Blanco B 830FX User Manual

Microwave Oven

& Installation Manual for Trim Kit

Operation Manual

Model BMO280X

READ these instructions carefully before installing and operating the oven. Store them in a safe place for further reference. IMPORTANT: Retain your “Proof of Purchase”. Read the warranty information on page 2 of this manual.

CONTENTS

Precautions to Avoid Possible Exposure to Excessive Microwave Energy ........................................................3

Specifications ................................................................................................................................................3

Before You Call for Service ............................................................................................................................4

Installation......................................................................................................................................................4

Earthing Instructions ......................................................................................................................................4

Radio Interference..........................................................................................................................................5

Important Safety Instructions ..........................................................................................................................5

Microwave Cooking Principles........................................................................................................................6

Microwave Safe Containers............................................................................................................................6

Part Names ..................................................................................................................................................6

Control Panel ................................................................................................................................................7

Operating Instructions ....................................................................................................................................8

Setting the Clock ..........................................................................................................................................8

Microwave Power Cooking ............................................................................................................................9

Setting the Minute Timer ................................................................................................................................9

Automatic Defrosting......................................................................................................................................9

Automatic Weight Cooking ............................................................................................................................9

Quick Start Cooking ....................................................................................................................................10

Child and Safety Lock..................................................................................................................................10

Grill ............................................................................................................................................................10

Combination 1 ............................................................................................................................................11

Combination 2 ............................................................................................................................................11

Cleaning and Care ......................................................................................................................................11

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

((aa))

Do not attempt to operate this oven with the door open. Open-door operation can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks.

((bb))

Do not place any object between the oven front face and the door or allow dirt/grime or residue from cleaning products to accumulate on sealing surfaces.

((cc))

Do not operate the oven if it is damaged. It is particularly important that the oven door closes properly and that there is no damage to the:

11..

Door (bent)

((dd))

The oven should not be repaired by anyone except by a MEA qualified Service Agent (refer to page 12).

22..

Hinges and latches (broken or loosened)

33..

Door seals and sealing surfaces.

SPECIFICATIONS

Power Consumption: 230-240V~50Hz, 1300W (Microwave), 230-240V 1000W (Heater)

Rated microwave power output: 900W

Operation Frequency: 2450MHz

Outside Dimensions: 305mm (H) × 525mm (W) × 455 mm (D)

Oven Cavity Dimensions: 219mm (H) × 350mm (W) × 355 mm (D)

Oven Capacity: 28Litres

Cooking Uniformity: Turntable System {Ø314mm}

Net Weight: Approx.19kg

*Specifications subject to change without notice.

BEFORE YOU CALL FOR SERVICE

If the oven fails to operate:

aa))

Check to ensure that the microwave oven is plugged in securely. If it is not, switch off the power, remove the plug from the outlet, wait 10 seconds and plug it in again securely.

bb))

Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly, test the outlet with another appliance.

cc))

Check to ensure that the control panel is programmed correctly and the timer is set.

dd))

Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise, the microwave energy will not flow into the oven.

IIFF NNOONNEE OOFF TTHHEE AABBOOVVEE RREECCTTIIFFYY TTHHEE SSIITTUUAATTIIOONN,, TTHHEENN CCOONNTTAACCTT AANN MMEEAA QQUUAALLIIFFIIEEDD SSEERRVVI ((RREEFFEERR TTOO PPAAGGEE 1122)).. DDOO NNOOTT TTRRYY TTOO AADDJJUUSSTT OORR RREEPPAAIIRR TTHHEE OOVVEENN YYOOUURRSSEELLFF..

INSTALLATION

11..

Make sure that all the packing materials are removed from the inside of the door.

22.. WWAARRNNIINNGG:: sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact an

33..

This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.

44..

Do not place the oven where heat, moisture or high humidity are generated, or near combustible materials.

55..

For correct operation, the oven must have sufficient airflow. In an open freestanding situation, allow 20mm of space from any overhead obstruction and 10mm from a back wall and 5mm from any side walls. If more than one side of the appliance is closed in, then installation is as per a "built-in" installation requiring adequate venting. The specification requirements for "built-in" installations are detailed in the Blanco Specification Book, and require the purchase of a trim kit and vented cabinetry design.

66..

Do not operate the oven without glass tray, roller support, and shaft in their proper positions.

77..

Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or sharp surface.

88..

The power socket must be readily accessible so that it can be easily unplugged in an emergency.

99..

Do not use the oven outdoors.

Check the oven for any damage, such as misaligned or bent door, damaged door seals and

MMEEAA QQuuaalliiffiieedd SSeerrvviiccee AAggeenntt ((rreeffeerr ttoo ppaaggee 1122))..

ICCEE AAGGEENNTT

EARTHING INSTRUCTIONS

This appliance must be earthed. The microwave oven is equipped with a cord which has an earth wire and an earth plug. It must be plugged into a wall receptacle that is properly installed and earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. It is recommended that a separate circuit, serving only the oven, be provided. Using a high voltage is dangerous and may result in a fire or other accident causing damage to the oven.

WWAARRNNIINNGG::

NNootteess:: 11..

Improper use of the earthing plug can increase the risk of electric shock.

If you have any questions about the earthing or electrical instructions, consult an SSeerrvviiccee AAggeenntt ((rreeffeerr ttoo ppaaggee 1122))..

22..

Neither the manufacturer nor the distributor can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.

THE WIRES IN THIS MAINS CABLE ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:

GGrreeeenn aanndd YYeellllooww == EEAARRTTHH BBlluuee == NNEEUUTTRRAALL BBrroowwnn == LLIIVVEE

MMEEAA QQuuaalliiffiieedd

RADIO INTERFERENCE

11..

Operation of the microwave oven can cause interference with your radio, TV or similar electrical equipment.

22..

When there is interference, it may be reduced or eliminated by taking the following measures: aa))

Clean the door and sealing surface of the microwave oven.

bb))

Reposition the receiving antenna on the radio or television.

cc))

Relocate the microwave oven with respect to the receiver.

dd))

Move the microwave oven away from the receiver.

ee))

Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

IMPORTANT SAFETY INSTRUCTIONS

When using this oven, basic safety precautions should be followed. Abiding by these will reduce the risk of burns, electric shock, fire, injury to persons and exposure to excessive microwave energy:

11..

Read all instructions before using the appliance.

22..

Use the appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapours in the appliance. This type of oven is specifically designed to heat, cook, defrost or dry food. It is not designed for industrial or laboratory use.

33..

Do not operate the oven when empty.

44..

Do not operate the appliance if it has a broken cord or plug, if it is not working properly or if it has been damaged or dropped. If the supply cord is broken, it must be replaced by MEA or one of their Service Agents in order to avoid a hazard.

55.. WWAARRNNIINNGG:: given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

66..

To reduce the risk of fire in the oven cavity: aa.. bb.. cc.. IIff ssmmookkee iiss oobbsseerrvveedd,, sswwiittcchh ooffff oorr uunnpplluugg tthhee aapppplli dd..

77.. WWAARRNNIINNGG::

88..

Heating of beverages can result in delayed eruptive boiling, therefore please take care handling the container.

99..

Do not fry food in the oven. Hot oil can damage oven parts and utensils and may result in skin burns.

1100..

Eggs in their shell and whole hard-boiled eggs should not be heated in the microwave oven since they may explode even after microwave heating has ended.

1111..

The appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely.

2..

112

Young children should be supervised to ensure that they do not play with the appliance.

1133..

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

1144..

Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts before cooking.

1155..

The contents of feeding bottles and baby jars should be stirred or shaken. The temperature should then be checked before serving in order to avoid burns.

1166..

Cooking containers may become hot due to the heat transferred from the hot food. Potholders may be needed to handle the container.

1177..

Containers should be checked to ensure that they are suitable for use in the microwave oven. TTeesstt:: becomes very hot should not be used.

1188.. WWAARRNNIINNGG:: repair operation involving the removal of any cover that gives protection against exposure to microwave energy.

1199.. WWAARRNNIINNGG:: by an MEA Qualified Service Agent.

2200..

The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean

condition could lean to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

Only allow children to use the oven without supervision when adequate instructions have been

When heating food in a plastic or paper container, keep an eye on the oven due to the possibility of ignition. Remove wire twist-ties from paper or plastic bags before placing bag in oven.

iaannccee aanndd kkeeeepp tthhee ddoooorr cclloosseedd iinn oorrddeerr ttoo ssttiiffllee aannyy ffllaammeess..

Do not use the oven cavity for storage purposes. Do not leave paper products, cooking utensils or food in the oven cavity when not in use.

Liquid or other food must not be heated in sealed containers since they are likely to explode.

CCoonnttaaiinneerr

Place the empty container in the oven, microwave at high power for 60 seconds. A container which

It is hazardous for anyone other than an MEA Qualified Service Agent to carry out any service or

If the door or door seals are damaged, the oven must not be operated until it has been repaired

MICROWAVE COOKING PRINCIPLES

11..

Arrange food carefully. Place thickest areas towards outside of dish.

22..

Watch cooking time. Cook for the minimum amount of time indicated and increase cooking time if necessary. Food which has been severely overcooked can smoke or ignite.

33..

Cover foods while cooking to prevent spattering and to help foods cook evenly.

44..

Turn foods over once during microwaving to speed up cooking. Large items such as roasts must be turned over at least once.

55..

Rearrange foods such as meatballs halfway through cooking. Place those on the bottom of the dish at the top and those in the centre of the dish to the outside.

MICROWAVE SAFE CONTAINERS

11..

The ideal material of a microwave container is transparent. This allows energy to pass through the container and to heat the food.

22..

Microwave oven energy can not penetrate metal, so metal utensils or dishes with metallic trim should not be used.

33..

Do not use recycled paper products eg. paper towels, when microwave cooking, as they may contain small metal fragments which may cause sparks and/or fires.

44..

Round/oval dishes rather than square/oblong ones are recommend, as food in corners tends to overcook.

55..

Narrow strips of aluminum foil may be used to prevent overcooking of exposed areas. Be careful not to use too much foil and keep a distance of 1 inch (2.54cm) between foil and cavity.

The list below is a general guide to help you select the correct microwave safe products.

COOKWARE MICROWAVE GRILL COMBINATION

COOKING COOKING COOKING

Heat-Resistant Glass Yes Yes Yes

Non Heat-Resistant Glass No No No

Heat-Resistant Ceramics Yes Yes Yes

Microwave-Safe Plastic Dish Yes No No

Kitchen Paper Yes No No

Metal Tray No Yes No

Metal Rack No Yes No

Aluminum Foil & Foil Containers No Yes No

NNOOTTEE::

Containers made from Plyethylene, melamine and phenol become hot in the microwave and are therefore unsuitable.

8 6 3

PART NAMES

Door Safety Lock System 6 Glass Tray

2 Oven Window 7 Control Panel

3 Oven Air Vent 8 Grill Heater

4 Shaft 9 Metal Rack

5 Roller Ring
