Blanco BWCG90X Instructions

Instructions for the Use and Care and Installation of

BRC90BX
BRCG90BX
BWCG90X
BWGG90X
BWC90X
BWC9X
BWC6X
BWCS120X

Rangehood

Dear Customer

You will find that the modern look of your Blanco rangehood blends in perfectly with your
kitchen décor. It is easy to use and performs to a high standard.

Blanco also makes a range of products that will enhance your kitchen – such as cooktops,
ovens, dishwashers, microwaves, sinks and taps. There are models to complement your
new Blanco rangehood. Blanco now has a range of laundry products to choose from.

Of course, we make every effort to ensure that our products meet all your requirements, and
our Customer Service Department is at your disposal, to answer your questions and to
listen to your suggestions.

Please complete the warranty section of this manual and keep your receipt as proof of
purchase. Retain all documents relating to the purchase of Blanco product.

Blanco is committed to providing increasingly efficient products that are easy to use, respect
the environment and are attractive and reliable.

BLANCO

AB

Fig.1

20

max 90 cm

Fig.2

A

235

A

A

Fig.3

B

A

C

A

Fig.4

B

Fig.5

A

Fig.6

Fig.8

Fig.7

C

B

G

Fig.9

A

B

C

D

E

E

D

A

Fig.10

GENERAL

These warnings are provided in the interest of safety. Carefully read the following important information
regarding installation safety and maintenance . You MUST read them carefully before installing or using the
appliance.

It is most important that this instruction book be retained with the appliance for future reference. Should the
appliance be sold or transferred , always ensure that the book is left with the appliance in order that the new
owner can get to know the function of the appliance and the relevant warnings .

The appliance has been designed for use in the ducted version (Fig.1B) and recirculated version (Fig.1A).

SAFETY PRECAUTION

1.Take care when the rangehood is operating in the same room as an open fireplace or burner that requires
air in the environment and uses an energy source other than electrical energy – this because the rangehood
removes air from the environment which a burner or fireplace may need for combustion. The negative pressure
in the environment must not exceed 4Pa (4x10-5 bar).

2. Provide adequate ventilation in the environment for a safe operation of the rangehood.

3. Follow the local laws applicable for external air evacuation.

4. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.

WARNING !
In certain circumstances electrical appliances may be a danger hazard.

A) This appliance is not intended for use by young children or infirm persons without supervision.
B) Young children should be supervised to ensure they do not play with the appliance.
C) Do not check or remove the filters when the rangehood is operating.
D) Flambè cooking is prohibited underneath the rangehood.
E) Constantly check food frying to avoid that the overheated oil may become a fire hazard.
F) Disconnect the electrical plug prior to any maintenance.
G) Do not touch lighting or adjacent areas when lighting is on - and for a period of time after using the light.
H) Avoid leaving cooktop on (gas and electric) without the saucepan covering the burner or cooking zone.
This is because heat transferring upwards to the rangehood will be damaging to the filters and a fire hazard.
I) Ensure adequate ventilation of the room where the rangehood is used at the same time as appliances
burning gas or other fuels. Exercise care when a rangehood is installed in an area where a gas burner is
operating. Depending on the size of the room, the rangehood may draw from the room air that is necessary
for proper combustion of the burner.
J) Ensure the rangehood is cleaned frequently.
L) There is a risk of fire if cleaning is not carried out in accordance with the instructions.
M) For any repairs always contact an authorised Technical Customer Service Centre and ask for original
spare parts. Repairs by untrained people may lead to damage and void warranty.

Warnings for Installation:

a) The exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels.
b) The minimum distance from the cooktop surface and the lowest part of the range hood must not be less
than 65cm. If the instructions for the cooktop specify a greater distance, please consider this.
c) The regulations concerning the discharge of exhaust air have to be fulfilled.
d) All Blanco rangehoods are used for indoor application/installation only.

Other Information:

This appliance conforms to the European Directive EC/2002/96, Waste Electrical and Electronic Equipment
(WEEE). By making sure that this appliance is disposed of in a suitable manner, the user is helping to
prevent potential damage to the environment or to public health.

The symbol on the product or on the packaging label on the carton indicates that the appliance should
not be treated as domestic waste, but should be delivered to a suitable electric and electronic appliance
recycling collection point. Follow local guidelines when disposing of waste. For more information on the
