BLANCO
FEATURED MODEL
513-612 8” & 8“ bowl depths
FEATURES
• 18 gauge, 304 series stainless steel
• 18/10 chrome/nickel content
• Easy-to-clean, Silver Ease™ matte finish
• Rear drain placement
CODE/STANDARDS COMPLIANCE
ASME 112.19.3-00
lAPMO/UPC listed
OPTIONAL ACCESSORIES
Sink Grid: 510-902
Colanders: 215-651
WARRANTY
Blanco America’s BLANCONORSTAR™ sinks feature a
“NO HASSLE” LIMITED LIFETIME WARRANTY to be
free of all manufacturing defects under normal use.
See our complete warranty for details.
SINK SPECIFICATIONS
Premium Series
BLANCONORSTAR™ LARGE EQUAL DOUBLE BOWL Undermount
Model 513-612
NOMINAL DIMENSIONS
MODEL OVERALL
513-612 32 x 20-7/8 Template provided with
DXF cutout templates available on our web site or this specification CD.
CUTOUT
SIZE
approximate 1/8* revea
392
157/16”
BOWL DEPTH
LEFT RIGHT
210
817/64"
MODEL 513-612
DRAIN
DIAMETER
8 8 3-1/2
iS
While Blanco America endeavors to provide accurate
information, all dimensions are nominal, cannot be
guaranteed, and are subject to change or cancellation.
Blanco America assumes no responsibility for use of
superseded or voided specifications.
PRODUCT SPECIFICATION
Undermount sink to be equal double bowl
design, 32” in length and 20-7/8* in front-toback depth. Sink to be made from 18 gauge,
304 series stainless steel, with 18/10 chrome/
nickel content and Silver Ease™ matte finish.
Sink to feature rear drain placement. Sink to be
Blanco Model 513-612, with left bowl depth of
8* and right bowl depth of 8".
JOB INFORMATION
71
VQ iJ
1 17764^
360
143/16"
-minimum cab in et 914.4
32
812
32"
36"
Q^
R3300
143/16”
5
30_
13/16"
/to
/ «V
Job Name:
Contact:
Date Specified:
Specifier:
Contractor:
___________
_____
BLANCO AMERICA
800.451.5782
www.blancoamerica.com
® 2006 BLANCO AMERICA
05/06 SPEC-003
