-...-400/2

3~400 50 12/3

3~400 50 16/4

3~400 50 12/3

3~400 50 16/4

30000/

15000

35500/

17700

30000/

15000

33000/

16000

298/74

414/103

300/75

358/89

-25...+55 °C 55 °C

26.8/

13.4

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

31.6/

15.8

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

26.8/

13.4

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

-25...+55 °C 55 °C

29.5/

14.3

2880/

1440

200 °C/2 h F200

300 °C/2 h F300

400 °C/2 h F400

*Smoke extraction mode: once for two hours

9

www.blaubergventilatoren.de

Axis-Jet

DESIGN AND OPERATING PRINCIPLE

Louvre shutters

Silencer 2

Mounting brackets

Casing

Nozzle

Terminal box

Silencer 1

Protective grille

Casing

The fans are supplied in an all-welded metal casing with rolled flanges. All the casing components are powder coated for improved
protection against the environmental effects. The casing has special brackets for mounting the motor which also double as guides and
ensure even distribution of air across the impeller blades thereby improving the aerodynamic performance. The fans also have external
mounting brackets for ceiling or wall mounting. A terminal box is mated to the casing for quick and convenient electrical connections.

Protective grille

The grille prevents penetration of objects which may damage the impeller or the fan casing.

Silencers

Sound insulation is achieved by means of cylindrical silencers installed on both sides. The casing of the silencers is completely lined with
wear-resistant mineral wool and perforated sheet. The silencer 1 at the inlet is equipped with an aerodynamically optimized inlet nozzle,
and the silencer 2 at the outlet is equipped with louvre shutters.

Motor

The fans are driven by three-phase asynchronous electric motors with a square-cage rotor. The motor is installed inside the fan casing.
The impeller of the motor is equipped with an axial high-efficient and dynamically balanced impeller with blades of optimized shape
made of corrosion-resistant aluminium alloy.

Airow direction for unidirectional fans

Sound-insulating material

Electric motor with

an impeller

10

Axis-Jet

www.blaubergventilatoren.de

MOUNTING AND SETUP

BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN

OBJECTS E.G. FOIL, PAPER.

WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT

MAINTENANCE AND REPAIR.

Wall or ceiling mounting with fixing brackets. Installation is carried out at 4 points using dowels or mounting studs. The specially designed
anti-vibration mounts (specially ordered accessories) are recommended for vibration absorption.
While choosing fasteners consider the material of the mounting surface as well as the weigh of the fan, refer to the “Technical data” section.
Fasteners for fan mounting are not included in the delivery set and should be ordered separately. Fasteners for unit mounting should be
selected by the service technician.

11

www.blaubergventilatoren.de

Axis-Jet

CONNECTION TO POWER MAINS

DISCONNECT THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT.

CONNECTION OF THE UNIT TO POWER MAINS IS ALLOWED BY A QUALIFIED

ELECTRICIAN WITH A WORK PERMIT FOR THE ELECTRIC UNITS UP TO 1000 V AFTER

CAREFUL READING OF THE PRESENT USER’S MANUAL. THE RATED ELECTRICAL

PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.

ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED

AND WILL VOID THE WARRANTY.

• The unit is rated for connection to 3~400 V/50 Hz according to the wiring diagram. The connection must be made using insulated
conductors (cables, wires). The actual wire cross section selection must be based on the maximum load current, maximum conductor
temperature depending on the wire type, insulation, length and installation method.

• The unit must be connected to power supply in accordance with the applicable standards.

The axial impulse fan is designed for integration into an automatic control system and is not intended for standalone operation.
Connect the fan motor via the terminal block (X1) by means of a durable heat-resistant insulated cable according to the wiring diagram
and the terminal designations.
The terminal block and the terminal designation label are inside the terminal box. The terminal box is installed on the fan casing or on a
mounting bracket depending on the particular model.

Single-speed fan wiring diagram Two-speed fan wiring diagram:

- running at low speed

X1

PE

1

U1

2

V1

3

W1

4

U2

V2

5

W2

6

L1

L2

L3

PE

3~400 V/50 Hz

L1

L2

L3

PE

X1

L1

L2

1

2

3

4

L3

3~400 V/50 Hz

PE

- running at high speed

X1

PE

1

U1

2

V1

3

W1

4

U2

V2

5

W2

6

L1

L2

L3

3~400 V/50 Hz

PE

X1

PE

1

U1

2

V1

3

W1

4

U2

V2

5

W2

6

L1

L2

L3

3~400 V/50 Hz

PE

12

Axis-Jet

MAKE SURE THAT THE FAN IMPELLER ROTATES IN THE DIRECTION MARKED BY THE

ARROW ON THE FAN CASING.

IF NECESSARY, CHANGE THE IMPELLER ROTATION DIRECTION BY ALTERING THE PHASE

SEQUENCE ON THE ELECTRIC MOTOR TERMINALS.

ASYNCHRONOUS ELECTRIC MOTOR STARTING METHODS

There are several methods for starting asynchronous squirrel-cage electric motors.
The most common methods are: direct-on-line (DOL), with a soft starter (SS) or with a frequency converter (FC).

Direct-on-line starting

In case of direct-on-line starting (i.e. by connecting the motor to the electric mains with a simple line contactor), the motor starting
time significantly increases due to high inertia of the impeller, which, in turn, results in high in-rush starting currents in the circuit. These
currents of long duration may cause voltage slumps (especially if the feed line section falls short of the requirements), which may affect
load operation.
The in-rush current consumed by an electric motor in case of DOL starting is 5-8 times larger than the rated value (or even 10-14 times
larger in some rare instances). It should be noted that the torque developed by the motor also significantly exceeds the rated value.
Upon energisation the motor operates as a transformer with a squirrel-cage secondary winding formed by the rotor cage with a very low
resistance.
The rotor develops high induced current causing a rush of current in the feed line.
The startup torque during starting averages 0.5-1.5 of the rated torque value.

www.blaubergventilatoren.de

Despite such advantages as simple construction, high startup current, quick start and low cost, direct-on-line systems are suitable only
in the following cases:

• the motor power is low compared to the mains power which limits the adverse effect of the rush of current

• the driven mechanism does not require gradual speed build-up or is equipped with a damping device to smooth out the inrush

• the high startup torque has no adverse effects on the operation of the driven mechanism

Soft start. SC starting.

A soft starter gradually increases the voltage supplied to the motor – from the initial to the rated value.
This starting system can be used to meet the following goals:

• limit the motor current

• regulate the torque

Regulation by limiting the current sets the maximum in-rush current equal to 300-400 % (or 250 % in some rare instances) of the rated
current and reduces torque characteristics. This type of regulation is especially suited for turbomachinery such as centrifugal pumps and
fans.
Regulation by variation of torque optimises the torque during startup and reduces in-rush current in the circuit. These conditions are
suitable for mechanisms with constant load resistance.
This type of soft starting may differ in the implementation pattern:

• motor start

• motor start and stop

• device bridging at the end of start sequence

• start and stop of several motors in stage circuits

Soft start. FC starting.

During the starting the FC raises the frequency from 0 Hz to the electrical mains frequency (50 or 60 Hz). As the frequency is increased
gradually, the motor can be assumed to operate at its rated speed for a given frequency value. Furthermore, on the assumption that the
motor runs at its rated speed the nominal torque should be immediately available whereas the current will be approximately equal to
the rated value.
This starting system is used for speed control and regulation and can be used in the following cases:

• start with high-inertia load

• start with high load and limited-capacity power supply source

• optimisation of electric power consumption depending on turbomachinery speed

The aforementioned starting system can be used for all types of mechanisms.

13

www.blaubergventilatoren.de

Problems associated with DOL starting

The problems caused by DOL starting may be divided into two groups:

1. An abrupt start causes mechanical shock, jolts in the mechanism, shock removal of free play etc.

2. A heavy start cannot be completed.

Let us review three variations of a heavy start:

1. The feed line performance is barely sufficient or insufficient to maintain the induced current.

Typical symptoms: Upon starting the circuit breakers at the system input are tripped; the lights, certain relays and contactors go off,
and the supply generator shuts down.
Solution: In the best-case scenario an SS device may help reduce the in-rush current to 250 % of the motor rated current. If this is
insufficient, an FC is necessary.

2. The motor cannot start the mechanism with DOL starting.

Typical symptoms: The motor fails to turn or “freezes” at certain speed which is maintained until actuation of the protection suite.
Solution: This problem may not be solved with an SS device. The motor develops insufficient shaft torque. However, this problem can

be addressed by using an FC, but each case may be different.

3. The motor spins up the mechanism with authority, but fails to reach the rated rotation speed.

Typical symptoms: The input automatic circuit breaker is tripped during spin-up. This often happens with heavy-weight fans with a
considerable rotation speed.
Solution: Such problems may be addressed with an SS device, but not with 100 % certainty. The closer the motor speed to the rated
value during the actuation of the protective equipment, the higher the chances of success. The use of an FC in this case helps solve the
problem fundamentally.

Axis-Jet

Standard switching equipment (automatic circuit breakers, contactors and motor starters) is not designed to withstand
prolonged overloads normally causing the fan to shut down automatically DOL starting that continues for a long period of
time.
Using switching equipment with a higher maximum current rating renders the electric motor protection system less sensitive.
As a result the switching equipment will not be able to detect motor overload in time due to a high current sensing threshold.
Such problems as mentioned above can only be addressed by utilizing a soft starter or a frequency converter to start the fan.

COMMISSIONING

THE ORGANISATION RESPONSIBLE FOR THE COMMISSIONING SHALL BE RESPONSIBLE

FOR PROPER MOTOR PHASING AND STARTING PATTERN SELECTION.

DURING STARTING THE INRUSH CURRENTS OF THE FAN MAY SEVERAL TIMES EXCEED

THE RATED VALUES.

SEE “ASYNCHRONOUS ELECTRIC MOTOR STARTING METHODS” IN THE “CONNECTION

TO POWER MAINS” SECTION

• After fan starting make sure that the motor rotates properly without undue vibration and abnormal noise.

• Make sure that the fan impeller rotates in the direction marked by the arrow on the fan casing. If necessary, change the impeller
rotation direction by changing the phase sequence on the electric motor terminals.

• Make sure that the fan energy consumption complies with the value given on the equipment nameplate and check the motor for
overheating.

• The phase current should be checked once the fan reaches the rated operating conditions.

• Do not switch the fan on and off several times without pauses as this may result in damage to the winding or insulation due to
overheating.

14

Axis-Jet

www.blaubergventilatoren.de

TECHNICAL MAINTENANCE

DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE

ANY MAINTENANCE OPERATIONS!

PRIOR TO COMMENCING ANY TECHNICAL MAINTENANCE PUT UP A PROHIBITORY

SIGN ON THE FAN STARTING PANEL:

“DO NOT SWITCH ON! MEN AT WORK!”

AVOID LIQUID SPILLS ON THE MOTOR! DO NOT USE AGGRESSIVE SOLVENTS AND

SHARP OBJECTS FOR CLEANING!

The technical maintenance of the fan includes periodic cleaning of the surfaces from dust and dirt and replacement of fan or motor parts.
The fan surfaces should be cleaned periodically as they get dirty.
To clean the motor impeller as well as the internal metal parts of the fan, use a soft dry brush with a long handle and some cloth. For easy
access to the motor impeller, disconnect the louvre shutters.

While carrying out motor repair or replacement make sure to provide sufficient access to the motor location:

• undo three bolts on each of the two mounting brackets and remove the casing with the silencers

• disconnect the casing from the silencer 1 by unscrewing the clamping bolts

• remove the terminal box cover and disconnect the electric motor cable from the terminal block

• undo the screws on the casing which secure the motor mounts

• carefully remove the motor on the mounts from the casing

• on completing the technical maintenance re-install the fan into the casing in the reverse order

Silencer 1

Silencer 2

Casing

15

www.blaubergventilatoren.de

While performing technical maintenance:

• Check the grounding screw terminals and electric connectors for proper tightness and tighten them up if necessary.

• Check the casing fastening screws for tightness and tighten them up if necessary.

• Check the bolt connecting the motor shaft to the hub for proper tightness and tighten it up if necessary.

• Check the fan impeller for clogging and clean when necessary. To clean the impeller, remove the side cover.

Technical maintenance must be carried out at least once a year.

TROUBLESHOOTING

POSSIBLE REASONS AND TROUBLESHOOTING

Problem Possible reasons Troubleshooting

The fan does not start. No power supply. Check the automatic circuit breaker. Check the

electric connections.

Axis-Jet

The automatic breaker
activates upon fan start-up.

Jammed motor. Carefully check the fan impeller for possible seizure

and eliminate it, if necessary. If the impeller is in order,
replace the electric motor.

Short circuit in the fan or the electric
circuit between the fan and the automatic
circuit breaker.

Excessive current consumption due to an
overload in the electric mains triggers the
thermal release of the automatic circuit
breaker.

Improper fan starting method. Use a soft starter or frequency converter to start the

Improper switching equipment. Re-select the switching equipment in accordance

The installed switching equipment is of
poor quality or its actual performance falls
short of the rated values stated by the
manufacturer.

Eliminate the cause of a short circuit.

Eliminate the cause of excessive current consumption.

motor (see "Asynchronous Electric Motor Starting

Methods" in the "Connection to power mains"
section).

with the current regulations and equipment
specifications.

Re-select the switching equipment by choosing a
unit which successfully passed commutation and
load tests and has a technical compliance certificate.
The selection should be limited to the top five foreign
switching equipment manufacturers.

The fan fails to reach the
required rotation speed due
to serious overheating of the
fan motor.

The fan motor runs at
overload capacity with
current consumption in
excess of the rated value.

The fan supplies more air
than expected.

16

Fan motor overloaded. Eliminate the overloa.

Improper fan starting method. Use a soft starter or frequency converter to start the

motor (see "Asynchronous Electric Motor Starting

Methods" in the "Connection to power mains"
section).

Wrong motor phasing. The impeller
rotates in the opposite direction of the
arrow on the fan casing.

Wrong choice of the fan. Replace the fan with a unit of proper standard size.

If necessary, change the impeller rotation direction by
changing the phase sequence on the electric motor
terminals.

Axis-Jet

www.blaubergventilatoren.de

The fan supplies less air than
expected.

Increased noise, vibration in
the fan.

Wrong choice of the fan. Re-calculate the parameters and select the right fan.

Wrong direction of the impeller rotation
direction.

Impeller contamination with foreign
objects or debris.

Loose screw connections. Check the screw connections for proper tightness.

No vibration mounts on the fan. Install the anti-vibration mounts.

Impeller contamination with foreign
objects or debris.

Worn bearings. Replace the bearings.

Unstable power supply, unstable motor
operation.

If necessary, change the impeller rotation direction by
changing the phase sequence on the electric motor
terminals (see the "Commissioning" section).

Clean the impeller from foreign objects or debris.

Clean the impeller from foreign objects or debris.

Check the stability of power supply parameters and
electric motor operation.

STORAGE AND TRANSPORTATION REGULATIONS

• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range +5 .. +40 ˚C
and relative humidity up to 70 %.

• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing
deformation.

• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.

• Follow the handling requirements applicable for the particular type of cargo.

• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation and
mechanical damage. The unit must be transported only in the working position.

• Avoid sharp blows, scratches, or rough handling during loading and unloading.

• Prior to the initial power-up after transportation at low temperatures, allow the unit to warm up at operating temperature for at least
3-4 hours.

17

www.blaubergventilatoren.de

Axis-Jet

MANUFACTURER’S WARRANTY

The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby
declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European
Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking
Council Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 24 months after the retail sale date provided the user's observance
of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the course of the unit operation
through the Manufacturer's fault during the guaranteed period of operation, the user is entitled to get all the faults eliminated by the
manufacturer by means of warranty repair at the factory free of charge. The warranty repair includes work specific to elimination of faults
in the unit operation to ensure its intended use by the user within the guaranteed period of operation. The faults are eliminated by means
of replacement or repair of the unit components or a specific part of such unit component.

The warranty repair does not include:

• routine technical maintenance

• unit installation/dismantling

• unit setup

To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the payment
paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact the Seller for warranty
service.

The manufacturer’s warranty does not apply to the following cases:

• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission with missing
component parts previously dismounted by the user.

• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's manual.

• User’s failure to ensure timely technical maintenance of the unit.

• External damage to the unit casing (excluding external modifications as required for installation) and internal components caused
by the user.

• Redesign or engineering changes to the unit.

• Replacement and use of any assemblies, parts and components not approved by the manufacturer.

• Unit misuse.

• Violation of the unit installation regulations by the user.

• Violation of the unit control regulations by the user.

• Unit connection to power mains with a voltage different from the one stated in the user's manual.

• Unit breakdown due to voltage surges in power mains.

• Discretionary repair of the unit by the user.

• Unit repair by any persons without the manufacturer’s authorization.

• Expiration of the unit warranty period.

• Violation of the unit transportation regulations by the user.

• Violation of the unit storage regulations by the user.

• Wrongful actions against the unit committed by third parties.

• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind, blockades).

• Missing seals if provided by the user’s manual.

• Failure to submit the user’s manual with the unit purchase date stamp.

• Missing payment paperwork certifying the unit purchase.

The manufacturer shall not accept any claims with regards to the condition of the paint-and-lacquer coating (hereinafter PLC)
in the following cases:

• Dents, cracks, scratches and abrasions of the PLC sustained during handling, mounting and assembly operations.

• Progress of corrosion on areas damaged with stones, sand, and roof coat tar during the performance of roofing work.

• Signs of direct exposure of the PLC to excessive temperatures, which occurred during the performance of roofing work.

• Violation of regulations on transportation, storage, installation, and operation of the unit.

• Presence of damage caused by exposure to industrial and chemical emissions, acidic or alkaline pollution, sap or other factors not

related to normal operating conditions.

18

FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND

TROUBLEFREE OPERATION OF THE UNIT.

USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON

PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL

WITH THE PURCHASE DATE STAMP.

Axis-Jet

CERTIFICATE OF ACCEPTANCE

Unit Type Jet axial fan

Model Axis-Jet-KI-__________________________________

Serial Number

Manufacture Date

Quality Inspector’s
Stamp

SELLER INFORMATION

Seller

Address

Phone Number

E-mail

www.blaubergventilatoren.de

Purchase Date

This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are
acknowledged and accepted.

Customer’s Signature

INSTALLATION CERTIFICATE

The Axis-Jet-KI-__________________________________ unit is installed pursuant to the requirements
stated in the present user's manual.

Company name

Address

Phone Number

Installation
Technician’s Full Name

Installation Date: Signature:

The unit has been installed in accordance with the provisions of all the applicable local and national construction,
electrical and technical codes and standards. The unit operates normally as intended by the manufacturer.

Signature:

Seller’s Stamp

Installation Stamp

WARRANTY CARD

Unit Type Jet axial fan

Model Axis-Jet-KI-__________________________________

Serial Number

Manufacture Date

Purchase Date

Warranty Period

Seller

Seller’s Stamp

19

www.blaubergventilatoren.de

B114EN-02
