BLANCO

SINK SPECIFICATIONS

SILGRANIT® Pinnacle Series

BLANCOAXIA 6S™ LEFT DRAINBOARD SINK

Model 511-782, 511-790

FEATURED MODEL

511-782 White, 7-1/4" & 5-1/8" bowl depths

ADDITIONAL MODELS

511-790 Anthracite, 7-1/4" & 5-1/8" bowl depths

FEATURES

• Sliding safety glass cutting board and multifunctional

colander included.

• 80% rock hard granite

• Color all the way through

• Highly resistant to scratching, staining and all

household acids and alkali solutions

• Non-porous, easy-to-clean

• Heat resistant to 536° F

• Extremely hygienic, does not absorb odors

or bacteria

CODE/STANDARDS COMPLIANCE

ASME 112.19.3-00 lAPMO/UPC listed

WARRANTY

Blanco America’s SILGRANIT’ sinks feature a “NO HASSLE” LIMITED LIFETIME WARRANTY to be free of all manufacturing defects under normal use. See our complete warranty for details.

□ White 511-782

□ Anthracite 511-790

NOMINAL DIMENSIONS

1000

39-3/8

CUTOUT

SIZE

MODEL OVERALL 511-782

DXF cutout templates available on our web site or this specification CD.

39-3/8 x 20-1/16 38-3/8x19-1/16

BOWL DEPTH

LEFT RIGHT

7-1/4

Bá

MODEL 511-782

5-1/8

DRAIN

DIAMETER

3-1/2

While Blanco America endeavors to provide accurate Information, all dimensions are nominal, cannot be guaranteed, and are subject to change or cancellation. Blanco America assumes no responsibility for use of superseded or voided specifications.

PRODUCT SPECIFICATION

Drop-In sink to be 39-3/8" In length and 20-1/16" in front-to-back depth. Sink to be made from Silgranil® hard composite material. Sink to feature rear drain placement and straight bowl sides with 5/8" cutout corner radius. Sink to be Blanco (Check one)

□ Model 511 -782 □ Model 511 -790

with large bowl depth of 7-1/4" and small bowl depth of 5-1/8".

JOB INFORMATION

Job Name:

Contact:

Date Specified:

________________

330

KNOCKOUT HOLE LOCATIONS

Pre-drilled for single-hole faucet

and remote drain operation.

No additional holes available.

63/64

187

7-11/32

542

21-11/32

1-13/16

BLANCO AMERICA

800.451.5782

www.blancoamerica.com

Specifier:

Contractor:

_________
